Strona 1/35
ICE MAKER
Model:
BIM25
User Manual
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS
Felix Storch, Inc.
Summit Appliance Division
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
2
TABLE OF CONTENTS
Important Safeguards 3
Installation Instructions 4-5
Before Using your Ice Maker 4
Installing your Ice Maker 4
Electrical Connection 5
Extension Cord 5
Connecting the Water Supply 5
Reversing the Door Swing of your Ice Maker 5
Operating your Ice Maker 6-7
Initial Start-Up Operation 6
Thermostat 6
Ice Cube Quantity and Cycle Time 7
Care and Maintenance 7-8
Cleaning your Ice Maker 7
Power Failure 7
Vacation Time/Storage 7
Moving your Ice Maker 7
Energy-Saving Tip 8
Troubleshooting 8
Limited Warranty 10
3
IMPORTANT SAFEGUARDS
WARNING
FOLLOW THESE BASIC PRECAUTIONS TO REDUCE
THE RISK OF FIRE, ELECTRICAL SHOCK, OR
INJURY WHEN USING YOUR ICE MAKER.
•
READ ALL INSTRUCTIONS BEFORE USING THE ICE MAKER.
•
DANGER: RISK OF CHILD ENTRAPMENT:
CHILD ENTRAPMENT AND SUFFOCATION ARE NOT PROBLEMS OF THE PAST.
JUNKED OR ABANDONED APPLIANCES ARE STILL DANGEROUS.
BEFORE YOU THROW AWAY YOUR ICE MAKER: TAKE OFF THE DOOR.
•
NEVER ALLOW CHILDREN TO OPERATE, PLAY WITH, OR CRAWL INSIDE THE
APPLIANCE.
•
NEVER CLEAN ICE MAKER PARTS WITH FLAMMABLE FLUIDS. THE FUMES CAN
CREATE A FIRE HAZARD OR EXPLOSION.
•
DO NOT STORE OR USE GASOLINE OR ANY OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. THE FUMES CAN
CREATE A FIRE HAZARD OR EXPLOSION.
● This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which
is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it
increase the greenhouse effect. Care must be taken during transportation and setting up of the
appliance that no parts of the cooling system are damaged. Leaking coolant can ignite and may
damage the eyes.
● In the event of any damage:
- Avoid open flames and anything that creates a spark,
- Disconnect from the electrical power line,
- Air the room in which the appliance is located for several minutes, and
- Contact the Service Department for advice.
● The more coolant there is in an appliance, the larger the room it should be installed in. In the
event of a leakage, if the appliance is in a small room, there is the danger of combustible gases
building up. For every ounce of coolant, at least 325 cubic feet of room space is required. The
amount of coolant in the appliance is stated on the data plate on the back of the appliance. It is
hazardous for anyone other than an authorized Service Person to carry out servicing or repairs
to this appliance.
● Take serious care when handling, moving, and using the appliance to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
● Replacing component parts and servicing shall be done by factory authorized service personnel
so as to minimize the risk of possible ignition due to incorrect parts or improper service.
