Instrukcja obsługi OSD Audio NERO-MAX12

OSD Audio odbiornik NERO-MAX12

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla OSD Audio NERO-MAX12 (22 stron) w kategorii odbiornik. Ta instrukcja była pomocna dla 5 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF
Strona 1/22
NERO MAX12 M U L T I R O O M
A M RP L I F I E
Six Source Six Zone Multi-Room Amp With iOS / Android App Control
Integrated App Control With Optional Keypad Control
POWER ZONE ZONE ZONE ZONE ZONE ZONE 1 2 3 4 5 6
NERO MAX12 WI-FI MULTIROOM
A M P L I F I E R
NERO MAX12 MANUAL
is intended to alert the user to the presence of nu-insulated “danger-
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
This product was designed and manufactured to meet strict quality and safety standards.
There are, however,some installation and operation precautions, which you should be par-
ticularly aware of.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER ( OR BACK )
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICE TO QUALIFIED SERVICE PERSONNEL
WARNING
1. - All the safety and operating instructions should be read before the appliance is operated.Read Instructions
2. - The safety and operating instructions should be retained for future reference.Retain Instructions
3. Heed Warnings - All warnings on appliance and in the operating instructions should be adhered to.
4. - All operating and use instructions should be followed.Follow instructions
5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc.
6. - The appliance should be only with a cart or stand that is recommended by the manufacturer. An Carts and Stands
appliance and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and cart combination to overturn.
NERO MAX12 MANUAL
Power: 8 Ohm - W x 2 per zone40
4 Ohm - 0W x 2 per zone8
Bridge
S/N: >85dB A WTD
THD: <0.1%
Freq Response: 20Hz-20KHz
Input Impedance: >47 K Ohm
Input Sensitivity: 250mv
Protection: Overload, Short Circuit, Temperature
System Voltage: DC +12V
External Mute Voltage: DC +12V
Power Supply: AC 115V/60Hz - 230V/50Hz
Output Connection: Terminal Block
Dimensions: 16.9”W x 3.5”H x 16.4”D
Weight: 25lbs
• NERO MAX12 Amp
• Expansion Ribbon Cable
• Rack Ears (Pre Installed on Amp)
• Speaker Termainal Blocks (Pre Installed on Amp)
• AC Power Cable
• Product Manual
CONTENTS
SPECS
FEATURES
The NERO MAX12 is a functional, easy to install, highly compatible, expandable and user-friendly
audio distribution system. It features six Analog Source Inputs and provides up to 0W @4-ohm 8
from a Class D amplifier for six zones expandable to 12 or 18 zones which can be controlled by the
either the OSD Control App (Free App that Duplicates the Keypads), Optional Keypads with IR
Remote Control or RS-232.
• 6x6 Audio Matrix Switch with 6 Bridgeable Zones and Six Source Inputs
• Expandable to 2/3 units, 12/18 zones of distributed Audio.
• Free iOS & Android App duplicates the Control Panels for each
Zone/Room. Optional Control Pads/IR Remote are available as well.
• High Efficiency Class D Amplifier; 0 watts (4-ohms) and watts (8-ohms)8 40
Each Zone can drive a single 4-ohm pair of speakers or two pair of 8-ohm speakers
Stereo/Bridge Mono Output for combining zones 100 Watts at 8 ohm only
• 3 Stereo line-level Pre-AMP L&R RCA Outputs (Zones 1-3)
• 6 Stereo line-level L&R RCA Analog Source Inputs
• RS232 for transferring and receiving the serial data between two devices.
• 6 Individual Zone Status (3.5mm): Used to control external Zone Devices (12V triggers)
• 6 IR Emitter 3.5mm Mono RCA outputs + 1 IR Emitter/Blaster 3.5mm Mono All Output
• 1 PA Input jack to set all zones to Source 1 (12Vdc Trigger)
• External Mute In/Control Out (3.5mm Mono RCA connections/12Vdc)
• AGC (Automatic Gain Control): brings low input levels up to a preset-level
• Unit ID Selector Switch: Master/Slave 1/Slave 2( Expandable settings)
• Multi Voltage Selector 115V or 230V, AC Input connection with Fuse Receptable (CE Certified)

Specyfikacje produktu

Marka: OSD Audio
Kategoria: odbiornik
Model: NERO-MAX12
