Setting up the appliance
A
Turn over for all the details on steaming
and ironing your garments ...
1
Quick Start Guide
Model: GSTT1100
Let’s get your new garment steamer
with ironing board ready to use!
This quick start guide contains basic instructions to get you started. For the full picture, please
refer to the supplied manual with comprehensive assembly, usage and safety advice.
CAUTION: Do not plug the unit into the power supply until it is fully assembled!
A brief assembly sequence is listed below. You will find more comprehensive instructions
and illustrations on pages 12–15 in the manual.
Place the base on a flat surface. Loosen the locks at the sides of the pole insertion holes.
Take the ironing board out of the box. Insert the two poles firmly into the holes on the base,
making sure the board and the base wheels are facing the same position. Tighten the locks.
Fix the hanger to the top of the poles.
Loosen the pole locks and extend the poles to the
appropriate height, then tighten the locks.
Attach the steam head rest by slightly pressing it in place
in its space on the pole.
To unfold the ironing board, slightly pull the board out.
Then extend the front leg by gently pushing it out with
your foot to the maximum level.
Remove the water tank cap and fill 800 mL of purified or cold, boiled water
into the tank using the measuring beaker. Close the tank and tighten the cap
securely. Then rest the main steamer unit securely on the lug and put the
steam hose through the guide(s).
Place the steam head in the steam head rest.
2
1
3
4
5
6
7
8
2
3
4
5
6
7
8
9
9
B
A variety of uses
You can use your new appliance for steaming garments in
vertical (hanging) position as well as for ironing them on the
integrated ironing board. For refreshing curtains or furnishings
in situ, you can also detach the main steamer unit from the
upright board structure and attach a shoulder strap for more
freedom of movement when using the appliance.
For all these different usage methods (explained overleaf),
please follow the simple operation steps below:
With the POWER switch in the OFF [ O ] position and the
STEAM switch pulled back, plug in the appliance.
Set the power switch to the ON [ I ] position.
Let the appliance run for one minute,
then push the STEAM switch forward to generate steam
for steaming or steam-ironing.
Pull back the STEAM switch to stop steam production.
10
POWER switch
10
11
11
Push
forward
to release
steam
Pull
back
to stop
steam
STEAM
switch
Give us a call
What? You mean this Quick Start Guide didn’t have ALL the answers? The manual has more
comprehensive instructions, or speak to us. Call our After Sales Support on 1300 112 534.
Well done, you made it! Now sit back and relax ... your new garment
steamer with ironing board is automatically covered by a 1 year warranty. V1.1
D
C
13
For vertical steaming, prepare the appliance for use as explained overleaf.
Please consult the manual for more details.
Hang the garment on the garment hanger at the top of the appliance, or on your own clothes hanger.
Vertical steaming
The two accessories for the steam head further improve the versatility of the
appliance for use with different types of fabric. The will open up fabric brush
the weave of fabrics to improve steam penetration and help remove dust and
lint. The prevents the soleplate coming into direct contact with steam defender
the fabric. You can use it to help release wrinkles on more heat-sensitive fabrics
that may otherwise get burnt from the heat of the soleplate. But always try on an
inconspicuous part of the garment first, for example, on an inside seam.
When you have finished with the appliance, pull the STEAM switch back to
stop steam production, place the steam head on the iron rest and unplug the unit.
12
12
14
When the temperature light switches off, direct
the steam away for a few seconds, then steam
will be emitted continuously and you may start.
With one hand pull the garment flat, with the
other hand guide the steam head over the
garment from top to bottom.
To remove stubborn creases from fabrics that
may be ironed, place the soleplate on the
fabric and utilise its hot temperature together
with the hot steam.
Horizontal ironing
13
For horizontal ironing, prepare the appliance for
use and place the garment on the ironing board.
When the temperature light switches off, direct the
steam away for a few seconds, then steam will be
emitted continuously and you may start.
Guide the iron smoothly over the garment to
remove creases and wrinkles. To steam-iron, keep
the switch in the pushed forward (steam) position.
To dry-iron, pull the switch back to the dry-ironing
position. The steam emission will stop.
E
Accessories
14
IMPORTANT!
We recommend using the self-clean function before first use to ensure all parts of the steam
system are clean. Please refer to the instructions on page 24 in the manual.
