Instruction manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/31/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/DPMDPHD2HD.

Packaging contents

• 1 x 2 m DisplayPort™, Mini DisplayPort™, or HDMI® to HDMI

converter cable

• 1 x 2 m Micro-USB cable

• 1 x instruction manual

DPMDPHD2HD

DisplayPort, Mini DisplayPort or HDMI to HDMI Converter Cable - 2 m (6 ft)

*actual product may vary from photos

Introduction

This unique converter cable combines multiple inputs into a single

adapter so that you can use the converter cable to connect your

DisplayPort, Mini DisplayPort, or HDMI laptop to an HDMI display

or projector. DPMDPHD2HD eliminates the need to have separate

adapters for each kind of video input and is much more cost

eective than an integrated panel or desktop switch.

Product diagram

Power and activity LEDs

Micro-USB 2.0 power

HDMI output

Mini DisplayPort input

DisplayPort input

HDMI input

Connect the converter cable

1. Connect the HDMI output to your display or projector.

2. Connect the provided Micro-USB cable to the Micro-USB power

port on the converter cable and the USB port on your computer

or your AC power adapter.

3. Connect the other end of the converter cable to the Mini

DisplayPort, DisplayPort, or HDMI port on your computer.

Reset the converter cable

When you push the button, it’s equivalent to removing the Reset

USB power. If multiple inputs are connected to the converter cable,

whichever input connects rst will be given priority.

• To reset the converter cable, insert a pin or paperclip into the

Reset button located on the back of the converter cable.

About the LED indicators

The converter cable comes with three green LED indicators, one

LED indicator per cable. For more information about what the LED

indicators mean, see the table below.

LED behavior Scenario

LED is illuminated The corresponding input is active.

LED isn’t illuminated The corresponding input isn’t active.

Bottom view

Top view

Reset button

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not

allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
