Important: You will need the BlueBOLT-CV1’s unique MAC address and challenge key (provided on the 2 labels

attached to the cover of the Quick Start Guide which is included in the M4315-PRO packaging). One label is

permanently adhered to the Quick Start Guide and the other is removable for your convenience.

1 2 3 4 5 6 7 8

UNSAFE VOLTAGE

BREAKER

WIRING FAULT

TEMPERATURE

15 A

BRIGHTNESS

OUTLET STATUS

REBOOT 1 REBOOT 2

M4315-PRO

BLT

Blue

™

EN AB LED

VOLTS

Power Management with Control System Interactive Functionality.

• 15 Amp Capacity M4315-PRO

• 8 Individually Controllable Rear Panel Outlets

• Fully Programmable

• TCP/IP (BlueBOLT™) Installed

• RS-232 Card (Included, not installed)

• Linear Filtration with 3 Isolated LiFT Filter Banks, 76db (5 kHz - 250 kHz), 46 db (250 kHz - 1 MHz)

• One Isolated Filter Bank for High Current Devices, 60db (5 kHz - 450 kHz), 46 db (450 kHz - 1 MHz)

• Front Panel Circuit Breaker

• Integrated Front Rack Ears

• 12 Volt Input Triggering

• Detachable 10 ft. Power Cord

• AVM & Protect-or-Disconnect Circuitry

M4315-PRO Instructions

INS00859 REV. D 5/10

BLT

Blue

™



ENABLED

Thank you for purchasing a Panamax M4315-PRO Power Management with control system interactive functionality, and congratulations on your choice.

The M4315-PRO features Panamax’s revolutionary AVM (Automatic Voltage Monitoring) circuit, and our exclusive Linear Filtering Technology (LiFT). To-

gether, these technologies comprise precisely what our customers have come to expect from Panamax: uncompromised AC protection and puriﬁcation.

Outlets: all rear panel outlets are separately controlled. They are grouped into four (4) ﬁlter-isolated banks. BlueBOLT™ is included, providing secure,

hosted IP system control and monitoring for the M4315-PRO.

Introduction

1 2 3 4 5 6 7 8

UNSAFE VOLTAGE

BREAKER

WIRING FAULT

TEMP ERATUR E

15 A

BRIGHTNESS

OUTLET STATUS

REBOOT 1 REBOOT 2

M4315-PRO

BLT

Blue

™

ENABLED

VOLTS

RS232

Table of Contents

Feature Descriptions....................................................................................................................................................................................... ..pg. 1

Important Safety Instructions, Front Panel Features Overview..............................................................................................................................pg. 2

Preset Proﬁle Information.................................................................................................................................................................................pg. 3

Rear Panel Features Overview, Bubble of Protection.......................................................................................................................................... pg. 4

BlueBOLT™ Setup, Registration, Trouble Shooting.............................................................................................................................................pg. 5

Diagram to Identify Connected Equipment, Additional Notes................................................................................................................................pg. 6

RS-232 Installation, RS-232 and Telnet Command Set / Protocol Speciﬁcations.............................................................................................pgs. 7, 8, 9, 10, 11

Product Speciﬁcations, FCC Notice, Contacting Customer Service..........................................................................................................................pg. 12

Box should contain the following, including the Quick Start Guide:

Before You Begin Inspect Upon Receipt.

1. M4315-PRO

2. RS-232 Card (Included not installed) 2. Four silicone rubber feet for shelf mounting.

® 2010 Panamax LLC, 1690 Corporate Circle, Petaluma, CA 94954 • www.panamax.com • 707-283-5900 • Fax 707-283-5901

3. Four Phillips pan head screws with cup washers for

rack mounting.

Features Descriptions

BlueBOLT™:

Remote Power Management technology provides secure, hosted IP

(Internet Protocol) system control. With BlueBOLT™, custom electronics

installers, integrators and end-users can remotely monitor and control power to

home theater equipment by accessing power management components from

anywhere in the world. From simple system reboots to comprehensive monitoring

of power status, BlueBOLT™

provides the power to control complex A/V systems

from their most fundamental level: their power source (M4315-PRO).

RS232 Communication Interface Card:

For custom conﬁguration and/or home automation control. (Included, not

installed)

LiFT Technology EMI/RFI Noise Filtration :

Your audio/video components are constantly being bombarded by electromag-

netic interference (EMI) and radio frequency interference (RFI) through their AC

power source. This contaminated power can affect audio/video equipment and

will degrade the overall performance of your entire system. Common symptoms

of contaminated power include loss of picture detail, dull colors, pops, hisses,

hums and visual artifacts.

Automatic Over & Under Voltage Protection (AVM):

Panamax’s patented power monitoring circuitry constantly monitors the AC line

voltage for unsafe voltage conditions such as momentary spikes or prolonged

over-voltages and under-voltages (brownouts). These unsafe conditions pose

a very dangerous threat to all electronic equipment within the home. If the

M4315-PRO senses an unsafe power condition, it will automatically disconnect

your equipment from the power to protect equipment from damage. Once the

voltage returns to a safe level, the M4315-PRO will automatically reconnect

the power.

• When subjected to a 6,000V (open circuit voltage) / 3,000A (short circuit cur-

rent) surge, the M4315-PRO limits its voltage output to less than 330V peak,

UL’s lowest rating.

• If the magnitude of the surge is greater than the capacity of the surge protec-

tion components, the M4315-PRO’s Protect or Disconnect Circuitry will dis-

connect your equipment in order to protect it. The M4315-PRO will need to

be repaired or replaced by Panamax if this occurs within the product’s 3 year

warranty.

4 Isolated Outlet Banks

The M4315-PRO is designed to provide noise isolation between the outlet banks

so that any noise created by A/V components plugged into the M4315-PRO

cannot contaminate the power going to equipment plugged into the other outlet

banks of the M4315-PRO.

Sequential Startup/Shutdown:

Complex audio/video systems may be susceptible to voltage transients gener-

ated internally at start-up/shutdown if all of the equipment is powered on or off

at the same time. This can cause speaker “thumps”, which are not only annoy-

ing, but can also damage the speakers and/or trip product circuit breakers. The

M4315-PRO is designed to eliminate these transients by providing a “start-up”

delay for the High-Current outlets and a “shut-down” delay for the Switched

Outlet Banks. This minimizes inrush current issues by allowing the components

plugged into the Switched Outlet Banks to power-up and stabilize before any

ampliﬁers and powered subwoofers are turned on. This sequence is reversed

during shut-down. The ampliﬁers and powered subwoofers turn off, their power

supplies drain, and then the equipment plugged into the Switched Outlet Banks

are turned off. Additionally, the start-up and shut-down delays can be adjusted

for custom applications.

Voltage Sense Trigger:

The M4315-PRO voltage sense trigger input uses a standard 3.5mm (1/8”)

mini-mono plug. This feature provides an ON/OFF trigger for the M4315-PRO

using a Direct Current (DC) voltage signal. Many components such as pre-

ampliﬁers and receivers have a DC trigger built in, and will transmit a constant

power signal when turned on and in use. The presence of this power signal will

turn on the M4315-PRO’s switched outlets. When the source component is

turned off, the voltage trigger signal is also turned off, and the M4315-PRO’s

shutdown sequence is initiated. An AC Adapter of the appropriate voltage (5-

24 VDC) plugged into a switched outlet may also be used if a DC trigger is not

built in.

Cable/Satellite/Antenna TV signal protection:

Coaxial protection circuits achieve optimum signal quality from our new coaxial

protectors that have the smallest signal loss on the market - less than 0.5 db

of attenuation from 0 Hz to 2.2 GHz. Our upgraded coaxial protection has been

speciﬁcally designed to virtually eliminate signal loss. The clamping level of

75V will meet the demands of both cable and satellite voltage while minimizing

exposure to damaging spikes and surges.

Telephone Line Protection:

Digital video recorders and satellite TV receivers require a telephone line con-

nection for TV show scheduling and/or Pay-Per-View services. The M4315-PRO

also provides surge protection for this line. One pair of RJ-11 telephone jacks

is provided for this. The circuitry utilizes auto-resetting PTCRs and solid state

SIDACtors® for reliability and unsurpassed protection. The clamping level of

the M4315-PRO’s telephone protector is 260 volts. This will allow typical ring

voltage (90-130VAC) and operating battery voltage (-48DC) to pass through

the circuit and still protect the modem in your satellite receiver from damage.

Incoming tel line must be plugged into the IN Jack. Patch cord to the equipment

must be plugged into OUT.

LAN Protection:

Protection circuits for 10/100/1000 baseT Ethernet lines. 8 wire protection,

62V clamping.

® Littlefuse, Inc.
