iCUE COMMANDER CORE XT
WEB: corsair.com
PHONE: (888) 222-4346
SUPPORT: support.corsair.com
BLOG: corsair.com/blog
FORUM: forum.corsair.com
YOUTUBE: youtube.com/corsairhowto
© 2020 CORSAIR MEMORY, Inc. All rights reserved. CORSAIR and the sails logo
are registered trademarks in the United States and/or other countries. All other
trademarks are the property of their respective owners. Product may vary slightly
from those pictured. 49-002296 AB Sm ar t RGB Lig ht ing a nd Fan Speed C ont roll er
iCUE COMMANDER CORE XT
6 5 4 3 2 1
FANS
RGB
TEMP 2
TEMP 1
ID
65 4 3 2 1
RGB HUB
ENGLISH 1 .......................................................
FRANÇAIS 5 .....................................................
DEUTSCHE 9 ...................................................
NEDERLANDS 13 ............................................
DANSK 17 ........................................................
SUOMALAINEN 21 ..........................................
SVENSKA 25 ....................................................
ITALIANO 29 .....................................................
ESPAÑOL 33 ....................................................
PORTUGUÊS 37 ..............................................
ΕΛΛΗΝΙΚΑ ................................................... 41
MAGYAR 45 .....................................................
ČEŠTINA 49 .....................................................
POLSKI 53 ........................................................
TÜRK 57 ...........................................................
NORSK 61 ........................................................
ROMÂ 65 .....................................................
РУССКИЙ ..................................................... 69
ةيبرعلا .............................................................. 73
繁體中文 ...................................................... 77
简体中文 ...................................................... 81
GETTING TO K NOW iCUE COM MANDER CO RE XT INSTALLATION
A 4-pin PWM fan headers
B 4-pin RGB hub
C 3-pin RGB header
D Thermistor header
E ID header
F SATA power and USB cable
NOTICE: Turn your computer off prior t o installing your COMMANDER CORE XT. Find a location for the
COMMANDER CORE XT that allows connection for all the fan cables installed in your computer
to reach the COMMANDER CORE XT.
NOTE: 4-pin PWM fan speed can be fully controlled through CORSAIR iCUE software. 3-pin fans plugged into the
COMMANDER CORE XT will operate at their rated full speed.
TIP: The thermal sensors are designed to measure ambient temperatures, so for the most accurate results, they should not
directly touch components. You may find it useful to mount the thermal sensors near air intake and exhaust points, and
if your PC case has multiple compartments, you can try placing each of the sensors in its own compartment. Since the
thermal sensors can easily be repositioned, you can try various locations and use what works best for you.
CONNECT FANS TO COMMANDER CORE XT
> Connect the 4-pin fan and 4-pin RGB
headers into the “FANS (A)” and “RGB HUB
(B)” headers respectively.
CONNECT THE T HERMAL SENSORS INTO THE 2-PIN “TEMP (D)” HEADERS
6 5 4 3 2 1
FANS
RGB
TEMP 2
TEMP 1
ID
65 4 3 2 1
RGB HUB
6 5 4 3 2 1
FANS
RGB TEMP 2
TEMP 1
ID
65 4 3 2 1
RGB HUB
B
E
D
D
F
C
A
D D
B A
21
ENGLISH ENGLISH
