MAX™ LOW PROFILE INSTRUCTION MANUAL
a. Congratulations
b. Pictures of Components
c. Family Info
d. How to Fill with Line
e. Drag Adjustment
f. Spool Tension Knob
g. Removing the Sideplate
h. Reel Function
i. Maintenance
j. Warranty Information
A. CONGRATULATIONS:
Thank you for purchasing one of the world’s most advanced low profile reels. The combination
of low profile design, ultra- Abu lightweight materials and precision engineering makes
Garcia®® THE choice for serious anglers around the globe. Rely on ® quality and Abu Garcia®
dependability to keep the fun in fishing.
The following guide will explain how to get the most out of your new Max™ low profile reel.
Each element is described by its name and function. Some features are not found on every reel
model. Read these instructions carefully before using your reel to ensure a proper understanding
of its operation.
B. COMPONENTS:
Include:
Star drag
Line guide
Handle
Spool
Spool Tension Knob
Palm Sideplate
Thumbscrew
Knobs
Thumb Bar
Brake Dial
Handle Sideplate
Gear Box
MagTrax™ Adjustment Dial
Frame
Handle Nut
Nut Retainer
Nut Retainer Screw
Handle Knob Caps
C. THE MAX FAMILY OF LOW PROFILE REELS:
Thanks to advanced technology and materials, the new Max™ reels are precision engineered
with a smoother feel and increased rformance on the water. The Max™ pe family of baitcasting
reels includes the Pro Max , Silver Max and Black Max™ ™ ™.
D. HOW TO FILL THE SPOOL WITH LINE
All are designed for monofilament, braid and fluorocarbon lines. Max™ low profile reels
Personal preference and fishing conditions will determine line selection. Begin by passing the
line through the guide located on the front of the reel. Secure the line to the reel using the arbor
knot. Control the filler spool by inserting a pencil into the spool hub. While maintaining tension
on the line with your fingers, wind the reel handle and continue to fill with line to approximately
1/16” (1.5 mm) below the top of the reel spool for best results (show picture). Do not overfill.
(CLICK HERE to learn how to tie the arbor knot in this video)
Braided Line
Some anglers prefer to add a monofilament backing to the reel spool before attaching braided
line. This helps reduce line slip. Using the above instructions, fill the spool with enough
monofilament line to cover the spool. Tie the tag end of the monofilament backing to the
braided line using a uni-to-uni knot, Albright knot or equivalent. Continue to fill the spool with
braid to approximately 1/16” (1.5 mm) inside the upper lip of the spool. Do not overfill.
(CLICK HERE to learn how to tie the uni- -uni knot in this video)to
E. DRAG ADJUSTMENT
All Max™ low profile reels deliver smooth and reliable drag tension. Control the amount of
drag by turning the adjustment star inside the reel handle. Rotate the star clockwise (right) to
increase drag or counterclockwise (left) to decrease drag. For best results the drag should be
adjusted to approximately one-third of the breaking test of the line being used. This can be
accomplished by tying the line to a spring scale for precise adjustment. Make sure the reel is
first mounted on a rod and the line has been run though the rod guides before tying to the scale.
The drag should always release before the line reaches its breaking point. Factors such as line
type, technique and fishing conditions may require adjustment to these recommendations. Any
drag setting above half of the line strength risks line breakage.
If a spring scale is unavailable, tie the line to a secure point. With the rod tip up (about a 45
degree vertical angle), apply pressure by turning the handle. Gradually tighten the drag
