Strona 1/40

Operator’s Manual

4-Cycle

Electric Start Capable

Backpack Blower

TB4BP EC

769-14811 / 00 04/18

DO NOT RETURN THIS UNIT TO THE RETAILER. PROOF OF

PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE.

For assistance regarding the assembly, controls, operation or

maintenance of the unit, please call the Customer Support Department

at 1-800-828-5500 in the United States or in Canada.1-800-668-1238

Additional information about the unit can be found on our website at

www.troybilt.com www.troybilt.caor .

For service, please call the Customer Support Department to obtain a

list of authorized service dealers near you. Service on this unit, both

within and after the warranty period, should only be performed by an

authorized and approved service dealer. When servicing, use only

identical replacement parts.

All information, illustrations, and specifications in this manual are based on

the latest product information available at the time of printing. We reserve

the right to make changes at any time without notice.

TABLE OF CONTENTS

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Rules for Safe Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Oil and Fuel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Starting/Stopping Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Maintenance and Repair Instructions . . . . . . . . . . . . . . . . . . . . .12

Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Optional Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

SAVE THESE INSTRUCTIONS

SERVICE INFORMATION

SAFETY WARNINGS FOR GAS UNITS

• Store fuel only in containers specifically designed and approved

for the storage of such materials.

• Always stop the engine and allow it to cool before filling the fuel

tank. Never remove the fuel tank cap or add fuel when the engine

is hot. Always loosen the fuel tank cap slowly to relieve any

pressure in the tank before fueling. Do not smoke.

• Always add fuel in a clean, well-ventilated outdoor area where

there are no sparks or flames. Do not smoke.

• Never operate the unit without the fuel cap securely in place.

• Avoid creating a source of ignition for spilled fuel. Wipe up any

spilled fuel from the unit immediately, before starting the engine.

Move the unit at least 30 feet (9.1 m) from the fueling source and

site before starting the engine. Do not smoke.

• Never start or run the unit inside a closed room or building.

Breathing exhaust fumes can kill. Only operate this unit in a well-

ventilated outdoor area.

READ ALL INSTRUCTIONS BEFORE OPERATING

• Read the instructions carefully. Be familiar with the controls and

proper use of the unit.

• Read this operating instruction manual carefully. Be thoroughly

familiar with the controls and the proper use of the equipment.

Know how to stop the unit and disengage the controls quickly.

• Do not operate this unit when tired, ill, or under the influence of

alcohol, drugs, or medication.

• Never allow children to operate the equipment. Never allow adults

unfamiliar with the instructions to use the unit. Never allow adults

to operate the equipment without proper instruction.

• All guards and safety attachments must be installed properly

before operating the unit.

• IMPORTANT SAFETY INSTRUCTIONS •

Read the Operator’s Manual and follow all warnings and safety instructions. Failure to do so can result in serious injury to the

operator and/or bystanders.

FOR QUESTIONS, CALL 1-800-828-5500 IN U.S. OR 1-800-668-1238 in CANADA

The purpose of safety symbols is to attract your attention to possible

dangers. The safety symbols, and their explanations, deserve your

careful attention and understanding. The safety warnings do not by

themselves eliminate any danger. The instructions or warnings they

give are not substitutes for proper accident prevention measures.

NOTE: Advises you of information or instructions vital to the

operation or maintenance of the equipment.

SAFETY ALERT: Indicates danger, warning or

caution. Attention is required in order to avoid serious

personal injury. May be used in conjunction with other

symbols or pictographs.

DANGER: Failure to obey a safety warning will result

in serious injury to yourself or to others. Always follow

the safety precautions to reduce the risk of fire, electric

shock and personal injury.

WARNING: Failure to obey a safety warning can

result in injury to yourself and others. Always follow the

safety precautions to reduce the risk of fire, electric

shock and personal injury.

CAUTION: Failure to obey a safety warning may result

in property damage or personal injury to yourself or to

others. Always follow the safety precautions to reduce

the risk of fire, electric shock and personal injury.

RULES FOR SAFE OPERATION

SYMBOL MEANING

WARNING: When using the unit, you must follow the

safety rules. Please read these instructions before operating

the unit in order to ensure the safety of the operator and any

bystanders. Please keep these instructions for later use.

WARNING: Gasoline is highly flammable and its

vapors can explode if ignited. Take the following

precautions:

SPARK ARRESTOR NOTE

NOTE: For users on U.S. Forest Land and in the states of

California, Maine, Oregon and Washington. All U.S. Forest Land

and the state of California (Public Resources Codes 4442 and 4443),

Oregon and Washington require, by law that certain internal

combustion engines operated on forest brush and/or grass-covered

areas be equipped with a spark arrestor, maintained in effective

working order, or the engine be constructed, equipped and maintained

for the prevention of fire. Check with your state or local authorities for

regulations pertaining to these requirements. Failure to follow these

requirements could subject you to liability or a fine. This unit is

factory equipped with a spark arrestor. If it requires replacement,

ask your LOCAL SERVICE DEALER to install the Accessory Part

#753-05669 Muffler Assembly.

WARNING: This product can expose you to

chemicals including engine exhaust, which is known to the

State of California to cause cancer, and carbon monoxide,

which is known to the State of California to cause birth

defects or other reproductive harm. For more information

go to www.P65Warnings.ca.gov.

RULES FOR SAFE OPERATION

WHILE OPERATING

• Wear safety glasses or goggles that meet current ANSI Z87.1

standards and are marked as such. Wear ear/hearing protection

when operating this unit. Wear a face or dust mask if the

operation is dusty.

• Never run the unit without the proper equipment attached.

• To reduce the risk of hearing loss associated with sound level(s),

always wear ear/hearing protection when operating this unit.

• Wear heavy long pants, boots, gloves, and a long sleeve shirt. Do

not wear loose clothing, jewelery, short pants, sandals or go

barefoot. Secure hair above shoulder level.

• To avoid static electricity shock, do not wear rubber gloves or

any other insulated gloves while operating this unit.

• Use the unit only in daylight or good artificial light.

• Keep outside surfaces free from oil and fuel.

• Avoid accidental starting. Be in the starting position whenever

pulling the starter rope. The operator and unit must be in a stable

position while starting. Refer to .Starting/Stopping Instructions

• Do not set unit on any surface except a clean, hard area while

engine is running. Debris such as gravel, sand, dust, grass, etc.

could be picked up by the air intake and thrown out by the

discharge opening, damaging unit, property, or causing serious

injury to bystanders or operator.

• Use the right tool. Only use this tool for its intended purpose.

• Do not force unit. It will do the job better and with less likelihood

of injury at a rate for which it was designed.

• Do not overreach or use from unstable surfaces such as ladders,

trees, steep slopes, rooftops, etc. Always keep proper footing

and balance.

• Always hold the unit with a firm grip when operating.

• Keep hands, face, and feet away from all moving parts. Do not

touch or try to stop the impeller when it is rotating. Do not

operate without guards in place.

• Do not put any object into openings. Do not use with any

opening blocked; keep free of dirt, debris, and anything that may

reduce the air flow.

• Do not touch the engine or muffler. These parts get extremely hot

from operation, even after the unit is turned off.

• Do not operate the engine faster than the speed needed to do

the job. Do not run the engine at high speed when not in use.

• Always stop the engine when operation is delayed or when

walking from one location to another.

• Stop the engine for maintenance, repair, to install or remove the

blower tubes. The unit must be stopped and the impeller no

longer turning to avoid contact with the rotating blades.

• If you strike or come into contact with a foreign object, stop the

engine immediately and check for damage. Do not operate

before repairing damage. Do not operate the unit with loose or

damaged parts.

• Use only replacement parts recommended for this tool that are

sold by a Troy-Bilt outlet. Use of any replacement parts purchased

elsewhere may be hazardous, and will also void your warranty.

• Never use this unit for spreading chemicals, fertilizers or other

substances which may contain toxic materials.

• To reduce fire hazard, replace faulty muffler and spark arrestor.

Keep the engine and muffler free from grass, leaves, excessive

grease or carbon build up.

• Turn the engine off and disconnect the spark plug for

maintenance or repair.

• Never point the blower or blowing debris in the direction of

people, animals, or in the direction of windows. Always direct the

blowing debris away from people, animals, and windows. Use

extra caution when blowing debris near solid objects such as

trees, automobiles, walls, etc.

OTHER SAFETY WARNINGS

• Always disconnect the spark plug before performing

maintenance or accessing movable parts. See Replacing the

Spark Plug.

• Never store the unit, with fuel in the tank, inside a building where

fumes may reach an open flame (pilot lights, etc.) or sparks

(switches, electrical motors, etc.).

• Allow the engine to cool before storing or transporting. Be sure to

secure the unit while transporting.

• Store the unit in a dry place, secured, or at a height to prevent

unauthorized use or damage. Keep out of the reach of children.

• Never douse or squirt the unit with water or any other liquid.

Keep handles dry, clean, and free from debris. Clean after each

use, see instructions.Cleaning and Storage

• Keep these instructions. Refer to them often and use them to

instruct other users. If you loan this unit to others, also loan these

instructions to them.

SPECIAL NOTE: Exposure to vibrations through prolonged use of

gasoline powered hand tools could cause blood vessel or nerve

damage in the fingers, hands, and joints of people prone to

circulation disorders or abnormal swelling. Prolonged use in cold

weather has been linked to blood vessel damage in otherwise

healthy people. If symptoms occur such as numbness, pain, loss of

strength, change in skin color or texture, or loss of feeling in the

fingers, hands or joints, discontinue use of this tool and seek

medical attention. A reduced vibration system does not guarantee

avoidance of these problems. Users who operate power tools on a

regular basis must closely monitor their physical condition and the

condition of this tool.

SAVE THESE INSTRUCTIONS

Specyfikacje produktu

Marka:	Troy-Bilt
Kategoria:	dmuchawa do liści
Model:	TB4BP EC

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Troy-Bilt TB4BP EC, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje dmuchawa do liści Troy-Bilt

Troy-Bilt TB430 Instrukcja

1 Października 2024

Troy-Bilt TB400 Instrukcja

1 Października 2024

Troy-Bilt TB672 Instrukcja

1 Października 2024

Troy-Bilt TB51BP Instrukcja

1 Października 2024

Troy-Bilt TB27VH Instrukcja

1 Października 2024

Troy-Bilt TB272V Instrukcja

1 Października 2024

Troy-Bilt TB4BP EC Instrukcja

1 Października 2024

Instrukcje dmuchawa do liści

Najnowsze instrukcje dla dmuchawa do liści

Einhell GC-CL 18/1 Li E-Solo Instrukcja

12 Października 2024

RYOBI RY40451 Instrukcja

9 Października 2024

Einhell RG-EL 1800 E Instrukcja

9 Października 2024

Anova E20SB Instrukcja

8 Października 2024

Einhell Royal LS 2500 E Instrukcja

8 Października 2024

DeWalt DCBL777 Instrukcja

8 Października 2024

Makita DUB183Z Instrukcja

8 Października 2024

Maruyama M260B Instrukcja

7 Października 2024

Maruyama BL5400SP Instrukcja

7 Października 2024

Maruyama BL8100 Instrukcja

7 Października 2024
