Key Features:

• ConvertsS/PDIFdigitalaudio(PCM)signalsfromcompatibledevicetoanaloguestereoaudio

• Acceptsuncompresseddigitalaudioinputsignals

• 2-channelLPCM(LinearPulseCodeModulation)at32,44.1,48,96&192KHz

• 24-bitS/PDIFincomingbitstreamonleftandrightchannels

AV ESSENTIALS, MADE SIMPLE.

WyreStorm Express™ Digital to Analog Audio

Converter (Coax/Optical Inputs)

EXP-CON-DAC

1 x WyreStorm EXP-CON-DAC Analogue audio converter

1 x Universal 5V DC/1A power supply

in the box

The WyreStorm Express EXP-CON-DAC is a digital to analogue audio converter capable of decoding connected S/PDIF coaxial or

TOSLINK optical digital audio sources to standard analogue stereo (L/R) audio with inputs selectable via on-board input select switch.

Stereo output signals can then be fed to external devices such as an amplier, Hi-Fi, recording deck, or powered speakers via standard

phono style (RCA) jacks.

If quick, reliable and cost eective conversion of digital audio to analogue is a requirement for your project, the EXP-CON-DAC makes

it incredibly easy to connect modern digital sources, such as AppleTV, Blu-Ray/DVD, DAB, digital computer audio to a legacy analogue

sound system without requiring expensive additional conversion equipment.

• Includes digital interpolation lter

• Optical & Digital Coaxial inputs

• Input Select switch

• LED Power indication

• Compact design

• Supports audio signals up to 24-bit with sampling rates up

to 192 kHz

• Low-latency Digital Filtering

• Dynamic Range: 106 dB A-wt

• THD+N (Total harmonic distortion plus noise) rating: -93dB

Additional Features & Benefits:

US OFFICE:

TEL: +1 518-289-1293

EMEA OFFICE:

TEL: + 44 (0) 1793 230 343

AV ESSENTIALS, MADE SIMPLE.

Specifications

WyreStormExpressproductsincludeatwelvemonthmanufacturerwarranty.

Please Note:

This product does not support Dolby Digital encoded audio. Verify you can turn o Dolby Digital in the source you will be

connecting to this converter. For a Dolby Digital version of this product, please see the EXP-CON-DAC-D.

Coaxial cable

from source

S/PDIF cable

from source

Audio cables

to avr

Dimensions (W x H x D) 64mm / 2.5” x 24mm / 0.9” x 64mm / 2.5”

Weight (Kg) 86g/3.03oz

Operating Temperature Range 0 to +35°C (32 to +95°F)

Operating Humidity Range 5 to 90 % RH (no condensation)

Power Supply 5v DC / 5W power supply (CE/FCC certied)

Power Consumption 1.0w (max)

Input S/PDIF Coaxial, TOSLINK Optical Digital

Output Stereo phono analogue

Distortion <0.001% @ 1kHz at 2V RMS

Signal to Noise Ratio > 90dB (20Hz - 20kHz)

Output Impedance 500Ω

Output Voltage 1.8V RMS @ Max Input (0dBFS)

Frequency Response <+/-0.5dB

Chassis aluminium (black)

Foradditionalproductinformationvisitwyrestorm.com

Fortechnicalsupportcontact: North America: +1 844-280-WYRE (9973) EMEA/ROW: +44 (0) 1793 230 343 150803

Specyfikacje produktu

Marka:	WyreStorm
Kategoria:	konwerter audio / video
Model:	EXP-CON-DAC
Kolor produktu:	Czarny
Wysokość produktu:	24 mm
Szerokość produktu:	64 mm
Głębokość produktu:	64 mm
Waga produktu:	86 g
Certyfikat środowiskowy (zrównoważonego rozwoju):	RoHS
Certyfikaty:	CE, FCC
Napięcie pracy:	5 V
Kod zharmonizowanego systemu (HS):	85176990
Wejście cyfrowe, optyczne audio:	1
Cyfrowe koncentryczne wyjście audio w:	1
Pobór mocy:	5 W
Adapter zewnętrznego zasilania:	Tak
Maks. rozdzielczość:	1920 x 1200 px
Wyjście audio (prawe/lewe):	1
