Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Supermicro A+ Server 1114S-WTRT (13 stron) w kategorii serwer. Ta instrukcja była pomocna dla 4 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek
Strona 1/13
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/supermicro/a-plus-server-1114s-wtrt/html/bg1.png)
Information for Lot 9 of d )ErP (Eco esign
This addresses Ecodesign addendum European Union (EU) requirements for servers and storage products.
All data and ratings within this addendum are in reference only to the in thSupermicro product(s) e
manual. the The below information conforms with requirements laid down in Annex II of Commission
Regulation . 2019/424
3(1)(a): See Section 1.1 of the system manual for the product type.
3(1)(b): e See the title page and preface of th system manual for trademark and the
manufacturer’s address.
3(1)(c): See the title page of the system manual for product model number(s).
3(1)(d): See the serial number on the physical system to determine the year . of manufacture
3(1)(e-j ): PSU Efficiency V ) (F and Power Factor alue (Table rom 80 Plus report)
PSU Model #: PWS- - 504P 1R
Watts: 500W
PSU E fficiency
P F ower actor
% of R Lated oad
10
%
20 %
50 %
100
%
50 %
Single -Output (AC DC)
86.16 %
91.84 %
94.11 %
92.61%
0.97
System (EUT) E P fficiency in I Sdle tate ower (Table)
Representative
Configurations
Measured Idle State
Power (W)
Calculated Idle Power Allowance
(W)
High-End Performance
Configuration
191
374.85
Typical Configuration
N/A
N/A
Low-End Performance
Configuration
119
204.37
System E(EUT) fficiency in A Sctive tate P ower (Table)
Representative
Configurations
Active tate S
E Sfficiency core
(Effserver)
Minimum A Sctive tate Efficiency for
2-S S ocket erver
High-End Performance
Configuration
56.1
Typical Configuration
N/A
N/A
Low-End Performance
Configuration
45
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/supermicro/a-plus-server-1114s-wtrt/html/bg2.png)
3(1)( ): k is . The operating condition class A2
Dry bulb temp °C
Humidity range, non condensing-
Operating
condition
class
Allowable
range
Recom
mended
range
Allowable range
Recommended range
Max dew
point (°C)
Maximum
rate of
change
(°
C/hr)
A1
15 32-
18 27-
–
12 and °C P Dew oint (DP)
8 % relative humidity (RH) to
17 ° and 80 C DP % RH
–
9 °C DP to
15 °C and DP
60 % RH
17
5/20
A2
10 35-
18 27-
–
12 and °C DP 8 % RH to
21 and 80 °C DP % RH
Same as A1
21
5/20
A3
5-40
18 27-
–
12 and °C DP 8 % RH to
24 and 85 °C DP % RH
Same as A1
24
5/20
A4
5-45
18 27-
–
12 and °C DP 8 % RH to
24 and 90 °C DP % RH
Same as A1
24
5/20
3(1)( ): l The idle state power at the higher boundary temperature of the operating conditions
class is 2 . W. 25 38
3(1)( ): m The active state efficiency and performance is 56.1.
3(1)(n): There are two methods by which a user can securely delete data from this system. The
user performing secure data deletion should be an IT professional.
The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility
works on X10/X11/H11/H12/M11 motherboard series with onboard SATA/NVMe devices.
Any user may access and download this utility through following link:
https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure
_Data_Deletion_Utility/
Download the shell utility package and extract it to a USB flash drive, then plug the drive
into the server for which secure data deletion is necessary. Then turn the system on.
Navigate to the BIOS setup menu, then place the server system into the UEFI shell
environment. Follow the instructions in the README file to invoke the utility and
complete the deletion.
The second method is through the secure data deletion tool provided by the original
manufacturer of the hard drive. This should be used in a scenario where the shell utility
is not applicable. Each manufacturer should have the tool available on their website. If
needed, please look on the hard drive label for the name of the manufacturer and model
information.
3(1)( ): o List of recommended combinations of blade servers with chassis: N/A.
3(1)(p): List of all current SKUs within this product family: N/A.
3(3)(a): There is no use of cobalt in batteries in this product.
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/supermicro/a-plus-server-1114s-wtrt/html/bg3.png)
The indicative weight range of eodymium in the HDD is n 0.0 if manufactured by Western
Digital, and is between 5- 25 grams if manufactured by Seagate.
3(3)(b): Please see the disassembly instructions on the next page.
Specyfikacje produktu
Marka: | Supermicro |
Kategoria: | serwer |
Model: | A+ Server 1114S-WTRT |
Kolor produktu: | Czarny |
Wbudowany wyłącznik: | Tak |
Częstotliwość wejściowa AC: | 50 - 60 Hz |
Napięcie wejściowe AC: | 100 - 240 V |
Wysokość produktu: | 43 mm |
Szerokość produktu: | 437 mm |
Głębokość produktu: | 597 mm |
Certyfikat środowiskowy (zrównoważonego rozwoju): | RoHS |
Procesor wbudowany: | Nie |
Prędkość transferu danych przez Ethernet LAN: | 10,100,1000,10000 Mbit/s |
Ilość portów Ethernet LAN (RJ-45): | 2 |
Zakres temperatur (eksploatacja): | 10 - 35 °C |
Zakres wilgotności względnej: | 8 - 90 % |
Typ procesora: | AMD |
Kod zharmonizowanego systemu (HS): | 84714100 |
Przewodowa sieć LAN: | Tak |
Waga wraz z opakowaniem: | 20900 g |
Diody LED: | Tak |
Zakres temperatur (przechowywanie): | -40 - 60 °C |
Dopuszczalna wilgotność względna: | 5 - 95 % |
Ilość obsługiwanych rozmiarów dysków pamięci: | 12 |
Obsługiwane rodzaje dysków: | HDD & SSD |
Obsługiwane rozmiary dysków pamięci: | 2.5, M.2 " |
Ilość portów USB 3.2 Gen 1 (3.1 Gen 1) Typu-A: | 7 |
Obudowa: | Rack (1U) |
Rodzaj chłodzenia: | Aktywne |
Liczba wentylatorów: | 4 went. |
Obsługiwane rodzaje pamięci: | DDR4-SDRAM |
Maksymalna pojemność pamięci: | 2000 GB |
Gniazdo procesora: | Socket SP3 |
Procesor: | AMD EPYC |
Typ BIOS: | AMI |
PCI Express x16 gniazda: | 3 |
Liczba gniazd M.2 (M): | 2 |
Ilość złączy SATA III: | 2 |
Zasilanie: | 500 W |
Prąd wejściowy: | 2.6 - 6.1 A |
Wspierane interfejsy dysków twardych: | PCI Express, Serial ATA III |
Rodzaj interfejsu sieci Ethernet: | 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
Kontroler LAN: | Broadcom 57416 |
Liczba portów VGA (D-Sub): | 1 |
Korekcja ECC: | Tak |
Monitorowanie stanu komputera: | CPU, FAN, Temperature |
Rozmiar pamięci BIOS: | 32 Mbit |
Ilość zatok 2,5 ": | 10 |
Model karty graficznej on-board: | Aspeed AST2500 |
Obsługa zasilania zapasowego (RPS): | Tak |
Liczba głównych źródeł zasilania: | 1 |
Wersja gniazd typu Slot (PCI Express): | 4.0 |
Rodzaj pamięci: | 288-pin DIMM |
Ilość slotów DIMM: | 8 |
Liczba obsługiwanych procesorów: | 1 |
Prędkość zegara pamięci RDIMM: | 3200 MHz |
Przemieszczanie twardej wnęki na napęd HDD: | Tak |
Certyfikat 80 PLUS: | 80 PLUS Platinum |
Ilość zainstalowanych, nadmiarowych źródeł zasilania: | 1 |
Średnica czaszy wentylatora: | 40 mm |
Obsługa Backplanes: | Tak |
Prąd stały (+12 V): | 42 A |
Zintegrowany BMC z IPMI: | Tak |
Port IPMI LAN (RJ-45): | Tak |
