Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 28, 2019 9:02 AM

Product Diagram (DP2DVIS/MDP2DVIS)

Port Function

1DVI Port • Used to connect the to a Converter DVI

Display Device.

DisplayPort Connector

(DP2DVIS)

Mini DisplayPort

Connector

(MDP2DVIS)

• Used to connect the to a Converter Video

Source Device.

Requirements

For the latest requirements, please visit orwww.startech.com/DP2DVIS www.startech.

com/MDP2DVIS.com.

• DisplayPort enabled computer system/video card (compatible with both Multi-

mode DisplayPort DP++ and Single-mode DisplayPort video cards)

• DVI-D (digital) enabled display device (i.e. monitor, projector, HDTV, etc.)

Installation

1. Make sure the video display device (i.e. monitor, projector, HDTV, etc.) is turned o,

before connecting to the adapter.

2. Connect a standard male/male DVI-D cable from the converter adapter to the video

display device.

3. Turn on the video display device.

DisplayPort to DVI Single-Link Active Converter

4. Connect the DisplayPort or Mini DisplayPort connector on the converter adapter to

the video source device (i.e. computer, laptop, etc.). The computer can be on or o,

as it should be able to automatically detect and congure the adapter and display

device (refer to documentation that came with the computer).

5. Once the external display is detected and congured, the video output should be

visible on the display device. Some adjustments may be necessary from the video

source devices output settings for optimal viewing.

Specications

Video Signal • DisplayPort 1.1a

• DVI-D (DDWG 1.0)

Connectors • 1 x DisplayPort male (DP2DVIS

• 1 x Mini Display Port male (MDP2DVIS)

• 1 x 25-pin DVI-D female

Maximum Video Resolution • 1920 x 1200

HDCP Support • Yes

Operating Temperature • 0°C ~ 70°C (32°F ~ 158°F)

Storage Temperature • 0°C ~ 70°C (32°F ~ 158°F)

Dimensions (LxWxH) • 200.0mm x 44.0mm x 20.0mm

Weight • 70 g

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a one-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.
