USER GUIDE
CORE 36M CART
CORE36MS-CTTZ • CORE36MSBP-CTTZ
TECHNICAL SPECIFICATIONS
CAPACITY
36 Devices
COMPATIBILITY
Designed for various sized Chromebooks, yet versatile enough
to support most tablets, laptops/hybrids and ultrabooks. Uses
device manufacturer supplied AC power cord.
UNIT DIMENSIONS
25.25”W x 26.5”D x 41.3875”H
SLOT DIMENSIONS
1.25”W x 14.75”D x 9.875”H
WEIGHT WITHOUT DEVICES
142 lbs.
WARRANTY
For product specic warranty information, please visit
bretford.com/warranty
TIMER
Digital
SHIPPING
Ships fully assembled
IMPORTANT USER NOTES
Product is for indoor use only.
User can plug in 36 devices at one time.
urn power switch off before plugging in devices.T
urn power switch off before unplugging the cart.T
Do not plug the cart in if the switch or power
cord has been damaged.
Do not plug the power cord into another extension cord
or re-locatable power tap.
Be sure to turn power switch off and unplug cart before
moving to a different location.
Ensure casters are locked before opening cart doors.
Be sure to lock up cart in a secure environment after
every use.
Do not share the lock combination code with any
unauthorized persons.
The socket-outlet shall be installed near the equipment
and shall be easily accessible.
MADE IN THE USA
2
GENERAL USE
POWER SWITCH
Located on the right hand side of the cabinet.
AC OUTLET ACCESS ADAPTER STORAGE
Bins provide convenient adapter storage. Plug adapters into AC outlets as needed. Use VELCRO® straps to secure power adapters.
DEVICE STORAGE
Polypropylene dividers store devices vertically and oer optimal spacing for device compatibility.
AC Outlet Access – Adapter Storage Device Storage
Cord Winder and Power Switch
USER GUIDE | CORE 36M CART
Using the Handle Inserting The Shackle / Lock Programming Interior Door Lock Holder
TORQUE RESISTANT HANDLE & LOCK INSTRUCTIONS
USING THE HANDLE
The torque resistant handle/lock serves as a handle to open and close the cabinet when the shackle is not inserted.
INSERTING THE SHACKLE
Hold the lock shackle on a slight angle when inserting into the shackle opening and push rmly. Once the shackle is inserted the cam is
no longer engaged and the torque resistant handle/lock will spin which deters access to devices by lowering the risk of the cam breaking.
LOCK PROGRAMMING
To program the user programmable combination padlock included:
1. Open the padlock using combination “0000.”
2. Insert the programming key and turn 90 degrees.
3. Set the combination you would like to use.
4. Remove the programming key.
3
DEVICE STORAGE & CABLE MANAGEMENT
1. Starting in the rear of the cart, insert a power adapter in the
storage bin for the associated device storage shelf (top, middle
or bottom).
2. Measure the amount of cable necessary to reach from the
power adapter located in the bin to the front of the cart, (around
the AC outlet box, through the divider panel and through the
cable management hooks). Leave sucient slack for the power
connector to connect to the device.
3. Wrap remaining cable to the power adapter using one of
the VELCRO® straps that came with the cart.
4. Plug the AC cord into one of the outlets nearest to where
the brick is located in the bin.
5. Repeat the above process for the 36 devices power
adapters and cables.
6. Insert a device into each of the 36 device slots.
7. Plug the power connector into each of the 36 devices.
8. Place cart near a wall outlet and plug cart in.
9. Turn on the power switch (on the cord-winder side of the cart).
10. Once the timer is turned on, it begins rotating power to the
dierent power strips every three (3) minutes. This allows for
ecient charging of the devices in the cart from one 15
amp wall circuit.
11. Only one group of the total devices in the cart will be
charging at a time–rotating every three minutes.
12. Supplied numbered stickers can be applied to shelves in
front of dividers, for slot numbering, if desired.
USER GUIDE | CORE 36M CART
Part #031-10065 • V 06 7 6.201
Bretford, B design, and Core are trademarks or registered marks of Bretford Manufacturing,
Inc. Patents Pending. ©2015 Bretford Manufacturing, Inc. All rights reserved. All other
referenced product names and logos are trademarks of their respective owners.
REMOVING REAR ACCESS PANEL
(CORE36MSBP-CTTZ)
Using the included T2511 Torx bit, remove the four screws
securing the rear adapter access panel. Use the handle
cutout to remove the panel. Inside, plug adapters into AC
outlets as needed, and secure with velcro straps. Reattach
rear adapter access panel using T2511 Torx bit and included
security screws.
Tools required: Multi-Bit screwdriver, T2511 Torx bit (included)
1. Insert the T2511 Torx bit into your Multi-Bit screwdriver.
2. Remove the four security screws from the back adapter
access panel.
3. Remove the rear adapter access panel.
4. Install your power adapters as needed.
5. Replace the rear adapter access panel.
6. Replace the four security screws, securing the rear
adapter access panel, using the included TORX 2511 bit.
