Version: Ma y 31, 2021
Disclaimer: While we endeavour to provide the most accurate, up-to-date information available, the content on this document may be out of date or include omissions, inaccuracies
or other errors. Therefore Club 3D does not accept any rights claimed on the content of this document. Please refer to a full overview of our Legacy Terms and Conditions on
www.club-3d.com. All other brand names are trademarks or registered trademarks and are the property of their respective owners. All content is subject to change without prior notice. Copyright © 2021, Club 3D B.V. www.club-3d.com
Input: Output:
Product Name:
Multistream Transport (MST) Hub DisplayPort™ 1.4 to
DisplayPort™ Dual Monitor 4K60Hz M/F
Product Series: Video Splitter
Product Code: CSV-7200
EAN code: 8719214471927
UPC code: 841615102143
Description:
The CSV-7200 is a DisplayPort™ 1.4 to DisplayPort™ Dual Monitor 4K60Hz
M/F MST hub. This DisplayPort™ 1.4 MST hub is designed to cater for your
most versatile connectivity demands, such as Tablet, laptop, etc. with a
DisplayPort™ 1.4 output.
Give your Ultrabook more displays. Ultrabooks and notebooks are increasingly
becoming more powerful and smaller in the physical form factor. With a single
DisplayPort™ 1.4 port available you can now drive one- or two- Displayport™
screen(s) simultaneously at 4K60Hz or One display at 4K120Hz. All it needs
is a free DisplayPort™ 1.4 port on your Laptop or Ultrabook to connect to the
MST hub and will provide you with unparalleled connection options for Dual
4K60Hz displays. The setup is easy and simple to do, provided your system
supports this function.
Features:
• Support dual display 3840 x 2160 @ 60HZ
• Support for BT.2020 color space
• Upstream port:
- DisplayPort™ 1.4 port
• Downstream port:
Windows(MST model)
- Support Dual Displayport™ (3840 x 2160@60Hz)
- Support Single Displayport™ (3840 x 2160@120Hz)
or
MAC OS(SST model)*
- Support Single Displayport™ (3840 x 2160@60Hz)
- Support Dual Displayport™ (3840 x 2160@30Hz)
* This resolution specification might be limited by the device itself
Disclaimer: * Specification is subject to change without notice.
Multistream Transport (MST) Hub DisplayPort™ 1.4 to
DisplayPort™ Dual Monitor 4K60Hz M/F
OS Support:
• Windows®10, Mac OS®
In the box:
• CSV-7200, Multistream Transport (MST) Hub DisplayPort™ 1.4
to DisplayPort™ Dual Monitor 4K60Hz M/F
• CAC-1408, USB 3.2 Gen1 Type-A to Micro USB Cable M/M 1m /3.28ft for
External Power
Available Interfaces
Input:
• DisplayPort™ Male
Output:
• 2x DisplayPort™ Female
Other info:
• Box size: 6x24x3.5cm / 2.36 x 9.45 x 1.38"
• Device size: 6 x 4.9 x 1.13 cm / 2.36 x 1.93 x 0.44"
• Total length Device: 20 cm/ 7.87"
• Box Weight: 28 gr / 0.99 oz
• Device Weight: 50 gr / 1.76 oz
• CAC-1408 Cable Weight: 26 gr/ 0.95 oz
• LDPE Bag Weight: 5 gr / 0.17 oz
• Total Weight: 109 gr / 3.87 oz
• Meets ROHS, FCC, and CE EMI requirements
Note:
- Please update your TV Firmware to the version which supports these
resolutions/refresh rates !
- Please update your Graphic drivers on your PC and make sure that DSC1.2 is
supported on your devices to support the these resolutions/refresh rates!
Please use one of our Extension/Adapter cables to connect to your devices:
In case you need assistance to choose the correct cable, please visit our
website www.club-3d.com or feel free to mail us at support@club-3d.com
and it will be our pleasure to assist you.
