Strona 1/12

Instruction manual

Betriebsanleitung

Mode d’emploi

Instruktionsvejledning

Manuale d´istruzioni

Gebruiksaanwijzing

Manual de instrucciones

Spectrum

XC Centre speaker

Instruction manual

Thank you for purchasing Tangent loudspeakers. You have just purchased one of

the best domestic hiﬁ loudspeakers available and we hope you will enjoy the music

they reproduce for many years to come. The following notes are designed to assist

you in obtaining a greater degree of musical satisfaction from your Tangent loud-

speakers. Before connecting your loudspeakers, we suggest that you read this leaﬂet

carefully.

Ampliﬁer capacity/power handling

Your Tangent loudspeaker system will operate satisfactorily with any good ampliﬁer

designed for use with an 4-8 Ohm impedance load. Allthough Tangent loudspeakers

are designed to handle high power loadings, you must remember that any loudspeaker

that is abused with excessive use of volume, tone controls and graphic equalisers is

likely to cause damage to the drive-units. Be carefull especially with small ampliﬁers

constantly driven on high power levels as these may be liable to go into »clipping

mode« and disort the signal causing possible damage. If you hear a distordet signal

through the loudspeakers you must reduce the power level.

Connecting to your ampliﬁer

We strongly recommend the use of high quality speaker cables, colour coded or groo-

ved cables are recommended to assist checking polarity, your local dealer should be

able to advise you on this point. Always switch OFF your ampliﬁer before making

any connections or adjustments to the system. Wire the right-hand channel cable

so that the positive (RED) terminal of your loudspeaker is connected to the positive

(RED) on your ampliﬁer, and the negative (BLACK) terminal of your loudspeaker is

connected to the negative (BLACK) terminal on your ampliﬁer. Repeat the instruc-

tions for all channels. Do NOT connect more than one loudspeaker to one terminal

on your ampliﬁer.

Phasing

Providing that you have followed the connecting instruction correctly the loudspea-

kers should be in phase and provide solid stereo images. If, however, you have any

doubt as to the phasing of the loudspeakers, try reversing the connections (RED &

BLACK) to ONE of the loudspeakers, and play a recording which has plenty of deep

bass operating both loudspeakers simultaneously with the stereo ampliﬁer switched

to »mono«. The correct polarity is indicated by ﬁrm full bass, when incorrect, the bass

will be noticeably much weaker.

Service

No routine attention is required to the working parts of the loudspeakers and being

very reliable Tangent loudspeakers rarely require service. Any service problems should

in the ﬁrst instance be referred to your dealer.

Set Up of Speaker System for your Home Theatre

A surround sound system, as a minimum, requires 5-7 loudspeakers. It is important to

position them carefully. Thus we recommend that you work with the arrangement of

the speakers in your system, perhaps our idea of placing the system initially may not

suit the way in which your furniture is arranged.(see page 10)

Specyfikacje produktu

Marka:	Tangent
Kategoria:	głośnik
Model:	Spectrum XC
Kolor produktu:	Czarny
Wysokość produktu:	160 mm
Szerokość produktu:	395 mm
Głębokość produktu:	198 mm
Waga produktu:	5500 g
Podręcznik użytkownika:	Tak
Szerokość opakowania:	470 mm
Wysokość opakowania:	245 mm
Głębokość opakowania:	265 mm
Rekomendowane użycie:	Uniwersalne
Technologia łączności:	Przewodowa
Impedancja:	6 Ω
Moc wyjściowa (RMS):	100 W
Kanały wyjścia audio:	- kan.
Waga wraz z opakowaniem:	6200 g
Rodzaj opakowania:	Pudełko
Zasięg częstotliwości:	55 - 20000 Hz
Rozmieszczenie głośników:	Plansza/półka
Ilość przetworników:	3
Głośnik wysokotonowy:	Tak
Głośnik niskotonowy:	Tak
Typ głośnika:	2-drożny
AirPlay:	Nie
Średnica głośnika wysokotonowego:	1 "
Średnica głośnika niskotonowego (imperial):	4 "
Obsługiwany Mutli-Room:	Nie
