Thank you for purchasing a Cerwin Vega Mobile product and we hope to provide you with
countless hours of listening enjoyment.
Please take a brief moment to register your new product. By registering your new product, you
will receive benefits such as:
- Important product notifications that may pertain to your purchase.
- Confirmation and record of ownership in case of loss or theft.
- Knowledgeable customer service and technical assistance pertaining to your product.
Register your new product by completely filling out this Product and Warranty Registration card
or register online at
www.cerwinvegamobile.com.
Registration is voluntary and failure to register will not diminish your limited warranty rights.
Limited Warranty (U.S.A.)
Cerwin Vega Mobile warrants all of our amplifiers and speakers to be free of defects in materials
and workmanship for a period of one (1) year.
This warranty is non-transferable and applies only to the original purchaser from an authorized
Cerwin Vega Mobile dealer. If service is required and necessary under this warranty due to
manufacturing defect or malfunction, then Cerwin Vega Mobile will repair and/or replace
defective product with either new or remanufactured like product at no charge at our discretion.
Damage to product caused by the following will not be covered under this warranty: abuse,
accident, misuse, neglect, modifications, repairing attempts, seller/installer misrepresentation.
This warranty does not cover any incidental, consequential, or cosmetic damage due to
accidents or normal wear and tear, nor does it cover the cost of removing or reinstallation of the
product.
Warranty is void if the product’s serial number has been removed, defaced, and/or tampered
with.
Warranty Procedure:
We recommend that you contact your Cerwin Vega Mobile authorized dealer where your original
purchase was made to initiate all warranty claims. Our authorized dealers can guide you through
the warranty procedure to ensure that your claim will be processed in a timely manner. All
warranty returns must be accompanied with a proof of purchase (a copy of the original sales
receipt) and be shipped freight prepaid to our facility with an RA (Return Authorization) number
clearly marked on the outside of the package. Direct returns from consumers or non-authorized
dealers will be refused if shipped without a valid RA number authorized by Cerwin Vega Mobile
beforehand.
INTERNATIONAL
Products purchased outside of the U.S.A. are covered only by that country’s distributor and not
by Cerwin Vega Mobile U.S.A.
Please Ship All Warranty Claims With Pre-Authorized RA Number To:
CV&DA Holdings, Inc.
ATTN: Customer Service Department
1225 E. 7th St.
Los Angeles, CA 90021 USA
Please Contact Customer Service for Further Warranty Information:
U.S.A.
Tel: 213-261-4161 / Fax: 213-947-4767
USERS MANUAL
Cerwin Vega Mobile Speakers
Congratulations for purchasing Cerwin Vega Mobile speakers for your car
audio system. You have chosen Cerwin Vega Mobile because you deserve
the best!
Cerwin Vega Mobile speakers are designed and engineered to reproduce
great sound quality for many years of listening enjoyment in your vehicle!
We highly recommend that your new speakers be installed by an authorized
Cerwin Vega Mobile dealer. Your authorized dealer can professionally
assemble/disassemble the interior of your vehicle and set the proper
speaker placement for ideal sound quality.
If you decide to install the speakers by yourself, please thoroughly read
through this manual before getting started. This manual will help familiarize
yourself with these speakers and guide you through the installation process
and procedures.
Please contact your local authorized Cerwin Vega Mobile dealer if you have
any questions regarding the instructions in this manual. If you require
additional assistance, please contact the Cerwin Vega Mobile Technical
Support Department during business hours at 213-261-4161.
PHYSICAL DIMENSIONS
(C)
THIELE/SMALL PARAMETERS
ENCLOSURES
The enclosures below are offered as a suggestion only. Assistance from an authorized Diamond
Audio retailer is recommended. All volumes are gross internal, driver and vent displacement has
been accounted for. The use of a 30hz sub-sonic filter is recommended.
UnitDimension XED12
Total Diameter (A) in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
5.67 (144.0)
5.23 (133.0)
11.7 (296.0)
10.82 (275.0)
12.5 (317.0)
Mounting Diameter (B)
Hole Diameter (C)
Mounting Depth (D)
Magnet Diameter (E)
Parameter (unit)
SPL (dB)
Qms
Qes
Qts
Fs (Hz)
Vas (L)
Cms (mm/N)
Mms (g)
Sd (m
2
)
BL (T*M)
Xmax (mm)
Pwr (W) NOM/MAX
XED12
85.5
3.9
4.82
0.62
0.55
27.4
103.2
0.070
346
0.049
22.1
17.8
150/1000
Re (Ω) [series]
delaeS
Vb (ft
3
)
CTQ/)zH( 3F
)W( eP
Vented
Vb (ft
3
)
)zH( 3F/pF
]htgnel x .aid[ ).ni( troP
XED12
0.88
53 / .71
800
1.25
40 / 35
4” x 16.5”
800)W( eP
XED12 Woofer:
12 inch Subwoofer
150 watts RMS / 1000 Watts MAX
Parabolic Poly Cone
Unique Foam / Blend High Roll Surround
Vented Pole Piece / Basket for Cooler VC Temps
Bumped Back Plate for Maximum Excursion
Signature Cerwin-Vega Bass!
(D)
(A)
(B)
(E)
