CABLE JUNCTION BOX
WKE 203 RK
WKE 203 RK
Cable junction box
CUSTOMIZABLE
115 x 115 x 93 mm
Article number: 86220301
Cable junction and connection box with IP66 certified acc. EN
60670, with electrical functional integrity E30 acc. to DIN
4102 Part 12, with insulation integrity FE180 acc. IEC
60331-11 as well as functional class F400 acc. EN 12101,
enclosure and terminal strips made from halogen-free special
duroplastic
Junction box 3-pole, termination capability for each pole 4 x
0.5 - 4 mm², Accessories supplied:, Wall plug set ø 6 mm, 3
cable glands M25, seal range 6 - 15 mm
Technical data
Measures
Width: 115 mm
Length: 115 mm
Height: 93 mm
Material:
Box: Duroplastic
Cover: Duroplastic
Sealing: Polyurethane
material: Duroplastic
Cover screw: Stainless steel V4A
Certificates
Accessory
KVS - Cable gland protection
WKE 200 ABL - External attachment set
Environmental attributes
Ambient temperature (min.): -25 °C
Ambient temperature (max.): 40 °C
Ambient temperature (24 h): 35 °C
Max. rel. humidity at 25° C (short
term):
95%
Max. rel. humidity at 40° C: 50%
Created on 2017-04-28. No responsibility is taken for the correctness of this information. Improvements for technical progress reserved. Page 1 of 2
Günther Spelsberg GmbH + Co. KG · Im Gewerbepark 1 · D-58579 Schalksmühle · Germany · Phone: +49 (0) 23 55 / 892-0 · Fax: +49 (0) 23 55 / 892-299
CABLE JUNCTION BOX
WKE 203 RK
Other attributes
Color: orange
Entries: 3
Rated cross section: 4 mm²
Tackable: No
Rated insulation voltage AC: 450 V
Explosion safety: none
Functional integrity: E 30
sealable: No
Heavy metals-free: Yes
PVC-free: Yes
Silicone-free: Yes
Ingress protection: IP66 - acc. EN
60529 / DIN VDE
0470-1
weatherproof: Yes
Equiqment: Terminal
Cover screw torque: 2.5 N m
Created on 2017-04-28. No responsibility is taken for the correctness of this information. Improvements for technical progress reserved. Page 2 of 2
Günther Spelsberg GmbH + Co. KG · Im Gewerbepark 1 · D-58579 Schalksmühle · Germany · Phone: +49 (0) 23 55 / 892-0 · Fax: +49 (0) 23 55 / 892-299
