HALO 30 | HALO 60 Quickstart Guide | 220820

UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

support@wyrestorm.com

1 of 4

Halo Series Plug and Play Portable Conference

Speakerphone

HALO 30 | HALO 60 Quickstart Guide

Setting up the Speakerphone

Connecting via Bluetooth®(ONLY APPLICABLE FOR HALO 60)

CONNECTING THE SPEAKERPHONE

CONNECTING TO A LAPTOP/PC

1. Connect the supplied USB Type-C cable into

the port at the base of the speakerphone.

2. Connect the other end of the supplied cable

into an available port on your PC or Laptop.

3. The speakerphone will automatically power

on, which is indicated by the Power LED

shown below.

1. Navigate to your connectivity settings

on your device and ensure Bluetooth is

switched on.

2. Click on Add Bluetooth or other device.

Then a new menu should appear. Click

the Bluetooth option.

3. A list of all discoverable Bluetooth

devices should now appear. Click on

the Device named WyreStorm HALO

60 and after a few seconds, you will be

connected.

Note: If the Speakerphone is powered off and there is still a USB device connected,

simply hold the Power button for 2 seconds and the device will power on.

To begin, make sure the that Halo 60

is discoverable. To do this, turn Bluetooth on by

tapping the Bluetooth button on the device. The

LED will illuminate white, indicating Bluetooth is

on. Next, press and hold the Bluetooth button

until the LED flashes blue. Now the Halo 60 is

discoverable.

2 of 4

HALO 30 | HALO 60 Quickstart Guide | 220820

UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

support@wyrestorm.com

CONNECTING TO A MOBILE DEVICE

1. Navigate to your connectivity settings on your mobile device and

ensure Bluetooth is switched on.

2. All nearby Bluetooth devices should now show. Press WyreStorm

HALO 60 and after a few seconds, you will be connected.

Software Device Setup

Connecting To Zoom

To connect the WyreStorm HALO Speakerphone to your Zoom software, rst navigate to your settings pane which can be found by clicking the gear icon in the

top right hand corner, then click on the Audio tab. Here you can change the speaker and microphone by using the dropdown menus. Select WyreStorm HALO

device under the applicable options.

WyreStorm HALO 60

Answer/End buttons are for use with

the paired Bluetooth device only and not

compatible with conferencing software.

Call/End Buttons

ANSWER END

3 of 4

Specications

Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior

notice.

HALO 30 | HALO 60 Quickstart Guide | 220820

UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

support@wyrestorm.com

HALO 30 HALO 60

Audio and Video

Inputs 1x USB-C Input

Supported Standards USB 2.0

Speakerphone

Microphone 360° 4x Omni-directional Mic Array with Echo Cancellation

Microphone Pickup

and Audio Range 3m/10ft

Speaker

Speaker Frequency Range

Signal-to-Noise Ratio

Max Speaker Audio Pressure

Microphone Frequency Range

Microphone Type

2 watts

10~20kHz

80dB

102dB SPL

100~10kHz

Digital MEMS

3 watts

10~20kHz

80dB

104dB SPL

100~10kHz

Digital MEMS

Control

Capacitive touch power on/off, volume +/- and microphone

mute buttons

Capacitive touch power on/off, Bluetooth® on/off, battery

level indicator, call/end, volume +/- and microphone mute

buttons

Power

Power Supply 5V DC 1A 5V DC 1A

Power Consumption Max: 2.5 watts Max 5 watts

Battery Life NA Up to 10 hours

Battery Capacity NA 2500mAh

Environmental

Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing

Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing

Max BTU 34 BTU/hr

Dimensions and Weight

Height 36mm/1.42in

Diameter 120mm/4.72in

Weight 0.22kg/0.49lb 0.29kg/0.64lb

Regulatory

Safety and Emission CE | FCC | RoHS | RCM | EAC

Connecting To Microsoft Teams

To connect the WyreStorm HALO Speakerphone to your Microsoft Teams software, rst navigate to your settings pane which can be found by clicking on your

display image in the top right hand corner, then click on the devices tab. Here you can change the Audio device by using the dropdown menu. Select WyreStorm

HALO device under the applicable options.

WyreStorm HALO 60

Specyfikacje produktu

Marka:	WyreStorm
Kategoria:	głośnik
Model:	HALO 30
Kolor produktu:	Czarny
Wysokość produktu:	120 mm
Szerokość produktu:	120 mm
Głębokość produktu:	36 mm
Wbudowane głośniki:	Tak
Głośnik:	Tak
Obsługiwane operacyjne systemy komórkowe:	Android, iOS
Mikrofon:	Tak
