46CC 2 STROKE CHAINSAW
OWNERS OPERATING MANUAL
04301 09/21
FMXOP24602
For service, spare parts or product information,
please contact Smart Marketing Group Pty. Ltd.
AUST. 1300 660 457 N.Z. 0800 474 876
www.stanleyproducts.com.au
40:1
2 Stroke
2
Please take note of serial number and write here for ease of
reference:
Serial Number:
Date of Purchase:
Place of Purchase:
Receipt Number:
CONTENTS
Section Page
Technical Information 2
Introduction 3
Warranty Statement 4
General Safety Instructions 5 - 7
Specific Safety Instructions 8 - 11
Components and Controls 12 - 13
Unpacking and Assembly 14 - 18
Operating Instructions 19 - 27
Maintenance and Storage 28 - 30
Trouble Shooting 30
Service Log 31
Contact Information 32
TECHNICAL INFORMATION
Specifications
Air-cooled 2-stroke engine FMXOP24602
Nominal Displacement 46cc
Actual Displacement 45.1cc
Max. engine power 1.8 kW
Fuel 2 Stroke Ratio 40:1
Fuel tank capacity 500 cc
Oil tank capacity 240 cc
Cutting length 360 mm
Spark plug Torch BM6A or L8RTC, or Bosch L8RTF
Weight 5.6 kg
Bar Length max. 406mm (16’’)
Chain pitch 9,525 mm
Template chain 1.27 mm
Sprocket 6 Teeth X 9.525 mm
Max. Speed 11,000 RPM
Engine idle speed 2700 - 3400 RPM
Chain Replacement Type 91PX55X or 3/8, 050x55
Guide Bar Replacement Type 160SDEA095 or SPS-16A-55P
Noise May exceed 113db (A)
SUGGESTED APPLICATIONS
These are some suggested articles which could be used by this
chain saw:
• Trees
• Branches
• Fire wood
• Clearing fallen branches
• Sculpturing
3
INTRODUCTION
Dear Customer,
Thank you for purchasing this chainsaw which has passed through
our extensive quality assurance processes. Every care has been
taken to ensure that it reaches you in perfect condition. However, in
the unlikely event that you should experience a problem, or if you
require any assistance please do not hesitate to contact us;
If you have a problem, call customer service do not
return this chainsaw to the place of purchase.
CUSTOMER SERVICE
Australia: 1300 660 457
New Zealand: 0800 474 876
Operating times: Monday – Friday
8.00am - 5.00 pm
Australian Eastern Standard Time (AEST)
EXPRESS WARRANTY STATEMENT CHAINSAW
You are not required to do anything to register your chainsaw
purchase. Please attach the purchase receipt to this manual and
ensure both are kept safe. We hope you enjoy your new chainsaw,
and if you have any problems call customer service on the above
phone numbers. Do not return to place of purchase.
Smart Marketing Group Pty Ltd (SMG) warrants that this chainsaw
will be free from manufacturing faults or defects for 12 months
from the date of purchase, providing original purchase receipt
is kept and shown when needed and is subject to the terms and
conditions below.
If a warranty fault appears within the warranty period, SMG
reserves the right to replace or repair the product. In the event
that SMG chooses to replace the product, this original warranty
will expire at the original date. If the product includes various
accessories or components, only the defective accessory or
component will be replaced or repaired.
SMG reserves the right to replace defective parts of the product with
parts and components of similar quality, grade and composition where
an identical part or component is not available.
Products presented for repair may be replaced by refurbished
products of the same type rather than being repaired. Refurbished
parts may be used to repair the products.
What is covered.
• Manufacturing fault or defect.
How to claim under this warranty.
• Call customer service, phone number below.
• Ensure you have the following: Original purchase receipt, Model
of chainsaw, Serial number of chainsaw.
• Discuss the issue.
• Customer service will advise which authorised service agent to
take the chainsaw to provided the issue is a warranty one.
• Take chainsaw to authorised service agent for repair.
What is not covered.
• Chainsaw used for hire.
• Damage caused by incorrect fuel or incorrectly mixed 2 stroke
fuel.
• Damage or deterioration due to transport.
• Damage caused by negligence, misuse, abuse or accident or
incorrect voltage and wattage.
• Any corrosion or rusting.
• Damage caused by incorrect set up and start up.
• Replacement parts due to general wear and tear.
• Chainsaw with serial number defacement, modification or
removal.
• Chainsaw which has been serviced by other than an authorised
SMG service agent.
• Chainsaw with no original purchase receipt.
• Chainsaw which have been on sold, not original purchaser.
• Damage due to non-servicing of chainsaw as is required by this
manual.
• Blockages / damage caused by dust, dirt, spiders webs
or insects.
• Damage caused by the incorrect fitting of accessories.
• Damage caused by overloading or overworking
the chainsaw.
• Damage to attached equipment or third party accessories.
• Damage caused by attached equipment or
third party accessories.
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel (+613) 9543 7266
Fax (+613) 9543 9839
service.group@smga.com.au
