Outdoor Piezoelectric

Request-to-Exit Pushbuttons

Manual

Features:

 Piezoelectric push buttons for indoor or

outdoor use (IP65)

 LED ring around button changes from

green to red or red to green when the

button is pressed

 Timed or toggle output

 Includes separate manual override button

in case power to piezoelectric push button

fails

 Relay rated 5A@24VDC with two

individually programmable outputs

(NO/NC)

SD-6176-SSQ Slimline plate "TOUCH/EXIT"

SD-6176-SS1Q Slimline plate "EXIT/SALIDA"

SD-6176-SSVQ Slimline plate, manual override

SD-6276-SSQ Single-Gang plate, "TOUCH/EXIT"

SD-6276-SS1Q Single-Gang plate, "EXIT/SALIDA"

SD-6276-SSVQ Single-Gang plate, manual override

ENFORCER Outdoor Piezoelectric Request-to-Exit Pushbuttons

2 SECO-LARM U.S.A., Inc.

1x Piezoelectric push button 2x Wires for manual override

1x Manual 2x Mounting screws

Operating voltage 12~24VDC

Contact rating 2.5A@24 VAC/VDC

Ring

LED

Standby Red

Active Green

Output time 1~30s, Toggle

IP rating IP65

Operating temperature 32°~158° F (0°~70° C)

Plate material Stainless steel

Weight

Single-Gang 3.5-oz (99g)

Single-Gang w/ manual override 4-oz (113g)

Slimline 2.6-oz (74g)

Slimline w/ manual override 3.1-oz (88g)

Overview:

Introduction:

Parts List:

Installation:

*SD-6176-SSVQ and SD-6276-SSVQ with Manual Override button shown, other models similar.

Slimline Single-Gang Side View Rear View

*SD-6176-SSVQ and SD-6276-SSVQ only.

1. Prepare wiring to provide 12~24 VDC power and connect devices to the relay outputs.

NOTE: The device includes one relay with two outputs. Outputs trigger simultaneously but can be configured

independently. To set the output modes, see Relay Output Modes on page 3.

2. Remove the plastic cover from the rear of the switch and carefully pierce the rubber grommet.

3. SD-6176-SSVQ and SD-6276-SSVQ: Wire the manual override button. See page 3.

4. Wire the switch according to the diagram on the right.

5. Connect (-) and (+) to a 12~24 VDC power source.

6. Connect other devices to Output 1 or 2.

7. Replace the plastic switch cover and screw the plate

onto the mounting surface

minal Block

LED Rin

Piezoelectric

pushbutton

Manual

Override

Button*

Manual

Override

Button*

Timer

Adjustment

Output mode

Selection

LED color

Selection

Terminal

blocks

Relay adjust

Buzzer

adjust

(Plastic switch

cover removed)

15/8" (42mm)

/8" (42mm) 23/4" (70mm)

41/2"

(114mm

)

ENFORCER Outdoor Piezoelectric Request-to-Exit Pushbuttons

SECO-LARM U.S.A., Inc. 3

Wiring the Manual Override: SD-6176-SSVQ and SD-6276-SSVQ Only

Configuring the Pushbutton:

Connect the manual override button with included wires

Wiring for N.O.:

Connect the two

wires between the

NO and COM

terminals of the

override button and

the Output 1 or 2

terminals on the

switch.

Wiring for N.C.:

Connect the two

wires between

the NC and COM

terminals of the

override button

and the Output 1

or 2 terminals on

the switch.

COM

N.O.

COM

N.C.

Notes:

1. Remove the thin panel on the bottom of the plastic cover to allow wiring to pass through.

2. There is only one relay, wiring the button to either output will allow the other output to trigger simultaneously.

3. Do not connect the manual override button to more than one output.

4. When wiring for either N.O. or N.C., be sure to also set the Relay Output Mode to N.O., as described below.

If Relay Output Mode and override button wiring do not match, the product may not function as expected

Manual

Override Button

1. Buzzer Output

2. Relay Output Mode

3. LED Ring Colors

4. Switch Output Type

5. Time Adjustment

Default:ON

Use the buzzer output jumper JP3 to program the buzzer output.

Placing the jumper on the left turns buzzer output ON. Placing the

umper on the right turns buzzer outputs OFF.

Outputs 1 and 2 can be set independently using jumpers JP1 and JP2.

Note: Both outputs trigger simultaneously. Place the jumper on the right

for N.O. operation and on the left for N.C. operation

Default: N.O

ON: LED is green while in standby, and turns red when triggered.

OFF: LED is red while in standby, and turns green when triggered.

Default: OFF

TIMER: When set to TIMER, pressing the switch will trigger the relay

for the set time. Set the time using the trimpot as described above.

TOGGLE: When set to TOGGLE, pressing the switch will cause the

relay to trigger until the switch is pressed

Default: Timer

Output duration is adjustable 1~30 seconds. (Must be set to ‘Timer’ in step 4)

Gently rotate the trimpot using a Philips head screwdriver.

Counterclockwise decreases the output time.

Clockwise increases the output time.

Default: 1s
