Strona 1/40

Table of contents

8 Intended use . . . . . . . . . . . . . . 4

( Safety instructions . . . . . . . . . . 4

Before you switch ON

the appliance . . . . . . . . . . . . . . . . . . 5

Delivery. . . . . . . . . . . . . . . . . . . . . . . . 5

Installation. . . . . . . . . . . . . . . . . . . . . . 5

In daily use . . . . . . . . . . . . . . . . . . . . . 6

Door lock . . . . . . . . . . . . . . . . . . . . . . 7

Damage . . . . . . . . . . . . . . . . . . . . . . . 7

Disposal . . . . . . . . . . . . . . . . . . . . . . . 7

7 Protection of

the environment . . . . . . . . . . . . 9

Packaging. . . . . . . . . . . . . . . . . . . . . . 9

Old appliances . . . . . . . . . . . . . . . . . . 9

* Getting to know

your appliance . . . . . . . . . . . . . . 9

Control panel . . . . . . . . . . . . . . . . . . . 9

Appliance interior . . . . . . . . . . . . . . . 10

+ Water softening system/

Special salt . . . . . . . . . . . . . . . 10

Setting . . . . . . . . . . . . . . . . . . . . . . . 10

Water hardness table . . . . . . . . . . . . 11

Using special salt . . . . . . . . . . . . . . . 11

Detergents with salt component . . . . 11

Switching off

water softening system . . . . . . . . . . . 11

, Rinse aid . . . . . . . . . . . . . . . . . 12

Setting amount of rinse aid. . . . . . . . 12

Switching off

rinse-aid refill indicator . . . . . . . . . . . 13

- Utensils . . . . . . . . . . . . . . . . . . 13

Not suitable . . . . . . . . . . . . . . . . . . . 13

Glass and utensil damage . . . . . . . . 13

Loading the dishwasher . . . . . . . . . . 13

Unloading the dishwasher . . . . . . . . 13

Cups and glasses. . . . . . . . . . . . . . . 14

Pans . . . . . . . . . . . . . . . . . . . . . . . . . 14

Cutlery basket. . . . . . . . . . . . . . . . . . 15

Etagere . . . . . . . . . . . . . . . . . . . . . . . 15

Folding spikes . . . . . . . . . . . . . . . . . 15

Small accessories holder . . . . . . . . . 15

Knife shelf . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the height of the basket . . 16

. Detergent . . . . . . . . . . . . . . . . . 17

Adding detergent . . . . . . . . . . . . . . . 17

Combination detergent . . . . . . . . . . . 18

/ Overview of programmes . . . . 19

Programme selection . . . . . . . . . . . . 20

Information for test institutes . . . . . . . 20

0 Additional options . . . . . . . . . . 20

Express Wash/ Speed Perfect

(VarioSpeed). . . . . . . . . . . . . . . . . . . 20

Intensive zone . . . . . . . . . . . . . . . . . . 20

Hygiene. . . . . . . . . . . . . . . . . . . . . . . 20

Half load . . . . . . . . . . . . . . . . . . . . . . 20

Extra drying. . . . . . . . . . . . . . . . . . . . 20

1 Operating the appliance . . . . . 21

Programme data . . . . . . . . . . . . . . . . 21

Aqua sensor . . . . . . . . . . . . . . . . . . . 21

Switching on the appliance. . . . . . . . 21

Timer programming . . . . . . . . . . . . . 21

End of programme . . . . . . . . . . . . . . 21

Interrupting the programme . . . . . . . 22

Terminating the programme . . . . . . . 22

Changing the programme. . . . . . . . . 22

Intensive drying. . . . . . . . . . . . . . . . . 22

en Intended use

2 Cleaning and maintenance . . . 23

Overall condition of the machine . . . 23

Special salt and rinse aid . . . . . . . . . 23

Filters . . . . . . . . . . . . . . . . . . . . . . . . 24

Spray arms . . . . . . . . . . . . . . . . . . . . 24

3 Fault, what to do? . . . . . . . . . . 25

Waste water pump . . . . . . . . . . . . . . 25

Fault table. . . . . . . . . . . . . . . . . . . . . 26

4 Customer service . . . . . . . . . . 34

5 Installation and connection . . 34

Product package . . . . . . . . . . . . . . . 35

Safety instructions. . . . . . . . . . . . . . . 35

Delivery. . . . . . . . . . . . . . . . . . . . . . . 35

Technical specifications . . . . . . . . . . 35

Installation. . . . . . . . . . . . . . . . . . . . . 36

Waste-water connection . . . . . . . . . . 36

Drinking water connection . . . . . . . . 36

Electrical connection. . . . . . . . . . . . . 37

Removing the appliance . . . . . . . . . . 37

Transportation. . . . . . . . . . . . . . . . . . 38

Protection against frost

(Emptying the appliance) . . . . . . . . . 38

8 Intended use

Intended use

This appliance is intended for

use in the home and

domestic environments.

Use the dishwasher only in

the home and only for its

designated purpose: for

washing domestic dishes.

This appliance is intended for

use up to a maximum altitude

of 4000 metres above sea

level.

( Safety instructions

Safety instructions

This appliance may be used by

children over the age of 8 years

old and by persons with

reduced physical, sensory or

mental capabilities or by

persons with a lack of

experience or knowledge if they

are supervised or are instructed

by a person responsible for

their safety how to use the

appliance safely and have

understood the associated

hazards.

Children must not play with, on,

or around the appliance.

Children must not clean the

appliance or carry out general

maintenance unless they are at

least 8 years old and are being

supervised.

Safety instructions en

Keep children below the age of

8 years old at a safe distance

from the appliance and power

cable.

Before you switch ON the

appliance

Please read the instructions for

use and installation carefully.

They contain important

information on how to install,

use and maintain the appliance.

Retain all documents for later

use or for the subsequent

owner.

You can download the

instructions for use from our

website free of charge. The

relevant Internet address can

be found overleaf on these

instructions for use.

Delivery

1. Check the packaging and

dishwasher immediately for

damage caused in transit. Do

not switch on a damaged

appliance, but contact your

supplier.

2. Please dispose of the

packaging material in an

environmentally friendly

manner.

3. Do not let children play with

packaging and its parts.

There is a risk of suffocation

from collapsible boxes and

film.

Installation

Following installation, ensure

that the back

of the dishwasher is not

freely accessible (protection

against contact due to hot

surface).

Install and connect

the appliance according

to the installation

and assembly instructions.

Prior to installation,

disconnect the dishwasher

from the power supply.

Ensure that the protective

conductor system

of the domestic supply has

been correctly installed.

The electrical connection

conditions must correspond

with the specifications

on the dishwasher rating

plate 92.

If the power cord of this

appliance is damaged,

it must be replaced with

a particular power cord.

To prevent injury, the power

cord may be purchased from

customer service only.

If the dishwasher is installed

in a high-sided unit, the unit

must be secured properly.

en Safety instructions

m Warning

Risk of scalding!

Open the door carefully when

the programme is still running.

There is a risk of hot water

spraying out of the appliance.

m Warning

Risks to children!

If fitted, use the childproof

lock. An exact description

can be

found in the back of the enve

lope.

Do not allow children to play

with or operate

the appliance.

Keep children away from

detergents and rinse aid.

These may cause chemical

burns in the mouth, throat

and eyes or asphyxiation.

Keep children away from

open dishwasher. There may

be small parts in the

dishwasher which children

could swallow and the water

inside the dishwasher is not

drinking water as it may

contain detergent residue.

Ensure that children do not

place fingers in the tablet

collecting tray 12. Small

fingers could become

caught in the slots.

When opening and closing

the door on an eye-level

appliance, ensure that

children do not become

jammed or crushed between

the appliance door and the

cupboard door below.

Children could become

locked in the appliance

(danger of suffocation) or get

into another dangerous

situation.

Redundant appliances: Pull

out the mains plug, sever

and dispose of the power

cord. Destroy the door lock

so that the door can no

longer be closed.

Protection of the environment en

7 Protection of the

environment

Protection of the environment

Both the packaging of new appliances

and the old appliances themselves

contain valuable raw materials

and recyclable materials.

Please dispose of the individual parts

separated according to type.

Please ask your dealer or inquire at your

local authority about current means

of disposal.

Packaging

All plastic parts of the appliance are

identified with internationally

standardised abbreviations (e.g. >PS<

polystyrene). Therefore, plastic waste

can be sorted out when the appliance is

being disposed of.

Please follow the safety instructions

under “Delivery”.

Old appliances

Please follow the safety instructions

under “Disposal of your appliance”.

* Getting to know your

appliance

Getting to know your appliance

Diagrams of the control panel

and the interior of the appliance can be

found in the envelope at the front.

Individual positions are referred

to in the text.

Control panel

* depending on model

** Number depending on model

This appliance is labelled in

accordance with European

Directive 2012/19/EU

concerning used electrical and

electronic appliances (waste

electrical and electronic

equipment - WEEE). The

guideline determines the

framework for the return and

recycling of used appliances as

applicable throughout the EU

( ON/OFF switch

0 Door opener

8 Programme selector

@ START button

H Timer programming *

P Additional options **

X Rinse aid refill indicator

` Salt refill indicator

h Display “Check water supply”

)" Dry display

)* Cleaning display

en Water softening system/Special salt

Appliance interior

* depending on model

+ Water softening

system/Special salt

Water softening system/Special salt

To ensure good washing results,

the dishwasher requires soft water, i.e.

containing low amounts of lime,

otherwise white limescale will be

deposited on the utensils and inner

container.

Tap water above a specific

degree of water hardness must be

softened, i.e. descaled,

for use in a dishwasher. Water

is softened with special salt in the water

softening system of the dishwasher.

The setting and therefore the required

amount of salt

depends on the degree of hardness of

your tap water (see table).

Setting

The amount of salt dispensed can be

set in 4 stages

depending on the hardness of your

water. Accordingly 0, 1, 2 or 3 displays

are lit (see table). Factory setting: 1.

1. Find out about the hardness

value of your tap water. Your water

utility company will help you with this.

2. Setting can be found in the water

hardness table.

3. Close the door.

4. Switch on ON/OFF switch (.

The Cleaning display )* flashes.

5. Press and hold down the START

button .@

6. Rotate programme selector 8 until

the salt refill indicator ` flashes.

7. Release button.

The salt refill indicator ` flashes

and the display “Check water

supply” h are lit (= Setting 1).

To change the setting:

1. Rotate programme selector 8 until

the required setting has been

selected.

2. Press START button .@

The salt refill indicator ` goes out.

The selected setting is saved.

1" Top basket

1* Knife shelf *

12 Tablet collecting tray

1: Top spray arm

1B Bottom spray arm

1J Dispenser for special salt

1R Filters

1Z Cutlery basket

1b Bottom basket

1j Dispenser for rinse aid

9" Detergent dispenser

9* Lock for detergent dispenser

92 Rating plate

Water softening system/Special salt en

Water hardness table

Using special salt

Always refill with special salt

immediately before switching on the

appliance. This ensures that overrun

special salt solution is immediately

washed out and does not corrode the

rinsing tank.

1. Open the screw-type cap of the

compartment .1J

2. Fill the tank with water (only required

when switching on the appliance for

the first time).

3. (not table Then add dishwasher salt

salt or tablets).

The water is displaced and runs out.

As soon as the salt refill indicator `

on the fascia is lit, top up the salt.

* depending on model

Using detergents with salt

component

Detergents with salt component

If combined detergents with a salt

component are used, salt can usually be

omitted up to a water hardness of

21° dH (37° fH, 26° Clarke, 3.7 mmol/

l). If the water hardness is over 21° dH,

special salt must be used.

Switching off water softening system

Switching off salt refill

indicator/water softening

system

If the salt refill indicator ` is impaired

(e.g. when using combined detergents

containing salt component), it can be

switched off.

Proceed as described under

“Adjusting the water softening

system” and select setting 0.

The water softening system and salt

refill indicator are now switched off.

m Caution

Never fill the salt dispenser with

detergent. You will destroy the water

softening system.

en Rinse aid

, Rinse aid

Rinse aid

As soon as the rinse-aid refill

indicator is lit on the fascia, there X

is still a rinse-aid reserve of 1-2 rinsing

processes. Refill with rinse aid.

The rinse aid is required for stain-free

utensils and clear glasses. Use only

rinse aid for domestic dishwashers.

Combined detergents with rinse-aid

component may be used up to a water

hardness of 21° dH (37° fH,

26° Clarke, 3.7 mmol/l) only. If

the water hardness is over 21° dH,

rinse aid must be used.

1. Open the dispenser 1j by pressing

and lifting the plate on the cover.

2. Carefully pour rinse aid up

to the max. mark in the filler opening.

3. Close cover until it clicks shut.

4. To prevent excessive foam formation

during the next rinse cycle, remove

any rinse aid which has run over with

a cloth.

Setting amount of rinse aid

The amount of rinse aid dispensed can

be set in 4 stages. Accordingly 0, 1, 2

or 3 displays are lit (see water hardness

table).

Factory setting: 2.

Do not change the amount of rinse aid

unless streaks (select lower

setting) or water stains (select higher

setting) are left on the utensils.

1. Close the door.

2. Switch on ON/OFF switch (.

The Cleaning display )* flashes.

3. Press and hold down the START

button .@

4. Rotate programme selector 8 until

the rinse aid refill indicator X

flashes.

5. Release button.

The rinse aid refill indicator X

flashes and the displays )"

and are lit (= Setting 2).h

To change the setting:

1. Rotate programme selector 8 until

the required setting has been

selected.

2. Press START button .@

The rinse-aid refill indicator X goes

out. The selected setting is saved.

Utensils en

Switching off rinse-aid refill

indicator

If the rinse-aid refill indicator X is

impaired (e.g. when using combined

detergents containing rinse-aid

component), it can be switched off.

Proceed as described under “Setting

amount of rinse aid” and select

setting 0.

The rinse aid refill indicator is now X

switched off.

- Utensils

Utensils

Not suitable

Cutlery and utensils made of wood.

Delicate decorative glasses, craft

and antique utensils. These decors

are not dishwasher-proof.

Plastic parts not resistant to heat.

Copper and tin utensils.

Utensils which are soiled with ash,

wax, lubricating grease or ink.

Aluminium and silver parts have a

tendency to discolour and fade during

the wash cycle. Even some types of

glass (e.g. crystal glass objects) may

turn cloudy after many wash cycles.

Glass and utensil damage

Causes:

Glass type and glass production

process.

Chemical composition of the

detergent.

Water temperature of the wash

programme.

Recommendation:

Use only glasses and porcelain

which the manufacturer designates

as dishwasher-proof.

Use a detergent which protects

utensils.

Take glass and cutlery out of the

dishwasher as soon as possible after

the programme ends.

Loading the dishwasher

1. Remove large food remnants. It is

not necessary to prerinse utensils

under running water.

2. Place the utensils so that

– they are secure and cannot tip

over.

– all utensils with their openings

face down.

– parts with curves or indentations

are at an angle, thereby allowing

water to drain.

– does not obstruct rotation of the

two spray arms and .1: 1B

Very small utensils should not be

washed in the machine, as they may fall

out of the baskets.

Unloading the dishwasher

To prevent water from dripping off the

upper basket onto the utensils in the

lower basket, it is recommended

to empty the appliance from the bottom

up.

Hot utensils are sensitive to shock!

Therefore, when the programme ends,

leave the utensils to cool down in the

dishwasher until they can be handled.

Note

When the programme ends, water

droplets can still be seen inside

the appliance. This does not affect

the drying of the utensils.

en Utensils

Cups and glasses

Top basket 1"

Note

Utensils must not be placed above the

tablet collecting tray 12. These may

block the lid of the detergent dispenser

and prevent it from opening fully.

Pans

Bottom basket 1b

Tip

Heavily soiled utensils (pans) should

be placed in the bottom basket. The

more powerful spray jet provides

a better dishwashing result.

Tip

Other examples, such as the best way

of loading your dishwasher, can

be found on our homepage as a free

download. The corresponding Internet

address can be found on the back page

of these instructions for use.

Utensils en

Cutlery basket

You should always place cutlery

unsorted with the points downwards.

To prevent injuries, place long, pointed

implements and knives on the knife

shelf.

Etagere

Etagere *

The etagere and the space underneath

can be used for small cups and glasses

or for larger items of cutlery, such as

wooden spoons or serving cutlery. The

etagere can be folded up if not required.

* Depending on the model, a 3-fold

height adjustment is possible. To do

this, first place the etagere vertically

and pull up, then place at a slight angle,

push down to the required height (1, 2,

or 3) and snap into place.

Folding spikes

Folding spikes *

* depending on model

The spikes can be folded down to

improve arrangement of pans, bowls

and glasses.

Small accessories holder *

Small accessories holder

* depending on model

Light-weight plastic accessories, e.g.

cups, lids, etc. can be held securely in

the small accessories holder.

CLICK

Specyfikacje produktu

Marka:	Profilo
Kategoria:	ZMYWARKI
Model:	BM3121EA
Typ kontroli:	Buttons, Rotary
Wbudowany wyświetlacz:	Tak
Typ wyświetlacza:	LED
Położenie urządzenia:	Wolnostojący
Częstotliwość wejściowa AC:	50 - 60 Hz
Napięcie wejściowe AC:	220 - 240 V
Wysokość produktu:	845 mm
Szerokość produktu:	600 mm
Głębokość produktu:	600 mm
Rozmiar produktu:	Pełny rozmiar (60 cm)
Kolor drzwiczek:	Biały
Kolor panelu sterowania:	Biały
Regulowana wysokość górnego koszyka:	Tak
Programy mycia:	Eco, Intensive, Quick
Liczba miejsc:	12 komplet.
Ilość programów piorących:	3
Poziom hałasu:	54 dB
Opóźniony start czasomierza:	Nie
Pół wsadu:	Tak
Czas cyklu:	195 min
Prąd:	10 A
Obciążenie:	2400 W
Pobór wody na cykl:	14 l
Zużycie energii na cykl:	1.02 kWh
Tryb wyłączenia:	0.1 W
Wskaźnik konieczności płukania:	Tak
Wskaźnik soli:	Tak
Wskaźnik pozostałego czasu:	Nie
Klasa efektywności energetycznej (stara):	A+
Ochrona szkła:	Tak
Światło wewnętrzne:	Nie
Asystent dozowania:	Tak
Roczne zużycie energii:	290 kWh
Kategoria suszenia:	A
Roczne spożycie wody:	3920 l
Wysokość do blatu:	815 mm
Automatyczne wykrywanie detergentu:	Tak
Maksymalny rozmiar naczyń (koszyk dolny):	300 mm
