4-462-817-11(2)
SHAKE-6D
Getting Started
USB Transfer
Tuner
Bluetooth
Sound Adjustment
Disc/USB Playback
Other Operations
Additional Information
HOME AUDIO
SYSTEM
Operating Instructions
2
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To reduce the risk of fire, do not cover the
ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.
Do not expose the appliance to naked flame
sources (for example, lighted candles).
To reduce the risk of fire or electric shock, do
not expose this appliance to dripping or
splashing, and do not place objects filled
with liquids, such as vases, on the appliance.
As the main plug is used to disconnect the
unit from the mains, connect the unit to an
easily accessible AC outlet. Should you
notice an abnormality in the unit, disconnect
the main plug from the AC outlet
immediately.
Do not install the appliance in a confined
space, such as a bookcase or built-in cabinet.
Do not expose batteries or appliances with
battery-installed to excessive heat, such as
sunshine and fire.
The unit is not disconnected from the mains
as long as it is connected to the AC outlet,
even if the unit itself has been turned off.
This equipment has been tested and found to
comply with the limits set out in the EMC
Directive using a connection cable shorter
than 3 meters.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
This appliance is classified as a CLASS 1
LASER product. This marking is located on
the rear exterior.
When unpacking or handling a big and/or
heavy speaker, be sure to handle the unit
with two or more persons. Dropping the unit
may cause personal injury and/or property
damage.
For customers in India
Disposal of Old
Electrical &
Electronic Equipment
(Applicable in the
European Union and
other European
countries with
separate collection
systems)
License and Trademark Notice
• is a trademark of DVD Format/Logo
Licensing Corporation.
• “DVD+RW”, “DVD-RW”, “DVD+R”,
“DVD-R”, “DVD VIDEO”, and the “CD”
logos are trademarks.
• MPEG Layer-3 audio coding technology
and patents licensed from Fraunhofer IIS
and Thomson.
• Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
• This product is protected by certain
intellectual property rights of Microsoft
Corporation. Use or distribution of such
technology outside of this product is
prohibited without a license from
Microsoft or an authorized Microsoft
subsidiary.
• “WALKMAN” and “WALKMAN” logo
are registered trademarks of Sony
Corporation.
WARNING
3
• This system incorporates Dolby* Digital.
* Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
• The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by
Sony Corporation is under license. Other
trademarks and trade names are those of
their respective owners.
• The N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the
United States and in other countries.
• Android is a trademark of Google Inc.
• THIS PRODUCT IS LICENSED UNDER
THE MPEG-4 VISUAL PATENT
PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL
USE OF A CONSUMER FOR
(i) ENCODING VIDEO IN
COMPLIANCE WITH THE
MPEG-4 VISUAL STANDARD
(“MPEG-4 VIDEO”)
AND/OR
(ii) DECODING MPEG-4 VIDEO
THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A
PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/
OR WAS OBTAINED FROM A
VIDEO PROVIDER LICENSED
TO PROVIDE MPEG-4 VIDEO.
NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION
INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND
COMMERCIAL USES AND
LICENSING MAY BE OBTAINED
FROM MPEG LA, L.L.C.
HTTP://WWW.MPEGLA.COM
• All other trademarks are trademarks of
their respective owners.
About this manual
• Icons, such as , listed at the top of
each explanation indicate the type of media
that can be used with the function being
explained.
• The default setting is underlined.
4
Table of Contents
About this manual ....................... 3
Playable discs/files on a USB
device...........................................5
Guide to parts and controls........ 10
Getting Started
Hooking up the system
securely...................................... 14
Positioning the speakers ............16
Performing “QUICK” setup ...... 16
Changing the color system
(Except for Russian model)....... 17
Setting the clock ........................ 17
Disc/USB Playback
Basic playback...........................18
Playing a data disc/USB
device......................................... 19
Other playback operations.........20
Using play mode........................ 22
Restricting playback of the
disc (Parental Control)............... 24
Viewing information of a disc
and USB device ......................... 25
Using the Setup Menu ............... 27
USB Transfer
Transferring music..................... 30
Tuner
Listening to the radio................. 34
Bluetooth
About the Bluetooth wireless
technology ................................. 35
Listening to music wirelessly on
a Bluetooth device .....................35
Setting the Bluetooth audio
codecs ........................................38
Setting/Canceling Bluetooth
standby mode.............................39
Sound Adjustment
Adjusting the sound ...................39
Creating your own sound
effect ..........................................39
Creating a party atmosphere
(DJ EFFECT).............................40
Singing along: Karaoke .............40
Other Operations
Changing the illumination
pattern and color ........................42
Using the timers.........................42
Changing the display .................43
Using optional equipment..........43
Deactivating the buttons on the
unit (Child Lock) .......................44
Additional Information
Troubleshooting.........................44
Precautions.................................52
Specifications.............................53
Language code list.....................56
Glossary .....................................58
Index ..........................................60
5
Playable discs/files on a USB device
Type Disc logo Characteristics Icon
DVD VIDEO • DVD VIDEO
• DVD-R/DVD-RW in DVD
VIDEO format or video mode
• DVD+R/DVD+RW in
DVD VIDEO format
VIDEO CD • VIDEO CD (Ver. 1.1 and
2.0 discs)
• Super VCD
• CD-R/CD-RW/CD-ROM
in VIDEO CD format or Super
VCD format
CD • AUDIO CD
• CD-R/CD-RW in AUDIO CD
format
DATA CD – • CD-ROM/-R/-RW in DATA CD
format that contains the following
file formats and conforms to ISO
96601) Level 1/Level 2 or Joliet
(extended format).
– MP3 files2)3)
– JPEG image files4)
– MPEG4 video files5)
– Xvid video files6)
DATA DVD – • DVD-ROM/-R/-RW/+R/+RW in
DATA DVD format that contains
the following file formats and
conforms to UDF (Universal Disk
Format).
– MP3 files2)3)
– JPEG image files4)
– MPEG4 video files5)
– Xvid video files6)
6
1) A logical format of files and folders on CD-ROMs, defined by ISO (International Organization for
Standardization).
2) MP3 (MPEG 1 Audio Layer 3) is a standard format defined by ISO/MPEG for compressed audio
data. MP3 files must be in MPEG 1 Audio Layer 3 format that have a file extension of “.mp3”.
3) Files with copyright protection (Digital Rights Management) cannot be played back by the system.
4) JPEG image files must conform to the DCF image file format. (DCF “Design rule for Camera File
System”: Image standards for digital cameras regulated by Japan Electronics and Information
Technology Industries Association (JEITA).)
5) MPEG4 video files: MPEG4 video files must be recorded in MP4 file format with the extension
“.mp4” or “.m4v”.
Supported video codec and audio codec are as follows:
– Video codec: MPEG4 Simple Profile (AVC is not supported.)
– Audio codec: AAC-LC (HE-AAC is not supported.)
6) Xvid video files must be recorded in Xvid format with the extension “.avi”.
• BDs (Blu-ray Discs)
• CD-ROM/-R/-RW other than those
recorded in the formats listed on page 5
• CD-ROMs recorded in PHOTO CD
format
• Data part of CD-Extra or Mixed CDs*
• CD Graphics disc
• Super Audio CDs
• DVD Audio
• DVD-R/-RW in VR (Video Recording)
mode
• DATA CD/DATA DVD that does not
contain MP3 files, JPEG image files,
MPEG4 or Xvid video files
• DATA CD/DATA DVD that is created in
Packet Write format
• DVD-RAM
• A DVD Video with a different region
code
• CPRM (Content Protection for
Recordable Media) compatible DVD-R/
-RW recorded in Copy-Once programs
• A disc that has a non-standard shape
(e.g., heart, square, star)
• A disc that has adhesive tape, paper, or a
sticker attached to it
* Mixed CD: This format records data on the
first track and audio (AUDIO CD data) on the
second and subsequent tracks of a session.
• In some cases, a CD-R/-RW and
DVD-R/-RW/+R/+RW cannot be
played back on this system due to the
recording quality or physical condition
of the disc, or the characteristics of the
recording device and authoring
software. The disc will not play back if
it has not been correctly finalized. For
more information, refer to the operating
instructions for the recording device.
USB Device – • USB device that contains the
following file formats.
– MP3 files2)3) or WMA/AAC
files3)
– JPEG image files4)
– MPEG4 video files5)
– Xvid video files6)
Type Disc logo Characteristics Icon
Discs that cannot be played
back
Notes on CD-R/-RW and
DVD-R/-RW/+R/+RW
7
• Some playback functions may not work
with some DVD+Rs/+RWs, even if
they have been correctly finalized. In
this case, view the disc by normal
playback.
• A disc created in Packet Write format
cannot be played back.
This product is designed to play back
discs that conform to the Compact Disc
(CD) standard. Recently, various music
discs encoded with copyright protection
technologies are marketed by some record
companies. Please be aware that among
those discs, there are some that do not
conform to the CD standard and may not
be playable by this product.
A DualDiscs is a two sided disc product
which mates DVD recorded material on
one side with digital audio material on the
other side. However, since the audio
material side does not conform to the
Compact Disc (CD) standard, playback
on this product is not guaranteed.
• This system can play back multisession
discs when an MP3 file, a JPEG image
file, an Xvid video file, or an MPEG4
video file is contained in the first
session. Any subsequent MP3 files,
JPEG image files, Xvid video files or,
MPEG4 video files recorded in later
sessions can also be played back (If later
sessions contain AUDIO CD format, the
system cannot play back this
multisession discs).
• If MP3 files and JPEG image files in
AUDIO CD format or VIDEO CD
format are recorded in the first session,
only the first session will be played
back.
Your system has a region code printed on
the rear of the unit and will only play back
a DVD labeled with the same region code.
A DVD VIDEO labeled will also play
back on this system.
If you try to play back any other DVD
VIDEO, the message [Playback
prohibited by area limitations.] will
appear on the TV screen. Depending on
the DVD VIDEO, no region code
indication may be given even though
playing the DVD VIDEO is prohibited by
area restrictions.
Some playback operations on a DVD
VIDEO or VIDEO CD may be
intentionally set by software producers.
Since this system will play back a DVD
VIDEO or VIDEO CD according to the
disc contents the software producers
designed, some playback features may not
be available. Be sure to read the operating
instructions of the DVD VIDEO or
VIDEO CD.
Music discs encoded with
copyright protection
technologies
Note on DualDiscs
Notes on playing multisession
discs
Region code
Note on DVD VIDEO and VIDEO
CD playback operations
ALL
8
• This system cannot play back a DATA
CD/DVD or a USB device in the
following cases:
These numbers may vary depending on
the file or folder configuration.
• This system can play back the following
files.
* USB device only
The system will attempt to play back
any data with the extensions above, even
if it is not in MP3/WMA/AAC/JPEG/
MPEG4/Xvid format. Playing this data
may generate a loud noise which could
damage your speaker system.
• Playback may take a longer time to start
when:
– a DATA CD/DATA DVD/USB
device is recorded with a complicated
tree structure.
– the audio files, image files, or video
files in another folder have just been
played back.
• Some files on DATA CDs/DATA DVDs/
USB devices cannot be played back by
the system depending on the file format.
• The system can play back to a depth of
8 folders only.
• The system may not be able to play back
an audio file, image file, or video file
depending on the file type.
• Folders that have no audio files, image
files, or video files are skipped.
• Files transferred by a device such as a
computer may not be played back in the
order in which they were transferred.
• The playback order may not be
applicable depending on the software
used for creating the audio file, image
file, or video file.
• Compatibility with all MP3/WMA/
AAC encoding/writing software,
recording devices, and recording media
cannot be guaranteed.
• Compatibility with all MPEG4 or Xvid
video encoding/writing software,
recording devices, and recording media
cannot be guaranteed.
• The system may not play back an Xvid
video file when the file has been
combined from two or more Xvid video
files.
• Depending on the Xvid video file, the
picture may be unclear or the sound may
skip.
• The system cannot play back some Xvid
video files that are longer than 2 hours.
Notes on playable files
Condition Disc USB
When the number of
folders (albums)
exceed
300 300
When the number of
files (tracks) exceed
999 2,000
When the number of
files in a folder exceed
650 650
File Extension of the file
MP3 audio file “.mp3”
WMA audio file*“.wma”
AAC audio file*“.m4a”, “.mp4”, or
“.3gp”
JPEG image file “.jpg”, “.jpeg”, or
“.jpe”
MPEG4 video
file
“.mp4” or “.m4v”
Xvid video file “.avi”
9
Check the websites below for the latest
information about compatible USB and
Bluetooth devices.
For customers in Russia:
<http://support.sony-europe.com/>
For customers in other countries/regions:
<http://www.sony-asia.com/support>
• This system is not guaranteed to operate
with all USB devices or memories.
• Although there are a variety of complex
functions for USB devices, the playable
contents of USB devices connected to
the system are music, photo, and video
contents only. For details, refer to the
operating instructions of the USB
device.
• When a USB device is inserted, the
system reads all the files on the USB
device. If there are many folders or files
on the USB device, it may take a long
time to finish reading the USB device.
• Do not connect the system and the USB
device through a USB hub.
• With some connected USB devices,
there may be a delay before an operation
is performed by this system.
• The playback order for the system may
differ from the playback order of the
connected USB device.
• Before using a USB device, make sure
that no virus-ridden files are on the USB
device.
Websites for compatible
devices
Notes about USB devices
10
Guide to parts and controls
This manual mainly explains operations using the remote control, but the same operations
can also be performed using the buttons on the unit having the same or similar names.
Unit
C D C E
HHHH
BA
QR P C N M L
K
J
I
CCCCCC
O
GF
11
Remote control RM-AMP100
1 "/1 (on/standby)
Turn on the system, or set it to
standby mode.
B MUSIC, MOVIE/GAME,
FOOTBALL
Select the preset sound effect
(page 39).
BASS BAZUCA (page 39)
Press to select the BASS BAZUCA
effect.
Hold down to select the BASS CUT
effect.
C +/– (select folder)
Select a folder on a data disc or a
USB device.
Remote control: m/M
(rewind/fast forward)
Find a point in a track or file during
playback.
./> (go back/go forward)
Select a track or file.
TUNING+/–
Tune to the station you want.
PRESET+/–
Select a preset station.
Unit: ENTER
Remote control:
Enter the settings.
Remote control: / / /
Select the menu items.
Remote control: /
Watch the Slow-motion Play.
N1) (play)
Start playback.
X (pause)
Pause playback.
To resume playback, press N.
x (stop)
Stop playback.
Press twice to cancel resume
playback.
D Unit: VOLUME/DJ CONTROL
Adjust the volume.
Adjust the DJ EFFECT level
(page 40).
You cannot use this knob to adjust
the volume when the DJ EFFECT is
activated.
Remote control: DJ
CONTROL +/–
Adjust the DJ EFFECT level
(page 40).
Remote control: VOL +/–1)
Adjust the volume.
1
ql
w;
4
8
3
wa
3
ws
4
wl
e;
ea
wk
wj
qh
8
wh
9
wg
wf
wd
12
E Disc tray
F Z OPEN/CLOSE
Insert or eject a disc.
G (N-Mark) (page 36)
Near Field Communication (NFC)
touchpoint indication.
H LED PATTERN2) (page 42)
Change the illumination pattern on
the speakers and the unit.
LED COLOR2) (page 42)
Change the illumination color on the
speakers and the unit.
Remote control: DVD/TUNER
MENU
Display the DVD menu items on the
TV screen.
Preset a radio station.
Display image files in thumbnail
view.
Remote control: DVD TOP
MENU
Display the DVD title on the TV
screen.
I DVD/CD
Select the DVD/CD function.
Unit: USB/USB SELECT
Remote control: USB
Select the USB function.
Select the USB device connected to
the A or B port during USB
function.
Unit: TUNER/BAND
Select the TUNER function.
Select the FM or AM band during
TUNER function.
Unit: AUDIO IN
Select the TV/SAT or PC/GAME
function.
Remote control: FUNCTION
Select a function.
J Display panel
K Bottom panel (page 15)
L REC TO USB B
Transfer onto the optional USB
device which is connected to the B
port.
M B (REC/PLAY) (USB) port
Connect and transfer to an optional
USB device.
N MIC 1/2 jack
Connect the microphones.
MIC LEVEL (MIN/MAX)
Adjust the microphone volume.
O A (PLAY) (USB) port
Connect an optional USB device.
P FLANGER, ISOLATOR, SOUND
FLASH, PHASER (page 40)
Select the DJ EFFECT type.
Q Remote control sensor
R BLUETOOTH (page 35)
Press to select Bluetooth function.
Hold down to activate Bluetooth
pairing during Bluetooth function.
S Numeric buttons1)
Select a track, chapter or file.
Tune or preset a radio station.
Enter a password.
AUDIO2)
Select the audio format.
SUBTITLE2)
Switch the language of the subtitle.
ANGLE
2)
Change the video angle (DVD
VIDEO with multi-angles only).
SETUP
2) (page 27)
Display the Setup Menu on the TV
screen.
14
Hooking up the system securely
A Antennas
Find a location and an orientation that
provide good reception when you set up
the antennas.
Keep the antennas away from the speaker
cords, the power cord and the USB cable
to avoid picking up noise.
B Speakers
– TWEETERS/WOOFERS and
SUBWOOFERS terminals
The speaker connectors are color-coded
with their respective speaker terminals
on the unit.
Example:
Notes
• Be sure to use only the supplied speakers.
• When connecting speaker cords, insert the
connector straight into the terminals.
Getting Started
AM loop
antenna
Extend the FM lead
antenna horizontally
White
15
Getting Started
– LED SPEAKER terminals
Connect the LED SPEAKER connector
of the speaker to this terminal.
The lighting on the speakers will react
according to the music source. You can
select the illumination pattern and color
according to your preference
(page 42).
Example:
C VIDEO OUT jack
Use a video cord to connect to the video
input jack of a TV or projector.
Note
Do not connect this unit to the TV through the
video deck.
D AUDIO IN jacks
Use an audio cord (not supplied) to
connect to the audio output jacks of the
following equipment. The sound is output
through this system.
– TV/SAT L/R
Connect to a TV or an audio/video
equipment.
– PC/GAME L/R
Connect to a computer or gaming
device.
E Power
Plug the power cord into a wall socket.
The demonstration appears in the display
panel. Press "/1 to turn on the system and
the demonstration automatically ends.
If the supplied adaptor on the plug does
not fit your wall outlet, detach it from the
plug (only for models equipped with an
adaptor).
Insert the two supplied R6 (size AA)
batteries, matching the polarities shown
below.
Notes
• Do not mix an old battery with a new one or
mix different types of batteries.
• If you do not use the remote control for a long
period of time, remove the batteries to avoid
damage from battery leakage and corrosion.
You can attach the supplied bottom panel
to the bottom of the main unit to raise the
front panel and to ease the operations.
1 Insert the hooks of the bottom
panel to the catcher holes on the
bottom of the main unit.
Inserting batteries
Attaching the bottom panel
Hook
Catcher
hole
Main unit
Bottom
panel
16GB
2 Insert the pins of the bottom
panel to the catcher holes. Then,
push the bottom panel until it
locks into the main unit.
Positioning the
speakers
To obtain optimum performance from the
system, we recommend you to place the
speakers as shown below.
A Unit
B Speaker (left)
C Speaker (right)
D TV
Performing “QUICK”
setup
Before using the system, you can make
the minimum basic adjustments in
“QUICK” setup.
1 Turn on your TV and select the
video input.
2 Press "/1 to turn on the system.
3 Press DVD/CD or USB.
4Press without inserting a
disc or connecting a USB
device.
[LANGUAGE SETUP] appears on the
TV screen. Displayed items may vary
depending on country or region.
5Press / repeatedly to select a
language, then press .
The setting is selected and [VIDEO
SETUP] appears on the TV screen.
6Press / repeatedly to select
the setting that matches your TV
type, then press .
After [QUICK SETUP is complete.]
appears on the TV screen, the system is
ready for playback.
To change the setting manually
See “Using the Setup Menu” (page 27).
To quit “QUICK” setup
Hold down SHIFT, then press SETUP.
Catcher hole
Pin
A
B C
D
0.3 m
LANGUAGE SETUP
OSD:
MENU:
AUDIO:
SUBTITLE:
ENGLISH
CHINESE 1
CHINESE 2
THAI
ENGLISH
17GB
Getting Started
Note
The guide message appears when you turn on
the system for the first time or after performing
“RESET” (page 50).
Changing the color
system
(Except for Russian model)
Set the color system to PAL or NTSC
depending on the color system of your
TV.
The default setting for color system is
different depending on the area.
Each time you perform the procedure
below, the color system changes as
follows:
NTSC y PAL
Use the buttons on the unit to perform this
operation.
1Press "/1 to turn on the system.
2Press DVD/CD.
3Hold down ENTER and LED
COLOR for more than 3 seconds.
“COLOR NTSC” or “COLOR PAL”
appears in the display panel.
Setting the clock
You cannot set the clock in Power Saving
Mode.
1 Press "/1 to turn on the system.
2 Press TIMER MENU.
If “PLAY SET” appears in the display
panel, press / repeatedly to
select “CLOCK SET”, then press
.
3Press / repeatedly to set the
hour, then press .
4Press / repeatedly to set the
minutes, then press .
18
Basic playback
1 For DVD/CD function:
Press DVD/CD.
For USB function:
Press USB repeatedly until “USB A”
or “USB B” lights up in the display
panel.
2 For DVD/CD function:
Press Z OPEN/CLOSE on the unit to
open the disc tray and load a disc with
the label facing up on the disc tray.
Press Z OPEN/CLOSE on the unit
again to close the disc tray.
Do not forcibly push the disc tray to
close it as this may cause a
malfunction.
For USB function:
Connect a USB device to the A or
B port.
Note
You can use a USB adaptor (not supplied) to
connect the USB device to the unit if the
USB device cannot be plugged into the
port.
3 Press N to start playback.
To select the playback source or
transferring destination (USB
memory select)
If the USB device has more than one
memory (for example, internal memory
and a memory card), you can select which
memory to use as a playback source or
transferring destination.
Note
You cannot select a memory during playback or
transfer. Make sure to select a memory before
starting playback.
1 Hold down SHIFT, then press
OPTIONS.
2Press / to select “USB MEM
SEL”, then press .
3Press / to select the memory
you want, then press .
Disc/USB Playback
When you play
back an 8 cm
disc such as a
CD single,
place it on the
inner circle of
the tray
USB device
To Press
Stop playback x
Pause playback X
Resume playback
or return to normal
playback
N
Cancel the resume
point
x twice
Select a track, file,
chapter or scene
. > or during
playback.
Or, press the numeric
buttons, then press .
(Operation might be
prohibited by disc or
USB device)
19
Disc/USB Playback
Playing a data disc/
USB device
1 Press DVD/CD or USB.
2 For DVD/CD function:
Load a disc on the disc tray.
For USB function:
Connect a USB device to the A or
B port.
3 Press MEDIA MODE repeatedly
to select the media you want to
play back.
• [MUSIC]: MP3, WMA*, AAC*
• [PHOTO]: JPEG
• [VIDEO]: Xvid and MPEG4
* USB device only.
4 Press N to start playback.
To start playback from a specific file,
see below.
Playing from a specific audio or
video file
1 Press SEARCH to display the
Folder List.
2Press / to select the folder you
want.
3Press to display the Track List or
File List.
4Press / to select the file you
want.
5Press to start playback from the
selected file.
Playing from a specific image file
(slide show)
1 Press DVD/TUNER MENU.
Thumbnail picture for the first 16 JPEG
image files in the selected folder is
displayed on the TV screen.
If there are more than 16 image files in
the selected folder, the scroll bar
appears at the right.
2Press / / / to select the file
you want.
3 Press N to start playback from the
selected file.
FOLDER EARCHS
Alone (1999)
B )ack for Good (1988
In the G rden of Ven (19a us 87)
In the Middle of Nowhere (1986)
Let’s Ta b u 8lk A o t Love (19 5)
Re dy for Roma ance (1986)
Rom 7)antic Warrior (19s 8
1st Albu m (1986)
FILE EARCHS
In the Middle of Nowher...
Give_Me_Pe ce_On_Ea ar t h
In_S ah ire
Lonely_Te _In_Chin towna sra
Riding_On_A_White_S aw n
S S aweet_Little_ hell
Ten_Tho nd_Lonely_Drusa u sm
Geronimo_ dills_Ca a c
1 2 43
5678
9 10 11 12
1 14 15 163
20
Other playback
operations
Depending on the type of disc or file, the
function may not work.
Press the numeric buttons to select the
track you want to play back, then press
.
To search using the SEARCH button
1 Press SEARCH to display the
Track List.
2Press / to select the track you
want to play back, then press .
1 Press SEARCH repeatedly
during playback to select the
search mode.
2 Press the numeric buttons to
enter the title, chapter, scene,
track, or index number you want,
then press .
Playback starts from the selected title,
chapter, track, scene, or index.
Notes
• For VIDEO CD with PBC playback, press
SEARCH to search the scene.
• For VIDEO CD without PBC playback, press
SEARCH to search the track and index.
To Press
View DVD menu DVD/TUNER MENU
View Folder List or
File List
SEARCH
Press SEARCH again to
turn off the Folder List
or File List.
Return to Folder
List when in Track
List or File List
RETURN
Locate a point
quickly in fast
forward or fast
reverse (Lock
Search)
m M or during
playback.
Each time you press
m M or , the
playback speed
changes.
Watch frame by
frame (Slow-
motion Play)
X , then press or
.
Each time you press
or , the playback
speed changes.
View images in
thumbnail view
DVD/TUNER MENU
Navigate in
thumbnail view
/ / /
View single image in thumbnail view.
Start image slide
show
N
You can change the
interval of the slide
show (page 29), and add
effects to the slide show
(page 28).
Stop image slide
show
x
View next or
previous image
during slide show
. > or
Rotate the image
by 90 degrees
/ while viewing a
picture.
Hold down SHIFT, then
press CLEAR to return
to the original view.
Searching a specific track
Searching a specific title/
chapter/scene/track/index
To Press
21
Disc/USB Playback
To search for a particular point
using the time code
1 Press SEARCH repeatedly during
playback to select the time search
mode.
2 Press the numeric buttons to enter
the time code, then press .
Example: To find a scene at 2 hours,
10 minutes, and 20 seconds after the
beginning, press 2, 1, 0, 2, 0
([2:10:20]).
Hold down SHIFT, then press CLEAR
to cancel the number.
To search using the DVD menu
1 Press DVD/TUNER MENU.
2Press / / / or the numeric
buttons to select the title or item you
want to play back, then press .
Hold down SHIFT, then press
ANGLE repeatedly during playback
to select the angle you want.
Hold down SHIFT, then press
SUBTITLE repeatedly during
playback to select the subtitle
language you want or turn off the
subtitle.
Hold down SHIFT, then press
AUDIO repeatedly during playback
to select the audio format or mode
you want.
DVD VIDEO
You can toggle audio format or language
when the source contains multiple audio
formats or multilingual audio.
When 4 digits are displayed, they indicate
a language code. See “Language code
list” (page 56) to confirm which language
the code represents. When the same
language is displayed two or more times,
the DVD VIDEO is recorded in multiple
audio formats.
VIDEO CD/CD/DATA CD/DATA DVD
(MP3 file) or USB device (audio file)
You can change the sound track.
• [STEREO]: The stereo sound.
• [1/L]: The sound of the left channel
(monaural).
• [2/R]: The sound of the right channel
(monaural).
SUPER VIDEO CD
• [1:STEREO]: The stereo sound of audio
track 1.
• [1:1/L]: The sound of the left channel of
audio track 1 (monaural).
• [1:2/R]: The sound of the right channel
of audio track 1 (monaural).
• [2:STEREO]: The stereo sound of audio
track 2.
• [2:1/L]: The sound of the left channel of
audio track 2 (monaural).
• [2:2/R]: The sound of the right channel
of audio track 2 (monaural).
Changing the angles
Displaying the subtitles
Changing the language/sound
23
Disc/USB Playback
x When playing a USB device
• [ALL USB DEVICES (SHUFFLE)]:
shuffle all USB devices.
• [ONE USB DEVICE (SHUFFLE)]:
shuffle a USB device.
• [FOLDER (SHUFFLE)]: shuffle all
compatible files in the folder on the
USB device.
Notes
• Shuffle Play cannot be performed for image
and video files.
• Shuffle Play is canceled when you
– turn off the system.
– open the disc tray.
– perform USB transfer (except REC1
Transfer).
– transfer music from a disc to a USB device
(except REC1 Transfer).
– change MEDIA MODE.
– switch the USB memory select.
• Shuffle Play may be canceled when you select
a folder or a track to play back.
You can make a program of up to 25 steps
in the order you want them to be played
back.
You can only program the audio tracks
from the current disc or USB A.
1 For DVD/CD function:
Press DVD/CD.
For USB function:
Press USB repeatedly until “USB A”
lights up in the display panel.
2( only)
Press MEDIA MODE repeatedly
to select [MUSIC].
3 When playback is stopped, hold
down SHIFT, then press PLAY
MODE repeatedly to select
[PROGRAM].
4 Press SEARCH.
The Folder List or Track List appears
on the TV screen.
5( only)
Press / repeatedly to select
the folder you want, then press
.
File List appears on the TV screen.
6Press / repeatedly to select
the track or file you want, then
press .
The program step number appears on
the left side of the selected track or file.
7 To program other tracks or
audio files in the same folder,
repeat step 6.
To program files on other folders,
press RETURN to return to Folder List
and repeat steps 5 and 6.
8 Press N to start Program Play.
Program List is displayed on the TV
screen.
When the Program Play ends, you can
restart the same program by pressing
N.
To delete a programmed step
1 Use the same procedure as in step
4 and step 5 of “Creating your own
program”.
2Press / to select the track or file
you want to delete, then press .
The program step number on the left
side of the selected track or file
disappears.
To delete the last step from the
Program List
Hold down SHIFT, then press CLEAR.
Creating your own program
(Program Play)
24
To display the Program List
Hold down SHIFT, then press
DISPLAY repeatedly.
To cancel Program Play
When playback is stopped, hold down
SHIFT, then press PLAY MODE
repeatedly to select other play modes.
Notes
• Program Play cannot be performed for image
and video files.
• Program Play is canceled when you
– open the disc tray.
– change MEDIA MODE.
– switch the USB memory select.
• (DVD/CD function only) The program list is
cleared when you open the disc tray.
• (USB function only) The program list is
cleared when you:
– perform the erase operation.
– remove the USB device.
– switch the USB memory select.
Hold down SHIFT, then press
REPEAT repeatedly.
Depending on the type of disc or file,
some settings may not be available.
• [OFF]: does not play back repeatedly.
• [ALL]: repeats all tracks or files in the
selected play mode.
• [DISC]: repeats all contents (DVD
VIDEO and VIDEO CD only).
• [TITLE]: repeats the current title (DVD
VIDEO only).
• [CHAPTER]: repeats the current
chapter (DVD VIDEO only).
• [TRACK]: repeats the current track.
• [FILE]: repeats the current video file.
To cancel Repeat Play
Hold down SHIFT, then press REPEAT
repeatedly to select [OFF].
Notes
• “ ” lights up in the display panel when
Repeat Play is set to [ALL] or [DISC].
• “ ” lights up in the display panel when
Repeat Play is set to [TITLE], [CHAPTER],
[TRACK] or [FILE].
• You cannot perform Repeat Play with VIDEO
CD during PBC playback.
• Depending on the DVD VIDEO, you cannot
perform Repeat Play.
• Repeat Play is canceled when you
– open the disc tray.
– turn off the system (DVD VIDEO and
VIDEO CD only).
– change the function (DVD VIDEO and
VIDEO CD only).
– perform USB transfer (except REC1
Transfer).
– transfer music from a disc to a USB device
(except REC1 Transfer).
– change MEDIA MODE.
– switch the USB memory select.
Restricting playback of
the disc
(Parental Control)
You can limit the playback of DVD
VIDEOs according to a predetermined
level. When a limited scene is played
back, that scene may be skipped or
replaced with different scenes.
1 When playback is stopped, hold
down SHIFT, then press SETUP.
The Setup Menu appears on the TV
screen.
2Press / repeatedly to select
[SYSTEM SETUP], then press
.
3Press / repeatedly to select
[PARENTAL CONTROL], then
press .
Playing repeatedly (Repeat
Play)
25
Disc/USB Playback
4 Enter or re-enter your 4-digit
password using the numeric
buttons, then press .
5Press / repeatedly to select
[STANDARD], then press .
6Press / repeatedly to select a
geographic area as the playback
limitation level, then press .
The area is selected.
When you select [OTHERS t], enter
the area code for the geographic area
you want according to the “Parental
Control area code list” on page 57 by
using the numeric buttons.
7Press / repeatedly to select
[LEVEL], then press .
8Press / repeatedly to select
the level you want, then press
.
The lower the value, the stricter the
limitation.
To turn off the “PARENTAL
CONTROL” function
Set [LEVEL] to [OFF] in step 8.
To play back a disc for which
“PARENTAL CONTROL” is set
1 Load the disc and press N.
The display for entering your password
appears on the TV screen.
2 Enter your 4-digit password using
the numeric buttons, then press .
The system starts playback.
If you forget your password
Remove the disc and repeat steps 1 to 3 of
“Restricting playback of the disc”
(page 24). When you are asked to enter
your password, enter “199703” using the
numeric buttons, then press . The
display will ask you to enter a new 4-digit
password. After you enter a new 4-digit
password, reload the disc and press N.
When the display for entering your
password appears, enter your new
password.
Viewing information of
a disc and USB device
Hold down SHIFT, then press
DISPLAY repeatedly during
playback.
1 [T **: : : : /D : : ]** **/C ** ** ** ** ** **
Playing time of the current title, track/
chapter/disc
[T-**: : : :** **/C-** ** ** ** ** **/D- : : ]
Remaining time of the current title,
track/chapter/disc
[ : : ]** ** **
Playing time of the current scene/
video file
Information on the TV screen
1 2 3 4
5
6
7
26
[ / / ]**** ** ** 1)
Date information of the current JPEG
image file
2 Bit rate
Appears when playing an audio file.
3 File type
Appears when playing an audio/JPEG
image/video file.
4 Playback status
5 Title2)/track/file name3)
Appears when playing an audio/JPEG
image/video file.
6 Album2)/folder name3)/chapter/
index number
Appears when playing an audio/JPEG
image/video file.
7 Artist name2)3)
Appears when playing an audio file.
1) Date information is displayed when the Exif
(Exchangeable Image File Format) is
recorded in the JPEG image file. Exif is a
digital camera image format defined by the
Japan Electronics and Information
Technology Industries Association (JEITA).
2) If an audio file has an ID3 tag, the system will
display an album name/title name/artist name
from the ID3 tag information. The system can
support ID3 ver 1.0/1.1/2.2/2.3.
3) If the file or folder contains characters which
cannot be displayed, those characters will be
displayed as “_”.
Notes
• Depending on the source being played,
– some information may not be displayed.
– some characters cannot be displayed.
• Depending on the play mode, the information
displayed may be different.
Displaying the audio information
(DVD VIDEO and video files only)
Hold down SHIFT, then press
AUDIO repeatedly during playback.
When playing a DVD VIDEO:
For example, in Dolby Digital format,
multiple signals ranging from monaural to
5.1 channel signals can be recorded on a
DVD VIDEO.
Example: For Dolby Digital 5.1 channel
When playing a video file:
Example: For MP3 format
Press DISPLAY repeatedly when
the system is on.
You can view the information as follows:
– playing time, remaining time of track,
title, chapter
– scene number
– file name, folder name
– title, artist and album information
Notes
• The disc name or track name may not be
displayed depending on the text.
• Playing time of MP3 files and video files may
not be displayed correctly.
Information in the display
panel
2 Surround components
2 Front components +
1 Center component
1 LFE (Low Frequency
Effect) component
Bit rate
27
Disc/USB Playback
Using the Setup Menu
By using the Setup Menu, you can make
various adjustments to items such as
picture and sound.
Displayed items vary depending on the
country or region.
Note
Playback settings stored in the disc take priority
over the Setup Menu settings. Therefore, some
of the Setup Menu settings may not be
performed.
1 When playback is stopped, hold
down SHIFT, then press SETUP.
2Press / repeatedly to select
the setup item from the
displayed list: [LANGUAGE
SETUP], [VIDEO SETUP],
[AUDIO SETUP], or [SYSTEM
SETUP], then press .
3Press / repeatedly to select
the item you want, then press
.
4Press / repeatedly to select
the setting you want, then press
.
The setting is selected and setup is
completed.
[OSD]
Switches the language of the on-screen
display.
[MENU]
Select the language for the DVD menu.
[AUDIO]
Switches the language of the sound track.
When you select [ORIGINAL], the
language given priority in the disc is
selected.
[SUBTITLE]
Switches the language of the subtitle
recorded on the DVD VIDEO.
When you select [AUDIO FOLLOW], the
language for the subtitles changes
according to the language you selected for
the sound track.
Note
If you select [OTHERS t] in [MENU],
[AUDIO], and [SUBTITLE], enter a language
code from the “Language code list” (page 56)
using the numeric buttons.
Setting the language –
LANGUAGE SETUP
29
Disc/USB Playback
[PHOTO INTERVAL]
(JPEG image files only)
Select the slide show duration.
[NORMAL]: You can set to the standard
duration.
[FAST]: You can set the duration shorter
than [NORMAL].
[SLOW 1]: You can set the duration
longer than [NORMAL].
[SLOW 2]: You can set the duration
longer than [SLOW 1].
[AUDIO DRC]
(Dynamic Range Compression)
Useful for watching movies at low
volume late at night.
[OFF]: No compression of dynamic
range.
[STANDARD]: Reproduces the sound
track with the kind of dynamic range that
the recording engineer intended.
[TRACK SELECTION]
Gives priority to the sound track which
contains the highest number of channels
when you play back a DVD VIDEO on
which multiple audio formats (PCM,
MPEG audio, or Dolby Digital) are
recorded.
[OFF]: No priority given.
[AUTO]: Priority given.
[SCORE MODE]
Select the scoring mode to rate your
singing when in Karaoke Mode.
[BEGINNER 1]: Beginner level. The
score is displayed while singing.
[BEGINNER 2]: Beginner level.
[EXPERT 1]: Advance level. The score
is displayed while singing.
[EXPERT 2]: Advance level.
[DEMO]: Demonstration mode. The
score is displayed regardless of singing.
[A/V SYNC]
(Video files only)
Adjusts the delay between the picture and
sound.
[OFF]: Does not adjust.
[ON]: Adjusts the difference between
picture and sound.
[DOWNMIX]
Select the audio output signal for playing
a multi-channel audio.
[NORMAL] : Output multi-channel
audio into a 2-channel stereo signal.
[DOLBY SURROUND]: Output multi-
channel audio into a 2-channel surround
signal.
Setting the audio options –
AUDIO SETUP
30
[SCREEN SAVER]
The screen saver will help prevent your
display device from becoming damaged
(ghosting). Press any button to cancel the
screen saver.
[ON]: The screen saver image appears if
you do not operate the system for about 15
minutes.
[OFF]: Off.
[BACKGROUND]
Selects the background color or picture to
be displayed on the TV screen.
[JACKET PICTURE]: The jacket
picture (still picture) appears in the
background, but only when the jacket
picture is already recorded on the disc.
[GRAPHICS]: A preset picture stored in
the system appears in the background.
[BLUE]: The background color is blue.
[BLACK]: The background color is
black.
[PARENTAL CONTROL]
Sets the playback restrictions. For details,
see “Restricting playback of the disc”
(page 24).
[MULTI-DISC RESUME]
[ON]: Stores the resume playback point
in the memory for up to 6 discs.
[OFF]: Does not store the resume
playback point in the memory. Playback
starts at the resume playback point only
for the current disc in the system.
[RESET]
Returns “SETUP” settings (except for
“PARENTAL CONTROL” settings) to
the default settings. For details, see
“Returning the “SETUP” settings to the
default” (page 50).
Transferring music
You can transfer music from a sound
source to a USB device connected to the
B port.
The audio format of files transferred by
this system is MP3. However, you can
also transfer WMA and AAC files from
USB A.
Notes
• Do not remove the USB device during
transfer or erase operations. Doing so may
corrupt the data on the USB device or damage
the USB device itself.
• MP3/WMA/AAC files are transferred with
the same bit rate as the original files.
• When transferring from an AUDIO CD,
TUNER, TV/SAT, or PC/GAME function,
you may select the bit rate before transferring.
• USB transfer and erase operations are
disabled while the disc tray is open.
Note on copyright-protected
content
The transferred music is limited to private
use only. Use of the music beyond this
limit requires permission of the copyright
holders.
To select the playback source or
transferring destination (USB
memory select)
See page 18.
To select the bit rate
You can select a higher bit rate to transfer
music with better quality.
1 Hold down SHIFT, then press
OPTIONS.
2Press / repeatedly to select
“REC BIT RATE”, then press .
Setting the system –
SYSTEM SETUP
USB Transfer
31
USB Transfer
3Press / repeatedly to select the
bit rate you want, then press .
• 128 KBPS: encoded MP3 tracks have
smaller file size and lower audio
quality.
• 256 KBPS: encoded MP3 tracks have
bigger file size but higher audio
quality.
You can easily transfer all the music on a
disc or USB A to USB B (Synchronized
Transfer). You can also transfer a single
track or audio file during playback
(REC1 Transfer).
Use the buttons on the unit to perform this
operation.
1 Connect a transferable USB
device to the B port as shown
below.
Note
You can use a USB adaptor (not supplied) to
connect the USB device to the unit if the
USB device cannot be plugged into the
port.
2 For disc:
Press DVD/CD and then load the disc.
If the system starts playback
automatically, press x twice to stop
the playback fully.
For USB:
Press USB/USB SELECT repeatedly
until “USB A” lights up in the display
panel and then connect a USB device
you want to transfer to A port.
3 For Synchronized Transfer:
When playback is stopped, hold down
SHIFT, then press PLAY MODE on
the remote control repeatedly to select
the play mode you want.
Notes
• If you start transferring in [FOLDER
(SHUFFLE)], the selected play mode
changes to [FOLDER] automatically.
• If you start transferring in Shuffle Play
(except [FOLDER (SHUFFLE)]), Repeat
Play or Program Play with no steps, the
selected play mode changes to Normal
Play automatically.
For REC1 Transfer:
Select the track or audio file you want
to transfer then start playback.
4 Press REC TO USB B.
“PUSH ENTER” appears in the
display panel.
5 Press ENTER.
The transfer starts when “DON’T
REMOVE” appears in the display
panel.
For Synchronized Transfer:
When the transfer is completed, the
transfer source and the USB device
stop automatically.
For REC1 Transfer:
When the transfer is completed, the
disc or the USB device continues to
play.
Transferring music from a disc
or USB device
USB device
32
You can transfer sound from an analog
audio source (other than DVD/CD, USB
or Bluetooth function) to a USB device.
Use the buttons on the unit to perform this
operation.
1 Connect a transferable USB
device to the B port (page 31).
2 Press TUNER/BAND or AUDIO IN
repeatedly to select the source
you want to transfer.
3 Press REC TO USB B.
“PUSH ENTER” appears in the
display panel.
4 Press ENTER.
The transfer starts when “DON’T
REMOVE” appears in the display
panel.
5 Start playback the source.
To stop transferring
Press x.
To create a new MP3 file
Press REC TO USB B during Analog
Transfer.
“NEW TRACK” appears in the display
panel.
A new MP3 is also created automatically
after approximately 1 hour of transfer.
Notes
• When a new MP3 file is created, transfer is
disabled for the time being.
• If you press REC TO USB B again after a few
seconds, a new MP3 file can be created.
1 Press USB repeatedly until
“USB A” or “USB B” lights up in
the display panel.
2 When playback is stopped, hold
down SHIFT, then press
OPTIONS.
3Press / repeatedly to select
“USB ERASE”, then press .
The Folder List is displayed on the TV
screen.
4Press / to select a folder,
then press .
5Press / to select the audio
file you want to erase, then
press .
Select [ALL TRACKS] to select all
audio files in the folder.
“FOLDER ERASE” or “TRACK
ERASE” and “PUSH ENTER”
appears in the display panel.
To cancel, press x.
6 Press .
“COMPLETE” appears in the display
panel.
Note
A folder that contains non-MP3/WMA/AAC
format audio files or sub folders cannot be
erased.
Transferring analog audio
(Analog Transfer)
Erasing audio files or folders
on the USB device
33
USB Transfer
Maximum number of MP3 files that
can be generated
• 298 folders
• 650 files in a folder
• 650 files in REC1-CD or REC1-MP3
folder.
These numbers may vary depending on
the file or folder configuration.
When transferring onto a USB device, a
“MUSIC” folder is created directly below
the “ROOT”. Folders and files are
generated within this “MUSIC” folder as
follows according to the transferring
method and source.
Synchronized Transfer
REC1 Transfer
Analog Transfer
*Folder and file numbers are assigned serially
thereafter.
Notes on transferring
• While transferring (except analog transfer),
no sound is output.
• CD-TEXT information is not transferred in
the created MP3 audio files.
• The transfer stops automatically if:
– the USB device runs out of space during
transfer.
– the number of audio files or folders on the
USB device reaches the limit.
• If a folder or file that you are trying to transfer
already exists on the USB device with the
same name, a sequential number is added after
the name without overwriting the original
folder or file.
• You cannot perform the following operations
during a transfer:
– Eject the disc.
– Select another track or file.
– Pause playback or find a point in the track or
file.
– Change the function or tuner band.
• When transferring music to a Walkman
®
using “Media Manager for WALKMAN”, be
sure to transfer in MP3 format.
• When connecting a Walkman
® to the system,
be sure to connect after the display “Creating
Library” or “Creating Database” on the
Walkman
® has disappeared.
Folder and file generation
rules
Source Folder name File name
Audio files Same as the source
AUDIO CD “CDDA0001”*“TRACK001”*
Source Folder name File name
Audio files “REC1-MP3” Same as the
source
AUDIO CD “REC1-CD” “TRACK001”*
Source Folder name File name
FM “TUFM0001”*“TRACK001”*
AM “TUAM0001”
*
PC/GAME “EXPG0001”*
TV/SAT “EXTS0001”*
34
Listening to the radio
1Press FUNCTION repeatedly to
select FM or AM band.
2 For automatic scanning:
Hold down TUNING+/– until the
frequency indication changes and then
release. “AUTO” lights up in the
display panel.
Scanning stops automatically when a
station is tuned in. “TUNED” and
“ST” (for FM stereo programs only)
light up in the display panel.
If “TUNED” does not light up and
scanning does not stop, press x to stop
scanning. Then, perform manual
tuning (below).
For manual tuning:
Press TUNING+/– repeatedly to tune
to the station you want.
For direct tuning:
Press D.TUNING, then press the
numeric buttons to enter the frequency
of the station you want. For example,
press 1, 0, 2, 5 and 0 to enter the
frequency of FM 102.50 MHz.
Press . If you cannot tune in the
station, make sure you have entered
the right frequency used in your area.
To cancel direct tuning, press
D.TUNING again.
Note
When you tune to an FM station that provides
RDS services, information such as the service
name or station name is provided by broadcasts.
You can check the RDS information by pressing
DISPLAY repeatedly.
Tip
To reduce static noise on a weak FM stereo
station, hold down SHIFT, then press FM
MODE repeatedly until “MONO” lights up in
the display panel.
To change the AM tuning interval
(Except for Saudi Arabian and
Russian models)
The default setting for AM tuning interval
is 9 kHz (or 10 kHz for some areas). You
cannot change the AM tuning interval in
Power Saving Mode.
Use the buttons on the unit to perform this
operation.
1 Press TUNER/BAND repeatedly to
select AM band.
2 Press "/1 to turn off the system.
3 While holding down X, press
"/1.
“AM 9K STEP” or “AM 10K STEP”
appears in the display panel.
When you change the interval, all the
AM preset stations are erased.
You can store up to 20 FM and 10 AM
stations as your favorite stations.
1 Tune to the station you want.
2 Press DVD/TUNER MENU.
3Press / repeatedly to select
the preset number you want,
then press .
“COMPLETE” appears in the display
panel. The station is stored.
To tune to a preset station
Press PRESET+/– repeatedly to select the
preset number you want.
You can also press the numeric buttons,
then press to select a preset station.
Tuner
Presetting radio stations
Preset number
36
4 Perform the pairing procedure
on the Bluetooth device.
For details, refer to the operating
instructions of your Bluetooth device.
5 Select the model number of the
unit on the display of the
Bluetooth device.
For example, select “SONY:SHAKE-
6D”.
If passkey is required on the Bluetooth
device, enter “0000”.
6 Perform the Bluetooth
connection on the Bluetooth
device.
When pairing is completed and the
Bluetooth connection is established,
the Bluetooth device name appears in
the display panel.
Depending on the Bluetooth device,
connection may start automatically
after pairing is completed.
You can check the Bluetooth device
address by pressing DISPLAY
repeatedly.
Notes
• You can pair up to 9 Bluetooth devices. If the
10th Bluetooth device is paired, the least
recently connected device will be replaced by
the new one.
• “Passkey” may be called “Passcode”, “PIN
code”, “PIN number”, or “Password”, etc.,
depending on the device.
• The pairing standby status of the system is
canceled after about 5 minutes. If pairing is
not successful, repeat from step 1.
• While connected to a Bluetooth device, this
system cannot be detected and connection
cannot be established from another Blueto o th
device which is never paired before.
• If you want to pair with another Bluetooth
device, repeat steps 1 to 6.
To cancel pairing operation
Hold down BLUETOOTH on the unit for
2 seconds or more until “BLUETOOTH”
appears in the display panel.
By touching the system with an NFC-
compatible smartphone, the system is
turned on in Bluetooth function
automatically, and then proceeds to
complete pairing and the Bluetooth
connection automatically.
What is “NFC”?
NFC (Near Field Communication) is a
technology enabling short-range wireless
communication between various devices,
such as mobile phones and IC tags.
Thanks to the NFC function, data
communication can be achieved easily
just by touching the designated touchpoint
on the NFC-compatible devices.
1 Download and install the app
“NFC Easy Connect”.
Download the free Android app from
Google Play by searching for “NFC
Easy Connect” or access it by using the
two-dimensional code below. Data
communication fees may be charged.
Two-dimensional code* for
direct access
* Use a two-dimensional code reader app.
Notes
• The app may not be available in some
countries/regions.
• Depending on your smartphone, you can
use the NFC function without installing
the app. In this case, the operations and
specifications may be different. For
details, refer to the operating instructions
of your smartphone.
Connecting with a smartphone
by one touch (NFC)
37
Bluetooth
2 Start the app “NFC Easy
Connect” on the smartphone.
Make sure that the application screen
is displayed.
3 Touch the smartphone to the
N-Mark on the system until the
smartphone vibrates.
Complete the connection by following
the instructions displayed on the
smartphone.
When the Bluetooth connection is
established, the BLUETOOTH
indicator stops flashing and remains
light up. Bluetooth device name
appears in the display panel.
You can switch the sound source from
the smartphone to another NFC-
compatible Bluetooth device.
For details, refer to the operating
instructions of your Bluetooth device.
Tip
If pairing and the Bluetooth connection fail, do
the following.
– Relaunch “NFC Easy Connect” and move the
smartphone slowly over the N-Mark.
– Remove the case from the smartphone if using
a commercially available smartphone case.
You can operate a Bluetooth device by
connecting the system and a Bluetooth
device using AVRCP.
Check the following before playing
music:
– The Bluetooth function of the Bluetooth
device is turned on.
– Pairing has been completed.
xFor a device
1 Press BLUETOOTH on the unit
to select Bluetooth function.
“BLUETOOTH” appears in the
display panel.
2 Establish connection with the
Bluetooth device.
The last connected Bluetooth device
will be connected automatically.
Perform the Bluetooth connection
from the Bluetooth device if the device
is not connected.
Once the connection is established, the
Bluetooth device name appears in the
display panel.
3 Press N.
Depending on the Bluetooth device,
– you may have to press N twice.
– you may need to start playback of an
audio source on the Bluetooth
device.
Notes
• When the system is not connected to any
Bluetooth device, the system will connect and
playback from the last connected Bluetooth
device automatically when you press N.
• If you try to connect another Bluetooth device
to the system, the current connected Bluetooth
device will be disconnected.
Compatible smartphones
Smartphones with a built-in NFC
function (OS: Android 2.3.3 or later,
excluding Android 3.x)
Playing music from a
Bluetooth device
38
xFor an NFC-compatible
smartphone
Touch the smartphone to the N-Mark on
the system to establish the Bluetooth
connection.
Start playback of an audio source on the
smartphone. For details on playback, refer
to the operating instructions of your
smartphone.
To disconnect the Bluetooth device
xFor a device
Press BLUETOOTH on the unit.
“BLUETOOTH” appears in the display
panel.
Depending on the Bluetooth device, the
Bluetooth connection may be canceled
automatically when you stop playback.
xFor an NFC-compatible
smartphone
Touch the smartphone to the N-Mark on
the system again.
Use the buttons on the unit to perform this
operation.
1 Press BLUETOOTH to select
Bluetooth function.
“BLUETOOTH” appears in the
display panel.
If the system is connected to a
Bluetooth device, the Bluetooth device
name appears in the display panel.
Press BLUETOOTH to disconnect the
Bluetooth device.
2 Hold down X and PHASER for
about 3 seconds.
“PAIR HISTORY” and “CLEAR”
appear in the display panel and all the
pairing information is erased.
Setting the Bluetooth
audio codecs
You can select the Bluetooth audio codecs
when the connected Bluetooth device
supports Advanced Audio Coding
(AAC).
1 Hold down SHIFT, then press
OPTIONS.
2Press / repeatedly to select
“BT AAC”, then press .
3Press / repeatedly to select
“BT AAC ON” or “BT AAC OFF”.
• BT AAC ON: Advanced Audio
Coding (AAC) is selected if the
Bluetooth device supports AAC.
• BT AAC OFF: Sub Band Codec
(SBC) is selected.
Notes
• You can enjoy high quality sound if the AAC
is selected. In case you cannot listen to AAC
sound from your device, select “BT AAC
OFF”.
• If you change this setting while the system is
connected to a Bluetooth device, the
Bluetooth device will be disconnected. To
connect to the Bluetooth device, perform the
Bluetooth connection again.
Erasing all the pairing
registration information
39
Sound Adjustment
Setting/Canceling
Bluetooth standby
mode
The system goes into Bluetooth standby
mode and waits for a Bluetooth
connection, even when the system is
turned off.
1 Hold down SHIFT, then press
OPTIONS.
2Press / repeatedly to select
“BT STANDBY”, then press .
3Press / repeatedly to select
“ON” or “OFF”.
4 Press ?/1 to turn off the system.
When Bluetooth standby mode is set to
on, the system will turn on
automatically when you establish the
Bluetooth connection from the
Bluetooth device.
Note
The system will not enter Bluetooth standby
mode if you erase the pairing information.
Adjusting the sound
Creating your own
sound effect
You can raise or lower the levels of
specific frequency bands and then store
the setting in the memory as “USER EQ”.
1 Hold down SHIFT, then press
OPTIONS.
2Press / repeatedly to select
“EQ EDIT”, then press .
Sound Adjustment
To Do this
Reinforce the
bass and create
a more powerful
sound
Press BASS BAZUCA on
the unit.
Reduce the bass
sound (BASS
CUT)
Hold down BASS
BAZUCA on the unit for
2 seconds or more.
To cancel the BASS CUT
effect, press BASS
BAZUCA again.
Notes
• The BASS BAZUCA
indicator flashes when
BASS CUT effect is
turned on.
• The BASS CUT effect is
turned off automatically
when you turn off the
system.
Select a preset
sound effect
Hold down SHIFT, then
press MUSIC, MOVIE/
GAME, or FOOTBALL.
To cancel preset sound
effect, hold down SHIFT,
then press MUSIC
repeatedly to select
“FLAT”.
40
3Press / repeatedly to adjust
the equalizer level, then press
.
4 Repeat step 3 to adjust the level
of other frequency bands and
surround effect.
The user equalizer setting is stored
when “USER EQ” appears in the
display panel.
To bring up the user equalizer
setting
Hold down SHIFT, then press MUSIC
repeatedly to select “USER EQ”.
Creating a party
atmosphere
(DJ EFFECT)
1 Press the following button to
select the effect type.
The selected button lights up and the
effect is activated.
• FLANGER: Create a deep flanging
effect that is similar to the roar of a
jet plane.
• ISOLATOR: Isolate a specific
frequency band by adjusting the
other frequency bands. For example,
when you want to focus on vocal and
etc.
• SOUND FLASH: Flash the sound
output. The sound cuts off
periodically.
• PHASER: Create a series of peaks
and troughs in the frequency
spectrum, like a sweeping effect.
2 Press DJ CONTROL +/– to adjust
the effect level.
To turn off the effect
Press the selected effect button again.
Notes
• The DJ EFFECT is automatically turned off
when you turn off the system or change the
function or tuner band.
• If you activate the DJ EFFECT during
transferring, the sound effect will not be
transferred onto the USB device.
• You cannot use VOLUME/DJ CONTROL on
the unit to adjust the volume when the DJ
EFFECT is activated.
Press VOL +/– on the remote control to adjust
the volume.
Singing along: Karaoke
1 Press DVD/CD or USB to select
“DVD/CD” or “USB”.
2 Turn MIC LEVEL on the unit to
MIN to reduce the microphone
volume level.
3 Connect an optional microphone
to MIC 1 or MIC 2 jack on the unit.
Connect another optional microphone
if you want to sing in duet.
4 Start playing the music and
adjust the volume. Press
ECHO +/– to adjust the echo
effect.
5 Start singing along with the
music.
To turn off the Karaoke Mode
Disconnect all the microphones or press
KARAOKE MODE.
Frequency band Equalizer level
Preparing for karaoke
41
Sound Adjustment
Notes
• Karaoke Mode is automatically turned off
when you
– turn off the system.
– change the function.
– disconnect all the microphones.
• If howling occurs:
– move the microphone away from the
speakers.
– change the direction of the microphone.
– lower the MIC LEVEL.
– press VOL – or ECHO – repeatedly.
• The sound from the microphone will not be
transferred onto the USB device during USB
transferring.
Press KEY CONTROL 2 #/ to suit
your vocal range in Karaoke Mode.
You can enjoy karaoke with a stereo-
recorded track, audio file, or video file,
even if it is a non-karaoke disc or media,
by reducing the sound of the vocals.
Press KARAOKE PON in Karaoke
Mode.
“K.PON ON” appears in the display
panel.
To cancel Karaoke Pon Mode
Press KARAOKE PON again.
When Karaoke Mode is turned on, you
can use the scoring mode.
Your score is calculated from a scale of 0
to 99 by comparing your voice with the
music source.
1 Start playing the music.
2 Hold down SHIFT, then press
SCORE before singing a song in
Karaoke Mode.
3 After singing for more than a
minute, hold down SHIFT, then
press SCORE again to view your
score.
To select the rating of the Score
Mode
See [SCORE MODE] in “Setting the
audio options – AUDIO SETUP”
(page 29).
Changing the key (Key Control)
Playing karaoke with any
stereo track, audio file, or
video file (Karaoke Pon)
Selecting the scoring mode
(Score Mode)
42
Changing the
illumination pattern
and color
Hold down SHIFT, then press LED
PATTERN or LED COLOR to select
the illumination pattern or color.
Hold down SHIFT, then press LED
PATTERN or LED COLOR to show
current setting. Press again to change the
illumination pattern or color on the unit
and the speakers instantaneously.
To turn off the illumination, hold down
SHIFT, then press LED PATTERN
repeatedly to select “PATTERN OFF”.
Using the timers
The system offers three timer functions.
You cannot activate both the Play Timer
and the Recording Timer at the same time.
If you use either with the Sleep Timer, the
Sleep Timer has priority.
You can fall asleep when listening to
music. The system turns off after the
preset time.
Press SLEEP repeatedly.
To cancel Sleep Timer, press SLEEP
repeatedly to select “SLEEP OFF”.
Tip
To check the remaining time before the system
turns off, press SLEEP.
Make sure you have set the clock.
Play Timer:
You can wake up to disc, tuner, or USB
device at a preset time.
Recording Timer:
You can transfer music from a preset radio
station into a USB device at a specified
time.
1 For Play Timer:
Prepare the sound source, then press
VOL +/– to adjust the volume.
To start from a specific track or file,
create your own program (page 23).
For Recording Timer:
Tune to the preset radio station
(page 34).
2 Press TIMER MENU.
3Press / repeatedly to select
“PLAY SET” or “REC SET”, then
press .
4 Set the time to start playback or
transferring.
Press / repeatedly to set the hour/
minute, then press .
5 Use the same procedure as in
step 4 to set the time to stop
playback or transferring.
6Press / repeatedly to select
the sound source you want, then
press .
For Recording Timer:
Connect a transferable USB device to
the B port.
7 Press "/1 to turn off the system.
Other Operations
Sleep Timer
Play Timer/Recording Timer
43
Other Operations
To check the timer setting or
activate the timer again
1 Press TIMER MENU.
“TIMER SELECT” flashes in the
display panel.
2 Press .
3Press / repeatedly to select
“PLAY SELECT” or “REC
SELECT”, then press .
To cancel the timer
Repeat the same procedure as above and
select “TIMER OFF” in step 3, and then
press .
Notes
• The system turns on before the preset time. If
the system is turned on at the preset time or if
“STANDBY” flashes in the display panel, the
Play Timer and the Recording Timer will not
play or transfer.
• Do not operate the system from the time the
system turns on until the playback or transfer
starts.
Changing the display
Press DISPLAY repeatedly while
the system is turned off.
Demonstration
The display changes and the indicator
flashes even when the system is turned
off.
No display (Power Saving Mode)
The display is turned off to conserve
power. The timer and clock continue to
operate.
Clock
The clock display automatically turns to
Power Saving Mode after a few seconds.
1 Hold down SHIFT, then press
OPTIONS.
2Press / repeatedly to select
“SPECTRUM”, then press .
3Press / repeatedly to select
the spectrum pattern you want,
then press .
To exit the options menu, hold down
SHIFT, then press OPTIONS.
Using optional
equipment
1Press VOL – repeatedly until
“VOLUME MIN” appears in the
display panel.
2 Connect an optional equipment
(page 15).
3 Press FUNCTION repeatedly to
select the function which
corresponds to the connected
equipment.
4 Start playing the connected
equipment.
5 Press VOL + repeatedly to adjust
the volume.
Changing the display mode
Changing the spectrum
pattern of the display panel
44
Deactivating the
buttons on the unit
(Child Lock)
You can deactivate the buttons on the unit
(except "/1) for preventing
misoperation, such as child mischief.
Hold down x on the unit for more
than 5 seconds.
“CHILD LOCK” and “ON” appear in the
display panel.
You can only operate the system using the
buttons on the remote control.
To cancel, hold down x on the unit for
more than 5 seconds until “CHILD
LOCK” and “OFF” appear in the display
panel.
Note
Child Lock function will be canceled when you
disconnect the power cord.
Troubleshooting
Should you encounter a problem with
your system, find your problem in the
troubleshooting checklist below and take
the corrective action.
If the problem persists, consult your
nearest Sony dealer.
Note that if the service personnel changes
some parts during repair, these parts may
be retained.
General
The clock or timer setting is canceled.
• The power cord is disconnected or a
power failure occurred. Set the clock
(page 17) and timer (page 42) again.
There is no sound.
• Adjust the volume.
• Check the speaker connections
(page 14).
• Check the connection of the optional
equipment, if any (page 15).
• Turn on the connected equipment.
• There is no audio output during
Recording Timer.
Additional Information
If “PROTECT EXX” (X is a number)
appears in the display panel
Immediately unplug the power cord,
and check the following items.
• Are you using only the supplied
speakers?
• Is anything blocking the ventilation
holes of the unit?
After checking the above items and
fixing any problems, plug in the power
cord again and turn on the system. If
the issue persists, consult your nearest
Sony dealer.
45
Additional Information
There is no microphone sound.
• Adjust the microphone volume.
• Make sure the microphone is connected
to the MIC 1 or MIC 2 jack correctly.
• Make sure the microphone is turned on.
There is severe hum or noise.
• Move the system away from sources of
noise.
• Connect the system to a different wall
outlet.
• Install a noise filter (commercially
available) to the power cord.
• Turn off surrounding electrical
equipment.
The timer does not function.
• Check the timer setting and set the
correct time (page 42).
• Cancel the Sleep Timer function
(page 42).
The remote control does not function.
• Remove the obstacles between the
remote control and the unit.
• Move the remote control closer to the
unit.
• Point the remote control at the unit’s
sensor.
• Replace the batteries (R6/size AA).
• Move the unit away from the
fluorescent light.
There is acoustic feedback.
• Reduce the volume.
• Move the microphone away from the
speakers or change the direction of the
microphone.
The color irregularity on a TV screen
persists.
• Turn off the TV at once, then turn it on
after 15 to 30 minutes. If the color
irregularity still persists, place the
speakers farther away from the TV.
“CHILD LOCK” appears when you
press any button on the unit.
• Set the Child Lock function to off
(page 44).
Speakers
Sound comes from one channel or
unbalanced left and right volume.
• Place the speakers as symmetrically as
possible.
• Check that the speakers are connected
securely and correctly.
• The source being played back is
monaural.
There is no sound from a specific
speaker.
• Check that the speaker is connected
securely and correctly.
Disc player
The disc tray does not open and
“LOCKED” appears in the display
panel.
• Consult your nearest Sony dealer or
local authorized Sony service facility.
The disc tray does not close.
• Load the disc correctly.
The disc does not eject.
• You cannot eject the disc during CD-
USB Synchronized Transfer or REC1
Transfer. Press x to cancel the transfer,
then press Z OPEN/CLOSE on the unit
to eject the disc.
• Consult your nearest Sony dealer.
Playback does not start.
• Wipe the disc clean (page 52).
• Reload the disc.
• Load the disc that this system can play
back (page 5).
• Remove the disc and wipe away the
moisture on the disc, then leave the
system turned on for a few hours until
the moisture evaporates.
• The region code on the DVD VIDEO
does not match the system.
46
The sound skips.
• Wipe the disc clean (page 52).
• Reload the disc.
• Move the unit to a place with no
vibration (e.g., on top of a stable stand).
• Move the speakers away from the unit,
or place them on separate stands. When
you listen to a track with bass sounds at
high volume, the speaker vibration may
cause the sound to skip.
Playback does not start from the first
track.
• Set the play mode to Normal Play
(page 22).
• Resume Play has been selected. Press x
twice. Then, press N to start playback.
You cannot perform some functions
such as Stop, Lock Search, Slow-
motion Play, Repeat Play, Shuffle
Play, or Program Play.
• Depending on the disc, you may not be
able to do some of the operations above.
Refer to the operating instructions
supplied with the disc.
The DATA CD/DVD (MP3 audio file/
JPEG image file/video file) cannot be
played back.
• The data is not stored in the desired
format.
• The system can play back to a depth of
8 folders only.
• The disc contains more than 300 folders.
• The JPEG image file is larger than
3,072 (width) × 2,048 (height) in normal
mode, or more than 3,300,000 pixels in
Progressive JPEG mode which is
mainly used on the Internet website.
• JPEG image files and video files with a
high width to length ratio cannot be
played back.
• The video files is larger than
720 (width) × 576 (height).
• Make sure you have selected the correct
Media Mode before playback.
The folder name, track name, file
name and ID3 tag characters do not
appear properly.
• The ID3 tag is not Version 1(1.0/1.1)
and Version 2(2.2/2.3).
• The character code that can be displayed
by this system are as follows:
– Upper cases (A to Z)
– Numbers (0 to 9)
– Symbols (< > * +, [ ] \ _)
Other characters appear as “_”.
The sound loses stereo effect when
you play back an AUDIO CD, VIDEO
CD, audio file, video file, or DVD
VIDEO.
• Unplug all the microphones or press
KARAOKE MODE repeatedly until
“ ” disappears from the display panel.
• Make sure the system is connected
properly.
• Check the speaker connections
(page 14).
USB device
Transferring results in an error.
• You are using an unsupported USB
device. Check the information on the
websites about compatible USB devices
(page 9).
• The USB device is not formatted
correctly. Refer to the operating
instructions of the USB device on how
to format.
• Turn off the system and remove the
USB device. If the USB device has a
power switch, turn the USB device off
and then on again after removing it from
the system. Then perform transferring
again.
• If the transferring and erase operations
are repeated multiple times, the file
structure within the USB device
becomes fragmented. Refer to the
operating instructions supplied with the
USB device on how to deal with this
problem.
47
Additional Information
• The USB device was disconnected or
the power was turned off during
transferring. Delete the partially-
transferred file, and perform
transferring again. If this does not fix the
problem, the USB device may be
broken. Refer to the operating
instructions of the USB device on how
to deal with this problem.
Audio files or folders on the USB
device cannot be erased.
• Check if the USB device is write-
protected.
• The USB device was disconnected or
the power was turned off during the
erase operation. Delete the partially-
erased file. If this does not fix the
problem, the USB device may be
broken. Refer to the operating
instructions of the USB device on how
to deal with this problem.
There is no sound.
• The USB device is not connected
correctly. Turn off the system and
reconnect the USB device, then turn on
the system and check if “USB A” or
“USB B” lights up in the display panel.
There is noise, skipping, or distorted
sound.
• You are using an unsupported USB
device. Check the information on the
websites about compatible USB devices
(page 9).
• Turn off the system and reconnect the
USB device, then turn on the system.
• The music data itself contains noise, or
the sound is distorted. Noise may have
entered during the transferring process.
Delete the file, and try transferring
again.
• The bit rate used when encoding audio
files was low. Send audio files with
higher bit rate to the USB device.
“READING” is displayed for an
extended time, or it takes a long time
before playback starts.
• The reading process can take a long time
in the following cases.
– There are many folders or files on the
USB device (page 8).
– The file structure is extremely
complex.
– The memory capacity is excessive.
– The internal memory is fragmented.
“OVER CURRENT” appears in the
display panel.
• A problem has been detected with the
level of electrical current from the A
port or B port. Turn off the system
and remove the USB device from the
port. Make sure there is no problem with
the USB device. If this display pattern
persists, contact your nearest Sony
dealer.
Erroneous display.
• The data stored in the USB device may
have been corrupted, perform the
transferring again.
• The character code that can be displayed
by this system are as follows:
– Upper cases (A to Z)
– Numbers (0 to 9)
– Symbols (< > * +, [ ] \ _)
Other characters appear as “_”.
The USB device is not recognized.
• Turn off the system and reconnect the
USB device, then turn on the system.
• Check the information on the websites
about compatible USB devices (page 9).
• The USB device does not work
properly. Refer to the operating
instructions of the USB device on how
to deal with this problem.
48
Playback does not start.
• Turn off the system and reconnect the
USB device, then turn on the system.
• Check the information on the websites
about compatible USB devices (page 9).
Playback does not start from the first
file.
• Set the play mode to Normal Play
(page 22).
Files cannot be played back.
• The JPEG image file is larger than
3,072 (width) × 2,048 (height) in normal
mode, or more than 3,300,000 pixels in
Progressive JPEG mode which is
mainly used on the Internet website.
• JPEG image files with a high width to
length ratio cannot be played back.
• Make sure you have selected the correct
Media Mode before playback.
• USB device formatted with file systems
other than FAT16 or FAT32 are
unsupported.*
• A WMA audio file that is the WMA
DRM, WMA Lossless, or WMA PRO
format cannot be played back.
• An AAC audio file that is the AAC
DRM or AAC Lossless format cannot
be played back.
• AAC audio files encoded at 96 kHz
cannot be played back.
• If you use a partitioned USB device,
only files on the first partition can be
played back.
• The system can play back to a depth of
8 folders only.
• The number of folders has exceeded
300.
• The number of files has exceeded 2,000.
• Files that are encrypted or protected by
passwords, etc. cannot be played back.
• Files with DRM (Digital Rights
Management) copyright protection
cannot be played back by this system.
• The MP3 PRO audio file can be played
back as MP3 audio file.
* This system supports FAT16 and FAT32, but
some USB devices may not support all of
these FAT. For details, refer the operating
instructions of each USB device or contact the
manufacturer.
There is no picture.
• Check that the system is connected
securely.
• If the video cord is damaged, replace it
with a new one.
• Make sure you connect the unit to the
video input jack of your TV (page 15).
• Make sure you turn on the TV and
operate the TV correctly.
• Make sure you select the video input on
the TV so that you can view the pictures
from the system.
• (Except for Russian model) Make sure
you set the color system correctly,
according to your TV’s color system.
Picture noise appears.
• Wipe the disc clean (page 52).
• If video signal from your system has to
go through your VCR to your TV, the
copy-protection applied to some DVD
VIDEO programs could affect the
picture quality.
• (Except for Russian model) When you
play back a VIDEO CD recorded in a
different color system from the one you
set to the system, the picture image may
be distorted (pages 17, 28).
• (Except for Russian model) Set the
color system to match your TV
(pages 17, 28).
The aspect ratio of the TV screen
cannot be changed.
• The aspect ratio is fixed on your DVD
VIDEO and video file.
• Depending on the TV, you may not
change the aspect ratio.
The language for the sound track
cannot be changed.
• Multilingual tracks are not recorded on
the DVD VIDEO being played back.
49
Additional Information
• The DVD VIDEO prohibits changing
the language for the sound track.
The subtitles language cannot be
changed.
• Multilingual subtitles are not recorded
on the DVD VIDEO being played back.
• The DVD VIDEO prohibits changing
the subtitles.
The subtitles cannot be turned off.
• The DVD VIDEO prohibits turning off
subtitles.
The angles cannot be changed.
• Multi-angles are not recorded on the
DVD VIDEO being played back.
• The DVD VIDEO prohibits changing
the angles.
Tuner
Severe hum or noise, or stations
cannot be received. (“TUNED” or
“ST” flashes in the display panel.)
• Connect the antenna properly.
• Change antenna location and its
orientation to obtain good reception.
• Connect a commercially available
external antenna.
• Consult your nearest Sony dealer if the
supplied AM antenna has come off from
the plastic stand.
• Turn off surrounding electrical
equipment.
Bluetooth device
Pairing cannot be done.
• Move the Bluetooth device closer to the
system.
• Pairing may not be possible if other
Bluetooth devices are present around the
system. In this case, turn off the other
Bluetooth devices.
• Make sure the correct passkey was
entered at the Bluetooth device.
Connection is not possible.
• The Bluetooth device you attempted to
connect does not support the A2DP
profile, and cannot be connected with
the system.
• Enable the Bluetooth function of the
Bluetooth device.
• Establish a connection from the
Bluetooth device.
• The pairing registration information has
been erased. Perform the pairing
operation again.
• While connected to a Bluetooth device,
this system cannot be detected and a
connection cannot be established from
another Bluetooth device which is never
paired before.
• Erase the pairing registration
information of the Bluetooth device
(page 38) and perform the pairing
operation again (page 35).
The sound skips or fluctuates, or the
connection is lost.
• The system and the Bluetooth device are
too far apart.
• If there are obstacles between the
system and your Bluetooth device,
remove or avoid the obstacles.
• If there is equipment that generates
electromagnetic radiation, such as a
wireless LAN, other Bluetooth device,
or a microwave oven nearby, move
them away.
The sound of your Bluetooth device
cannot be heard on this system.
• Increase the volume on your Bluetooth
device first, and then adjust the volume
using VOL +/–.
There is severe hum, noise, or
distorted sound.
• If there are obstacles between the
system and your Bluetooth device,
remove or avoid the obstacles.
50
• If there is equipment that generates
electromagnetic radiation, such as a
wireless LAN, other Bluetooth device,
or a microwave oven nearby, move
them away.
• Turn down the volume of the connected
Bluetooth device.
To reset the system
If the system still does not operate
properly, reset the system to factory
default settings.
Use the buttons on the unit to perform this
operation.
1 Unplug and plug the power cord
back in.
2 Press "/1 to turn on the system.
3 Hold down x and LED COLOR at
the same time for about 3 seconds.
“RESET” appears in the display panel.
All user-configured settings, such as
preset radio stations, timer, and the
clock are reset to factory default
setting.
Returning the “SETUP” settings to
the default
You can return the “SETUP” settings
(except for “PARENTAL CONTROL”
settings) to the default settings.
1 Hold down SHIFT, then press
SETUP.
2Press / repeatedly to select
[SYSTEM SETUP], then press .
3Press / repeatedly to select
[RESET], then press .
4Press / repeatedly to select
[YES], then press .
It takes a few seconds to complete. Do
not press "/1 when resetting the
system.
When letters/numbers appear in the
display panel
When the self-diagnosis function is
activated to prevent the system from
malfunctioning, a 5-character service
number (e.g. C 13 50) with a combination
of a letter and 4 digits appears on the TV
screen or in the display panel. In this case,
check the following table.
Self-diagnosis Function
First 3
characters of
the service
number
Cause and corrective
action
C 13 This disc is dirty.
• Clean the disc with a
soft cloth (page 52).
C 31 The disc is not inserted
correctly.
• Restart the system, then
re-insert the disc
correctly.
E XX
(XX is a number)
To prevent a
malfunction, the system
has performed the self-
diagnosis function.
• Contact your nearest
Sony dealer or local
authorized Sony
service facility and
give the 5-character
service number.
Example: E 61 10
51
Additional Information
One of the following messages may
appear or flash in the display panel during
operation.
CANNOT PLAY
• A disc that cannot be played back was
inserted.
• A DVD VIDEO with unsupported
region code was inserted.
DATA ERROR
• The file does not conform to the
required format.
• The file extensions does not match the
file format.
DEVICE ERROR
The USB device could not be recognized
or an unknown device is connected.
DEVICE FULL
The memory of the USB device is full.
ERASE ERROR
Erase of audio files or folders on the USB
device failed.
FATAL ERROR
The USB device was removed during
transfer or erase operation, and may have
been damaged.
FOLDER FULL
You cannot transfer onto the USB device
because the number of folder has reached
its maximum.
NO DEVICE
No USB device is connected.
NO DISC
There is no disc on the disc tray.
NO MEMORY
The memory selected for playback or
transfer has no memory media inserted in
the USB device.
NO MUSIC
MP3/WMA/AAC data does not exist in
MUSIC playback mode.
NO PHOTO
JPEG data does not exist in PHOTO
playback mode.
NO STEP
All of the programmed steps have been
erased.
NO VIDEO
MPEG4/Xvid data does not exist in
VIDEO playback mode.
NOT IN USE
You tried to perform a specific operation
under conditions where that operation is
prohibited.
NOT SUPPORTED
An unsupported USB device is connected
or the USB device is connected through a
USB hub.
OFF TIME NG
The on time and off time of Play Timer or
Recording Timer is the same.
PROTECTED
The USB device is write-protected.
PUSH STOP
You tried to perform an operation that can
be performed only when the playback is
stopped.
READING
The system is reading information of the
disc or USB device. Some operations are
not available.
REC ERROR
The transfer did not start, stopped
partway, or otherwise could not be
performed.
STEP FULL
You tried to program more than 25 steps.
TRACK FULL
You cannot transfer onto the USB device
because the number of file has reached its
maximum.
UNLOCKED
The disc theft-preventive function is
released.
Messages
52
Precautions
When carrying the unit
Perform the following procedure to
protect the disc mechanism.
Use the buttons on the unit to perform this
operation.
1 Press "/1 to turn on the system.
2 Press DVD/CD.
3 Remove the disc.
Press Z OPEN/CLOSE to open and
close the disc tray.
Wait until “NO DISC” appears in the
display panel.
4 Hold down DVD/CD and FLANGER
for 3 seconds.
“MECHA LOCK” appears in the
display panel.
5 Unplug the power cord.
Notes on discs
• Before playing, wipe the disc with a cleaning
cloth from the center outward to the edge.
• Do not clean discs with solvents, such as
benzine, thinner, or commercially available
cleaners or anti-static spray intended for vinyl
LPs.
• Do not expose discs to direct sunlight or heat
sources such as hot air ducts, nor leave it in a
car parked in direct sunlight.
On safety
• Completely disconnect the power cord (mains
lead) from the wall outlet (mains) if it is not
going to be used for an extended period of
time. When unplugging the unit, always grip
the plug. Never pull the cord itself.
• Should any solid object or liquid get into the
system, unplug the system, and have it
checked by qualified personnel before
operating it again.
• AC power cord must be changed only at the
qualified service shop.
On placement
• Do not place the system in an inclined
position or in locations that are extremely hot,
cold, dusty, dirty, or humid or lacking
adequate ventilation, or subject to vibration,
direct sunlight or a bright light.
• Be careful when placing the unit or speakers
on surfaces that have been specially treated
(for example, wax, oil, polish) as staining or
discoloration of the surface may result.
• If the system is brought directly from a cold to
a warm location or is placed in a very damp
room, moisture may condense on the lens
inside the unit, and cause the system to
malfunction. In this situation, remove the
disc, and leave the system turned on for about
an hour until the moisture evaporates.
On heat buildup
• Heat buildup on the unit during operation is
normal and is not a cause for alarm.
• Do not touch the cabinet if it has been used
continuously at a high volume because the
cabinet may have become hot.
• Do not obstruct the ventilation holes.
On the speaker system
This speaker system is not magnetically
shielded, and the picture on nearby TV sets may
become magnetically distorted. In this situation,
turn off the TV, wait 15 to 30 minutes, and turn
it back on. If there is no improvement, move the
speakers far away from the TV.
Cleaning the cabinet
Clean this system with a soft cloth slightly
moistened with a mild detergent solution.
Do not use any type of abrasive pad, scouring
powder, or solvent, such as thinner, benzine,
or alcohol.
IMPORTANT NOTICE
Caution: If you leave a still video image
or on-screen display image displayed on
your TV for an extended period of time via
this system, you risk permanent damage to
your TV screen. Projection TVs are
especially susceptible to this.
53
Additional Information
On Bluetooth communication
• Bluetooth devices should be used within
approximately 10 meters (unobstructed
distance) of each other. The effective
communication range may become shorter
under the following conditions.
– When a person, metal object, wall or other
obstruction is between the devices with a
Bluetooth connection.
– Locations where a wireless LAN is
installed.
– Around microwave ovens that are in use.
– Locations where other electromagnetic
waves occur.
• Bluetooth devices and wireless LAN
(IEEE 802.11b/g) use the same frequency
band (2.4 GHz). When using your Bluetooth
device near a device with wireless LAN
capability, electromagnetic interference may
occur. This could result in lower data transfer
rates, noise, or inability to connect. If this
happens, try the following remedies:
– Try connecting this system and Bluetooth
device when you are at least 10 meters away
from the wireless LAN equipment.
– Turn off the power to the wireless LAN
equipment when using your Bluetooth
device within 10 meters.
• The radio waves broadcast by this system may
interfere with the operation of some medical
devices. Since this interference may result in
malfunction, always turn off the power on this
system and Bluetooth device in the following
locations:
– In hospitals, on trains, in airplanes, at gas
stations, and any place where flammable
gases may be present.
– Near automatic doors or fire alarms.
• This system supports security functions that
comply with the Bluetooth specification as a
means of ensuring security during
communication using Bluetooth technology.
However, this security may be insufficient
depending on the setting contents and other
factors, so always be careful when performing
communication using Bluetooth technology.
• Sony cannot be held liable in any way for
damages or other loss resulting from
information leaks during communication
using Bluetooth technology.
• Bluetooth communication is not necessarily
guaranteed with all Bluetooth devices that
have the same profile as this system.
• Bluetooth devices connected with this system
must comply with the Bluetooth specification
prescribed by the Bluetooth SIG, Inc., and
must be certified to comply. However, even
when a device complies with the Bluetooth
specification, there may be cases where the
characteristics or specifications of the
Bluetooth device make it impossible to
connect, or may result in different control
methods, display or operation.
• Noise may occur or the audio may cut off
depending on the Bluetooth device connected
with this system, the communications
environment, or surrounding conditions.
Specifications
Amplifier section
The following are measured at:
Russian model:
AC 220 V – 240 V, 50/60 Hz
Other models:
AC 120 V – 240 V, 50/60 Hz
Tweeters/woofers
Power Output (rated):
350 W + 350 W (at 4 ohms, 1 kHz,
1% THD)
RMS output power (reference):
600 W + 600 W (per channel at
4 ohms, 1 kHz)
Subwoofers
Power Output (rated):
350 W + 350 W (at 4 ohms, 100 Hz,
1% THD)
RMS output power (reference):
600 W + 600 W (per channel at
4 ohms, 100 Hz)
Inputs
TV/SAT (AUDIO IN) L/R
Voltage 2 V, impedance 47 kilohms
PC/GAME (AUDIO IN) L/R
Voltage 2 V, impedance 47 kilohms
MIC 1, MIC 2
Sensitivity 1 mV, impedance
10 kilohms
A (USB), B (USB) port: Type A
54
Outputs
VIDEO OUT
Max. output level 1 Vp-p, unbalanced,
Sync. negative load impedance
75 ohms
USB section
Supported bit rate
WMA: 48 kbps – 192 kbps, VBR,
CBR
AAC: 48 kbps – 320 kbps, VBR, CBR
Sampling frequencies
WMA: 44.1 kHz
AAC: 44.1 kHz
Supported USB device
Mass Storage Class
Maximum current
500 mA
Disc/USB section
Supported bit rate
MPEG1 Layer-3:
32 kbps – 320 kbps, VBR
MPEG2 Layer-3:
8 kbps – 160 kbps, VBR
MPEG1 Layer-2:
32 kbps – 384 kbps, VBR
Sampling frequencies
MPEG1 Layer-3:
32 kHz/44.1 kHz/48 kHz
MPEG2 Layer-3:
16 kHz/22.05 kHz/24 kHz
MPEG1 Layer-2:
32 kHz/44.1 kHz/48 kHz
Xvid
Video codec: Xvid video
Bit rate: 4.854 Mbps (MAX)
Resolution/Frame rate:
720 × 480 30 fps
720 × 576 25 fps
Audio codec: MP3
MPEG4
File format: MP4 File Format
Video codec:
MPEG4 Simple Profile
(AVC is not compatible.)
Bit rate: 4 Mbps
Resolution/Frame rate:
720 × 576 30 fps
Audio codec: AAC-LC
(HE-AAC is not compatible.)
DRM: Not compatible
Disc player section
System
Compact disc and digital audio and
video system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 W
* This output is the value measurement
at a distance of 200 mm from the
objective lens surface on the Optical
Pick-up Block with 7 mm aperture.
Frequency response
20 Hz – 20 kHz
Video color system format
NTSC and PAL
Tuner section
FM stereo, FM/AM superheterodyne tuner
Antenna
FM lead antenna
AM loop antenna
FM tuner section
Tuning range
87.5 MHz – 108.0 MHz (50 kHz step)
AM tuner section
Tuning range
Saudi Arabian and Russian models:
531 kHz – 1,602 kHz (9 kHz step)
Other models:
530 kHz – 1,610 kHz (10 kHz step)
531 kHz – 1,602 kHz (9 kHz step)
55
Additional Information
Bluetooth section
Communication system
Bluetooth Standard version 3.0 + EDR
(Enhanced Data Rate)
Output
Bluetooth Standard Power Class 2
Maximum communication range
Line of sight approx. 10 m1)
Frequency band
2.4 GHz band (2.4000 GHz –
2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread
Spectrum)
Compatible Bluetooth profiles2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported codecs
SBC (Sub Band Codec)
AAC (Advanced Audio Coding)
1) The actual range will vary depending on
factors such as obstacles between devices,
magnetic fields around a microwave oven,
static electricity, reception sensitivity,
antenna’s performance, operating system,
software application, etc.
2) Bluetooth standard profiles indicate the
purpose of Bluetooth communication between
devices.
Speakers
Speaker system
3-way, Bass reflex
Speaker unit
Woofers: 200 mm, cone type
Tweeters: 25 mm, horn type
Subwoofers: 350 mm, cone type
Rated impedance
4 ohms
Dimensions (w/h/d) (Approx.)
490 mm × 660 mm × 360 mm
Mass (Approx.)
26.5 kg
Quantity: 2 pieces
General
Power requirements
Russian model:
AC 220 V – 240 V, 50/60 Hz
Other models:
AC 120 V – 240 V, 50/60 Hz
Power consumption
370 W
Dimensions (w/h/d) (excl. speakers)
(Approx.)
505 mm × 160 mm × 350 mm
Mass (excl. speakers) (Approx.)
6.2 kg
Supplied accessories
Remote control (1)
R6 (Size AA) batteries (2)
FM lead/AM loop antenna (1)
Video cord (1)
Bottom panel (1)
Design and specifications are subject to
change without notice.
Specyfikacje produktu
| Marka: | Sony |
| Kategoria: | system hi-fi |
| Model: | SHAKE-6D |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Sony SHAKE-6D, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje system hi-fi Sony
16 Stycznia 2025
22 Grudnia 2024
22 Grudnia 2024
5 Października 2024
4 Października 2024
2 Października 2024
1 Października 2024
1 Października 2024
1 Października 2024
30 Września 2024
Instrukcje system hi-fi
- system hi-fi Yamaha
- system hi-fi Samsung
- system hi-fi AEG
- system hi-fi Sven
- system hi-fi LG
- system hi-fi Motorola
- system hi-fi Logitech
- system hi-fi Sharp
- system hi-fi BeamZ
- system hi-fi Huawei
- system hi-fi Pioneer
- system hi-fi Philips
- system hi-fi Plantronics
- system hi-fi SilverCrest
- system hi-fi Technics
- system hi-fi JBL
- system hi-fi Onkyo
- system hi-fi Roland
- system hi-fi Geemarc
- system hi-fi Nokia
- system hi-fi Scott
- system hi-fi KEF
- system hi-fi Kärcher
- system hi-fi Bose
- system hi-fi Panasonic
- system hi-fi Klipsch
- system hi-fi Muse
- system hi-fi Crestron
- system hi-fi Behringer
- system hi-fi Asus
- system hi-fi Nedis
- system hi-fi IK Multimedia
- system hi-fi Medion
- system hi-fi Boss
- system hi-fi OK
- system hi-fi Lenco
- system hi-fi Marquant
- system hi-fi Majestic
- system hi-fi Jensen
- system hi-fi ILive
- system hi-fi Native Instruments
- system hi-fi Garmin
- system hi-fi Blaupunkt
- system hi-fi Vivax
- system hi-fi ATen
- system hi-fi Salora
- system hi-fi Teac
- system hi-fi Dual
- system hi-fi Grundig
- system hi-fi Kiloview
- system hi-fi Homedics
- system hi-fi Soundmaster
- system hi-fi Hyundai
- system hi-fi DAP-Audio
- system hi-fi Creative
- system hi-fi Manhattan
- system hi-fi Honor
- system hi-fi Tripp Lite
- system hi-fi Shure
- system hi-fi ECG
- system hi-fi Matsui
- system hi-fi Denon
- system hi-fi Block
- system hi-fi Cambridge
- system hi-fi Sanus
- system hi-fi Kenwood
- system hi-fi Scosche
- system hi-fi Polk
- system hi-fi Alpine
- system hi-fi Gembird
- system hi-fi Røde
- system hi-fi Dynaudio
- system hi-fi Paradigm
- system hi-fi Bang & Olufsen
- system hi-fi Cobra
- system hi-fi JVC
- system hi-fi Konig & Meyer
- system hi-fi Memphis Audio
- system hi-fi Jamo
- system hi-fi Focusrite
- system hi-fi Rega
- system hi-fi Steelseries
- system hi-fi Oppo
- system hi-fi Lowrance
- system hi-fi TechniSat
- system hi-fi Auna
- system hi-fi Vimar
- system hi-fi Schneider
- system hi-fi LD Systems
- system hi-fi Krüger&Matz
- system hi-fi Audioengine
- system hi-fi OneConcept
- system hi-fi Pure
- system hi-fi Marshall
- system hi-fi Clarion
- system hi-fi Netgear
- system hi-fi Thomson
- system hi-fi Pro-Ject
- system hi-fi AVM
- system hi-fi Velleman
- system hi-fi Ferguson
- system hi-fi Korg
- system hi-fi DataVideo
- system hi-fi Magnat
- system hi-fi DreamGEAR
- system hi-fi Pyle
- system hi-fi ELAC
- system hi-fi Zoom
- system hi-fi Cardo
- system hi-fi NGS
- system hi-fi Midland
- system hi-fi Marantz
- system hi-fi AOC
- system hi-fi Monster
- system hi-fi Sennheiser
- system hi-fi Esoteric
- system hi-fi Jabra
- system hi-fi Chord
- system hi-fi Camry
- system hi-fi Vtech
- system hi-fi Werma
- system hi-fi Speco Technologies
- system hi-fi Lenoxx
- system hi-fi Bowers & Wilkins
- system hi-fi Samson
- system hi-fi Imperial
- system hi-fi PreSonus
- system hi-fi Monitor Audio
- system hi-fi Audio Pro
- system hi-fi NACON
- system hi-fi Revox
- system hi-fi Nevir
- system hi-fi Olympus
- system hi-fi TriStar
- system hi-fi Ibiza Sound
- system hi-fi Vonyx
- system hi-fi Musical Fidelity
- system hi-fi Alto
- system hi-fi Fluid
- system hi-fi Razer
- system hi-fi Peavey
- system hi-fi ION
- system hi-fi ART
- system hi-fi NAD
- system hi-fi Continental Edison
- system hi-fi RCF
- system hi-fi Harman Kardon
- system hi-fi Rolls
- system hi-fi Audio-Technica
- system hi-fi SPC
- system hi-fi GoGen
- system hi-fi TC Helicon
- system hi-fi NEC
- system hi-fi Brandson
- system hi-fi Sonoro
- system hi-fi Parrot
- system hi-fi Aiwa
- system hi-fi JL Audio
- system hi-fi AKAI
- system hi-fi Majority
- system hi-fi Teufel
- system hi-fi Clatronic
- system hi-fi Dali
- system hi-fi Vision
- system hi-fi Telefunken
- system hi-fi Oregon Scientific
- system hi-fi Focal
- system hi-fi DBX
- system hi-fi Kicker
- system hi-fi Omnitronic
- system hi-fi Hama
- system hi-fi Mackie
- system hi-fi Shokz
- system hi-fi Marmitek
- system hi-fi FiiO
- system hi-fi Duronic
- system hi-fi Smart-AVI
- system hi-fi MXL
- system hi-fi Lotronic
- system hi-fi Bush
- system hi-fi Sharkoon
- system hi-fi Watson
- system hi-fi Saramonic
- system hi-fi Loewe
- system hi-fi Bluesound
- system hi-fi Sangean
- system hi-fi AVer
- system hi-fi Walrus Audio
- system hi-fi SVS
- system hi-fi Franklin
- system hi-fi Victrola
- system hi-fi Arcam
- system hi-fi Elta
- system hi-fi Mac Audio
- system hi-fi Infinity
- system hi-fi McIntosh
- system hi-fi Denver
- system hi-fi Albrecht
- system hi-fi Hitachi
- system hi-fi Fender
- system hi-fi AKG
- system hi-fi SmallHD
- system hi-fi RCA
- system hi-fi Electro Harmonix
- system hi-fi Atlas Sound
- system hi-fi Gemini
- system hi-fi Trevi
- system hi-fi Technaxx
- system hi-fi Atlona
- system hi-fi GPX
- system hi-fi Arturia
- system hi-fi Sencor
- system hi-fi Polsen
- system hi-fi PowerBass
- system hi-fi Power Dynamics
- system hi-fi Rockford Fosgate
- system hi-fi Steinberg
- system hi-fi Canton
- system hi-fi Nextbase
- system hi-fi Senal
- system hi-fi TOA
- system hi-fi Monacor
- system hi-fi Daewoo
- system hi-fi ADE
- system hi-fi Tannoy
- system hi-fi Electro-Voice
- system hi-fi Anthem
- system hi-fi Audizio
- system hi-fi Tascam
- system hi-fi RME
- system hi-fi Laser
- system hi-fi WAGAN
- system hi-fi Kunft
- system hi-fi Best Buy
- system hi-fi AudioControl
- system hi-fi Audiolab
- system hi-fi Vocopro
- system hi-fi Technical Pro
- system hi-fi WiiM
- system hi-fi SPL
- system hi-fi Cyrus
- system hi-fi Terratec
- system hi-fi Crunch
- system hi-fi Geneva
- system hi-fi Sound Devices
- system hi-fi House Of Marley
- system hi-fi Reflexion
- system hi-fi REVO
- system hi-fi DPA
- system hi-fi Crosley
- system hi-fi HK Audio
- system hi-fi Swissvoice
- system hi-fi Fenton
- system hi-fi BSS Audio
- system hi-fi Belkin
- system hi-fi SWIT
- system hi-fi Kramer
- system hi-fi KanexPro
- system hi-fi RGBlink
- system hi-fi Glide Gear
- system hi-fi Hosa
- system hi-fi Key Digital
- system hi-fi Music Hall
- system hi-fi AMX
- system hi-fi Goodis
- system hi-fi Sonance
- system hi-fi Rotel
- system hi-fi Altec Lansing
- system hi-fi American Audio
- system hi-fi Devialet
- system hi-fi IFi Audio
- system hi-fi Audison
- system hi-fi Caliber
- system hi-fi Sony Ericsson
- system hi-fi Proscan
- system hi-fi Exibel
- system hi-fi Logik
- system hi-fi Energy Sistem
- system hi-fi Sagem
- system hi-fi Sonos
- system hi-fi Brigmton
- system hi-fi Sunstech
- system hi-fi AudioAffairs
- system hi-fi Magnum
- system hi-fi Steren
- system hi-fi Audiosonic
- system hi-fi Coby
- system hi-fi Envivo
- system hi-fi Galaxy Audio
- system hi-fi Bigben Interactive
- system hi-fi Apogee
- system hi-fi Pyle Pro
- system hi-fi Autotek
- system hi-fi MB Quart
- system hi-fi Bigben
- system hi-fi Massive
- system hi-fi IDance
- system hi-fi Alba
- system hi-fi Naxa
- system hi-fi QTX
- system hi-fi Konig
- system hi-fi Boston Acoustics
- system hi-fi Mpman
- system hi-fi Vizio
- system hi-fi Nikkei
- system hi-fi Peaq
- system hi-fi Ematic
- system hi-fi ESI
- system hi-fi Roadstar
- system hi-fi Anchor Audio
- system hi-fi Superior
- system hi-fi Quantis
- system hi-fi Irradio
- system hi-fi Karcher Audio
- system hi-fi Cmx
- system hi-fi Russound
- system hi-fi Comica
- system hi-fi Audient
- system hi-fi Bluetrek
- system hi-fi Starkey
- system hi-fi PAC
- system hi-fi Skytec
- system hi-fi Luxman
- system hi-fi M-Audio
- system hi-fi Stereoboomm
- system hi-fi Tivoli Audio
- system hi-fi Wolfgang
- system hi-fi Numan
- system hi-fi Iluv
- system hi-fi Vankyo
- system hi-fi WyreStorm
- system hi-fi Sonifex
- system hi-fi TV One
- system hi-fi Nxg
- system hi-fi Lynx
- system hi-fi MIPRO
- system hi-fi Solid State Logic
- system hi-fi HiFi ROSE
- system hi-fi OSD Audio
- system hi-fi Andover
- system hi-fi Mark Levinson
- system hi-fi Auto-T
- system hi-fi Soundstream
- system hi-fi Xoro
- system hi-fi Adastra
- system hi-fi Avante
- system hi-fi Titanwolf
- system hi-fi CSL
- system hi-fi Liam&Daan
- system hi-fi Universal Audio
- system hi-fi JB Systems
- system hi-fi Orbitsound
- system hi-fi HUMANTECHNIK
- system hi-fi SIIG
- system hi-fi Hercules
- system hi-fi Primare
- system hi-fi Griffin
- system hi-fi Xantech
- system hi-fi Eissound
- system hi-fi Extron
- system hi-fi ClearOne
- system hi-fi Ebode
- system hi-fi Motu
- system hi-fi Mission
- system hi-fi Teradek
- system hi-fi TCM
- system hi-fi Crown
- system hi-fi Morel
- system hi-fi Zvox
- system hi-fi Antelope Audio
- system hi-fi CE Labs
- system hi-fi Z CAM
- system hi-fi Avid
- system hi-fi Icon
- system hi-fi Mtx Audio
- system hi-fi General Electric
- system hi-fi Aquatic AV
- system hi-fi Parasound
- system hi-fi Promate
- system hi-fi SoundCast
- system hi-fi Hollyland
- system hi-fi Defender
- system hi-fi Boytone
- system hi-fi Astell&Kern
- system hi-fi Glorious
- system hi-fi Maretron
- system hi-fi JK Audio
- system hi-fi Xact
- system hi-fi Ruark Audio
- system hi-fi Magnavox
- system hi-fi ANT
- system hi-fi Leviton
- system hi-fi Rane
- system hi-fi ESX
- system hi-fi NUVO
- system hi-fi Lexicon
- system hi-fi Fluance
- system hi-fi Altra
- system hi-fi On-Q
- system hi-fi Vantage Point
- system hi-fi Planet Audio
- system hi-fi CAD Audio
- system hi-fi IFi
- system hi-fi E-bench
- system hi-fi Digigram
- system hi-fi Roon
- system hi-fi Voco
- system hi-fi Linear
- system hi-fi SSV Works
- system hi-fi DAP
- system hi-fi The Box
- system hi-fi AmpliVox
- system hi-fi Audiofrog
- system hi-fi Accsoon
- system hi-fi Juke Audio
- system hi-fi Meridian
- system hi-fi DiGiGrid
- system hi-fi CLXmusic
- system hi-fi Nuheara
- system hi-fi Acoustic Solutions
- system hi-fi Metric Halo
- system hi-fi Universal Remote Control
- system hi-fi Prism Sound
- system hi-fi MoFi
- system hi-fi Antelope
- system hi-fi Auvi
- system hi-fi Switchcraft
- system hi-fi Aplic
- system hi-fi Crystal Video
- system hi-fi Atoll
- system hi-fi Bennett & Ross
- system hi-fi Pronomic
- system hi-fi Beatfoxx
- system hi-fi NEAR
- system hi-fi Vaxis
- system hi-fi INKEE
Najnowsze instrukcje dla system hi-fi
9 Kwietnia 2025
5 Kwietnia 2025
3 Kwietnia 2025
2 Kwietnia 2025
2 Kwietnia 2025
1 Kwietnia 2025
1 Kwietnia 2025
29 Marca 2025
28 Marca 2025
28 Marca 2025
