User Manual

www.provision-isr.com

Digital Video Recorder User Manual

CAUTION

 Read this user manual carefully to ensure correct and safe use of your PROVISION- ISR DVR.

 T he content of this manual could be outdated or incorrect, for any clarification contact PROVISION ISR support.-

 This device should be operated only from the type of power source indicated on the marking label. The voltage of the

power must be verified before using.

 If you plan not to use the DVR for a long time, shutdown and unplug the power cable.

 Do not place this device close to a radiators, heat registers, stoves or other device heat sources (e.g. ).

 Do not place this device near water. Clean only with a dry cloth

 Do not block any ventilation openings and make surethe device is in a ventilated place.

 Avoid damaging the HDD, neverunpluga the DVR!If DVR is , working the recordingmust be ended before shutting it down.

P “ress the shut down button from the” main menu , and wait for this message: "Now you can unplug the DVR".

 This equipment is for indoor use only.

 Do not expose the DVR to rain, to high humidity, or to extreme temperature conditions.

 In case any solid or liquid get inside the DVR:shut down and unplug the power line and call a qualified technician.

 Refer all servicing to qualified service personnel. No any parts repaired by yourself without technical aid or approval .

 This manual is suitable for channel digital video recorders. PROVISION- the ISR 4/8/16/32

 All examples and pictures used in th manual are from is PROVISION-ISR sDVR .
