Introduction .................................... 2

Keys, doors and windows .............. 6

Seats, restraints ........................... 30

Storage ........................................ 54

Instruments and controls ............. 64

Lighting ........................................ 96

Climate control ........................... 106

Driving and operating ................. 115

Vehicle care ............................... 201

Service and maintenance .......... 241

Technical data ........................... 247

Customer information ................ 261

Index .......................................... 270

Contents

Emergency numbers

For emergency service call the Vauxhall

Incident Manager

0800 55 33 88 (Free

Linkline)*

Vauxhall Assistance General Enquiries 0845 7565 565

You will need to

provide:

Vehicle registration

number

Contact telephone

number

Model and colour of

your Vauxhall

Details of your precise

location

* Calls may be chargeable from mobile phones

2 Introduction

Introduction

Introduction 3

Vehicle specific data

Please enter your vehicle's data on

the previous page to keep it easily

accessible.

Please refer to the sections "Service

and maintenance", "Technical data",

the vehicle's identification plate and

national registration documents.

Introduction

Your vehicle is a designed

combination of advanced technology,

safety, environmental friendliness

and economy.

Some functions are only operational

when ignition is switched on, when

combustion engine is running or

when electric engine is ready.

Make sure your passengers are

aware of the possible risk of accident

and injury which may result from

improper use of the vehicle.

You must always comply with the

specific laws and regulations of the

country that you are in. These laws

may differ from the information in this

Owner's Manual.

Disregarding the description given in

this manual may affect your warranty.

When this Owner's Manual refers to a

workshop visit, we recommend your

Vauxhall Authorised Repairer.

All Vauxhall Authorised Repairers

provide first-class service at

reasonable prices. Experienced

mechanics trained by Vauxhall work

according to specific Vauxhall

instructions.

The customer literature pack should

always be kept ready to hand in the

vehicle.

Using this manual

● This manual describes all options

and features available for this

model. Certain descriptions,

including those for display and

menu functions, may not apply to

your vehicle due to model

variant, country specifications,

special equipment or

accessories.

● The "In brief" section will give you

an initial overview.

● The table of contents at the

beginning of this manual and

within each section shows where

the information is located.

● The index will enable you to

search for specific information.

● This Owner's Manual depicts left-

hand drive vehicles. Operation is

similar for right-hand drive

vehicles.

● The Owner's Manual uses the

engine identifier code. The

corresponding sales designation

and engineering code can be

found in the section "Technical

data".

● Directional data, e.g. left or right,

or front or back, always relate to

the direction of travel.

● Displays may not support your

specific language.

● Display messages and interior

labelling are written in bold

letters.

4 Introduction

Danger, Warnings and

Cautions

9Danger

Text marked 9 Danger provides

information on risk of fatal injury.

Disregarding this information may

endanger life.

9Warning

Text marked 9 Warning provides

information on risk of accident or

injury. Disregarding this

information may lead to injury.

Caution

Text marked Caution provides

information on possible damage to

the vehicle. Disregarding this

information may lead to vehicle

damage.

Symbols

Page references are indicated with 3.

3 means "see page".

Page references and index entries

refer to the indented headings given

in the section table of content.

Thank you for choosing a Vauxhall.

We wish you many hours of

pleasurable driving.

Your Vauxhall Team

Introduction 5

6 Keys, doors and windows

Keys, doors and

windows

Keys, locks ..................................... 6

Keys ............................................ 6

Radio remote control ................... 7

Electronic key system .................. 8

Central locking system ................ 9

Automatic locking ...................... 13

Child locks ................................. 14

Doors ........................................... 15

Load compartment .................... 15

Vehicle security ............................ 20

Anti-theft locking system ........... 20

Anti-theft alarm system .............. 20

Immobiliser ................................ 22

Exterior mirrors ............................ 22

Convex shape ........................... 22

Electric adjustment .................... 22

Folding mirrors .......................... 23

Heated mirrors ........................... 23

Interior mirrors ............................. 24

Manual anti-dazzle .................... 24

Automatic anti-dazzle ................ 24

Windows ...................................... 25

Windscreen ............................... 25

Power windows ......................... 25

Heated rear window .................. 27

Heated windscreen .................... 27

Sun visors .................................. 28

Roller blinds ............................... 28

Roof ............................................. 28

Glass panel ............................... 28

Keys, locks

Keys

Caution

Do not attach heavy or bulky items

to the ignition key.

Replacement keys

The key number is specified on a

detachable tag.

The key number must be quoted

when ordering replacement keys as it

is a component of the immobiliser

system.

Locks 3 237.

Central locking 3 9.

Starting the engine 3 118.

Radio remote control 3 7.

Electronic key 3 8.

The code number of the adapter for

the locking wheel nuts is specified on

a card. It must be quoted when

ordering a replacement adapter.

Wheel changing 3 228.

Keys, doors and windows 7

Key with foldaway key section

Press button to extend. To fold the

key, first press the button.

Lock cylinders

Designed to free-wheel if they are

forcefully rotated without the correct

key or if the correct key is not fully

inserted. To reset, turn cylinder with

the correct key until its slot is vertical,

remove key then re-insert it. If the

cylinder still free-wheels, turn the key

through 180° and repeat operation.

Radio remote control

Enables operation of the following

functions via the use of the remote

control buttons:

● central locking system 3 9

● anti-theft locking system 3 20

● anti-theft alarm system 3 20

● tailgate unlocking and opening

● power windows 3 25

● mirrors folding 3 23

The remote control has a range of up

to 100 m, but may also be much less

due to external influences. The

hazard warning flashers confirm

operation.

Handle with care, protect from

moisture and high temperatures and

avoid unnecessary operation.

Replacing battery in radio remote

control

Replace the battery as soon as the

range reduces.

Batteries do not belong in household

waste. They must be disposed of at

an appropriate recycling collection

point.

8 Keys, doors and windows

1. Remove the back cover from the

remote control.

2. Extract the flat battery from its

location.

3. Replace battery with a battery of

the same type. Pay attention to

the installation position.

4. Clip the back cover in place.

Fault

If the central locking system cannot

be operated with the radio remote

control, the cause may be one of the

following:

● Fault in radio remote control.

● Electronic key is out of reception

range.

● The battery voltage is too low.

● Overload of the central locking

system by operating at frequent

intervals, the power supply is

interrupted for a short time.

● Interference from higher-power

radio waves from other sources.

Manual unlocking 3 9.

Electronic key system

Enables a keyless operation of the

following functions:

● central locking system 3 9

● power tailgate 3 15

● ignition switching on and starting

the engine 3 118

The electronic key simply needs to be

on the driver's person.

Additionally, the electronic key

includes the functionality of the radio

remote control 3 7.

Handle with care, protect from

moisture and high temperatures and

avoid unnecessary operation.

Keys, doors and windows 9

Notice

To save battery power, the keyless

functions are set to stand-by after 21

days of non-use. To reactivate the

functions, press a button on the

electronic key.

Replacing battery in electronic

key

Replace the battery as soon as the

system no longer operates properly

or the range is reduced. The need for

battery replacement is indicated by a

message in the Driver Information

Centre 3 91.

Batteries do not belong in household

waste. They must be disposed of at

an appropriate recycling collection

point.

1. Remove the cover.

2. Extract the flat battery from its

location.

3. Replace battery with a battery of

the same type. Pay attention to

the installation position.

4. Clip the cover in place.

Fault

If the central locking cannot be

operated or the engine cannot be

started, the cause may be one of the

following:

● Fault in electronic key.

● Electronic key is out of reception

range.

● The battery voltage is too low.

● Overload of the central locking

system by operating at frequent

intervals, the power supply is

interrupted for a short time.

● Interference from higher-power

radio waves from other sources.

To rectify the cause of the fault,

change the position of the electronic

key.

Manual unlocking 3 9.

Central locking system

Unlocks and locks doors, load

compartment and fuel filler flap.

A pull on an interior door handle

unlocks the respective door. Pulling

the handle once more opens the door.

Notice

In the event of an accident in which

airbags or belt pretensioners are

deployed, the vehicle is

automatically unlocked.

Notice

A short time after unlocking with the

remote control or electronic key, the

doors are being locked automatically

10 Keys, doors and windows

if no door has been opened. A

precondition is that the setting is

activated in the Info Display 3 88.

Remote control operation

Unlocking

Press O.

Unlocking mode can be set in the Info

Display. Two settings are selectable:

● All doors, load compartment and

fuel filler flap will be unlocked by

pressing O once.

● Only the driver's door and fuel

filler flap will be unlocked by

pressing O once. To unlock all

doors, load compartment and

fuel filler flap, press O twice.

Select the relevant setting in the Info

Display.

Info Display 3 88.

Unlocking the tailgate

Press P longer to unlock the

tailgate only.

Unlocking and opening the tailgate

3 15.

Locking

Close doors, load compartment and

fuel filler flap.

Press N.

If the vehicle is not closed properly,

the central locking system will not

work.

Confirmation

Operation of the central locking

system is confirmed by the hazard

warning flashers. A precondition is

that the setting is activated in the Info

Display3 88.

Keys, doors and windows 11

Electronic key system operation

The electronic key must be outside

the vehicle, within a range of approx.

1 m of the relevant door side.

Unlocking

Pass a hand behind the door handle

of a front door to unlock the vehicle or

press the tailgate button.

Unlocking mode can be set in the Info

Display. Two settings are selectable:

● Only the driver's door and fuel

filler flap will be unlocked by

passing a hand behind the

driver's door handle.

● All doors, load compartment and

fuel filler flap will be unlocked by

passing a hand behind the

passenger's door handle or by

pressing the tailgate button.

● Only the tailgate will be unlocked

by pressing the tailgate button.

Info Display 3 88.

Locking

Press marking of the front door

handles.

Entire vehicle will be locked.

12 Keys, doors and windows

If the vehicle is not closed properly,

the electronic key remains in the

vehicle or the ignition is not off,

locking will not be permitted and a

warning chime sounds.

Keep the hand behind the door

handle or keep the tailgate button

pressed to close the windows.

Unlocking and opening the tailgate

The tailgate can be unlocked and

opened hands-free by pushing the

touchpad under the tailgate moulding

when the electronic key is in range.

The doors remain locked.

Load compartment 3 15.

Operation with buttons on the

electronic key

The central locking system can also

be operated with the buttons on the

electronic key.

Press O to unlock.

Press N to lock.

Press P longer to unlock and open

only the power tailgate.

Remote control operation 3 9.

Confirmation

Operation of central locking system is

confirmed by the hazard warning

flashers. A precondition is that the

setting is activated in the Info Display

3 88.

Central locking button

Locks or unlocks all doors, the load

compartment and fuel filler flap from

inside the passenger compartment.

Press Q to lock. The LED in the button

illuminates.

Press Q again to unlock. The LED in

the button extinguishes.

Keys, doors and windows 13

Operation with the key in case of

a central locking system fault

In case of a fault, e.g. vehicle battery

or remote control / electronic key

battery is discharged, the left front

door can be locked or unlocked with

the mechanical key.

Manual unlocking

Electronic key: press and hold the

latch to extract the integral key.

Manually unlock the left front door by

inserting and turning the key in the

lock cylinder.

The other doors can be opened by

pulling the interior handle. The load

compartment and fuel filler flap will

possibly not be unlocked.

By switching on the ignition, the anti-

theft locking system is deactivated.

Manual locking

Manually lock the left front door by

inserting and turning the key in the

lock cylinder.

To lock the other doors, remove the

black cover by using a key.

Insert key carefully and move to the

inner side of the door without turning

the key.

Remove key and attach black cover.

The fuel filler flap and tailgate are

possibly not locked.

Automatic locking

Automatic locking after driving off

This system allows automatic locking

of the doors and tailgate as soon as

the speed of the vehicle exceeds a

certain speed.

14 Keys, doors and windows

If one of the doors or the tailgate is

open, the automatic central locking

does not take place. This is signalled

by the sound of the locks rebounding,

accompanied by illumination of h in

the Driver Information Display, an

audible signal and the display of an

alert message.

This function can be activated or

deactivated at any time. With the

ignition on, press Q until an audible

signal starts and a corresponding

message is displayed.

The state of the system stays in

memory when switching off the

ignition.

Automatic relock after unlocking

This feature automatically locks all

doors, load compartment and fuel

filler flap a short time after unlocking

with the remote control or electronic

key, provided no door has been

opened.

Child locks

9Warning

Use the child locks whenever

children are occupying the rear

seats.

Mechanical child locks

Turn the red child lock in the rear door

to the horizontal position by using a

key. The door cannot be opened from

the inside.

To deactivate, turn the child lock to

the vertical position.

Keys, doors and windows 15

Electric child locks

Remotely operated system to prevent

opening of the rear doors via the

interior door handles and the use of

the rear power windows.

Switching on

Press R. The indicator light in the

button comes on, accompanied by a

confirmation message. This indicator

light remains on until the child lock is

switched off.

Switching off

Press R again. The indicator light on

button goes off, accompanied by a

confirmation message.

Doors

Load compartment

Tailgate

Opening

After unlocking, press the tailgate

button and open the tailgate.

Closing

Use the interior handle.

Do not push the touchpad whilst

closing as this will unlock the tailgate

again.

Central locking system 3 9.

16 Keys, doors and windows

Power tailgate

9Warning

Take care when operating the

power tailgate. Risk of injury,

particularly to children.

Keep a close watch on the

movable tailgate when operating.

Ensure that nothing becomes

trapped during operating and no

one is standing within the moving

area.

The power tailgate can be operated

by:

● Pressing P longer on the

electronic key.

● Hands-free operation with motion

sensor below the rear bumper.

● The tailgate button and T in the

open tailgate.

On vehicles with automatic

transmission, the tailgate can only be

operated when the vehicle is

stationary and automatic

transmission in P.

The turn lights flash and a chime

sounds when the power tailgate is

operating.

Notice

Operating the power tailgate does

not operate the central locking

system. To open the tailgate with the

button on the electronic key, or with

the tailgate button or via hands-free

operation, it is not necessary to

unlock the vehicle. A precondition is

that the electronic key is outside the

vehicle, within a range of approx.

1 m of the tailgate.

Do not leave the electronic key in the

load compartment.

Lock the vehicle after closing if it was

unlocked previously.

Central locking system 3 9.

Operation with the electronic key

Press P longer to open or close the

tailgate.

Keys, doors and windows 17

Hands-free operation

To open or close the tailgate move the

foot below the rear bumper back and

forth in the area below the number

plate. Do not hold the foot longer or

move too slow below the bumper. The

electronic key must be outside the

vehicle, within a range of approx.

1 m of the tailgate.

Activation or deactivation of hands-

free operation can be set in the Info

Display.

Info Display 3 88.

9Danger

Do not touch any vehicle parts

below the vehicle during hands-

free operation. There is a risk of

injury from hot engine parts.

Automatic locking after hands-free

operation

Press button S in the open tailgate,

the whole vehicle will be locked after

hands-free closing of the tailgate.

Operation with the tailgate button

To open the tailgate, press the

tailgate button until the tailgate starts

to move. If the vehicle is locked, the

electronic key must be outside the

vehicle, within a range of approx.

1 m of the tailgate.

18 Keys, doors and windows

To close, press T in the open

tailgate until the tailgate starts to

move.

Stop or change direction of

movement

Stop movement of the tailgate

immediately:

● press P longer on the

electronic key, or

● press the tailgate button, or

● press T on the open tailgate

Pressing one of the switches again

will reverse the direction of

movement.

Adjust reduced opening height

1. Open power tailgate with any

operation switch.

2. Stop movement at the desired

height by pressing T. If

required, manually move the

stopped tailgate to the desired

position.

3. Press and hold the button T on

the inside of the open tailgate for

3 seconds.

Notice

Adjusting opening height should be

programmed at ground level.

A chime sound indicates the new

setting and the turn lights will flash.

The reduced height can only set at an

opening angle of above 30°.

To delete reduced height position,

open tailgate in half position and

press T for 3 seconds.

The tailgate can only be held open if

a minimum height is exceeded

(minimum opening angle from 30°).

The opening height cannot be

programmed below that height.

Safety function

If the power tailgate encounters an

obstacle during opening or closing,

the direction of movement will

automatically be reversed slightly.

Multiple obstacles in one power cycle

will deactivate the function. In this

case, close or open the tailgate

manually.

The power tailgate has pinch sensors

on the side edges. If the sensors

detect obstacles between tailgate and

chassis, the tailgate will open, until it

is activated again or closed manually.

The safety function is indicated by a

warning chime.

Keys, doors and windows 19

Remove all obstacles before

resuming normal power operation.

If the vehicle is equipped with factory-

fitted towing equipment and a trailer

is electrically connected, the power

tailgate can only be opened with the

tailgate button or closed with T in

the open tailgate. Ensure that there

are no obstacles in the moving area.

Overload

If the power tailgate is repeatedly

operated at short intervals, the

function is disabled for some time.

Move tailgate manually into end

position to reset the system.

Initialising power tailgate

If the power tailgate cannot be

operated automatically (e.g. after

disconnecting the vehicle battery), a

warning message is displayed in the

Driver Information Centre.

Activate electronics as follows:

1. Open tailgate manually.

2. Close tailgate manually.

3. Switch on ignition.

Seek the assistance of a workshop if

the problem is not solved.

General hints for operating

tailgate

9Danger

Do not drive with the tailgate open

or ajar, e.g. when transporting

bulky objects, since toxic exhaust

gases, which cannot be seen or

smelled, could enter the vehicle.

This can cause unconsciousness

and even death.

Caution

Before opening the tailgate, check

overhead obstructions, e.g. a

garage door, to avoid damage to

the tailgate. Always check the

moving area above and behind the

tailgate.

Notice

The installation of certain heavy

accessories onto the tailgate may

affect its ability to remain open.

Notice

The operation of the power tailgate

is disabled under low vehicle battery

conditions. In this case, the tailgate

may not even by manually operable.

Notice

With the power tailgate disabled and

all doors unlocked, the tailgate can

only be operated manually. In this

event, manually closing the tailgate

requires significantly greater force.

Notice

At low outside temperatures the

tailgate may not open fully by itself.

In this case lift the tailgate manually

to its normal end position.

20 Keys, doors and windows

Vehicle security

Anti-theft locking system

9Warning

Do not use the system if there are

people in the vehicle! The doors

cannot be unlocked from the

inside.

The system deadlocks all the doors.

All doors must be closed otherwise

the system cannot be activated.

Unlocking the vehicle disables the

mechanical anti-theft locking system.

This is not possible with the central

locking button.

Activating

Press N on the radio remote control

twice within 5 seconds.

Anti-theft alarm system

The anti-theft alarm system is

combined with the central locking

system.

It monitors:

● doors, tailgate, bonnet

● passenger compartment

including adjoining load

compartment

● vehicle inclination, e.g. if it is

raised

● ignition

Activation

All doors, the load compartment and

the engine compartment must be

closed and the electronic key must

not remain in the vehicle.

● Radio remote control: activated

45 seconds after locking the

vehicle by pressing e once.

● Electronic key system: activated

45 seconds after locking the

vehicle by pressing with a finger

or thumb on one of the front door

handles at the markings.

If a door, the tailgate or the bonnet is

not properly closed, the vehicle is not

locked. However, the anti-theft alarm

is self-activated after 45 seconds.

Notice

Changes to the vehicle interior such

as the use of seat covers and open

windows, could impair the function

of passenger compartment

monitoring.

Keys, doors and windows 21

Activation without monitoring of

passenger compartment and

vehicle inclination

Switch off the monitoring of

passenger compartment and vehicle

inclination when animals are being

left in the vehicle, because of high

volume ultrasonic signals or

movements triggering the alarm. Also

switch off when the vehicle is on a

ferry or train.

1. Close tailgate, bonnet, windows.

2. Switch off ignition and press o

within 10 seconds until the LED in

the button o illuminates.

3. Close doors.

4. Activate the anti-theft alarm

system.

Indication

LED in the o button flashes if the

anti-theft alarm system is activated.

The hazard warning lights illuminates

for a few seconds.

Deactivation

Radio remote control: Unlocking the

vehicle by pressing c deactivates the

anti-theft alarm system.

Electronic key system: Unlocking the

vehicle by pressing on one of the front

door handles at the markings

deactivates the anti-theft alarm

system.

The electronic key must be outside

the vehicle, within a range of approx.

1 m of the relevant door side.

The system is not deactivated by

unlocking the driver's door with the

key or with the central locking button

in the passenger compartment.

The hazard warning lights flash for a

few seconds.

Alarm

When triggered, the alarm siren

sounds and the hazard warning lights

flash simultaneously. The number

and duration of alarm signals are

stipulated by legislation.

The anti-theft alarm system can be

deactivated by pressing c, by

pressing on one of the front door

handles at the markings with

electronic key system or switching on

the ignition.

22 Keys, doors and windows

A triggered alarm, which has not been

interrupted by the driver, will be

indicated by the LED in the button

o. The LED will flash quickly the

next time the vehicle is unlocked with

the radio remote control.

If the battery has been reconnected

(e.g. after maintenance work), wait for

10 minutes to restart the engine.

Fault

If the LED in the button o

illuminates permanently when

switching on the ignition, seek the

assistance of a workshop.

Locking the vehicle without

activation of the anti-theft alarm

Lock the vehicle by locking the

driver's door with the integral key.

Immobiliser

The system is part of the ignition

switch and checks whether the

vehicle is allowed to be started with

the key being used.

The immobiliser is activated

automatically after the key has been

removed from the ignition switch.

Notice

Radio Frequency Identification

(RFID) tags may cause interference

with the key. Do not have it placed

near the key when starting the

vehicle.

Notice

The immobiliser does not lock the

doors. Always lock the vehicle after

leaving it 3 9.

Switch on the anti-theft alarm

system 3 20.

Emergency operation of electronic

key 3 117.

Exterior mirrors

Convex shape

The shape of the mirror makes

objects appear smaller, which will

affect the ability to estimate

distances.

Side blind spot alert 3 168.

Electric adjustment

Select the relevant exterior mirror by

pushing the mirror button to the left or

right.

Then swivel the control to adjust the

mirror.

Keys, doors and windows 23

Folding mirrors

For pedestrian safety, the exterior

mirrors will swing out of their normal

mounting position if they are struck

with sufficient force. Reposition the

mirror by applying slight pressure to

the mirror housing.

Electric folding

Pull mirror button rearwards. Both

exterior mirrors will fold.

Pull mirror button rearwards again to

return both exterior mirrors to their

original position.

If an electrically folded mirror is

manually extended, pulling mirror

button rearwards will only electrically

extend the other mirror.

Automatic folding

When the vehicle is unlocked, the

mirrors swing to their normal

mounting position. When the vehicle

is locked, the mirrors are folded down.

To enable or disable automatic

folding of the exterior mirrors, consult

a workshop.

Heated mirrors

Operated by pressing b.

Heating works with the engine

running and is switched off

automatically after a short time.

Heated rear window 3 27.

24 Keys, doors and windows

Interior mirrors

To adjust the mirror, move the mirror

housing in the desired direction.

Manual anti-dazzle

To reduce dazzle, adjust the lever on

the underside of the mirror housing.

Automatic anti-dazzle

Dazzle from following vehicles is

automatically reduced, when driving

in the dark.

Keys, doors and windows 25

Windows

Windscreen

Windscreen stickers

Do not attach stickers such as toll

road stickers or similar on the

windscreen in the area of the interior

mirror. Keep the sensor free from

dust, dirt and ice. Otherwise the

detection zone of the rain sensor /

light sensor and the view area of the

camera in the mirror housing could be

restricted.

Sensors 3 69, 3 97

Windscreen replacement

Caution

If the vehicle has a front-looking

camera sensor for the driver

assistance systems, it is very

important that any windscreen

replacement is performed

accurately according to Vauxhall

specifications. Otherwise, these

systems may not work properly

and there is a risk of unexpected

behaviour and / or messages from

these systems.

Power windows

9Warning

Take care when operating the

power windows. Risk of injury,

particularly to children.

If there are children on the rear

seats, switch on the child safety

system for the power windows.

Keep a close watch on the

windows when closing them.

Ensure that nothing becomes

trapped in them as they move.

Switch on ignition to operate power

windows.

Operate the switch for the respective

window by pushing to open or pulling

to close.

Pushing or pulling gently to the first

detent: window moves up or down as

long as the switch is operated.

26 Keys, doors and windows

Pushing or pulling firmly to the second

detent then releasing: window moves

up or down automatically with safety

function enabled. To stop movement,

operate the switch once more in the

same direction.

Safety function

If the window glass encounters

resistance above the middle of the

window during automatic closing, it is

immediately stopped and opened

again.

Override safety function

In the event of closing difficulties due

to frost or the like, switch on the

ignition, then pull the switch to the first

detent and hold. The window moves

up without safety function enabled.

To stop movement, release the

switch.

Child safety system for rear

windows

Press V to deactivate rear door

power windows; the LED illuminates.

To activate, press V again.

Operating windows from outside

The windows can be operated

remotely from outside the vehicle.

Press and hold e to close windows.

Release button to stop window

movement.

If the windows are fully closed, the

hazard warning lights will flash twice.

Overload

If the windows are repeatedly

operated within short intervals, the

window operation is disabled for

some time.

Keys, doors and windows 27

Initialising the power windows

If the windows cannot be closed

automatically (e.g. after

disconnecting the vehicle battery), a

warning message is displayed in the

Driver Information Centre.

Vehicle messages 3 91.

Activate the window electronics as

follows:

1. Close doors.

2. Switch on ignition.

3. Pull switch until the window is

closed and keep pulling for

additional 2 seconds.

4. Push switch until the window is

completely open and keep

pushing for additional 2 seconds.

5. Repeat for each window.

Heated rear window

Operated by pressing b together with

heated exterior mirrors.

Heating works with the engine

running and is switched off

automatically after a short time.

Depending on climate control system,

b is located at a different position.

Vehicles with heating and

ventilation system or air

conditioning system

Vehicles with electronic climate

control system

Heated windscreen

Operated by pressing ,. LED in

button illuminates.

Heating works with the engine

running and is switched off

automatically after a short time.

Depending on climate control

system, , is located at a different

position.

28 Keys, doors and windows

Vehicles with electronic climate

control system

Vehicles with air conditioning

system

Sun visors

The sun visors can be folded down or

swivelled to the side to prevent

dazzling.

If the sun visors have integral mirrors,

the mirror covers should be closed

when driving.

A ticket holder is located on the

backside of the sun visor.

Roller blinds

To reduce sunlight at the second row

seats, pull the blind upwards using

the grip and engage it at the top of the

door frame.

Roof

Glass panel

Sunblind

Press N gently to the first detent at

the rear: the sunblind is opened as

long as the switch is operated.

Press N firmly to the second detent

and then release at the rear: the

sunblind is opened as long as the

switch is operated.

Press N gently to the first detent at

the front: the sunblind is closed as

long as the switch is operated.

Keys, doors and windows 29

Press N firmly to the second detent

and then release at the front: the

sunblind is closed as long as the

switch is operated.

Safety function

If the sunblind encounters resistance

during automatic closing, it is

immediately stopped and opened

again.

Function standby

In ignition switch position 1 the

sunblind is operational 3 116.

Initialising after a power failure

After a power failure, it may only be

possible to operate the sunblind to a

limited extent. Initialise the system as

follows:

1. Turn key in ignition switch to

position 1.

2. Press N twice gently to the first

detent at the rear, the sunblind

opens slightly.

3. Immediately press N twice gently

to the first detent at the front, the

sunblind closes slightly.

After step 3 the sunblind is in

initialising mode without safety

function.

4. Press N gently to the first detent

at the rear until the sunblind is

completely opened.

5. Press N gently to the first detent

at the front until the sunblind is

completely closed.

After this procedure, the sunblind is

initialised with safety function

activated.

When N is pressed firmly to the

second detent during initialising, the

procedure is cancelled.

30 Seats, restraints

Seats, restraints

Head restraints ............................ 30

Front seats ................................... 31

Seat position .............................. 31

Manual seat adjustment ............ 32

Power seat adjustment .............. 34

Armrest ...................................... 36

Heating ...................................... 36

Ventilating .................................. 36

Rear seats ................................... 37

Armrest ...................................... 37

Heating ...................................... 37

Seat belts ..................................... 37

Three-point seat belt ................. 38

Airbag system .............................. 40

Front airbag system ................... 44

Side airbag system .................... 44

Curtain airbag system ............... 45

Airbag deactivation .................... 45

Child restraints ............................. 47

Child restraint systems .............. 47

Child restraint installation

locations ................................... 50

Head restraints

Position

9Warning

Only drive with the head restraint

set to the proper position.

The upper edge of the head restraint

should be at upper head level. If this

is not possible for extremely tall

people, set to highest position, and

set to lowest position for small people.

Adjustment

Head restraints on front seats

Height adjustment

Pull the head restraint upwards or

press the catch to release and push

the head restraint downwards.

Seats, restraints 31

Head restraints on rear seats

Height adjustment

Pull the head restraint upwards or

press the catch to release and push

the head restraint downwards.

Removal

Press catch, pull the respective head

restraint upwards and remove.

Front seats

Seat position

9Warning

Only drive with the seat correctly

adjusted.

9Warning

Never adjust seats while driving as

they could move uncontrollably.

9Danger

Do not sit closer than 25 cm to the

steering wheel, to permit safe

airbag deployment.

9Warning

Never store any objects under the

seats.

● Sit with buttocks as far back

against the backrest as possible.

Adjust the distance between the

seat and the pedals so that legs

are slightly angled when pressing

the pedals. Slide the front

passenger seat as far back as

possible.

● Set seat height high enough to

have a clear field of vision on all

sides and of all display

instruments. There should be at

least one hand of clearance

between head and the roof

frame. Your thighs should rest

lightly on the seat without

pressing into it.

32 Seats, restraints

● Sit with shoulders as far back

against the backrest as possible.

Set the backrest rake so that it is

possible to easily reach the

steering wheel with arms slightly

bent. Maintain contact between

shoulders and the backrest when

turning the steering wheel. Do

not angle the backrest too far

back. We recommend a

maximum rake of approx. 25°.

● Adjust seat and steering wheel in

a way that the wrist rests on top

of the steering wheel while the

arm is fully extended and

shoulders are on the backrest.

● Adjust the steering wheel 3 68.

● Adjust the head restraint 3 30.

● Adjust the height of the seat belt

3 38.

● Adjust the thigh support so that

there is a space approx. two

fingers wide between the edge of

the seat and the hollow of the

knee.

● Adjust the lumbar support so that

it supports the natural shape of

the spine.

Manual seat adjustment

Drive only with engaged seats and

backrests.

Longitudinal adjustment

Pull handle, slide seat, release

handle. Try to move the seat back and

forth to ensure that the seat is locked

in place.

Backrest inclination

Turn handwheel. Do not lean on

backrest when adjusting.

34 Seats, restraints

Adjustable thigh support

Pull the lever and slide the thigh

support.

Power seat adjustment

9Warning

Care must be taken when

operating the power seats. There

is a risk of injury, particularly for

children. Objects could become

trapped.

Keep a close watch on the seats

when adjusting them. Vehicle

passengers should be informed

accordingly.

Longitudinal adjustment

Move switch forwards / backwards.

Seat height

Move switch upwards / downwards.

Seat inclination

Seats, restraints 35

Move front of switch upwards /

downwards.

Backrest inclination

Turn switch forwards / backwards.

Lumbar support, adjustable thigh

support, see manual seat adjustment

3 32.

Memory function for power seat

adjustment

Two different driver's seat settings

can be stored.

Info Display 3 88.

Storing memory position

● Adjust driver's seat to desired

position.

● Press and hold M and 1 or 2

simultaneously until a chime

sounds.

Recall of memory positions

Press and hold 1 or 2 until the stored

seat position has been reached.

Releasing the button during seat

movement cancels the recall.

Safety function

If the driver's seat encounters

resistance during movement, the

recall may stop. After removing the

obstruction, press and hold the

appropriate memory position button

for 2 seconds. Try recalling the

memory position again. If the recall

does not operate, consult a

workshop.

Overload

If the seat setting is electrically

overloaded, the power supply is

automatically cut-off for a short time.

Notice

After an accident in which airbags

have been deployed, the memory

function for each position button will

be deactivated.

36 Seats, restraints

Armrest

The armrest can be slid forwards by

10 cm. Pull the handle to slide the

armrest. Under the armrest there is a

storage compartment.

Heating

Adjust heating to the desired setting

by pressing ß for the respective seat

one or more times. The control

indicator in the button indicates the

setting.

Prolonged use of the highest setting

for people with sensitive skin is not

recommended.

Seat heating is operational when

engine is running and during an

Autostop.

Stop-start system 3 120.

Ventilating

Activate ventilation by pressing A for

the respective front seat.

Ventilated seats are operational when

engine is running and during an

Autostop.

Stop-start system 3 120.

Seats, restraints 37

Rear seats

Armrest

Fold armrest down. The armrest

contains cupholders.

Heating

Adjust seat heating by turning thumb

wheel ß for the respective rear outer

seat to the desired setting.

Prolonged use of the highest setting

for people with sensitive skin is not

recommended.

Seat heating is operational when

engine is running and during an

Autostop.

Seat belts

The seat belts are locked during

heavy acceleration or deceleration of

the vehicle, holding the occupants in

the seat position. Therefore the risk of

injury is considerably reduced.

9Warning

Fasten seat belt before each trip.

In the event of an accident, people

not wearing seat belts endanger

their fellow occupants and

themselves.

38 Seats, restraints

Seat belts are designed to be used by

only one person at a time.

Child restraint system 3 47.

Periodically check all parts of the seat

belt system for damage, soiling and

proper functionality.

Have damaged components

replaced. After an accident, have the

seat belts and triggered seat belt

pretensioners replaced by a

workshop.

Notice

Make sure that the seat belts are

neither damaged by shoes or sharp-

edged objects nor trapped. Prevent

dirt from getting into the seat belt

retractors.

Notice

Use the belt buckle inteded for the

respective seat belt when fastening

in order to ensure proper

functionality.

Seat belt reminder

Each seat is equipped with a seat belt

reminder, indicated by a control

indicator X for the respective seat in

the overhead console.

Seat belt reminder 3 80.

Seat belt force limiters

Stress on the body is reduced by the

gradual release of the seat belt during

a collision.

Seat belt pretensioners

In the event of a head-on, rear-end or

side-on collision of a certain severity,

the front seat belts and the outer rear

seat belts are tightened by seat belt

pretensioners.

9Warning

Incorrect handling (e.g. removal or

fitting of seat belts) can trigger the

seat belt pretensioners.

Deployment of the seat belt

pretensioners is indicated by

continuous illumination of control

indicator v.

Airbag and seat belt

pretensioners3 80

Triggered seat belt pretensioners

must be replaced by a workshop.

Seat belt pretensioners can only be

triggered once.

Notice

Do not affix or install accessories or

other objects that may interfere with

the operation of the seat belt

pretensioners. Do not make any

modifications to seat belt

pretensioner components as this will

invalidate the vehicle operating

permit.

Three-point seat belt

Fasten

Seats, restraints 39

Withdraw the seat belt from the

retractor, guide it untwisted across

the body and insert the latch plate into

the buckle. Make sure the belt fits

tightly to the body while driving.

Loose or bulky clothing prevents the

seat belt from fitting snugly. Do not

place objects such as handbags or

mobile phones between the seat belt

and your body.

9Warning

The seat belt must not rest against

hard or fragile objects in the

pockets of your clothing.

Seat belt reminder X 3 80.

Height adjustment

1. Pull seat belt out slightly.

2. Press the button to disengage the

height adjuster and push it

upwards or downwards.

Adjust the height so that the seat belt

lies across the shoulder. It must not

lie across the throat or upper arm.

Do not adjust while driving.

40 Seats, restraints

Unfasten

To release seat belt, press red button

on seat belt buckle.

Using seat belts while pregnant

9Warning

The lap belt must be positioned as

low as possible across the pelvis

to prevent pressure on the

abdomen.

Airbag system

The airbag system consists of a

number of individual systems

depending on the scope of

equipment.

When triggered the airbags inflate

within milliseconds. They also deflate

so quickly that it is often unnoticeable

during the collision.

9Warning

The airbag system deploys in an

explosive manner, repairs must be

performed by skilled personnel

only.

9Warning

Adding accessories that change

the vehicle's frame, bumper

system, height, front end or side

sheet metal, may keep the airbag

system from working properly. The

operation of the airbag system can

also be affected by changing any

parts of the front seats, seat belts,

Seats, restraints 41

airbag sensing and diagnostic

module, steering wheel,

instrument panel, inner door seals

including the speakers, any of the

airbag modules, ceiling or pillar

trim, front sensors, side impact

sensors or airbag wiring.

Notice

The airbag systems and belt

pretensioner control electronics are

located in the centre console. Do not

put any magnetic objects in this

area.

Do not affix any objects onto the

airbag covers and do not cover them

with other materials. Have damaged

covers replaced by a workshop.

Each airbag is triggered only once.

Have deployed airbags replaced by

a workshop. Furthermore, it may be

necessary to have the steering

wheel, the instrument panel, parts of

the panelling, the door seals,

handles and the seats replaced.

Do not make any modifications to

the airbag system as this will

invalidate the vehicle operating

permit.

Control indicator v for airbag systems

3 80.

Child restraint systems on front

passenger seat with airbag

systems

Warning according to ECE R94.02:

EN: NEVER use a rearward-facing

child restraint on a seat protected by

an ACTIVE AIRBAG in front of it;

DEATH or SERIOUS INJURY to the

CHILD can occur.

DE: Nach hinten gerichtete

Kindersitze NIEMALS auf einem Sitz

verwenden, der durch einen davor

befindlichen AKTIVEN AIRBAG

geschützt ist, da dies den TOD oder

SCHWERE VERLETZUNGEN DES

KINDES zur Folge haben kann.

FR: NE JAMAIS utiliser un siège

d'enfant orienté vers l'arrière sur un

siège protégé par un COUSSIN

GONFLABLE ACTIF placé devant lui,

sous peine d'infliger des

BLESSURES GRAVES, voire

MORTELLES à l'ENFANT.

ES: NUNCA utilice un sistema de

retención infantil orientado hacia

atrás en un asiento protegido por un

AIRBAG FRONTAL ACTIVO. Peligro

de MUERTE o LESIONES GRAVES

para el NIÑO.

RU: ЗАПРЕЩАЕТСЯ

устанавливать детское

удерживающее устройство лицом

назад на сиденье автомобиля,

оборудованном фронтальной

подушкой безопасности, если

ПОДУШКА НЕ ОТКЛЮЧЕНА! Это

может привести к СМЕРТИ или

СЕРЬЕЗНЫМ ТРАВМАМ

РЕБЕНКА.

42 Seats, restraints

NL: Gebruik NOOIT een achterwaarts

gericht kinderzitje op een stoel met

een ACTIEVE AIRBAG ervoor, om

DODELIJK of ERNSTIG LETSEL van

het KIND te voorkomen.

DA: Brug ALDRIG en bagudvendt

autostol på et forsæde med AKTIV

AIRBAG, BARNET kan komme i

LIVSFARE eller komme ALVORLIGT

TIL SKADE.

SV: Använd ALDRIG en bakåtvänd

barnstol på ett säte som skyddas med

en framförvarande AKTIV AIRBAG.

DÖDSFALL eller ALLVARLIGA

SKADOR kan drabba BARNET.

FI: ÄLÄ KOSKAAN sijoita taaksepäin

suunnattua lasten turvaistuinta

istuimelle, jonka edessä on

AKTIIVINEN TURVATYYNY, LAPSI

VOI KUOLLA tai VAMMAUTUA

VAKAVASTI.

NO: Bakovervendt

barnesikringsutstyr må ALDRI brukes

på et sete med AKTIV

KOLLISJONSPUTE foran, da det kan

føre til at BARNET utsettes for

LIVSFARE og fare for ALVORLIGE

SKADER.

PT: NUNCA use um sistema de

retenção para crianças voltado para

trás num banco protegido com um

AIRBAG ACTIVO na frente do

mesmo, poderá ocorrer a PERDA DE

VIDA ou FERIMENTOS GRAVES na

CRIANÇA.

IT: Non usare mai un sistema di

sicurezza per bambini rivolto

all'indietro su un sedile protetto da

AIRBAG ATTIVO di fronte ad esso:

pericolo di MORTE o LESIONI

GRAVI per il BAMBINO!

EL: ΠΟΤΕ μη χρησιμοποιείτε παιδικό

κάθισμα ασφαλείας με φορά προς τα

πίσω σε κάθισμα που προστατεύεται

από μετωπικό ΕΝΕΡΓΟ ΑΕΡΟΣΑΚΟ,

διότι το παιδί μπορεί να υποστεί

ΘΑΝΑΣΙΜΟ ή ΣΟΒΑΡΟ

ΤΡΑΥΜΑΤΙΣΜΟ.

PL: NIE WOLNO montować fotelika

dziecięcego zwróconego tyłem do

kierunku jazdy na fotelu, przed

którym znajduje się WŁĄCZONA

PODUSZKA POWIETRZNA.

Niezastosowanie się do tego

zalecenia może być przyczyną

ŚMIERCI lub POWAŻNYCH

OBRAŻEŃ u DZIECKA.

TR: Arkaya bakan bir çocuk emniyet

sistemini KESİNLİKLE önünde bir

AKTİF HAVA YASTIĞI ile

korunmakta olan bir koltukta

kullanmayınız. ÇOCUK ÖLEBİLİR

veya AĞIR ŞEKİLDE

YARALANABİLİR.

UK: НІКОЛИ не використовуйте

систему безпеки для дітей, що

встановлюється обличчям назад,

на сидінні з УВІМКНЕНОЮ

ПОДУШКОЮ БЕЗПЕКИ, інакше це

може призвести до СМЕРТІ чи

СЕРЙОЗНОГО ТРАВМУВАННЯ

ДИТИНИ.

HU: SOHA ne használjon hátrafelé

néző biztonsági gyerekülést előlről

AKTÍV LÉGZSÁKKAL védett ülésen,

mert a GYERMEK HALÁLÁT vagy

KOMOLY SÉRÜLÉSÉT okozhatja.

HR: NIKADA nemojte koristiti sustav

zadržavanja za djecu okrenut prema

natrag na sjedalu s AKTIVNIM

ZRAČNIM JASTUKOM ispred njega,

to bi moglo dovesti do SMRTI ili

OZBILJNJIH OZLJEDA za DIJETE.

SL: NIKOLI ne nameščajte otroškega

varnostnega sedeža, obrnjenega v

nasprotni smeri vožnje, na sedež z

Seats, restraints 43

AKTIVNO ČELNO ZRAČNO

BLAZINO, saj pri tem obstaja

nevarnost RESNIH ali SMRTNIH

POŠKODB za OTROKA.

SR: NIKADA ne koristiti bezbednosni

sistem za decu u kome su deca

okrenuta unazad na sedištu sa

AKTIVNIM VAZDUŠNIM

JASTUKOM ispred sedišta zato što

DETE može da NASTRADA ili da se

TEŠKO POVREDI.

MK: НИКОГАШ не користете детско

седиште свртено наназад на

седиште заштитено со АКТИВНО

ВОЗДУШНО ПЕРНИЧЕ пред него,

затоа што детето може ДА ЗАГИНЕ

или да биде ТЕШКО ПОВРЕДЕНО.

BG: НИКОГА не използвайте

детска седалка, гледаща назад,

върху седалка, която е защитена

чрез АКТИВНА ВЪЗДУШНА

ВЪЗГЛАВНИЦА пред нея - може да

се стигне до СМЪРТ или

СЕРИОЗНО НАРАНЯВАНЕ на

ДЕТЕТО.

RO: Nu utilizaţi NICIODATĂ un scaun

pentru copil îndreptat spre partea din

spate a maşinii pe un scaun protejat

de un AIRBAG ACTIV în faţa sa;

acest lucru poate duce la DECESUL

sau VĂTĂMAREA GRAVĂ a

COPILULUI.

CS: NIKDY nepoužívejte dětský

zádržný systém instalovaný proti

směru jízdy na sedadle, které je

chráněno před sedadlem AKTIVNÍM

AIRBAGEM. Mohlo by dojít k

VÁŽNÉMU PORANĚNÍ nebo ÚMRTÍ

DÍTĚTE.

SK: NIKDY nepoužívajte detskú

sedačku otočenú vzad na sedadle

chránenom AKTÍVNYM AIRBAGOM,

pretože môže dôjsť k SMRTI alebo

VÁŽNYM ZRANENIAM DIEŤAŤA.

LT: JOKIU BŪDU nemontuokite atgal

atgręžtos vaiko tvirtinimo sistemos

sėdynėje, prieš kurią įrengta AKTYVI

ORO PAGALVĖ, nes VAIKAS GALI

ŽŪTI arba RIMTAI SUSIŽALOTI.

LV: NEKĀDĀ GADĪJUMĀ

neizmantojiet uz aizmuguri vērstu

bērnu sēdeklīti sēdvietā, kas tiek

aizsargāta ar tās priekšā uzstādītu

AKTĪVU DROŠĪBAS SPILVENU, jo

pretējā gadījumā BĒRNS var gūt

SMAGAS TRAUMAS vai IET BOJĀ.

ET: ÄRGE kasutage tahapoole

suunatud lapseturvaistet istmel, mille

ees on AKTIIVSE TURVAPADJAGA

kaitstud iste, sest see võib

põhjustada LAPSE SURMA või

TÕSISE VIGASTUSE.

MT: QATT tuża trażżin għat-tfal li

jħares lejn in-naħa ta’ wara fuq sit

protett b’AIRBAG ATTIV quddiemu;

dan jista’ jikkawża l-MEWT jew

ĠRIEĦI SERJI lit-TFAL.

GA: Ná húsáid srian sábháilteachta

linbh cúil RIAMH ar shuíochán a

bhfuil mála aeir ag feidhmiú os a

chomhair. Tá baol BÁIS nó GORTÚ

DONA don PHÁISTE ag baint leis.

Beyond the warning required by

ECE R94.02, for safety reasons a

forward-facing child restraint system

must only be used subject to the

instructions and restrictions in the

table 3 50.

The airbag label is located on both

sides of the front passenger sun visor.

Airbag deactivation 3 45.

44 Seats, restraints

Front airbag system

The front airbag system consists of

one airbag in the steering wheel and

one in the instrument panel on the

front passenger side. These can be

identified by the word AIRBAG.

The front airbag system is triggered in

the event of a front-end impact of a

certain severity. The ignition must be

switched on.

The inflated airbags cushion the

impact, thereby reducing the risk of

injury to the upper body and head of

the front seat occupants

considerably.

9Warning

Optimum protection is only

provided when the seat is in the

proper position.

Seat position 3 31.

Keep the area in which the airbag

inflates clear of obstructions.

Fit the seat belt correctly and

engage securely. Only then is the

airbag able to protect.

Side airbag system

The side airbag system consists of an

airbag in each front seat backrest.

This can be identified by the word

AIRBAG.

The side airbag system is triggered in

the event of a side impact of a certain

severity. The ignition must be

switched on.

The inflated airbags cushion the

impact, thereby reducing the risk of

injury to the upper body and pelvis in

the event of a side-on collision

considerably.

Seats, restraints 45

9Warning

Keep the area in which the airbag

inflates clear of obstructions.

Notice

Only use protective seat covers that

have been approved for the vehicle.

Be careful not to cover the airbags.

Curtain airbag system

The curtain airbag system consists of

an airbag in the roof frame on each

side. This can be identified by the

word AIRBAG on the roof pillars.

The curtain airbag system is triggered

in the event of a side-on impact of a

certain severity. The ignition must be

switched on.

The inflated airbags cushion the

impact, thereby reducing the risk of

injury to the head in the event of a

side-on impact considerably.

9Warning

Keep the area in which the airbag

inflates clear of obstructions.

The hooks on the handles in the

roof frame are only suitable for

hanging up light articles of

clothing, without coat hangers. Do

not keep any items in these

clothes.

Airbag deactivation

The front passenger airbag system

must be deactivated for child restraint

system on the passenger seat

according to the instructions in the

table 3 50. The side airbag and

curtain airbag systems, the belt

pretensioners and all driver airbag

systems will remain active.

The front passenger airbag system

can be deactivated via a key-

operated switch in the glovebox.

46 Seats, restraints

Use the ignition key to choose the

position:

OFF*: front passenger airbag is

deactivated and will not

inflate in the event of a

collision, control indicator

OFF* illuminates

continuously in the centre

console

ONÓ: front passenger airbag is

active

9Danger

Deactivate passenger airbag only

in combination with the use of a

child restraint system, subject to

the instructions and restrictions in

the table 3 50.

Otherwise, there is a risk of fatal

injury for a person occupying a

seat with a deactivated front

passenger airbag.

If the control indicator Ó illuminates

for approx. 60 seconds after the

ignition is switched on, the front

passenger airbag system will inflate

in the event of a collision.

If the control indicator * illuminates

after the ignition is switched on, the

front passenger airbag system is

deactivated. It stays on while the

airbag is deactivated.

If both control indicators are

illuminated at the same time, there is

a system failure. The status of the

system is not discernible, therefore

no person is allowed to occupy the

front passenger seat. Contact a

workshop immediately.

Consult a workshop immediately if

neither of the two control indicators

are illuminated.

Change status only when the vehicle

is stopped with the ignition off.

Status remains until the next change.

Control indicator for airbag

deactivation 3 81.

Seats, restraints 47

Child restraints

Child restraint systems

9Danger

If using a rear-facing child restraint

system on the front passenger

seat, the airbag system for the

front passenger seat must be

deactivated. This also applies to

certain forward-facing child

restraint systems as indicated in

the tables 3 50.

Airbag deactivation 3 45.

Airbag label 3 40.

We recommend a child restraint

system which is tailored specifically to

the vehicle. For further information,

contact your workshop.

Before fastening a child seat adjust

the head restraint 3 30.

When a child restraint system is being

used, pay attention to the following

usage and installation instructions

and also those supplied with the child

restraint system.

Always comply with local or national

regulations. In some countries, the

use of child restraint systems is

forbidden on certain seats.

Child restraint systems can be

fastened with:

● Three-point seat belt

● ISOFIX brackets

● Top-tether

Three-point seat belt

Child restraint systems can be

fastened by using a three-point seat

belt. After fastening the child restraint

system the seat belt has to be

tightened 3 50.

ISOFIX brackets

Fasten vehicle-approved ISOFIX

child restraint systems to the ISOFIX

brackets. Specific vehicle ISOFIX

child restraint system positions are

marked in the ISOFIX table 3 50.

ISOFIX brackets are indicated by a

label on the backrest.

An i-Size child restraint system is an

universal ISOFIX child restraint

system according UN Regulation No.

129.

All i-Size child restraint systems can

be used on any vehicle seat suitable

for i-Size, i-Size table 3 50.

48 Seats, restraints

Either a Top-tether strap or a support

leg must be used in addition to the

ISOFIX brackets.

i-Size child seats and vehicle seats

with i-Size approval are marked with

i-Size symbol, see illustration.

Top-tether anchors

Top-tether anchors are marked with

the symbol : for a child seat.

In addition to the ISOFIX brackets,

fasten the Top-tether strap to the

Top-tether anchors.

ISOFIX child restraint systems of

universal category positions are

marked in the table by IUF 3 50.

Selecting the right system

The rear seats are the most

convenient location to fasten a child

restraint system.

Children should travel facing

rearwards in the vehicle as long as

possible. This makes sure that the

child's backbone, which is still very

weak, is under less strain in the event

of an accident.

Suitable are child restraint systems

that comply with valid UN ECE

regulations. Check local laws and

regulations for mandatory use of child

restraint systems.

The following child restraints are

recommended for the following

weight classes:

●Group 0, Group 0+:

Maxi Cosi Cabriofix with or

without ISOFIX base for children

up to 13 kg

●Group I: Duo Plus with ISOFIX

and Top-tether for children from

9 kg to 18 kg

●Group II, Group III: Kidfix XP with

or without ISOFIX for children

from 15 kg to 36 kg

●Group III: Graco Booster for

children from 22 kg to 36 kg

Ensure that the child restraint system

to be installed is compatible with the

vehicle type.

Ensure that the mounting location of

the child restraint system within the

vehicle is correct, see following

tables.

Allow children to enter and exit the

vehicle only on the side facing away

from the traffic.

When the child restraint system is not

in use, secure the seat with a seat belt

or remove it from the vehicle.

Seats, restraints 49

Notice

Do not affix anything on the child

restraint systems and do not cover

them with any other materials.

A child restraint system which has

been subjected to stress in an

accident must be replaced.

50 Seats, restraints

Child restraint installation locations

Permissible options for fastening a child restraint system with a three-point seat belt

Weight class

On front passenger seat

On rear outer seats On rear centre seatactivated airbag deactivated airbag

Group 0: up to 10 kg XU/L1,2 U/L3U

Group 0+: up to 13 kg XU/L1,2 U/L3U

Group I: 9 to 18 kg XU/L1,2 U/L3,4 U4

Group II: 15 to 25 kg U/L1,2 XU/L3,4 U4

Group III: 22 to 36 kg U/L1,2 XU/L3,4 U4

U : universal suitability in conjunction with three-point seat belt

L : suitable for particular child restraint systems of the 'specific-vehicle', 'restricted' or 'semi-universal' categories. The

child restraint system must be approved for the specific vehicle type (refer to the vehicle type list of the child restraint

system)

X : no child restraint system permitted in this weight class

1: move seat forwards as far as necessary and adjust seat backrest inclination as far as necessary to a vertical position

to ensure that the belt runs forwards from the upper anchorage point

2: move seat height adjustment upwards as far as necessary and adjust seat backrest inclination as far as necessary

to a vertical position to ensure that the belt is tight on the buckle side

3: move the respective front seat ahead of the child restraint system forwards as far as necessary

4: adjust the respective headrest as necessary or remove if required

Seats, restraints 51

Permissible options for fitting an ISOFIX child restraint system with ISOFIX brackets

Weight class Size class Fixture

On front passenger seat

On rear outer seats On rear centre

seatactivated airbag deactivated airbag

Group 0: up to 10 kg G ISO/L2 X X X X

F ISO/L1 X X X X

E ISO/R1 X IL IL3X

Group 0+: up to 13 kg E ISO/R1 X IL IL3X

D ISO/R2 X IL IL3X

C ISO/R3 X IL IL3X

Group I: 9 to 18 kg D ISO/R2 X IL IL3,4 X

C ISO/R3 X IL IL3,4 X

B ISO/F2 X IL, IUF IL, IUF3,4 X

B1 ISO/F2X X IL, IUF IL, IUF3,4 X

A ISO/F3 X IL, IUF IL, IUF3,4 X

Group II: 15 to 25 kg X X IL3,4 X

Group III: 22 to 36 kg X X IL3,4 X

52 Seats, restraints

IL : suitable for particular ISOFIX restraint systems of the 'specific-vehicle', 'restricted' or 'semi-universal' categories.

The ISOFIX restraint system must be approved for the specific vehicle type (refer to the vehicle type list of the child

restraint system)

IUF : suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight class

X : no ISOFIX child restraint system approved in this weight class

1: move seat forwards as far as necessary and adjust seat backrest inclination as far as necessary to a vertical position

to ensure that the belt runs forwards from the upper anchorage point

2: move seat height adjustment upwards as far as necessary and adjust seat backrest inclination as far as necessary

to a vertical position to ensure that the belt is tight on the buckle side

3: move the respective front seat ahead of the child restraint system forwards as far as necessary

4: adjust the respective headrest as necessary or remove if required

ISOFIX size class and seat device

A – ISO/F3 : forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg

B – ISO/F2 : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg

B1 – ISO/F2X : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg

C – ISO/R3 : rear-facing child restraint system for children of maximum size in the weight class up to 18 kg

D – ISO/R2 : rear-facing child restraint system for smaller children in the weight class up to 18 kg

E – ISO/R1 : rear-facing child restraint system for young children in the weight class up to 13 kg

F– ISO/L1 : left lateral facing position child restraint system (carry-cot)

G – ISO/L2 : right lateral facing position child restraint system (carry-cot)

Permissible options for fitting an i-Size child restraint system with ISOFIX brackets

On front passenger seat

On rear outer seats On rear centre seatactivated airbag deactivated airbag

i-Size child restraint systems X i - U i - U X

Seats, restraints 53

i - U : suitable for i-Size 'universal' forward and rearward facing child restraint systems

X : seating position not suitable for i-Size 'universal' child restraint systems.

54 Storage

Storage

Storage compartments ................ 54

Glovebox ................................... 54

Cupholders ................................ 54

Centre console storage ............. 55

Load compartment ....................... 55

Load compartment cover ........... 57

Rear floor storage cover ............ 58

Lashing eyes ............................. 59

Safety net .................................. 59

Warning triangle ........................ 61

First aid kit ................................. 61

Roof rack system ......................... 62

Roof rack ................................... 62

Loading information ..................... 62

Storage compartments

9Warning

Do not store heavy or sharp

objects in the storage

compartments. Otherwise, the

storage compartment lid could

open and vehicle occupants could

be injured by objects being thrown

around in the event of hard

braking, a sudden change in

direction or an accident.

Glovebox

On some versions the glovebox is

ventilated. Air ventilation and

temperature depend on the settings

of the climate control system. The air

vent in the glovebox can be closed

3 113.

Other versions may have a CD player

in the glovebox.

The glovebox should be closed whilst

driving.

Cupholders

Cupholders are located in the centre

console.

Storage 55

Additional cupholders are located in

the rear armrest. Fold down armrest.

Centre console storage

The storage container can be used to

store small items.

Depending on the version, the

storage compartment is located

under a cover.

Load compartment

The rear seat backrest is divided into

2/3 to 1/3 parts. Both parts can be

folded down individually to increase

the size of the load compartment.

Before folding rear seat backrests,

execute the following if necessary:

● Move front seats forward if

necessary.

● Remove the load compartment

cover.

● Press and hold the catch to push

the head restraints down.

Load compartment cover 3 57.

Head restraints 3 30

Load compartment extension

● Check that the outer seat belts

are lying correctly on the

backrests.

56 Storage

● Pull the release lever on one or

both outer sides and fold down

the backrests onto the seat

cushion.

● Alternatively fold seat backrests

from the load compartment: pull

switch on left or right sidewall of

the load compartment to fold the

corresponding part of the rear

seat backrest.

9Warning

Take care when operating the rear

backrests from the load

compartment. The backrest is

folded with considerable power.

Risk of injury, particularly to

children.

Ensure that nothing is attached to

the rear seats or located on the

seat cushion.

● To fold up, raise the backrests

and guide them into an upright

position until they engage

audibly.

9Warning

When folding up, ensure that

backrests are securely locked in

position before driving. Failure to

do so may result in personal injury

or damage to the load or vehicle in

the event of hard braking or a

collision.

Storage 57

Opening the pass through in the

centre backrest

Fold down the rear armrest.

Pull grip and open the cover.

Suitable for loading long, narrow

objects.

Load compartment cover

Do not place any objects on the cover.

Removing cover

Unhook retaining straps from tailgate.

Lift cover at the rear and push it

upwards at the front.

Remove the cover.

Fitting cover

Engage cover in side guides and fold

downwards. Attach the retaining

straps to the tailgate.

58 Storage

Rear floor storage cover

The rear floor cover can be lifted and

removed. Raise cover at the loop and

remove.

To hold the load compartment cover

in an upright positon, lift it up past the

retractable stops.

Double load floor

The double load floor can be inserted

in the load compartment in two

positions:

● lower position above the spare

wheel well cover

● upper position interlocked with

the grab handle into back panel

trim

To remove, press the handle to

unlock the load floor and lift it up while

using the handle.

If mounted in the upper position, the

space between the load floor and the

spare wheel well cover can be used

as a storage compartment.

In this position, if the rear seat

backrests are folded forwards, an

almost completely flat load bay is

created.

In the upper position, the double load

floor is able to withstand a maximum

load of 100 kg. In the lower position,

the double load floor is able to

withstand the maximum load of

150 kg.

Storage 59

Lashing eyes

The lashing eyes are designed to

secure items against slippage, e.g.

using lashing straps or luggage net.

Safety net

The safety net can be installed behind

the rear seats or, if the rear seat

backrests are folded, behind the front

seats.

Passengers must not be transported

behind the safety net.

Installation

Behind the rear seats

● There are installation openings

on both sides in the roof frame

above the rear seats: suspend

and engage rod of net at one

side, compress rod and suspend

and engage at the other side.

● Attach the hooks of safety net

straps in the lashing eyes behind

the rear seats.

● Tension both straps by pulling at

the loose end.

● Rear seat backrests must be

raised up.

60 Storage

Behind the front seats

● There are installation openings

on both sides in the roof frame

above the front seats: suspend

and engage rod of net at one

side, compress rod and suspend

and engage at the other side.

● Attach hooks of safety net straps

to the lashing eyes at the lower

area of the rear seats.

● Tension both straps by pulling at

the loose end.

● Push down head restraints and

fold down rear seat backrests

3 55.

Depending on version, the hooks of

the safety net straps are attached to

the lashing eyes on the backside of

the rear seats.

● Push down head restraints and

fold down rear seat backrests.

● Attach the hooks of safety net

straps to the lashing eyes on the

backside of the rear sets.

● Tension both straps by pulling at

the loose end.

Storage 61

Removal

Pull the flap at the tightener on both

sides to release the straps. Detach

hooks from the lashing eyes.

Unhook the safety net rods from the

installation openings in the roof

frame.

Roll up the net and secure with a

strap.

Warning triangle

Stow the warning triangle in the space

on the inside of the tailgate and

secure it with the Velcro® fastener.

Depending on version, the warning

triangle may be stowed below the rear

floor cover of the load compartment.

First aid kit

Stow the first aid kit in the storage

compartment on the right side of the

load compartment.

Depending on version, the first aid kit

may be stowed below the rear floor

cover of the load compartment.

62 Storage

Roof rack system

Roof rack

For safety reasons and to avoid

damage to the roof, the vehicle-

approved roof rack system is

recommended.

Follow the installation instructions

and remove the roof rack when not in

use.

Vehicles with roof railing

Fasten the roof rack in the roof railing

above the mounting points located in

each door frame of the vehicle body.

Vehicles without roof railing

Open all doors.

Mounting points are located in each

door frame of the vehicle body.

Detach the cover from each mounting

point and fasten the roof rack with the

attached screws.

Loading information

● Heavy objects in the load

compartment should be placed

against the seat backrests. Make

sure that the backrests are

securely engaged. If objects can

be stacked, heavier objects

should be placed at the bottom.

● Prevent sliding of loose objects

by securing them with straps

attached to the lashing eyes

3 59.

● Do not allow the load to protrude

above the upper edge of the

backrests.

Storage 63

● Do not place any objects on the

load compartment cover or the

instrument panel, and do not

cover the sensor on top of the

instrument panel.

● The load must not obstruct the

operation of the pedals, parking

brake and gear selector, or

hinder the freedom of movement

of the driver. Do not place any

unsecured objects in the interior.

● Do not drive with an open load

compartment.

9Warning

Always make sure that the load in

the vehicle is securely stowed.

Otherwise objects can be thrown

around inside the vehicle and

cause personal injury or damage

to the load or car.

● The payload is the difference

between the permitted gross

vehicle weight (see identification

plate 3 247) and the EC kerb

weight.

To calculate the payload, enter

the data for your vehicle in the

weights table at the front of this

manual.

The EC kerb weight includes

weights for the driver (68 kg),

luggage (7 kg) and all fluids (fuel

tank 90% full).

Optional equipment and

accessories increase the kerb

weight.

● Driving with a roof load increases

the sensitivity of the vehicle to

cross-winds and has a

detrimental effect on vehicle

handling due to the vehicle's

higher centre of gravity.

Distribute the load evenly and

secure it properly with retaining

straps. Adjust the tyre pressure

and vehicle speed according to

the load conditions. Check and

retighten the straps frequently.

Do not drive faster than 75 mph.

The permissible roof load is

85 kg. The roof load is the

combined weight of the roof rack

and the load.

64 Instruments and controls

Instruments and

controls

Instrument panel overview ........... 66

Controls ....................................... 68

Steering wheel adjustment ........ 68

Steering wheel controls ............. 68

Heated steering wheel ............... 68

Horn ........................................... 69

Pedestrian safety alert ............... 69

Windscreen wiper and washer ..69

Rear window wiper and

washer ...................................... 71

Outside temperature .................. 71

Clock ......................................... 72

Power outlets ............................. 72

Inductive charging ..................... 73

Cigarette lighter ......................... 74

Ashtrays .................................... 74

Warning lights, gauges and indi‐

cators ........................................... 75

Speedometer ............................. 75

Odometer .................................. 75

Tachometer ............................... 75

Fuel gauge ................................ 76

Battery gauge ............................ 76

Power indicator gauge ............... 76

Engine coolant temperature

gauge ....................................... 77

Engine oil level monitor ............. 77

Service display .......................... 77

Control indicators ...................... 78

Turn lights .................................. 80

Seat belt reminder ..................... 80

Airbag and belt tensioners ......... 80

Airbag deactivation .................... 81

Charging system ....................... 81

Malfunction indicator light .......... 81

Service vehicle soon ................. 81

Stop engine ............................... 81

System check ............................ 82

Hybrid system active ................. 82

Hybrid system fault .................... 82

Brake and clutch system ........... 82

Electric parking brake ................ 82

Electric parking brake fault ........ 82

Automatic operation of electric

parking brake off ....................... 83

Antilock brake system (ABS) ..... 83

Gear shifting .............................. 83

Lane departure warning ............ 83

Lane keep assist ....................... 83

Advanced lane keep assist ........ 83

Electronic Stability Control and

Traction Control system ........... 84

Electronic Stability Control and

Traction Control system off ...... 84

Engine coolant temperature ...... 84

Preheating ................................. 84

Exhaust filter .............................. 84

AdBlue ....................................... 85

Deflation detection system ........ 85

Engine oil pressure .................... 85

Low fuel ..................................... 85

Charge cord connected ............. 85

Reduced engine power ............. 86

Autostop .................................... 86

Exterior light .............................. 86

Low beam .................................. 86

High beam ................................. 86

High beam assist ....................... 86

LED headlights .......................... 86

Front fog lights ........................... 86

Rear fog light ............................. 86

Rain sensor ............................... 86

Night vision ................................ 86

Pedestrian safety alert fault ....... 87

Side blind spot alert ................... 87

Active emergency braking ......... 87

Door open .................................. 87

Displays ....................................... 87

Driver Information Centre .......... 87

Info Display ................................ 88

Vehicle messages ........................ 91

Warning chimes ......................... 92

Vehicle personalisation ................ 92

Instruments and controls 65

Telematics services ..................... 93

Vauxhall Connect ...................... 93

Emergency call .......................... 93

ERA GLONASS ......................... 94

66 Instruments and controls

Instrument panel overview

Instruments and controls 67

1Power windows ..................... 25

2Exterior mirrors ..................... 22

3Side air vents ...................... 113

4Turn lights, headlight

flash, low / high beam,

high beam assist ................. 101

Exit lighting ......................... 105

Parking lights ...................... 102

Buttons for Driver

Information Centre ................ 87

5Cruise control ..................... 145

Adaptive cruise control ....... 149

Speed limiter ....................... 147

Heated steering wheel .......... 68

6Instruments ........................... 75

Driver Information Centre ...... 87

7Infotainment controls

8Windscreen wiper and

washer, rear wiper and

washer ................................. 69

9Power button ....................... 117

10 Central locking system ............ 9

11 Controls for Info Display

operation .............................. 88

12 Hazard warning flashers .... 101

13 Air vents ............................. 113

14 Vauxhall Connect ................. 93

15 Inclination sensor ................. 20

16 Reading lights .................... 104

17 Interior lights ...................... 103

18 Seat belt reminder ................ 37

Airbag deactivation .............. 45

19 Interior mirror ....................... 24

20 Glovebox .............................. 54

21 Centre air vents .................. 113

22 Climate control system ........ 106

23 USB charging port ................ 72

24 Power outlet .......................... 72

25 Parking assist, advanced

parking assist ..................... 160

Lane departure warning ..... 175

Eco button for stop-start

system ................................. 120

Electronic Stability Control

and Traction Control ........... 142

Sport mode ......................... 144

26 Manual transmission .......... 135

Automatic transmission ...... 131

27 Electric parking brake ......... 138

28 Selective ride control .......... 143

29 Ignition switch ..................... 116

30 Steering wheel adjustment ..68

31 Horn ..................................... 69

32 Bonnet release lever .......... 206

33 Instrument panel fuse box . 218

34 Light switch .......................... 96

Headlight range

adjustment ........................... 98

Front / rear fog lights .......... 102

Instrument illumination ....... 103

68 Instruments and controls

Controls

Steering wheel adjustment

Unlock lever, adjust steering wheel,

then engage lever and ensure it is

fully locked.

Do not adjust steering wheel unless

vehicle is stationary and steering

wheel lock has been released.

Steering wheel controls

Some driver assistance systems,

Infotainment system and a connected

mobile phone can be operated via the

controls on the steering wheel.

Further information is available in the

Infotainment manual.

Cruise control 3 145.

Speed limiter 3 147.

Adaptive cruise control 3 149.

Heated steering wheel

Activate heating by pressing *.

Activation is indicated by the LED in

the button.

Heating is operational when the

engine is running and during an

Autostop.

Stop-start system 3 120.

Instruments and controls 69

Horn

Press j.

Pedestrian safety alert

The sound of the pedestrian safety

alert is generated to indicate the

vehicle presence to pedestrians when

combustion engine is off. It is active

up to 12 mph.

Windscreen wiper and

washer

Windscreen wiper with adjustable

wiper frequency

HI : fast

LO : slow

INT : interval wiping

OFF : off

For a single wipe when the

windscreen wiper is off, press the

lever down to position 1x.

Do not use if the windscreen is frozen.

Switch off in car washes.

To activate interval wiping mode the

next time ignition is switched on,

press the lever downwards to position

OFF and back to INT.

Adjustable wiper frequency

Wiper lever in position INT.

Turn the adjuster wheel to adjust the

desired wipe frequency.

70 Instruments and controls

Windscreen wiper with rain sensor

HI : fast

LO : slow

AUTO : automatic wiping with rain

sensor

OFF : off

In AUTO position, the rain sensor

detects the amount of water on the

windscreen and automatically

regulates the frequency of the

windscreen wiper. If ignition is

switched off, automatic wiping mode

is deactivated. To activate automatic

wiping mode the next time ignition is

switched on, press the lever

downwards to position OFF and back

to AUTO.

For a single wipe when the

windscreen wiper is off, press the

lever downwards to position 1x.

Do not use if the windscreen is frozen.

Switch off in car washes.

Adjustable sensitivity of the rain

sensor

Turn the adjuster wheel to adjust the

sensitivity.

Make sure the sensor is not blocked

3 25.

Control indicator < 3 69.

Windscreen washer

Pull lever. Washer fluid is sprayed

onto the windscreen and the wiper

wipes a few times.

Washer fluid 3 208.

Instruments and controls 71

Rear window wiper and

washer

Rear window wiper

OFF : off

INT : intermittent operation

ON : continuous operation

Do not use if the rear window is

frozen.

Switch off in car washes.

The rear window wiper comes on

automatically when the windscreen

wiper is switched on and reverse gear

is engaged.

Activation or deactivation of this

function can be changed in the Info

Display 3 88.

Rear window washer

Push lever.

Washer fluid is sprayed onto the rear

window and the wiper wipes a few

times.

The rear window washer system is

deactivated when the fluid level is

low.

Washer fluid 3 208.

Outside temperature

A drop in temperature is indicated

immediately and a rise in temperature

after a time delay.

Illustration shows an example.

If outside temperature drops to 3 °C,

a warning message is displayed in the

Driver Information Centre.

9Warning

The road surface may already be

icy even though the display

indicates a few degrees above 0

°C.

72 Instruments and controls

Clock

Date and time are shown in the Info

Display.

The adjustment of date and time is

described in the Infotainment Manual.

Info Display 3 88.

Power outlets

A 12 V power outlet is located behind

the storage cover. Press cover to

open.

A 12 V power outlets is also located

in the rear console.

At the left sidewall in the load

compartment, another 12 V power

outlet is located.

Do not exceed the maximum power

consumption of 120 W.

A 230 V power outlet may also be

located in the rear console.

Do not exceed the maximum power

consumption of 150 W.

With ignition off, the power outlets are

deactivated. Additionally the power

outlets are deactivated in the event of

low vehicle battery voltage.

Instruments and controls 73

Electrical accessories that are

connected must comply with the

electromagnetic compatibility

requirements laid down in

DIN VDE 40 839.

Do not connect any current-delivering

accessories, e.g. electrical charging

devices or batteries.

Do not damage the outlet by using

unsuitable plugs.

Stop-start system 3 120.

USB ports

A USB port is located behind the

storage cover. Press cover to open.

A further USB port may be located in

the rear console.

The USB ports are prepared for

charging external devices and

provide a data connection to the

Infotainment system. For further

information, see Infotainment

manual.

Notice

The sockets must always be kept

clean and dry.

Inductive charging

9Warning

Inductive charging can affect the

operation of implanted

pacemakers or other medical

devices. If applicable, seek

medical advice before using the

inductive charging device.

9Warning

Remove any metal objects from

the charging device before

charging a mobile device, as these

objects could become very hot.

74 Instruments and controls

To charge a device, the ignition must

be switched on.

To charge a mobile device:

1. Remove all objects from the

charging device.

2. Place the mobile device with the

display facing upwards on the

charging device in the storage.

Use the elastic band to secure the

mobile device.

Charging status is indicated in the

LED: illuminates green, when mobile

device is charging.

PMA or Qi compatible mobile devices

can be charged inductively.

On some mobile devices, a back

cover with an integrated coil or a

jacket may be required to use

inductive charging.

Protective cover for the mobile device

could have impact on the inductive

charging.

In the event that the mobile device is

not charging properly, rotate it 180°

and place it on the charging device

again.

Cigarette lighter

The cigarette lighter is located behind

the storage cover. Press cover to

open.

Press in cigarette lighter. It switches

off automatically once the element is

glowing. Pull out cigarette lighter.

Ashtrays

Caution

To be used only for ash and not for

combustible rubbish.

A portable ashtray can be placed in

the cupholders.

Instruments and controls 75

Warning lights, gauges

and indicators

Speedometer

Indicates vehicle speed.

Odometer

The total recorded distance is

displayed in miles.

Tachometer

Displays the engine speed.

Drive in a low engine speed range for

each gear as much as possible.

A red marker indicates the beginning

of the warning zone of excessive

revolutions. For Diesel engines, the

warning zone starts at 5000

revolutions per minute. For petrol

engines, the warning zone starts at

7000 revolutions per minute.

76 Instruments and controls

Caution

If the needle is in the red warning

zone, the maximum permitted

engine speed is exceeded. Engine

at risk.

Fuel gauge

Control indicator r illuminates if the

fuel level is low.

Never run the fuel tank dry.

The top-up quantity may be less than

the specified fuel tank capacity, due

to the remaining fuel in the tank.

Battery gauge

The battery gauge displays the high

voltage battery state of charge.

Power indicator gauge

The power indicator gauge informs

about the current energy situation of

the vehicle.

Charge : Battery is being charged

with energy resulting from

braking or deceleration of

the vehicle

Eco : An optimum in energy is

accessible in all driving

modes

Power : Vehicle is driven in a

dynamic driving style with

focus on performance

Instruments and controls 77

Engine coolant temperature

gauge

Displays the coolant temperature.

grey marking /

90 : normal operating

temperature

red marking : temperature too

high

Control indicator o illuminates if

coolant temperature is too high.

Switch off engine immediately.

Caution

If engine coolant temperature is

too high, stop vehicle, switch off

engine. Danger to engine. Check

coolant level.

Engine oil level monitor

The state of the engine oil level is

displayed in the Driver Information

Centre for a few seconds following

the service information after switching

on the ignition.

A proper state of engine oil level is

indicated by a message.

If engine oil level is low, I flashes

and a message is indicated,

accompanied by the C indicator.

Confirm engine oil level by using the

dipstick and top up engine oil

respectively.

Engine oil 3 207.

A fault of measurement is indicated

by a message. Check engine oil level

manually by using the dipstick.

Service display

The service system informs when to

change the engine oil and filter or a

vehicle service is required. Based on

driving conditions, the interval at

which an engine oil and filter change

is required can vary considerably.

Service information 3 241.

If service is required within the next

1800 miles, the remaining distance or

time duration is indicated for several

seconds. Simultaneously C

illuminates permanently as reminder.

If service is required in less than

600 miles, C flashes and then

illuminates permanently. Remaining

distance or time duration is indicated

for several seconds.

Overdued service is indicated by a

message in the Driver Information

Centre which indicates the overdued

distance. C flashes and then

illuminates permanently until service

is executed.

Reset of service interval

After each service, the service

indicator must be reset to ensure

proper functionality. It is

recommended to seek the assistance

of a workshop.

If service is executed by yourself,

operate as following:

● switch off ignition

78 Instruments and controls

● press and SET / CLR

● switch on ignition, the distance

indication begins a countdown

● when the display indicates =0,

release SET / CLR

The symbol C disappears.

Retrieving service information

The status of the service information

can be retrieved at any time via the

Info Display. Press Check in the

vehicle settings menu. The service

information is displayed for a few

seconds.

Info Display 3 88.

Service information 3 241.

Control indicators

The control indicators described are

not present in all vehicles. The

description applies to all instrument

versions. Depending on the

equipment, the position of the control

indicators may vary. When the

ignition is switched on, most control

indicators will illuminate briefly as a

functionality test.

The control indicator colours mean:

red : danger, important reminder

yellow : warning, information, fault

green : confirmation of activation

blue : confirmation of activation

white : confirmation of activation

grey : system paused, at least one

system limitation has been

detected

Control indicators are located in the

Driver Information Centre.

Driver Information Centre 3 87.

Overview

The numbers in the overview table

indicate what to do, when a control

indicator illuminates or flashes.

1 : only for information

2 : information and warning

3 : seek the assistance of a

workshop

4 : stop engine and seek the

assistance of a workshop

5 : have the cause of the fault

remedied immediately by a

workshop

6 : stop vehicle, do not continue the

journey and seek the assistance

of a workshop

O1 Turn lights 3 80

X2 Seat belt reminder

3 80

v5 Airbag and belt

tensioners 3 80

V1 Airbag deactivation

3 81

p4 Charging system

3 81

Z5 Malfunction indicator

light 3 81

Instruments and controls 79

C5 Service vehicle soon

3 81

STOP 6 Stop engine 3 81

J4 System check 3 82

R6 Brake and clutch

system 3 82

1 /

2 /

Electric parking brake

3 82, automatic

operation of electric

parking brake off

3 83

E5 Electric parking brake

fault 3 82

u2 Antilock brake system

(ABS) 3 83

R1 Gear shifting 3 83

)1 Lane departure

warning 3 83

L2 Lane keep assist

3 83

O2 Advanced lane keep

assist 3 83

b2 /

5Electronic Stability

Control and Traction

Control system 3 84

W o4 Engine coolant temper‐

ature high 3 84

!1 Preheating 3 84

%2 /

3Exhaust filter 3 84

Y1 AdBlue 3 85

w2 /

3Deflation detection

system 3 85

I4 Engine oil pressure

3 85

Y2 Low fuel 3 85

D1 Autostop 3 86

81 Exterior light 3 86

91 Low beam 3 86

C1 High beam 3 86

f1 High beam assist

3 86

>1 Front fog lights 3 86

ø1 Rear fog light 3 86

<1 Rain sensor 3 86

B1 Side blind spot alert

3 87

Ø2 /

3Active emergency

braking 3 87

h2 Door open 3 87

i5 Hybrid system fault

3 82

READY 1 Hybrid system active

3 82

M2 Reduced engine power

3 86

K3 Pedestrian safety alert

fault 3 87

j2 Charging cable

connected 3 85

92 Electronic Stability

Control and Traction

Control system off

3 84

80 Instruments and controls

Turn lights

O illuminates or flashes green.

Illuminates briefly

The parking lights are switched on.

Flashes

Turn lights or the hazard warning

flashers are activated.

Rapid flashing: failure of a turn light or

associated fuse, failure of turn light on

trailer.

Bulb replacement 3 212.

Turn lights 3 101.

Seat belt reminder

Seat belt reminder on all seats

X illuminates or flashes red in the

Driver Information Centre together

with the indication in the roof console

for each seat belt.

● When the ignition is switched on,

X in the Driver Information

Centre and the symbol for the

respective seat in the roof

console comes on, if the seat belt

of any occupied seat has not

been fastened.

●After driving off, X in the Driver

Information Centre and the

symbol for the respective seat in

the roof console flashes for a

certain time together with a

chime. After a certain time of

driving X illuminates constantly

until the seat belt of the

respective seat has been

fastened or if any passenger has

unfastened the seat belt.

Seat belts 3 37.

Airbag and belt tensioners

v illuminates red.

When the ignition is switched on, the

control indicator illuminates for

approx. 4 seconds.

If it does not illuminate, does not

extinguish after 4 seconds or

illuminates whilst driving, there is a

fault in the airbag system. Seek the

assistance of a workshop. The

airbags and belt pretensioners may

fail to trigger in the event of an

accident.

Deployment of the belt pretensioners

or airbags is indicated by continuous

illumination of v.

9Warning

Have the cause of the fault

remedied immediately by a

workshop.

Instruments and controls 81

Belt pretensioners 3 37.

Airbag system 3 40.

Airbag deactivation

ÓON illuminates yellow.

The front passenger airbag is

activated.

*OFF illuminates yellow.

The front passenger airbag is

deactivated.

Airbag deactivation 3 45.

Charging system

p illuminates red.

Illuminates when the ignition is

switched on and extinguishes shortly

after the engine starts.

Illuminates when the engine is

running

Stop, switch off engine. Vehicle

battery is not charging. Engine

cooling may be interrupted. The

brake servo unit may cease to be

effective. Seek the assistance of a

workshop.

Malfunction indicator light

Z illuminates or flashes yellow.

Illuminates when the ignition is

switched on and extinguishes shortly

after the engine starts.

Illuminates when the engine is

running

Fault in the emission control system.

The permitted emission limits may be

exceeded. Seek the assistance of a

workshop immediately.

Flashes when the engine is

running

Fault that could lead to catalytic

converter damage. Ease up on the

accelerator until the flashing stops.

Seek the assistance of a workshop

immediately.

Service vehicle soon

C illuminates yellow.

Illuminates briefly when the ignition is

switched on.

May illuminate together with other

control indicators and a

corresponding message in the Driver

Information Centre.

Seek the assistance of a workshop

immediately.

Stop engine

STOP illuminates red.

Illuminates briefly when the ignition is

switched on.

82 Instruments and controls

Illuminates together with other control

indicators, accompanied by a warning

chime and a corresponding message

in the Driver Information Centre.

Stop engine immediately and seek

the assistance of a workshop.

System check

J illuminates yellow or red.

Illuminates yellow

A minor engine fault has been

detected.

Illuminates red

A major engine fault has been

detected.

Stop engine as soon as possible and

seek the assistance of a workshop.

Hybrid system active

READY illuminates green. The hybrid

system ist active.

Hybrid system fault

i illuminates red.

The hybrid system has a fault.

Switch off ignition and seek the

assistance of a workshop.

Brake and clutch system

R illuminates red.

The brake and clutch fluid level is too

low.

9Warning

Stop. Do not continue your

journey. Consult a workshop.

Brake fluid 3 209.

Electric parking brake

m illuminates or flashes red.

Illuminates

Electric parking brake is applied

3 138.

Flashes

Electric parking brake is not applied

automatically. The application or the

release are faulty.

9Warning

Have the cause of the fault

remedied immediately by a

workshop.

o illuminates yellow.

Illuminates

Automatic operation is deactivated or

faulty. Activate automatic operation

again or have the cause remedied by

a workshop in the event of a fault.

Automatic operation 3 138.

Electric parking brake fault

E illuminates yellow.

Illuminates

Electric parking brake has a fault

3 138.

9Warning

Have the cause of the fault

remedied immediately by a

workshop.

Instruments and controls 83

Automatic operation of

electric parking brake off

o illuminates yellow.

Illuminates

Automatic operation is deactivated or

faulty. In the event of a fault, o

illuminates together with other control

indicators or it is accompanied by a

corresponding message in the Driver

Information Centre.

Activate automatic operation again or

have the cause remedied by a

workshop in the event of a fault.

Automatic operation 3 138.

Antilock brake system

(ABS)

u illuminates yellow.

Illuminates for a few seconds after the

ignition is switched on. The system is

ready for operation when the control

indicator extinguishes.

If the control indicator does not

extinguish after a few seconds, or if it

illuminates while driving, there is a

fault in the ABS. The brake system

remains operational but without ABS

regulation.

Antilock brake system 3 138.

Gear shifting

R with the number of a higher gear is

indicated, when upshifting is

recommended for fuel saving

reasons.

Lane departure warning

) illuminates green or flashes yellow.

Illuminates green

System is switched on and ready to

operate.

Flashes yellow

System recognises an unintended

lane change.

Lane departure warning 3 175.

Lane keep assist

a illuminates or flashes yellow.

Illuminates yellow

Together with C when a fault has

been detected.

Flashes yellow

The system performs a correction.

Lane keep assist 3 177.

Advanced lane keep assist

O illuminates grey, green or yellow.

Illuminates grey

The system is paused. At least one

system limitation has been detected.

Illuminates green

The system is active and ready to

operate.

Illuminates yellow

The system has a fault.

Advanced lane keep assist 3 179.

84 Instruments and controls

Electronic Stability Control

and Traction Control system

b illuminates or flashes yellow.

Illuminates

A fault in the system is present.

Continued driving is possible. Driving

stability, however, may deteriorate

depending on road surface

conditions.

Have the cause of the fault remedied

by a workshop.

Flashes

The system is actively engaged.

Engine output may be reduced and

the vehicle may be braked

automatically to a small degree.

Electronic Stability Control and

Traction Control system 3 142.

Selective ride control 3 143.

Electronic Stability Control

and Traction Control system

off

9 illuminates yellow. The system has

been deactivated.

Electronic Stability Control and

Traction Control system 3 142.

Selective ride control 3 143.

Engine coolant temperature

o illuminates red.

Illuminates when the engine is

running

Stop, switch off engine.

Caution

Coolant temperature too high.

Check coolant level immediately

3 208.

If there is sufficient coolant, consult a

workshop.

Preheating

! illuminates yellow.

Preheating of diesel engine is

activated. Only activates when

outside temperature is low. Start the

engine when control indicator

extinguishes.

Starting the engine 3 118.

Exhaust filter

% or C illuminates yellow.

The exhaust filter requires cleaning.

Continue driving until the control

indicator extinguishes.

Illuminates temporarily

Start of saturation of the exhaust filter.

Start cleaning process as soon as

possible by driving at a vehicle speed

of at least 40 mph.

Illuminates constantly

Indication of a low additive level. Seek

the assistance of a workshop.

Exhaust filter 3 123.

86 Instruments and controls

The vehicle plug of the charge cord is

still connected to the charge port. The

vehicle cannot be started.

Disconnect the vehicle plug from the

charge port and close the charge port

door.

Charging 3 187.

Reduced engine power

M illuminates yellow.

The charging level of the high voltage

battery is low. Only reduced engine

power is available.

Autostop

D illuminates or flashes green.

Illuminates green

Engine is in an Autostop.

Flashes green

Autostop is temporarily unavailable,

or Autostop mode is invoked

automatically.

Stop-start system 3 120.

Exterior light

8 illuminates green.

The exterior lights are on 3 96.

Low beam

9 illuminates green.

Illuminated when low beam is on.

High beam

C illuminates blue.

Illuminates when high beam is on,

during headlight flash 3 97.

High beam assist

f illuminates green.

The high beam assist is activated

3 97.

LED headlights

C illuminates and a warning

message is displayed in the Driver

Information Centre.

Seek the assistance of a workshop.

Front fog lights

> illuminates green.

The front fog lights are on 3 102.

Rear fog light

r illuminates yellow.

The rear fog light is on 3 102.

Rain sensor

< illuminates green.

Illuminated when rain sensor position

on wiper lever is selected.

Windscreen wiper and washer 3 69.

Night vision

B illuminates green or red.

If the conditions are met to display the

image provided by the night vision

camera and to trigger alerts, B

illuminates green.

If some operation conditions are not

met and only the image provided by

the night vision camera is available,

B illuminates orange.

Instruments and controls 91

3. Select the distance for which

electrical is to be reserved or

reserve the whole capacity of the

high voltage battery.

4. Press ON.

5. To use the reserved electrical

energy change to electric mode.

The setting of this function is not

stored when the ignition is switched

off.

Smartphone app

With the myVauxhall smartphone

app, some vehicle functions can be

operated / displayed.

To operate these functions, download

the app from Apple App Store or

Google Play Store.

Vehicle messages

Messages are indicated in the Driver

Information Centre, in some cases

together with a warning chime.

Press SET / CLR to confirm a

message.

Vehicle and service messages

The vehicle messages are displayed

as text. Follow the instructions given

in the messages.

94 Instruments and controls

Notice

The service is only available for

markets where it is legally required.

Furthermore, it depends on the

availability of the emergency centres

and the infrastructure in the country.

Status LED in the overhead

console

Illuminates green and red and

extinguishes after a short time, when

the ignition is switched on: the system

works properly.

Illuminates red: fault in the system.

Contact a workshop.

Flashes red: backup battery needs

replacement. Contact a workshop.

Emergency call

The emergency call function will

establish a connection to the nearest

public safety answering point (PSAP).

A minimum set of data including

vehicle and location information will

be sent to the PSAP.

In case of an emergency, press the

red SOS button in the overhead

console for more than 2 seconds. The

LED flashes green to confirm that a

connection to the nearest PSAP is

being established. The LED

illuminates steadily as long as the call

is active.

Pressing the SOS button immediately

a second time will terminate the call.

The LED switches off.

Automatic crash notification

In case of an accident with airbag

deployment and without damage of

needed hardware, an automatic

emergency call is established and an

automatic crash notification will be

transmitted to the next PSAP.

ERA GLONASS

ERA GLONASS is a manually or

automatically actuated emergency

service. Emergency centres provide

assistance and information during an

emergency.

In case of an accident with an impact

of appropriate severity, an

emergency call is placed

automatically, regardless of airbag

activation. An immediate connection

with an advisor will be established

who will check whether help is

needed.

9Danger

The service is only available for

markets where it is legally required

and activated. Furthermore, the

manual and the automatic

emergency call function depend

on the availability of the

emergency centres and the

infrastructure in the country.

Notice

In order to be available and

operational, the system requires

functioning vehicle electrics, mobile

service and GLONASS satellite link.

Depending on equipment, a backup

battery is used.

Instruments and controls 95

Control buttons

SOS button

In an emergency situation press and

hold SOS button for more than 2

seconds.The green LED and the

voice message will confirm that the

call has been sent to the emergency

centre.

The green LED illuminates when the

service connection is established. It

will go out when the connection is

complete.

A minimum set of data is transferred

to the emergency centre, including

such data as car location, car model,

vehicle identification number. The

operator will contact you and, if

necessary, send rescue workers from

the relevant support services.

To cancel the call, press the SOS

button again. The green LED goes

out. The voice message confirms the

cancellation.

Status LED

The system provides feedback via

voice messages and an LED.

Green : The system is activated. A

connection to an operator

is on duty.

Red : The system is booting up

after switching on ignition,

the LED goes out after 3

seconds. If the LED stays

red, a malfunction has

been detected in the

system. An emergency

call may not work. Contact

a workshop immediately.

Red

flashing : The internal backup

battery is defective.

Contact a workshop

immediately.

Seek the assistance of a workshop if

the LED does not illuminate after

switching on the ignition.

96 Lighting

Lighting

Exterior lighting ............................ 96

Light switch ................................ 96

Automatic light control ............... 97

High beam ................................. 97

High beam assist ....................... 97

Headlight flash ........................... 98

Headlight range adjustment ...... 98

Headlights when driving

abroad ...................................... 99

Daytime running lights ............... 99

Matrix-LED headlights ............... 99

Hazard warning flashers .......... 101

Turn lights ................................ 101

Front fog lights ......................... 102

Rear fog light ........................... 102

Parking lights ........................... 102

Reversing lights ....................... 103

Misted light covers ................... 103

Interior lighting ........................... 103

Instrument panel illumination

control ..................................... 103

Interior lights ............................ 103

Reading lights .......................... 104

Sunvisor lights ......................... 104

Lighting features ........................ 104

Centre console lighting ............ 104

Entry lighting ............................ 104

Exit lighting .............................. 105

Battery discharge protection .... 105

Exterior lighting

Light switch

Turn light switch:

AUTO : automatic light control

switches automatically

between daytime running

light and headlight

8: sidelights

9: headlights

Control indicator 8 3 86.

Lighting 99

Headlights when driving

abroad

No matrix-LED headlights

When driving in countries where

traffic drives on the opposite side of

the road, the headlights do not have

to be adjusted.

Matrix-LED headlights

When driving in countries where

traffic drives on the opposite side of

the road, the headlights have to be

adjusted.

1. With the engine switched off, pull

the indicator lever and hold.

2. Start the engine.

3. Hold the indicator lever for

another 5 seconds.

4. Release the indicator lever.

After the setting has been changed,

an animation is displayed in the Driver

Information Centre to indicate the

change of the light distribution.

If the headlights are adjusted, a

message is displayed in the Driver

Information Centre each time the

engine is started.

The adjustment of the headlights is

kept until it is reversed by the driver.

To reverse the adjustment, repeat the

steps described above.

Daytime running lights

Daytime running lights increase

visibility of the vehicle during daylight.

They are switched on automatically

when the engine is running and the

light switch is set to AUTO.

The system switches between

daytime running lights and low beam

automatically, depending on the

lighting conditions.

Matrix-LED headlights

The Matrix-LED headlight system

contains a variety of particular LEDs

in each headlight which enables the

control of the adaptive forward

lighting functions.

Light distribution and intensity of light

are variably triggered depending on

the lighting conditions, road type and

driving situation. The vehicle adapts

the headlights automatically to the

situation to enable optimal light

performance for the driver.

The adaptive forward lighting and the

Matrix-LED headlights functions can

be deactivated or activated in the Info

Display and by switching off or on the

automatic light control.

Info Display 3 88.

The following functions are available

if the adaptive forward lighting is

activated in the Info Display and the

light switch is in AUTO or 9.

Town light

Activated automatically at a speed up

to approx. 31 mph. The beam has a

broad shape to avoid glaring

oncoming traffic.

100 Lighting

Country light

Activated automatically at a speed

above 30 mph when driving in rural

areas. The illumination of the current

lane and the side of the road is

adapted. Oncoming and preceding

vehicles are not dazzled.

Adverse weather light

If bad weather conditions are

detected, low beam is dimmed to

avoid dazzling the oncoming traffic.

Cornering light

Activated at a speed of up to approx.

25 mph when turning off. Depending

on the steering wheel angle and the

turn lights, a particular LED light

function is triggered which illuminates

the direction of travel.

Curve light

Particular LEDs, based on steering

angle and speed, are additionally

triggered to improve lighting in

curves. This function is activated at a

speed up to approx. 43 mph.

Reverse parking function

To assist driver's orientation when

parking, cornering lights and

reversing light illuminate when

headlights are activated and reverse

gear is engaged. Cornering light and

reversing light remain illuminated for

a short time after disengaging the

reverse gear, or when accelerating to

a speed above approx. 6 mph.

Glare-free high beam

This feature allows high to function as

main driving light in dark

surroundings.

Each LED on right or left side is

triggered or faded out particularly

according to the traffic situation. This

gives the best light distribution

without dazzling other road users.

Lighting 101

Glare-free high beam is switched on

automatically at a speed above

28 mph. It is switched off at a speed

below 22 mph, but the system

remains active.

Motorway mode

Activated automatically at a speed

above 65 mph. Illumination is

adapted to the higher speed driven on

motorways. If there is no oncoming

traffic, the visibility on the side of the

vehicle is increased. When following

vehicles ahead or passing, dazzling

for these vehicles is reduced.

Fault

When the system detects a failure in

the matrix-LED headlight system, it

selects a preset position to avoid

dazzling of oncoming traffic. A

warning is displayed in the Driver

Information Centre.

Hazard warning flashers

Operated by pressing ¨.

When braking in an emergency, the

hazard warning flashers are switched

on automatically depending on the

force of deceleration. They are

switched off automatically the first

time you accelerate.

Turn lights

up : right turn lights

down : left turn lights

A resistance point can be felt when

moving the indicator lever.

Constant flashing is activated when

the indicator lever is being moved

beyond the resistance point. It is

deactivated when the steering wheel

is moved in the opposite direction or

indicator lever is manually moved

back to its neutral position.

102 Lighting

Activate temporary flashing by

holding the indicator lever just before

the resistance point. Turn lights will

flash until indicator lever is being

released.

To activate three flashes, tap the

indicator lever briefly without passing

the resistance point.

If you forget to cancel the turn lights

for more than 20 seconds, the volume

of the audible signal will increase if

the speed is above 40 mph.

Front fog lights

Operated by pressing >.

Light switch in position AUTO:

switching on front fog lights will switch

headlights on automatically.

Rear fog light

Operated by pressing r.

Light switch in position AUTO:

switching on rear fog light will switch

headlights on automatically.

Light switch in position 8: rear fog

light can only be switched on with

front fog lights.

The vehicle rear fog light is

deactivated when towing a trailer or a

plug is connected with the socket,

e.g. when a bicycle carrier is used.

Parking lights

When the vehicle is parked, the

parking lights on one side can be

activated:

1. Switch off ignition.

2. Move the lever all the way up

(right parking lights) or down (left

parking lights).

Confirmed by a signal and the

corresponding turn lights control

indicator.

Lighting 105

This function can be activated or

deactivated in the vehicle

personalisation.

Vehicle personalisation 3 92.

The following lights will additionally

switch on when the driver's door is

opened:

● illumination of some switches

● Driver Information Centre

● door pocket lights

Exit lighting

The following lights are switched on

when the ignition is switched off:

● headlights

● interior lights

● centre console lighting

● rear lights

They will switch off automatically after

a delay. This function works only in

the dark.

Battery discharge protection

To prevent discharge of the vehicle

battery when the ignition is switched

off, some interior lights are switched

off automatically after some time.

110 Climate control

Air conditioning A/C

Press A/C to switch on cooling. The

LED in the button illuminates to

indicate activation. Cooling is only

functional when the engine is running

and climate control fan is switched on.

Press A/C again to switch off cooling.

The air conditioning system cools and

dehumidifies (dries) when outside

temperature is above a specific level.

Therefore condensation may form

and drip from under the vehicle.

If no cooling or drying is required,

switch off the cooling system for fuel

saving reasons.

Maximum air conditioning AC/MAX

Press MENU to enter the climate

control settings menu.

Touch A/C MAX to activate/

deactivate maximum air conditioning.

The maximum air conditioning

function sets the temperature as low

as possible and adjusts the

distribution to all air vents. In addition,

it sets the air flow to maximum and

activates the air recirculation.

Manual air recirculation 4

Press 4 to activate the air

recirculation mode. The LED in the

button illuminates to indicate

activation.

Press 4 again to deactivate

recirculation mode.

9Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling, the

air humidity increases, so the

windows may mist up from inside.

The quality of the passenger

compartment air deteriorates,

which may cause the occupants to

feel drowsy.

In warm and very humid ambient air

conditions, the windscreen may mist

up from outside, when cold air is

directed towards it. If windscreen

mists up from outside, activate

windscreen wiper and deactivate l.

112 Climate control

The operating status of the

temperature preconditioning is shown

by a LED.

● LED illuminates: A timer has

been set.

● LED flashes: The system is

operating.

The LED is extinguished at the end of

the operation or when the

temperature preconditioning is

stopped using the remote control.

The temperature preconditioning can

be programmed by using the Info

Display.

Notice

The temperature preconditioning is

only activated if the ignition is off and

the vehicle is locked.

If the charging level of the high

voltage battery is below 50%, the

temperature preconditioning is not

activated.

When the vehicle is connected,

battery charging takes precedence

over pre-conditioning.

Consequently, it can only be

activated if the battery is charged

above a threshold fixed at 80%.

If a recurrent heating / ventilation is

programmed and two heating /

ventilation procedures are carried

out without operating the vehicle, the

programming is deactivated.

Setting timer

Press MENU .

Touch OPTIONS.

Specyfikacje produktu

Marka:	Vauxhall
Kategoria:	Samochód osobowy
Model:	Grandland X 2021

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Vauxhall Grandland X 2021, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje Samochód osobowy Vauxhall

Vauxhall Agila Jan 2009 Instrukcja

23 Września 2024

Vauxhall Combo 2009 Instrukcja

23 Września 2024

Vauxhall Insignia 2016 Instrukcja

21 Września 2024

Vauxhall New Insignia 2013 Instrukcja

20 Września 2024

Vauxhall Signum 2007 Instrukcja

16 Września 2024

Vauxhall Grandland X 2022 Instrukcja

11 Września 2024

Vauxhall Grandland X 2020 Instrukcja

6 Września 2024

Vauxhall New Insignia 2014 Instrukcja

5 Września 2024

Vauxhall Agila 2006 Instrukcja

2 Września 2024

Vauxhall Grandland X 2021 Instrukcja

1 Września 2024

Instrukcje Samochód osobowy

Najnowsze instrukcje dla Samochód osobowy

Kia Cee-d Instrukcja

28 Września 2024

Kia Carens 1 Instrukcja

28 Września 2024

Kia Carens II Instrukcja

28 Września 2024

Kia e-Soul - 2019 Instrukcja

28 Września 2024

Audi A1 Instrukcja

28 Września 2024

Audi Q3 Instrukcja

28 Września 2024

Audi S5 Cabriolet Instrukcja

28 Września 2024

Audi A5 Coupe - 2015 Instrukcja

28 Września 2024

Audi S3 Instrukcja

28 Września 2024

Audi Q7 Instrukcja

28 Września 2024
