INSTALLATION INSTRUCTIONS
Sensor Modules
SMAUD01, SMVID01, SMMAG01, SMLIT01, SMCC01, SMVLT01
DESCRIPTION
The Xantech Sensor Module product line provides several sensing solutions for a wide variety of
automation needs. Used in conjunction with Xantech’s award winning MRC platform*, source
management and control is easy and reliable. Also, the sensor modules can be used with the
CBCSM1 connecting block to provide a simple interface solution. The CBCSM1 can provide positive
and negative logic through its PULL UP and PULL DOWN connections.
(* MRC44, MRAUDIO4X4, MRC88, MRAUDIO8X8)
The Xantech Sensor Module product line is composed of six complete, easy to install packages.
SMAUD01 Audio Sensor Module
SMVID01 Video Sensor Module
SMMAG01 Magnetic and Current Sensor Module
SMLIT01 LED and Light Sensor Module
SMCC01 Contact Closure Sensor Module
SMVLT01 AC\DC Voltage Sensor Module
Each module comes with double-sided foam tape and mounting screws. Also, built into the sensor is
a convenient LED light that turns ‘on’ to indicate the sensor is in an ‘on’ condition.
SPECIFICATIONS
Delay: Adjustable between 0 and 15 seconds.
+12VDC, <50mA.
1/8” (3.5mm) mini-plug, Tip: +12VDC, Ring: Signal, Sleeve: Ground.
Sensor Module Dimensions: 3/4” W x 3 3/4” L x 3/4” H.
Control Cable Length: Approx. 6 feet
Sensor Cable** Length: 6.5’ SMAUD01, SMVID01
Sensor Cable** Length: 5.0’ SMMAG01, SMLIT01
(** not applicable on the SMCC01, SMVLT01)
Xantech Corporation
13100 Telfair Avenue, 2/F
Sylmar, CA 91342
Installation Instructions, Sensor Modules
© 2006 Xantech Corporation, Document #08905072A
This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Xantech
Corporation.
Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
- 2 -
ADJUSTMENTS
Each sensor module has an adjustment for delay (between 0 and 15 seconds). The delay adjustment
determines the amount of time the sensor module remains “on” after the stimulus condition stops. For
instance, when SMVLT01 no longer sees a voltage that stimulated the sensor to the “on” condition,
the delay will determine when the sensor returns to the “off” condition.
Increase Decrease
Delay Clockwise Counter-Clockwise
Sensitivity Clockwise Counter-Clockwise
The sensitivity adjustment is found on all sensor modules except the SMCC01 and SMVLT01.
Increasing the sensitivity will make the sensor easier to ‘trip’. Decreasing the sensitivity makes the
sensor harder to ‘trip’.
- 3 -
INSTALLATION – SMAUD01: Audio Sensor Module
The SMAUD01 sensor module provides status feedback by monitoring the line-level audio
connection. The sensor head is placed in between and input and output audio signal. For instance,
the sensor head is placed between an amplifier and a CD player on either the right or left channel
audio cable.
SMAUD01 is intended for line-level signals only. Do not use with amplifier outputs or speaker volume
controls.
(1) Plug the 1/8” (3.5mm) mini-plug into the sensing controller (CBCSM1 and MRC platform
provides power to the sensor module). Sensing controller power should be off.
(2) Connect the sensor head on the output of the audio source.
(3) Connect the audio cables as you would normally do.
(4) Turn on the audio source output. (i.e. ‘play’ button on a CD player)
(5) Verify the SMAUD01 LED indicator is ‘on’.
(6) Turn off the audio source output. (i.e. ‘stop’ button on a CD player)
(7) Verify the SMAUD01 LED indicator is ‘off’.
(8) If the indicator is not ‘off’, then adjust the sensitivity until the LED just turns off.
(9) Repeat Steps 4 to 8 until both ‘on’ and ‘off’ conditions are satisfied.
