Please read instruction manual before use.
Portable AM/FM Radio, Cassette Recorder and CD Player
MODEL NO: CX-CD248
COBY INTRODUCTION
Please read and follow the instruction manual carefully be-
fore operating in order to avoid any damage to the unit.
1.By using AC power
Insert one end of the AC power cord into the AC socket
on the rear of the unit and the other end into a standard
wall socket.
POWER SUPPLY
2 By using batteries.
Insert 8x"D"size batteries (not included) in the battery
compartment in the back of the unit by matching the
polarities.
The unit will not operate on battery power when
the AC power cord is plugged into the AC socket.
Replace batteries when the power indicator dims,
the volume decreases or the sound distorts.
Use batteries of high quality and check them
regularly. Alkaline batteries are recommended.
Do not mix new batteries with old or used batteries.
Use only batteries of the same brand and type
Batteries should not be left in the unit if they
are exhausted or if the unit is not to be used
for a long period of time as they may leak and
damage the unit. Battery leakage is not covered
under the warranty.
IMPORTANT SAFEGUARDS
Always operate the product from a power supply
of the same voltage, frequency and rating as indicated
on the product identification plate.
Do not operate product with a damaged cord or plug.
Never install the unit where there are heat sources such
as radiators, heat registers, stoves, direct sunlight,
excessive dust or where there is mechanical vibration
or shock. Switch off and unplug from AC outlet when not
in use.
CONCERNING COMPACT DISCS
Only compact discs identified with this
mark can be used with this player.
IMPORTANT
The CD mechanism and the sensitive circuitry may
cause interference to a radio tuner nearby. Do not
operate this unit while operating other radio devices.
Danger This product utilizes invisible laser
radiation. Avoid direct exposure
to the beam.
Caution Use of controls, adjustments or procedures
not listed in this manual may result in hazardous
radiation exposure.
CARE and MAINTENANCE
Handle your unit with care to extend the life of the unit.
Use a soft and clean cloth damped with plain lukewarm water
to clean the exterior of the unit.
Never use solvents such as benzene or other strong chemical
cleaners since these could damage your unit.
It is important that no liquid reaches the inside of the unit.
Do not touch the CD laser part or look directly at it.
LOCATION OF CONTROLS
6.CD Compartment
1.Volume Control
2.Function Selector
3.CD Display
4.CD Operation Buttons
5.Cassette Compartment
7.Band Selector
8.Tuning Control
9.Cassette Operation Buttons
10.CD Compartment Open/Close Button
11.Tuning Indicator Window
12.Telescopic Antenna
9
8 1076
11
4
5
3
12
1
2
CD OPERATION
Set the FUNCTION Selector to the CD position and insert a CD.
1. Press PLAY/PAUSE button to play.
2. Press PLAY/PAUSE button to pause while in play mode.
3. Press PLAY/PAUSE button once more to resume play.
4. Press STOP to stop play.
5. Always press STOP and wait for complete stop to remove CD
from CD player.
Play/Stop/Pause Mode
1. Slide the Function Selector switch to radio.
2. Select the desired AM or FM with the band switch.
3. Tune the desired station by turning the Tuning Control.
4. Adjust the volume with Volume Control as desired.
5. Extend Telescopic Antenna and adjust the direction and angle
to obtain the optimum reception.
6. Set the Function Switch to Tape for power standby mode.
RADIO OPERATION
You can use headphones with 3.5mm diameter stereo plug and
have impedance of 32ohms. When the headphones are con-
nected, the speakers are disconnected automatically.
Set the VOLUME to a low level before using headphones and
gradually adjust the Volume Control to the comfortable listening
level.
Do not play the VOLUME too loud for extended periods of time
to avoid any damage your hearing.
HEADPHONES (Not included)
1. Press Repeat button once to repeat current track only,
the indicator is lighting and keeping on. twice to repeat
all tracks, the indicator is flashing.
2. Press Repeat button twice to cancel repeat current track.
Or once to cancel repeat all tracks.
Repeat Mode Tracking Mode
1. To go back to beginning of current track, press once.
2. To go back to previous tracks, press repeatedly.
3. To go to next track, press once or repeatedly to play
your desired track.
We recommend that you use only type1 (Normal Bias)
cassette tape with your tape player.
CASSETTE TAPE OPERATION
1. Set the FUNCTION Selector to the TAPE (OFF) position.
2. Press STOP/EJECT to open the tape deck door. Insert
a tape and close the door.
3. Press PLAY to start play, the tape will stop automatically
at the end.
4. Press to rewind or press to fast forward tape.
This unit is equipped with ALC (Automatic Level control) cir-
cuitry that automatically sets the recording to the optimum level.
Adjusting the VOLUME control does not effect the recording.
RECORDING FROM RADIO/CD
Recording from Radio
1.Set the FUNCTION Selector to the RADIO position.
2.Set the BAND Selector to AM or FM.
3.Turn the TUNING Dial to tune in a radio station.
4.Open the cassette deck door and insert the blank tape.
5.Press PAUSE, then press RECORD, the PLAY key is automati-
cally engaged with RECORD button.
6.Release the PAUSE button to begin recording. You can use the
PAUSE button to edit any unwanted commercials or programs
during your recording.
7.Recording will stop automatically at the end of the tape or
press STOP to end the recording manually.
Recording from CD
1.Set the FUNCTION selector to the CD position.
2.Insert a CD.
3.Open the cassette deck door and insert the blank tape.
4.Press RECORD and the PLAY key is automatically engaged.
5.Press the PLAY/PAUSE button on the CD player, the Play/Pause
indicator will illuminate.
6.Press the STOP button to manually end recording or it will stop
automatically at the end of recording.
SPECIFICATIONS
Power Sourc : AC 110/220V 50/60Hz 10W DC 12V
5. Press STOP/EJECT to stop play.
6. Press STOP/EJECT one more time to open the cassette
door and take the tape out.
7. Adjust the sound with the VOLUME control.
To program:
(1) Press REPEAT button at stop mode,”REPEAT”
indicatorlight will flash, the serial number for
programming frozen at the same time.
(2) Press FF (orREW )button to select the track
number.
(3) When desired track is displayed, press REPEAT
button to confirm.
(4) Repeat (2)~(3) to set up 16 tracks. The display
will show the current set track.
(5) Set tracks can be reviewed by pressing REPEAT
button.
(6)
Program Function
To complete the programming and to play,
press PLAY/PAUSE button to start the
programmed tracks.
(5) To clear the programming, press STOP( )
button.
(REPEAT function will change
into PROGRAM function at stop mode)
We recommend that the unit be powered by AC (house current)
when recording since this function uses the most power. We re-
commend that you use Type 1 (normal bias) cassette tapes only.
Note: After setting up to 10 tracks(P0-P9), the letters
"a-b-c-d-e-f"(Pa-Pf) will replace the digits "11-12-13-14
-15-16", because the LCD can only display
two digits at most.
