Thank you for choosing Watson Pro
AM-95-NC
VM-95-NC
Li-ion Battery with LCD
and 3-Stud or V Mount
TM
Please read this user manual carefully and keep
it for reference before using the battery.
SAFETY INSTRUCTIONS
Make sure the battery is fully charged before use.
When not in use, remove the battery from its device. Some
electronic equipment will draw current even when the switch is off.
Do not short-circuit the terminals. This battery is protected with
an internal self-resetting fuse, but short circuits may still cause
severe damage to the battery.
Do not attempt to open the battery case under any circumstances.
Do not remove the battery from any equipment that is powered on.
Always power off your equipment before removing the battery.
Use the battery only under proper environmental conditions: 14°F
to 122°F (-10°C to 50°C) and with a relative humidity (RH) less than
85%.
Storage environment: short-term (one month) -4°F to 122°F (-20°C
to 50°C) and RH 45% to 75%; medium-term (three months) -4°F
to 104°F (-20°C to 40°C) and RH 45% to 75%; long-term (one year)
23°F to 86°F (-5°C to 30°C) and RH 45% to 75%.
The battery may be warm during use or recharging. This is normal.
The battery should be charged up to 50% for long-term storage.
After 4 months of storage, the battery will require a recharge up
to 50%.
Keep the battery out of fire, heat, and high pressure.
Do not expose the battery to rain or moisture.
Do not drop the battery or expose it to strong shocks.
Keep this unit away from water and any flammable gases or liquids.
Clean the battery and terminals with a clean, soft, and dry cloth.
When operation time has noticeably decreased, the battery may
need to be replaced.
Keep this product away from children.
Store the battery in a cool, dry place.
PRODUCT FEATURES
LCD screen shows real-time,
to-the-minute, remaining
battery capacity and usage.
Built-in P-tap connector
powers your camera
accessories.
5 V/1 A USB 2.0 output for
USB-powered devices.
Built-in intelligent control
circuit for protection against
damage caused by current,
voltage, temperature, or
short-circuiting.
OVERVIEW
1. LCD
Battery capacity meter
Remaining charging or usage
time (minutes)
Charging indicator
Battery capacity percentage
1. Battery-level check button
1. P-tap port
12 V, 10 A max.
USB output
Press the battery level check
button to start charging or to
power your USB device.
1. Mounting interface
Re ti me :000 00 M
88%
POWER
CHECK
1
1
2
2
3
3
4
4
5
5
