POWDER TRICKLER-2
and UPGRADE KIT
LIMITED LIFETIME WARRANTY
Your powder trickler is warranted to be free from defects in material or
workmanship for as long as the original owner owns it. This warranty is
extended only to the original consumer purchaser. This warranty
excludes any electrical components or products. All RCBS products are
intended for non-commercial use by hobbyists. Any other use of these
products will void the warranty. Should you believe that your powder
trickler is defective in material or workmanship, you must return the
powder trickler to Ammunition Accessories Inc. through its Oroville
operation (hereinafter “Oroville Operations”) postage paid for evaluation.
If defective, the product will be repaired or replaced at Oroville
Operations’ option, at no charge.
Send a dated proof of purchase to Oroville Operations for return shipping
and handling, along with the Powder trickler to:
Ammunition Accessories Inc.,
Oroville Operations
605 Oro Dam Blvd East
Oroville, California 95965
Warranty services cannot be provided without meeting the above
requirements.
THIS LIMITED LIFETIME WARRANTY DOES NOT COVER DEFECTS
OR DAMAGE RESULTING FROM: CARELESSNESS, MISUSE,
COMMERCIAL USE, ABUSE, IMPROPER INSTALLATION,
MODIFICATION, OR NORMAL WEAR AND TEAR. THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS
LIMITED LIFETIME WARRANTY. OROVILLE OPERATIONS IS NOT
LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT AND UNDER NO CIRCUMSTANCES SHALL
OROVILLE OPERATIONS BE LIABLE FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES. HOWEVER, SOME STATES DO NOT
ALLOW LIMITATIONS ON INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
The above warranty provides the sole and exclusive warranty available
to the customer in the event of a defect in material or workmanship in the
powder trickler. This warranty gives you specific legal rights, and you
may also have other rights which vary from State to State.
SAFETY
Reloading is an enjoyable and rewarding hobby that can be
conducted safely. But, as with any hobby, carelessness or
negligence can make reloading hazardous. This product has
been designed from the beginning with the user's safety in mind.
When reloading, safety rules must be followed. By observing
these rules, the chance of a hazardous occurrence causing
personal injury or property damage is minimized.
GENERAL
• Use all equipment as the manufacturer recommends. Study
the instructions carefully and become thoroughly familiar with
the operation of the product. If you do not have written
instructions, request a copy from the equipment manufacturer.
• Do not take short cuts. Attempting to bypass established
procedures is an invitation to an accident.
• Observe "good housekeeping" in the reloading area. Keep
tools and components neat, clean and orderly. Promptly and
completely clean up primer and powder spills.
• Reload only when you can give your undivided attention. Do
not reload when fatigued or ill, or under the influence of
medications or alcohol.
• Develop a reloading routine to avoid mistakes which may
prove hazardous. Do not rush - load at a leisurely pace.
• Always wear adequate eye protection to protect your eyes
from flying particles. You assume unnecessary risk when
reloading without wearing safety glasses.
LOADING DATA
• Use only laboratory tested reloading data. We highly
recommend the current SPEER Reloading Manual.
• OBSERVE ALL WARNINGS ABOUT THE USE OF
MAXIMUM LISTED LOADS
INTRODUCTION
The Powder Trickler-2 has been designed to work with both
mechanical and electronic scales. The adjustable height base
and extended reach dispensing tube are guaranteed to reach the
powder pan of most powder scales. The weighted base and non-
skid feet keep the Trickler from moving around during
dispensing.
Photo 1 Adjustable base – high (NOTE: angle/draft to speed
trickling)
Photo 2 Adjustable base - low
ASSEMBLY
Clean powder trickler tubes and body prior to use. Use alcohol or
Outers Crud Cutter to remove oils or solvents.
Remove the green plastic retainer from the Powder Dispensing
Tube and insert the tube through hole in the Powder Trickler
body, replace the green plastic retainer.
Photo 3 Insert tube and install retaining ring
(UPGRADE KIT assembly starts here)
Slide the Powder Dispensing Tube extension over the Powder
Tube and secure the Socket Head Set Screw.
Photo 4 Secure extension tube set screw
Place the Powder Trickler onto the Adjustable base, align the
Powder Dispensing tube with the “SCALE” marking on the upper
portion of the Adjustable base. Alignment of the dispensing tube
with the “SCALE” mark adds a slight draft(taper) to speed the
trickling process. Secure the three socket head set screws in the
upper base.
Photo 5 Align dispensing tube with “SCALE” mark on upper base
Photo 6 SECURING the three SHSS
USE
Unscrew the lower portion of the Adjustable Base until the
desired powder dispensing tube height is achieved. The
dispensing tube should be ¼” or greater above the scale pan.
Fill the Powder Trickler reservoir with smokeless powder and
turn the dispensing tube clockwise to start the flow of powder.
At the end of the reloading session, pour the remaining
smokeless powder back into the original factory container. This
will preserve the identity and shelf life of the smokeless powder.
MAINTENANCE
Periodically clean powder trickler tubes and body. Use alcohol or
Outers Crud Cutter to remove oils or solvents.
Clean Powder Trickler when changing powders to prevent
contamination. Pay special attention to the interior of the powder
trickler tube and insure that there is no powder from the previous
session stuck inside the tube.
Customer Service
1-800-533-5000 (US or Canada) or 530-533-5191
Hours: Monday - Thursday, 6:30am - 4:00pm Pacific Time
(hours may vary)
e-mail: rcbs.tech@atk.com or visit our website at www.rcbs.com
RCBS 605 Oro Dam Blvd. East Oroville, CA 95965
7200561/1010
