Strona 1/12

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM

USB C

DOCKING

STATION

USBC2000

USER MANUAL

4K@30Hz

TABLE OF CONTENTS

NE E D HELP ?

LE AVE THE TEC H TO U S

LIVE 24/7

TECHNICAL

SUPPORT

1.877.877.2269

1.877.877.2269 BLACKBOX.COM

1. SPECIFICATIONS ........................................................................................................................................................................... 3

2. OVERVIEW ...................................................................................................................................................................................... 4

2.1 Introduction ...............................................................................................................................................................................................4

2.2 Features ....................................................................................................................................................................................................4

2.3 What’s Included ........................................................................................................................................................................................ 5

2.4 Hardware Description ..............................................................................................................................................................................5

3. OPERATION .................................................................................................................................................................................... 8

4. CONNECTION DIAGRAM .............................................................................................................................................................. 9

APPENDIX: DISCLAMER/TRADEMARKS ...................................................................................................................................... 10

A.1 Disclaimer ............................................................................................................................................................................................... 10

A.2 Trademarks Used in this Manual ............................................................................................................ .............................................. 10

1.877.877.2269 BLACKBOX.COM

NE E D H E L P?

LE AVE THE TE C H TO U S

LIVE 24/7

TECHNICAL

SUPPORT

1.877.877.2269

CHAPTER 1: SPECIFICATIONS

TABLE 1-1. SPECIFICATIONS

SPECIFICATION DESCRIPTION

Connectors

Input Connectors (1) USB-C Female (with our Type-C M to M cable)

Output Connectors

(3) USB 3.0 Female;

(1) USB-C Female (for data and charging);

(1) RJ-45;

(1) HDMI Female;

(1) Micro SDX;

(1) SD/MMCX

Environmental

Operating Temperature 32 to 113°F (0 to 45° C)

Storage Temperature +14 to +158°F (-10 to +70° C)

Operating Humidity 10 to 85% RH (no condensation)

Storage Humidity 5 to 90% RH (no condensation)

Regulatory Approvals

Certifications FCC, CE

CAN ICES-3(B)/NMB-3(B)

Power

Power Supply USB-C Female Port,

Up to 100 W (20 V/5 A)

Specyfikacje produktu

Marka:	Black Box
Kategoria:	podstawa/stacja dokująca
Model:	USBC2000
Kolor produktu:	Srebrny
Technologia łączności:	Dokujący
Certyfikaty:	FCC, CE, CAN ICES-3(B)/NMB-3(B)
Ilość portów Ethernet LAN (RJ-45):	1
Liczba portów USB 2.0:	3
Przewodowa sieć LAN:	Tak
Zintegrowany czytnik kart:	Tak
Ilość portów HDMI:	1
Mikrofon:	Nie
Segment HP:	Business, Enterprise, Home
