Atlas SCR
Triac and Thyristor Analyser
Model SCR100
User Guide
©
Peak Electronic Design Limited 2004/2011
In the interests of development, information in this guide is subject to change without notice - E&OE
GB100-5
electronic design ltd
®
Atlas SCR User Guide June 2011 – Rev 5
Page 2
Want to use it now?
We understand that you want to use your right now. Atlas SCR
The unit is ready to go and you should have little need to refer
to this user guide, but please make sure that you do at least take
a look at the notices on page 4!
Contents Page
Introduction......................................................................... 3
Safety Considerations.......................................................... 4
Analysing components ........................................................ 5
SCRs.............................................................................. 6
Triacs............................................................................. 7
Notes on SCRs (Thyristors) and Triacs............................... 8
Gate Sensitivity ................................................................. 10
Gate Voltage ..................................................................... 11
Care of your ..................................................... 12 Atlas SCR
Battery Replacement ................................................... 12
Self Tests ..................................................................... 13
Appendix A – Accessories ................................................ 14
Appendix B – Technical Specifications ............................ 15
Warranty Information........................................................ 16
Atlas SCR User Guide June 2011 – Rev 5
Page 3
Introduction
The is an advanced instrument designed specifically Atlas SCR
for the analysis of SCR (Thyristor) and Triac devices.
Summary Features:
• Automatic component identification (Thyristor or Triac).
• Automatic pinout identification.
• Displays actual trigger (gate) current classification.
• Measures gate voltage during trigger.
• Fixed load current of 100mA.
• Unique automatic boost function ensures a device test
voltage of 12V regardless of battery condition.
• Suitable for devices requiring gate currents up to 90mA.
• Automatic and manual power-off.
