User’s Guide
for Echo™ III Desktop
Thunderbolt™
3
to PCIe® Card Expansion System
Support Note: This document was up to date at the
time of printing. However, changes to the hardware or
software may have occurred since then. Please check the Sonnet
website for the latest documentation.
1. Go to www.sonnettech.com/support/kb/kb.php
2. Navigate to and click the Echo III Desktop link.
3. Click the Manual link.
4. Click the Echo III Desktop User’s Guide [English] link and then
check the Document Version information. If the version listed is
later than this document ( ), click the Download Now revision E
button for the latest version.
For
Windows
1 Introduction and System Requirements 1
Introduction
Mac Compatibility
Windows Compatibility
Linux Compatibility
System Requirements
Preparing to Use the Echo Chassis With a Mac Computer
Preparing to Use the Echo Chassis With a Windows Computer
Preparing to Use the Echo Chassis With a Linux Computer
2 Echo III Desktop Description 2
Exterior
Echo III Module (Inner Assembly)
Thunderbolt 3 (40Gbps) Cable
Thunderbolt 3 Connector Retainer Clip
3 PCIe Card Installation and Module Setup Steps 4
4 Complete Setup and Configuration 7
Setup and Configuration Steps—Mac Users
Setup and Configuration Steps—Windows Users
5 Tips, General Information, and Known Issues 9
Tips, General Information
Known Issues
6 Precautions, FCC Compliance, and Support Information 10
Safety Precautions
Warnings
FCC Compliance
Contacting Customer Service
Contents
1
Chapter 1 – Introduction and System Requirements
Introduction
Congratulations on your purchase! The Echo III Desktop is a
Thunderbolt 3 expansion system for PCIe cards. Through its
PCIe slots, you may connect three non-GPU adapter cards to any
computer with Thunderbolt ports to expand its capabilities and
add connectivity beyond what’s offered through its native ports.
Mac® Compatibility
• Mac (M1 Max/M1 Pro/M1) computers with PCIe cards that
have M1 processor-compatible drivers
• Mac (Intel®) computers with Thunderbolt 3 ports
• Macs with Thunderbolt 2 or Thunderbolt ports via an Apple
Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter plus
Thunderbolt cable (both sold separately)
• macOS® 10.12.6+
Windows® Compatibility
• PCs with Thunderbolt 3 or Thunderbolt 4 ports
• Windows 10 (64-bit Edition Version 2004 or greater)
Important Notes: At the time of writing, Windows 11 is
NOT compatible, as it does not currently support multi-slot
Thunderbolt expansion systems.
Windows computers require the latest BIOS and Thunderbolt
drivers to support this product. Check with your computer
manufacturer for update information.
Linux® Compatibility
• Linux computer with Thunderbolt 3 or Thunderbolt 4 ports
• Linux Kernel 5.0+
System Requirements
While Echo expansion systems require no drivers beyond those
pre-installed in your computer’s OS, most expansion cards you
install do; Thunderbolt-compatible drivers to enable them to
work properly through the Thunderbolt interface are required.
More information on which cards are compatible with the
Echo III Desktop is available at: https://sonnettech.com/support/
Preparing to Use the Echo Chassis With a Mac
Computer
The drivers required to support the are installed as Echo module
part of macOS; there are no preparation steps beyond updating
your computer to macOS 10.12.6 or newer.
Preparing to Use the Echo Chassis With a Windows 10
Computer
1. Update Windows. You must use Windows 10, 64-Bit Version
2004 or newer. To check the version number, type winver in
the search bar and click enter.
2. Update your computer’s BIOS to the latest version. If you
need help updating your BIOS, contact your computer
manufacturer.
3. Update your Thunderbolt Bus Driver to the latest version;
you will need version 16.3.61.275 or newer. To check
your driver version, go to Settings:Apps:Thunderbolt(TM)
Software and you will see the version number. If it is not
16.3.61.275 or newer, then you need to update it. Check with
your computer manufacturer for an update.
Preparing to Use the Echo Chassis With a Linux
Computer
The drivers required to support the are installed as Echo module
part of Linux Kernel 5.0 and later; there are no preparation steps
beyond updating your computer to Linux Kernel 5.0 or later.
