Strona 1/59

TRENDnet User’s Guide Cover Page

TRENDnet User’s Guide Table of Contents

Contents

Product Overview 1...........................................................................

Package Contents 1..........................................................................................................

Features ......................................................................................................................... 1

Product Hardware Features........................................................................................... 2

Application Diagram ...................................................................................................... 4

Basic Router Setup .......................................................................... 5

Creating a Home Network ............................................................................................. 5

Router Installation ......................................................................................................... 6

Connect additional wired devices to your network ....................................................... 9

Wireless Networking and Security ................................................. 10

How to choose the type of security for your wireless network .................................. 10

Secure your wireless network ..................................................................................... 11

Connect wireless devices to your router ..................................................................... 13

Connect wireless devices using WPS ........................................................................... 14

Basic wireless settings ................................................................................................. 16

Steps to improve wireless connectivity ....................................................................... 18

Advanced wireless settings .......................................................................................... 19

Access Control Filters .................................................................... 20

Access control basics ................................................................................................... 20

MAC address filters ................................................................................................. 20

Domain/URL Filters ................................................................................................. 21

Protocol/IP filters .................................................................................................... 22

Firewall rules ........................................................................................................... 23

Advanced Router Setup ................................................................. 25

Access your router management page ........................................................................ 25

Set your router date and time ..................................................................................... 26

Manually configure your Internet connection ............................................................ 26

IPv6 Internet Connection Settings ............................................................................... 27

Clone a MAC address ................................................................................................... 27

Change your router IP address .................................................................................... 28

Set up the DHCP server on your router ....................................................................... 28

Set up DHCP reservation ............................................................................................. 29

Enable/disable UPnP on your router ........................................................................... 30

Allow/deny VPN connections through your router ..................................................... 30

Allow/deny multicast streaming.................................................................................. 31

Identify your network on the Internet ........................................................................ 31

Allow remote access to your router management page ............................................. 32

Open a device on your network to the Internet .......................................................... 32

DMZ ......................................................................................................................... 32

Virtual Server .......................................................................................................... 33

Special Applications ................................................................................................ 35

Add static routes to your router .................................................................................. 36

Enable dynamic routing on your router ...................................................................... 38

Router Maintenance & Monitoring ............................................... 39

Reset your router to factory defaults .......................................................................... 39

Router Default Settings ............................................................................................... 39

Backup and restore your router configuration settings .............................................. 40

Restart your router ...................................................................................................... 42

Check connectivity using the router management page ............................................. 42

Check the router system information ......................................................................... 43

View your router log .................................................................................................... 44

TRENDnet User’s Guide Table of Contents

Configure your router log ............................................................................................ 45

View your router packet statistics ............................................................................... 46

View wireless devices connected to your router ......................................................... 46

Router Management Page Structure ............................................. 47

Technical Specifications................................................................. 48

Troubleshooting ............................................................................ 50

Appendix ......................................................................................51

TRENDnet User’s Guide TEW- 711BR

Product Overview

TEW-71 1BR

Package Contents

In addition to your router, the package includes:

• Mul - ti Language Quick Installation Guide

• CD- ROM (User’s Guide)

• Network cable (1.5 .) m / 5 ft

• Power adapter (5V DC, 1A)

If any package contents are missing or damaged, please contact the retail store, online

retailer, or reseller/distributor from which the product was purchased.

Features

TRENDnet’s N150 Wireless Home Router, model TEW-711BR, offers proven 150 Mbps

wireless n networking to share files, play games, and surf the internet. Embedded

GREENnet technology reduces power consumption by up to 50%. For your convenience

the wireless network is setup and pre-encrypted out of the box.

Ease of Use

Easy Setup

Get up and running in minutes with the intuitive guided setup

One Touch Connection

Securely connect to the router at the touch of the Wi-Fi Protected Setup (WPS) button

Access Control

Pre- Encrypted

For your convenience the wireless network is pre-encrypted with its own unique

password

Parental Controls

Control access to specific websites and manage which devices can access the router

Performance

N150 Wireless

Reliable 150 Mbps Wireless N

Ethernet Ports

Ethernet ports to hardwire up to four devices

Energy Savings

Embedded GREENnet technology reduces power consumption by up to 50%

IPv6

IPv6 network support

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual

data throughput and coverage will vary depending on interference, network traffic, building

materials and other conditions.

TRENDnet User’s Guide TEW- 711BR

Front View

• Power LED -This LED indicator is solid green when your router is powered on.

Otherwise if this LED indicator is off, there is no power to your router.

• Status LED - This LED indicator is blinking green when your router is ready and

working successfully. If this LED indicator is solid green on or off, your router is

not receiving power or not working properly.

• WAN (Link/Activity) LED – This LED indicator is solid green when your router

WAN port is physically connected to the modem Network port (also called

network port) successfully with a Network cable. The LED indicator will be

blinking green while data is transmitted or received through the WAN port of

your router.

• WLAN (Link/Activity) LED – This LED indicator is blinking green when the

wireless is “On” and functioning properly on your router. This LED indicator will

be blinking green rapidly while data is transmitted or received by your wireless

clients or wireless network devices connected to your router.

• LAN 1- 4 (Link/Activity) LEDs – These LED indicators are solid green when the

LAN ports are successfully connected to your wired network devices (which are

turned on). These LED indicators will blink green while data is transmitted or

received through your router’s LAN ports.

TRENDnet User’s Guide TEW- 711BR

Basic Router Setup

Creating a Home Network

What is a network?

A network is a group of computers or devices that can communicate with each other. A

home network of more than one computer or device also typically includes Internet

access, which requires a router.

A typical home network may include multiple computers, a media player/server, a

printer, a modem, and a router. A large home network may also have a switch,

additional routers, access points, and many Internet-capable media devices such as TVs,

game consoles, and Internet cameras.

• Modem – Connects a computer or router to the Internet or ISP (Internet

Service Provider).

• Router – Connects multiple devices to the Internet.

• Switch –Connect several wired network devices to your home network. Your

router has a built-in network switch (the LAN port 1-4). If you have more wired

network devices than available Ethernet ports on your router, you will need an

additional switch to add more wired connections.

How to set up a home network

1. For a network that includes Internet access, you’ll need:

• Computers/devices with an Ethernet port (also called network port) or wireless

networking capabilities.

• A modem and Internet service to your home, provided by your ISP (modem

typically supplied by your ISP).

• A router to connect multiple devices to the Internet.

2. Make sure that your modem is working Your modem . properly is often provided by

your Internet Service Provider (ISP) when you sign up for Internet service. If your

modem is not working contact your ISP to verify functionality.

3. Set up your router. See “How to setup your router” below.

4. To connect additional wired computers or wired network devices to your network,

see “Connect additional wired devices to your network” on page 9.

5. To set up wireless networking on your router, see “Wireless Networking and Security”

on page 10.

How to setup your router

Refer to the Quick Installation Guide or continue to the next section “Router

Installation” on page 6 for more detailed installation instructions.

Where to find more help

In addition to this User’s Guide, you can find help below:

• http://www.trendnet.com/support

(document and s, downloads, FAQs are available from this Web page)

TRENDnet User’s Guide TEW- 711BR

Router Installation

Before you Install

Many Internet Service Providers (ISPs) allow your router to connect to the Internet

without verifying the information fields listed below. Skip this section for now and if

your router cannot connect to the Internet using the standard installation process, come

back to this page and contact your ISP to verify required ISP specification fields listed

below.

1. Obtain IP Address Automatically (DHCP)

Host Name (Optional)

Clone Mac Address (Optional)

2. Fixed IP address

WAN IP Address: _____. _____._____._____

(e.g. 215.24.24.129)

WAN Subnet Mask: _____. _____._____._____

WAN Gateway IP Address: _____. _____._____._____

DNS Server Address 1: _____. _____._____._____

DNS Server Address 2: _____. _____._____._____

3. PPPoE to obtain IP automatically

User Name: _________

Password: ________________

Verify Password: ________________

4. PPPoE with a fixed IP address

User Name: _________

Password: ________________

Verify Password: ________________

IP Address: ____. _____._____._____ (e.g. 215.24.24.129)

5. PPTP or Russian PPTP

Type (Dynamic IP or Static IP)

My IP Address: _____. _____._____._____

(e.g. 215.24.24.129)

Subnet Mask:_____. _____._____._____

Gateway:_____. _____._____._____

Server IP: _____. _____._____._____

PPTP Account: ________________

PPTP Password: ________________

Retype Password: ________________

6. L2TP or Russia L2TP

Type (Dynamic IP or Static IP)

My IP Address: _____. _____._____._____

(e.g. 215.24.24.129)

Subnet Mask:_____. _____._____._____

Gateway:_____. _____._____._____

Server IP: _____. _____._____._____

L2TP Account: ________________

L2TP Password: ________________

Retype Password: ________________

7. Russia PPPoE

Type (Dynamic IP or Static IP)

User Name: _________

Password: ________________

Verify Password: ________________

IP Address: ____. _____._____._____ (e.g. 215.24.24.129)

TRENDnet User’s Guide TEW- 711BR

Setup Wizard

1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and

the wizard will automatically appear.

Note: If you have already configured your router before, the wizard no longer will

appear automatically. In your web browser, go to http://tew-711br or you can access

the router management using the default IP address http://192.168.10.1. Your router

will prompt you for a user name and password. Enter your user name and password

and click Login, then click on Wizard.

2. Select your language from the drop- . down list at the top right and click Next

3. Please wait for the wizard to automatically detect your Internet connection.

If the wizard is unable to detect your Internet connection type, you will be prompted to

manually select and configure your Internet connection settings. Select your Internet

connection type and click Next.

Note: Dynamic IP (DHCP) is typical for most Internet services. You can verify your

settings with your Internet Service Provider.

4. Confirm your settings. This window displays your predefined router wireless settings

and click Save to complete the wizard Please wait for the settings to be applied..

Note: For added security, the router wireless network is pre-encrypted with its own

unique wireless network security key. You can find the unique network security key and

the pre-assigned network name (SSID) on a sticker on the top of the router and on a

label on the bottom of the router. You will need this information to connect to the

router. To change the network security key, refer to page 11 “Secure your wireless

network”. If the router is reset to factory defaults, the wireless encryption will reset to

the network security key printed on the product labels of the router.

TRENDnet User’s Guide TEW- 711BR

Connect additional wired devices to your network

You can connect additional computer to your network by s or other network enabled devices using Ethernet cables to connect them to one of the available LAN ports labeled 1,2,3,4 on

your router. Check the status of the LED indicators (1, 2, 3, or 4) on the front panel of your router to ensure the physical cable connection from your computer or device.

Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network

settings (also called TCP/IP settings) are configured to obtain IP address settings automatically (also called dynamic IP address or DHCP) and to Obtain DNS Server address settings

automatically.

Specyfikacje produktu

Marka:	TRENDnet
Kategoria:	router
Model:	TEW-711BR
Kolor produktu:	Czarny
Wysokość produktu:	34 mm
Szerokość produktu:	158 mm
Głębokość produktu:	109 mm
Waga produktu:	204 g
Pasmo częstotliwości:	2.4 GHz
Certyfikaty:	CE, FCC, RoHS, CSMA/CA, ACK, ETSI
Gniazdko wyjścia DC:	Tak
Zasilacz sieciowy:	Tak
Maksymalny zakres zewnętrzny:	300 m
Standardy komunikacyjne:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Liczba kanałów:	13 kan.
Modulacja:	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Czułość odbiorcy:	802.11b: -85dBm @ 11Mbps\n802.11g: -68dBm @ 54Mbps\n802.11n: -62dBm @ 150Mbps
Prędkość transferu danych przez Ethernet LAN:	10, 100 Mbit/s
Ilość portów Ethernet LAN (RJ-45):	5
Zakres temperatur (eksploatacja):	0 - 40 °C
Zarządzanie przez stronę www:	Nie
Standardy Wi- Fi:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Przewodowa sieć LAN:	Tak
Pobór mocy:	2.8 W
WLAN prędkość przesyłania danych:	11, 54, 150 Mbit/s
Szyfrowanie / bezpieczeństwo:	128-bit WEP, 64-bit WEP, WPA, WPA2, WPA2-PSK
Podstawowy standard Wi-Fi:	Wi-Fi 4 (802.11n)
Typ interfejsu Ethernet LAN:	Fast Ethernet
Diody LED:	LAN, Status, WAN, WLAN
Zakres temperatur (przechowywanie):	-10 - 70 °C
Klient DHCP:	Nie
Maksymalna temperatura termometru zwilżonego (wet bulb temp.) Podczas eksploatacji (w °f):	32 - 104 °F
Technologia okablowania:	10/100Base-T(X)
Obsługa jakość serwisu (QoS):	Tak
Poziom wzmocnienia anteny (max):	2 dBi
Ilość anten:	1
Prąd wejściowy:	1 A
WLAN wskaźnik przesyłu danych (max):	150 Mbit/s
Możliwości montowania w stelażu:	Nie
Universal Plug and Play (UPnP):	Tak
Konstrukcja anteny:	Zewnętrzny
Filtrowanie adresów MAC:	Tak
Filtrowanie:	Tak
Tłumaczenie adresów sieciowych (NAT):	Tak
Ethernet WAN:	Tak
Obsługiwane protokoły sieciowe:	PPPoE, PPTP, L2TP, UPnP
Serwer DHCP:	Nie
Obsługa DMZ:	Tak
Maksymalny zakres wewnętrzny (pomieszczenie):	100 m
Połączenie xDSL:	Nie
