J-MIC
Item ref: 171.8 24UK
Rechargeable Dual Handheld UHF Wireless S et
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
J-MIC DUAL User Manual
Introduction
Thank you for choosing the J-MIC set for your wireless microphone requirements.
This system is designed to provide a reliable, cable-free solution with minimal
setup and ease o use. Please read and keep this user manual to get the best f
results from your product and avoid damage through misuse.
Setting up
The J-MIC set is supplied as 2
individual handheld microphone
transmitters and rechargeable a
6.3mm plug-in receiver.
To charge the receiver, connect
the supplied USB lead from the
type-C socket on the receiver to a
USB power supply with the type-
A plug.
Note: the audio is not transmitted
to the USB port. The USB is for
power onl y.
The internal rechargeable battery
is a Li-ion 18650 type and may
be replaced if needed by sliding
off the cover on the transmitter.
Unscrew the lower part of each
handheld transmitter to reveal
the battery compartment at the
rear. Slide in 2 x AA batteries in
tandem with the positive button
towards the microphone grille.
Note: The front side of the opened microphone compartment has an aperture
labelled SET This is not used, as the J-MIC system is pre-set to operate on the “ ”.
UK/EU license-free UHF band.
Replace the lower cover of each microphone once batteries are installed.
J-MIC DUAL User Manual
Operation
The J-MIC receiver is designed to plug directly into a microphone input jack on a
mixer or amplifier. Turn down the volume level on the microphone input of the
mixer or amplifier before connecting to avoid loud noises when connecting.
Note: The output of both of the handheld transmitters is mixed to the same
single 6.3mm unbalanced jack.
On the plug-in receover, slide the on/off switch to the on position and a small red
LED will light from inside the receiver to show that it is powered on.
Each handheld transmitter has an on/off switch. Press and hold this button to
switch on the handheld transmitter and the display will show the UHF carrier
frequency of that microphone. At this point, each microphone is live to the
receiver. Gradually turn up the volume level on the mixer or amplifier and speak
into the handheld microphones in turn until the sound can be heard through the
speakers or recording equipment. Increase the volume to the required level.
If the U-MIC set is not being used for long periods, turn down the volume level
on the connected mixer or amplifier and switch both handheld microphones and
the receiver off. For long term storage, unplug the jack and USB receiver and
remove the batteries form the handheld transmitters.
