Spektrum

FIRMA Smart ESC Series

Spektrum FIRMA Smart Geschwindigkeitsreglerserie

Série de variateurs ESC Spektrum

FIRMA Smart

Smart ESC

SPEKTRUM FIRMA

NOTICE

All instructions, warranties and other collateral documents are subject to

change at the sole discretion of Horizon Hobby, LLC. For up-to-date product

literature, visit horizonhobby.com or towerhobbies.com and click on the support

or resources tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate

various levels of potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁ cial injury.

CAUTION: Procedures, which if not properly followed, create the probability

of physical property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar

with the features of the product before operating. Failure to operate

the product correctly can result in damage to the product, personal

property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and

common sense and requires some basic mechanical ability. Failure to oper-

ate this Product in a safe and responsible manner could result in injury or

damage to the product or other property. This product is not intended for use

by children without direct adult supervision. Do not attempt disassembly, use

with incompatible components or augment product in any way without the

approval of Horizon Hobby, LLC. This manual contains instructions for safety,

operation and maintenance. It is essential to read and follow all the instruc-

tions and warnings in the manual, prior to assembly, setup or use, in order to

operate correctly and avoid damage or serious injury.

Age Recommendation: Not for children under 14 years. This is not a toy.

NOTICE: This product is only intended for use with unmanned, hobby-grade,

remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

Waterproof Component

Your new Horizon Hobby® Spektrum

™

ESC has been designed and built to allow

you to operate the product in many “wet conditions”, including puddles, creeks,

wet grass, snow and even rain.

While waterproof, this component has not been designed to be immersed in

water for long periods of time and should NOT be treated like a submarine.

In addition, most metal parts, including any screws and nuts, as well as the

contacts in the electrical cables, will be susceptible to corrosion if additional

maintenance is not performed after running in wet conditions.

To maximize the long-term performance of your ESC and to keep the warranty

intact, it should only be used as described in the “Usage Conditions” section

of this manual. Additionally, the procedures described in the “Wet Conditions

Maintenance” section must be performed regularly if you choose to run in wet

conditions. If you are not willing to perform the additional care and maintenance

required, then you should not operate your vehicle in those conditions.

CAUTION: Failure to exercise caution while using this product and

comply with the following precautions could result in product

malfunction and/or void the warranty.

General Precautions

• R

ead through the wet conditions maintenance procedures and make sure that

you have all the tools you will need to properly maintain your ESC.

• Do not operate your ESC where it could come in contact with salt water (ocean

water or water on salt-covered roads), contaminated or polluted water. Salt

water is very conductive and highly corrosive, so use caution.

Usage Conditions

Your ESC will operate successfully in any of the following, individual-usage scenarios:

• 2 hours continuous operation in damp grass or vegetation.

• 2 hours continuous operation in heavy fog (95% humidity, saturated air, condensing water).

• 1 hour continuous operation in light rain (<0.10 in/2.5mm per hour).

• 15 minutes continuous operation in heavy rain (>0.30 in/7.6mm per hour).

• 1 hour continuous operation in light sleet (<0.10 in/2.5mm per hour).

• 1 hour continuous operation in light snow (<0.25 in/6.35mm per hour).

• 45 minutes continuous operation in standing or running fresh water (the water

level should always remain below the vehicle frame), or constant splashing

water, without any immersion of waterproof component(s).

• 5 minutes continuous operation in standing or running fresh water (the water level

should never rise higher than 0.5 in (about 10mm) above the vehicle frame), constant

splashing water, or frequent, intermittent immersion of waterproof component(s).

• 1 hour continuous operation in damp sand, dirt, mud or snow (the material

level should always be below the vehicle frame), constant splatter without any

immersion or coverage of waterproof component(s).

Furthermore, when appropriate maintenance procedures (as described below) are

performed promptly following exposure, the ESC will remain best protected from corrosion

or other long-term, water-related damage.

Wet Conditions Maintenance

• Gently rinse the mud and dirt off the ESC with a garden hose.

• Remove the battery pack(s) and dry the contacts.

• If you have an air compressor or a can of compressed air available, blow off

the ESC to help remove any water that may have gotten into small crevices or

corners. Dry any water that may be inside a recessed connector housing.

• Let the ESC air dry before you store it. Water may continue to seep or evaporate

out of tight areas for a few hours.

NOTICE: Never use a pressure washer to clean your vehicle.
