Strona 1/6
A
B C D E F G
1
2
3
4
04-0525A
(x4) bolt (x4) concrete
anchor
(x4) small
washer
(x4) large
washer
(x4) M4X12
screw
(x4) M5X12
screw (x4) M6X12 screw
Fixed LCD TV/Monitor Mount - 10" to 24"
Attach the wall plate to the wall again and insert the bolts (A) and large washers
(D) into the holes (figure 1-b) and tighten.
Wood Stud Installation
Step 1: Wall Plate Installation
Installation Instructions
Use a high-quality electronic stud finder (commercially available) to locate dead
center of two studs and mark their locations with a pencil (figure 1-a).
Hold the wall plate to the wall and mark four locations to be used for mounting the
wall plate.
Take down the plate and drill four holes at the position you've marked.
1
2
3
1
2
1
IMPORTANT: If you don't understand the installation instructions, please consult an
installation specialist
Maintenance
Place your TV screen down on a soft, flat surface, and locate the threaded
mounting points that are located on the back of the display.
According to the size of the display's hole, choose the corresponding screw (E/F/G)
and small washer (C) and insert into the hole as shown (figure 2-a) and tighten.
Concrete/Brick Wall Installation
Step 2: Display Plate Installation
Position the Wall Plate onto the wall again and insert the bolts (A) and large
washer (D) into the anchor as shown (figure 1-b) and tighten.
Pre-drill four holes at the positions you've marked and insert one concrete anchor
(B) into each hole.
Place the wall plate against the wall and mark four locations to be used for
mounting the wall plate.
Step 3: Final Installation
Check the mounting screws every two months for tightness.
Hang the display plate onto the top of the
wall plate and slide it onto the wall plate as
shown (figure 3-a).
SIIG offers a 5-year manufacturer warranty with this product. Please see our web site for
more warranty details. If you encounter any problems with this product, please follow the
procedures below.
• Clearly write your RMA number on the top of the returned package. SIIG will refuse to
accept any shipping package, and will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
• You are responsible for the cost of shipping. Ship the product to the following address:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and International
Economy outside of the U.S. at no cost to the customer.
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #: ________________
• Properly pack the product for shipping. All software, cable(s) and any other accessories
that came with the original package must be included.
Step 2: After obtaining an RMA number, ship the product.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then click RMA to submit an request to SIIG RMA. If
the product is determined to be defective, an RMA number will be issued.
QUESTIONS? SIIG ’ s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with new
drivers and solutions. Answers to your questions could be just a few clicks away. You can
also submit questions online and a technical support analysts will promptly respond.
A) If it is within the store's return policy period, please return the product to the store where
you purchased from.
B) If your purchase has passed the store's return policy period, please follow these steps
to have the product repaired or replaced.
Technical Support and Warranty
