Strona 1/4
USER GUIDE
CUBE Carts
TVC16PAC-CK CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Charcoal finish !
TVC32PAC-CK CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Charcoal finish !
TVC16PAC-RED CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Red finish !
TVC32PAC-RED CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Red finish !
TVC16PAC-SKY CUBE Charging Cart AC for up to 16 devices w/Back Panel … 1.4”W Slots | Sky Blue finish !
TVC32PAC-SKY CUBE Charging Cart AC for up to 32 devices w/Back Panel … 1.4”W Slots | Sky Blue finish!
CAPACITY! !slot width = 1.4”
TVC16PAC-XXX 1 shelf 16 devices ! !
TVC32PAC-XXX 2 shelves 32 devices ! !
COMPATIBILITY Designed for various sized laptops & chromebooks, yet versatile enough to
support most tablets. Uses the device manufacturer supplied AC power cord and adapter.
OUTSIDE DIMENSIONS 30” W x 26.5”D x 37.5”H"
SLOT DIMENSIONS! "1.4”W x 17”D x 12”H (fixed)
WEIGHT!TVC16PAC-XXX 134 pounds empty! "
259 pounds with 16 ea 5 lb devices"
+ an allowable 45 lbs in the bottom shelf area
TVC32PAC-XXX 143 pounds empty! "
303 pounds with 32 ea 5 lb devices"
POWER MANAGER!Digital"
POWER REQUIREMENTS!120Vac, 50/60Hz, 12A
SHIPPING Ships fully assembled, ready to load devices
WARRANTY For product specific warranty information,
please visit: bretford.com/warranty
Part # 080-1016
rev April 2022
MADE IN USA
with globally
sourced products
www.bretford.com
Technical Specifications
POWER CORD WINDER
Located on the left side
of the cabinet, provides a
cord winder for the 7-
foot power cord
LOCKING 5” CASTERS
Allow the cart to be easily
maneuvered into small
spaces. When engaged,
lock the cart into position.
Front View
Rear View
REAR ACCESS SECURITY PANEL
Held securely in place with a key
lock. Once unlocked, the panel
easily lifts off to expose the back of
the cart, where the adapters and
cord sets are kept in cable bins.
DOOR LOCK SHROUD
Protects the padlock
during transport
WARNING:
This cart is not intended
to hold items on the top
surface. Do not place
any item weighing more
than 1 pound on the top
surface of the cart to
avoid damage.
INTEGRATED HANDLE
Handle integrated into
the top of the cart for
pushing and moving
the cart.
USER GUIDE | CUBE CARTS
SETTING THE COMBINATION LOCK
Your new CUBE Cart comes equipped with a resettable Combination Padlock. You can program the
lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for
changing the combination. Remember to depress the shackle before disengaging it from the lock.
General Use
STEEL CONSTRUCTION
Designed to store,
secure, transport &
charge up to 32
devices. All-steel
construction is sturdy
and provides strength
to support 32
devices.
USER GUIDE | CUBE CARTS
Device Storage & Cable Management
1. At the back of the cart, use the key from the hardware
pack to unlock the rear access panel.
2. The two keys included in the hardware pack are for the
person(s) responsible for managing the computer
adapters and cable sets, through the rear access panel.
3. Lift the rear access panel off of the chassis.
This exposes the power outlet modules for the shelves.
4. Starting in the rear of the cart with the rear access panel
panel removed, insert a power adapter in the storage bin
for the associated device storage shelf (top or bottom).
5. Measure the amount of cable necessary to reach from
the power adapter located in the bin to the front of the
cart (over the AC outlet box, from the back to the front
of the cart, through the cable management slots that are
integrated into the plastic dividers.)
6. Leave sufficient slack for the power connector to plug
into the device.
7. Plug the device AC adapter plug into one of the outlets
nearest to where the power adapter is located in the bin.
8. Repeat the above process for the total number of
devices’ power adapters & cable sets.
9. In the front of the cart, insert a device into each of the
slots, and plug in the power connector to each device.
10. Replace the Rear Access Panel and lock the panel using
the key from the Hardware Pack.
11. Place the cart near a wall outlet and plug the cart in.
12. Turn on the power switch - located in front of the push
handle
13. In the TVC32PAC-XXX CUBE Cart for 32 devices, once
the cart is turned on, the power manager begins rotating
power to the power strips every 5 minutes. This allows
efficient charging of the devices in the cart from one
single 15 amp circuit.
PLASTIC DIVIDERS
features slots for routing the computer plug cable to the
plug-in spot on the computer - high or low, left or right.
NOTE: Plastic dividers are not removable or resettable.
TVC32PAC-XXX
TVC16PAC-XXX
REAR ACCESS PANEL
Locks in position
with the keys from
the hardware pack
POWER OUTLET MODULES
16 AC outlets per shelf,
matches the quantity of
slots in the front of the cart
