20 102021 .1
R3 Compact M Susic ystem
Audio
Frequency response 40Hz – 20kHz
Drivers 2 x 75mm Ruark NS+
Amplifier 30W Analogue class AB
Enhancements Bass, treble, loudness, 3D audio
DAC/ADC up to 24-bit 192kHz
Connectivity
Radio DAB/DAB+, FM with RDS (87.5-108MHz) and
Internet Radio
Radio presets 10 presets in each mode
Bluetooth V4.0, SBC, AAC, A2DP, aptX
Wi-Fi 802.11b/g/n; WPS2 setup, WEP, WPA & WPA2
Ethernet RJ45
Music services Spotify Connect, Amazon Music,
Deezer, Tidal
Media Compatible with UPnP™ DLNA media servers;
MP3 up to 48kHz 320kbps, AAC up to 96kHz 320kbps,
FLAC up to 24 bit 48kHz, WAV up to 16 bit 48kHz - - and
24 bit 44.1kHz, WMA up to 44.1kHz 320kbps
CD support CD, CD- -RROM, CD /RW discs; MP3, WMA &
AAC up to 320 Kbps
Line in - Stereo RCA input (max 2.3 Vrms)
Optical input TOSLINK digital input (24-bit 192kHz)
Line- out Line-level stereo RCA (2.0Vrms)
Headphone 3.5mm 32 5 -jack, 2 mW into 16 Ohm
USB 2.0 Fat32 memory stick playback, 5V 1A (5W)
Aerial Removable telescopic
Aerial connector 75Ω F- type connector
Features
Remote control Infrared
App control UNDOK (iOS & Android)
Display High- contrast OLED
Alarms 2 (daily, once, weekends, weekdays)
Auto standby A fter 20 mins of inactivity
Adjustable input levels Line in, optical
User interface languages:
EN, DE, FR, ES
General Specifications
Finishes Rich walnut veneer or soft grey with grey
woven grille fabric
Remote batteries 2 x 1.5V AAA
Box contains R3 Compact Music System, universal
power adapter with regional plugs, remote control,
remote control batteries, telescopic aerial, aerial
spanner, quick start guide
Power adapter 100-240VAC 50 60Hz input-
14VDC 2.85A 40W output, 1.8m cable,
2.1 x 5.5mm DC plug
Power consumption 1.6W network standby, 5.0W idle
Product dimensions
H167 x W420 x D220mm
Product weight 5.2 kg
Inner carton dimensions H370 x W600 x D190mm
Packaged weight 6.9kg
Shipping carton dimensions H330 x L520 x W460mm
Shipping carton weight 1.2kg
Gross weight 15.0kg (box of 2)
Walnut product code/EAN
R3- WAL / 5060637250051
Soft grey product code/EAN
R3-SG / 5060637250068
