Strona 1/8

GB -1-

Chart

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

(see at right for options description)

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the program.

When the door is opened during a washing cycle, the

cycle is temporarily paused: the Start indicator blinks.

To resume the cycle push Start button and close

the door within 3 seconds.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute

(0:01 is shown into the display).

If pressed when the dishwasher is switched off,

it drains any possible liquids from dishwasher

(1 minute process).

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional

options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the

appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information

on the EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

Table of programs

Deter-

gent

Consumption

PPrograms Available

options Loading instructions Litres kWh Minutes 1)

1Aqua Steam 40-70°C

Delay

Multizone

Antibacterial

rinse

Normally or heavily soiled crockery,

including pots and pans. Thanks to

steam action, soaking or hand

pretreatment is no longer needed. In

addition hygiene is ensured due to

the high temperature steam.

X 7-14 0.99-1.80 70-185

2Pre-Wash cold Delay

Multizone Crockery to be washed later. — 4.0 0.03 14

3Glasses 40°C Delay

Multizone

Light soiling, for example glasses and

cups. X 10.0 0.85 100

4Quickwash 45°C Delay

Multizone

Lightly soiled crockery, with no

dried-on food. X 11.0 0.80 30

5Eco 2) 50°C

Delay

Multizone

Antibacterial

rinse

Normally soiled crockery.

Energy-saving program. X 11.0 0.98 170

6Overnight 55°C Delay

Multizone

Normally soiled crockery, gentle and

quiet thanks to the lower spray

pressure (39dbA).

X 13.0 1.20 290

5019 396 01986ADG 6999

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ

THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING

ANY BUTTON EXCEPT CANCEL/OFF BUTTON. FOR ENERGY SAVING

THE CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30

SECONDS IF NO CYCLE HAS STARTED.

MULTIZONE

Allows you to choose the washing

zones. Press this button (repeatedly)

to select the wash zones:

both racks

only lower rack

only upper rack

- indicator lits

TABLET SETTING

This setting allows to

optimize the cycle

performances according

the type of detergent

used. Push the Tablet

button for 3 seconds (until

the indicator lights up) if

you are using the

combined detergents in

tablet (rinse aid, salt and

detergent in 1 dose). If you

are using powder

detergent or liquid

detergent, the Tablet

indicator on the control

panel has to be off.

DELAYED START

BUTTON

Push the button

(repeatedly) to delay the

start of the program.

Adjustable from 1 to 24

hours. With each press of

the button, the delayed

start indicator increases

by one hour and after 24

restarts from 0. Then

press the START button.

The dishwasher will start

after the set time.

ANTIBACTERIAL RINSE 3)

This function activates an

antibacterial rinse at the end of the

wash cycle, guaranteeing a further

reduction of bacteria. Press the

button to activate or deactivate the

function. This function can be used

with the programs indicated in the

table of programs. The dishwasher

door must be kept shut for the entire

duration of the program in order to

guarantee reduction of bacteria. If

the door is opened the indicator lamp

starts flashing.

SALT INDICATOR

When lit (at the end of the cycle),

the salt reservoir needs to be

refilled.

RINSE AID INDICATOR

When lit (at the end of the cycle),

the rinse aid dispenser needs to

be refilled.

Quick reference guide

GB -2-

First time use

1- salt reservoir

2- rinse aid dispenser

3- detergent dispenser

4- racks system

5,6,7,8- available functions on the panel

9- filters

10- spray arms

Water hardness should be set only

before the first wash or if water

hardness has been changed

1Visual indicator

(depending

on the model).

Unscrew cap.

Fill the salt reservoir with water

before the first wash only.

(depending on the model)

The salt level indicator lamp may remain lit

at the end of several wash cycles. If the

water hardness level falls within category

(soft), no salt is required.

Salt indicator on the control panel Salt indicator on the salt reservoir cap

The indicator lamp lights up when SALT

NEEDS TO BE ADDED. green: OK. clear: NEEDS TO

BE ADDED

Daily check

Filling the salt reservoir - Dissolve limescale (not necessary if water hardness level is set to “soft”!)

- Press and hold together Programs and buttons for minimum 3 seconds.CANCEL/Off

- The current water hardness setting will be visible on the display.

- Press the Programs button to increase setting. Value range goes from 1 to 7 (when the level reaches 7, the next press of

the start button will set the level back to 1).

- Wait 30 seconds (control panel switches off) or press Start/Resume button to save setting.

Add salt (never add detergent!)

min. 0.8 kg / max. 1 kg

Screw on the cap.

Salt residual

around the cap

need to be

removed. Some

salt reservoir have

a level indicator

integrated in the

cap (see below

how to check).

At first time use, the salt reservoir has to be filled independently from water hardness level (see description below in step 1 “Daily check”).

1. Ask your water supply company what the water hardness is... 2. ...enter this value on

your dishwasher Suggestions for detergent use

German

degrees °dH

French

degrees °fH

English

degrees °eH

Water hardness

level

Insert value is shown

in the display

Gel or Powder

(rinse aid and salt) Tablets

0 - 5 0 - 9 0 - 6.3 Soft 1

go to step 1

(see “Daily

check”)

6 - 10 10 - 18 7 - 12.6 Medium 2

11 - 15 19 - 27 13.3 - 18.9 Average 3

16 - 21 28 - 37 19.6 - 25.9 Medium-hard 4 if water is

HARD extra salt

needs to be added

(go to step 1,

“Daily check”)

22 - 28 38 - 50 26.6 - 35 Hard 5

29 - 35 51 - 63 35.7 - 44.1 Very hard 6

36 - 50 64 - 90 44.8 - 62.4 Extremely hard 7

Water hardness level is factory

set for medium-hard water

(level 4).

Even if you use tablets which

include salt functionality, you

must still add regeneration salt

since such detergents are not

effective enough at softening

hard water.

How to set water hardness in order to always assure the best cleaning results

GB -3-

Daily check

Check the rinse aid indicator to check the level

into the dispenser.

(depending on the model)

Rinse aid indicator on the control panel Rinse aid indicator on the dispenser

The indicator lamp lights up when RINSE AID NEEDS

TO BE ADDED. dark: OK. clear: NEEDS TO BE ADDED

Only use rinse aids recommended for use in domestic dishwashers. Immediately wipe away any rinse aid spilt accidentally. This prevents the formation of excess suds which can cause a fault function of the

appliance.

If there are streaks: reduce the dosage by turning the dial to a lower setting (1-3). If crockery is not perfectly dry: increase the dosage by turning the dial to a higher setting (5-6). Plastic dishes have more difficulty

drying and a higher rinse aid setting will not improve the situation.

Detergents with rinse aid incorporated may be effective only with longer programs. In the case of shorter programs, detergent residue may be a problem (if necessary, use powder detergent). Detergents with

rinse aid incorporated tend to form excess suds.

Daily use

Adding detergent -

Use only detergent specifically for dishwashers in accordance with the supplier’s recommendations

Open the cover A

(press the dedicated button).

Only fill the

detergent dispenser

prior to starting a

wash program.

Shut the cover

by pressing dedicated ribs.
