Strona 1/40

769-26139 / 00 05/21

IMPORTANT: Read this manual thoroughly before using this product. Follow all instructions.

SAVE THESE INSTRUCTIONS

TBC304

4-Cycle Cultivator

Operator’s Manual

TABLE OF CONTENTS

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Oil and Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Starting and Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

SERVICE

All information, illustrations, and specifications in this manual are based

on the latest product information available at the time of printing. We

reserve the right to make changes at any time without notice.

The product may vary slightly from the illustrations contained in this

manual.

DO NOT RETURN THIS UNIT TO THE RETAILER. PROOF OF

PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE.

For assistance regarding the assembly, operation or maintenance of

the unit, please call (in the United States) or 1-800-828-5500 1-800-

668-1238 (in Canada). Additional information can be found at

www.troybilt.com www.troybilt.ca (in the United States) or (in

Canada).

Warranty service is available through an authorized service center.

To locate a service center in your area, please visit our website or

call the number listed above. Service on this unit, both within and

after the warranty period, should only be performed by an

authorized and approved service center. When servicing, use only

identical replacement parts.

SAFETY

SPARK ARRESTOR NOTE

NOTE: For users on U.S. Forest Land and in the states of

California, Maine, Oregon and Washington. All U.S. Forest Land

and the state of California (Public Resources Codes 4442 and

4443), Oregon and Washington require, by law that certain internal

combustion engines operated on forest brush and/or grass-covered

areas be equipped with a spark arrestor, maintained in effective

working order, or the engine be constructed, equipped and

maintained for the prevention of fire. Check with your state or local

authorities for regulations pertaining to these requirements. Failure

to follow these requirements could subject you to liability or a fine.

This unit is factory equipped with a spark arrestor. If it requires

replacement, contact your local service dealer to install the

appropriate muffler assembly.

SYMBOL MEANING

WARNING: Signals a SERIOUS hazard.

Failure to obey a safety WARNING CAN symbol result in

serious injury to yourself or to others.

CAUTION: Signals a MODERATE hazard.

Failure to obey a safety symbol result in CAUTION MAY

property damage or injury to yourself or to others.

The purpose of safety symbols is to attract your attention to

possible dangers. The safety symbols, and their explanations,

deserve your careful attention and understanding. The safety

warnings do not by themselves eliminate any danger. The

instructions or warnings they give are not substitutes for proper

accident prevention measures.

NOTE: Advises you of information or instructions vital to the

operation or maintenance of the equipment.

DANGER: Signals an EXTREME hazard.

Failure to obey a safety symbol result in DANGER WILL

serious injury or death to yourself or to others.

WARNING: This product can expose you to

chemicals including engine exhaust, which is known to the

State of California to cause cancer, and carbon monoxide,

which is known to the State of California to cause birth

defects or other reproductive harm. For more information

go to www.P65Warnings.ca.gov.

WARNING: Read the operator’s manual

and follow all warnings and safety instructions. Failure

to do so can result in serious injury to the operator

and/or bystanders.

www.troybilt.ca (Canada) to have parts, owner manuals, and

warranty information at your fingertips.

• IMPORTANT SAFETY INSTRUCTIONS •

READ ALL INSTRUCTIONS BEFORE OPERATING

• Read the instructions carefully. Be familiar with the controls and

proper use of the unit. Know how to stop the unit and disengage

the controls quickly.

• Stay alert. Do not operate this unit when tired, ill or under the

influence of alcohol, drugs or medication.

• Never allow children to operate the unit. Teens must be trained,

accompanied and supervised by an adult. Never allow adults to

operate the unit without proper instruction.

• All guards and safety attachments must be installed properly

before operating the unit.

• Inspect the unit before use. Check for damaged parts. Check for

fuel leaks. Make sure all parts operate properly. Make sure all

fasteners are in place and secure. Make sure all moving parts are

properly aligned and are not bound. Replace parts that are cracked,

chipped, or damaged in any way. Have all damaged or improperly

working parts repaired or replaced by an authorized service

center. Do not operate the unit with loose or damaged parts.

• Be aware of risk of injury to the head, hands and feet.

• Carefully inspect the area before starting the unit. Remove

rocks, broken glass, nails, wire, string and other objects that

may be thrown or become entangled with the unit.

• Clear the area of children, bystanders and pets; keep them

outside a 50-foot (15 m) radius, at a minimum. Even then, they are

still at risk from thrown objects. Encourage bystanders to wear

eye protection. If you are approached, stop the unit immediately.

• Squeeze the throttle control and check that it returns

automatically to the idle position. Make all adjustments or

repairs before using the unit.

• Do not change the engine governor settings or overspeed the

engine.

• This unit is intended for occasional, household use only.

WARNING: When using the unit, all safety

instructions must be followed. Please read these

instructions before operating the unit in order to ensure the

safety of the operator and any bystanders. Please keep

these instructions for later use.

WHILE OPERATING

• Wear safety glasses or goggles that meet current ANSI / ISEA

Z87.1 standards and are marked as such. Wear ear/hearing

protection when operating this unit. Wear a face mask or dust

mask if the operation is dusty.

• Wear heavy long pants, boots, gloves and a long sleeve shirt. Do

not wear loose clothing, jewelry, short pants, sandals or go

barefoot. Secure hair above shoulder level.

• Wear protective footwear that will improve footing on slippery

surfaces.

• The tines should remain stationary when the engine idles. If they

do not, refer to . Adjusting the Idle Speed

• Make sure the tines are not in contact with anything before

starting the unit.

• Use the unit only in daylight or good artificial light.

• Avoid accidental starting. Be in the starting position whenever

pulling the starter rope. The operator and unit must be in a

stable position while starting. Refer to . Starting and Stopping

• Use the right tool. Only use this tool for its intended purpose.

Only use the unit as described in this manual.

• Always hold the unit with both hands when operating. Keep a

firm grip on the handle.

• Do not overreach. Always keep proper footing and balance. Take

extra care when working on stairs, steep slopes or inclines.

• Use extreme caution when reversing or pulling the unit towards

you.

• Keep hands, face, and feet away from all moving parts. Do not

touch or try to stop moving parts.

• Do not touch the engine, gear housing or muffler. These parts get

extremely hot from operation, even after the unit is turned off.

• Do not operate the unit faster than the speed needed to do the

job. Do not run the unit at high speed when not in use.

• Do not force the unit. It will do a better, safer job when used at

the intended rate.

SAFETY WARNINGS FOR GAS UNITS

• Store fuel only in containers specifically designed and approved

for the storage of such materials.

• Always stop the engine and allow it to cool before filling the

tank. Never remove the fuel tank cap or add fuel when the

engine is hot. Always loosen the fuel tank cap slowly to relieve

any pressure in the tank before fueling.

• Always add fuel in a clean, well-ventilated outdoor area where

there are no sparks or flames. DO NOT smoke.

• Never operate the unit without the fuel cap securely in place.

• Avoid creating a source of ignition for spilled fuel. Wipe up any

spilled fuel from the unit immediately, before starting the unit.

Move the unit at least 30 ft. (9.1 m) from the fueling source and

site before starting the engine. DO NOT smoke.

• Never start or run the unit inside a closed room or building.

Breathing exhaust fumes can kill. Operate this unit only in a well-

ventilated outdoor area.

WARNING: Gasoline is highly flammable and

its vapors can explode if ignited. Take the following

precautions:
