Strona 1/4
Subwoofer Manual
Manuel de subwoofer
Features Caractéristiques
Models: SXt10d2, SXt10d4, SXt12d2, SXt12d4
• OnePiecePolypropyleneDustcap
• HighTemperature2.0InchOFCVoiceCoils
•DieCastAluminumHeatsinkSpiderSpacer
• OptimizedforSealedorVentedEnclosures
• RigidPowderCoatedSteelFrame
• NickelPlated12GaugeSpeakerTerminals
• HighExcursionMotorDesign
• Pare-poussièremonopièce
•Aluminiummoulédissipateurthermiquespiderspacer
• Bobinesacoustiquesencuivreexemptd’oxygèneà
hautetempérature
• Panierrigideenacier
• Bornesd’enceintenickeléesdecalibre12
• Modèledemoteuràgrandbattement
www.phoenixgold.com
SubwooferOwner’sManual
Enclosures
SEALED Enclosure recommendations
ENCLOSURE INFORMATION
Phoenix Gold subwoofers are overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure is built to these same exacting
standards. The enclosure must be constructed of at least .75 inch MDF for 10 and 12 inch subwoofers or .625 MDF for 8 inch subwoofers. Screws or air staples
are excellent construction fasteners when used with a strong bonding “yellow” wood working glue that can ll joint gaps. Be sure that the enclosure’s panels are
airtight at all joining seams. Lining the walls with a polyester matting 1 to 3 inches thick is sufcient.
Your PG dealer has extensive knowledge, tools and the experience needed for the design and construction necessary for your subwoofer application. We also
recommend you consult with your dealer for specic technical assistance related to your installation. The charts provided should be used as a reference when
building an enclosure for your subwoofer.
INFORMATIONS SUR L’ENCEINTE
Les caissons d’extrêmes graves sont fabriqués en fonction de normes rigoureuses an de fournir des années de plaisir acoustique. Il est important que
l’enceinte du caisson des extrêmes graves soit construite en fonction de ces mêmes normes rigoureuses. L’enceinte doit comprendre au moins un RP d’au
moins 3/4” de pouces. Les vis ou agrafeuses pneumatiques constituent d’excellentes pièces de xation lorsqu’elles sont utilisées avec une colle forte de
couleur «jaune » pour le travail du bois qui peut combler les écarts de jointures. Assurez-vous que les panneaux de l’enceinte soient étanches au niveau de
toutes les piqûres de liaison. Le revêtement des murs à l’aide d’une natte en polyester épaisse de 1 à 3 pouces suft.
Votre concessionnaire PG dispose de grandes connaissances, d’outils et d’expérience requise pour la conception et la constructions de votre application
de caisson d’extrêmes graves. Nous recommandons également de consulter votre concessionnaire an d’obtenir une assistance technique spécique se
rapportant à votre installation. Les tableaux fournis devraient être utilisés comme référence au moment de construire une enceinte pour votre caisson aux
extrêmes graves PG. Les tableaux présentent plusieurs types d’enceinte. L’enceinte de Qualité du son offre une sortie de musique qui est plus profonde, plus
serrée et davantage de sortie sonore an de reproduire véritablement le matériau source d’origine. L’enceinte SPL satisfait le besoin en «basshead» pour une
sortie maximale tout en sacriant un peu de la qualité du son.
SEALED
VOLUME(cu.ft.)
SXt10d2
SXt10d4
SXt12d2
SXt12d4
SPL 0.4 0.75
Normal 0.6 1.1
SQ 0.8 1.5
SPL = More overall output and compact enclosure size, but sacrices some low bass and smooth overall output
Normal = Excellent blend of low bass, accurate and strong overall outputRecommended for most listeners.
SQ = Smooth and exceptional low bass output, but larger enclosure size and sacrices some overall output
Additional Notes:
- For vented enclosures a subsonic lter set at 30Hz to 40Hz is highly recommended.
- Sealed enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer.
- Vented enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer. But DO NOT include displacement of the vent.
- In many cases, a 3 inch round vent/port can be used instead of a rectangle/slot vent. This can reduce the vent length and
simply the enclosure construction. However, in some rare cases at high power a small amount of port noise maybe audible. The
provided slot/rectangle ports will provide maximum performance and the most predictable results. Contact technical support for
additional enclosure options.
-
www.phoenixgold.com
VENTED - Normal SXt10d2
SXt10d4
SXt12d2
SXt12d4
Volume(cu.ft.) 1.5 2.0
VentOpening(in.) 2x8 2x10
VentLength(in.) 22.75 21.5
TuningFreq 38Hz 35Hz
VENTED - SPL SXt10d2
SXt10d4
SXt12d2
SXt12d4
Volume(cu.ft.) 1.25 1.75
VentOpening(in.) 2x8 2x10
VentLength(in.) 21 18
TuningFreq 44Hz 40Hz
SubwooferOwner’sManual
Vented Enclosure Recommendations
+
-
+
-
Allvoicecoilsarewiredinparallelfor2ohmload.
RX250.1makesmaximumpowerintoa2ohmload.
SXt12d4 or SXt10d4
SINGLE SUBWOOFER SYSTEM
Dual4ohmSubwoofer(wiredinparallel)
Dual4ohmSubwoofers(wiredinparallel)
SXt12d4 or SXt10d4
DUAL SUBWOOFER SYSTEM
Allvoicecoilsarewiredinparallelfor1ohmload.
SX600.1makesmaximumpowerinto1ohmload.
Touteslesbobinesmobilessontcâbléesenparallèlede2Ohms.
RX250.1fairepuissancemaximaleen2Ohms.
Touteslesbobinesmobilessontcâbléesenparallèlepour
1Ohm.SX600.1rendlapuissancemaximaledechargeen
1ohm.
RX250.1Terminal
SX600.1Terminal
SYSTEM EXAMPLES
+
-
+
-
+
-
+
