Strona 1/8
Cabled scanners
Barcode CCD scanner
Related products
C37
OPR3001
Cabled device•
Barcode laser scanner•
RS232, Keyboard Wedge, USB•
OPR2001
Cabled device•
Barcode laser scanner•
RS232, Keyboard Wedge, USB•
With stand•
OPL7836
Cabled device•
Barcode laser scanner•
RS232, Keyboard Wedge, USB•
C 7_0023
Basic Product Specifications
Operating indicators
Visual: 1 LED (red/green/orange)•
Non-visual: Buzzer•
Operating keys
Entry options: •
1 scan key
Communication
RS232: DB9 PTF connector with external power •
supply
Keyboard Wedge: MiniDIN6 F/M connector•
USB: Ver. 1.1, HID/VCP, USB-A connector•
Power
Voltage requirement: 5V • ± 10% (Keyboard Wedge
and USB), 6V (min. 4.5, max. 6.6V) (RS232)
Barcode scanner Optics
Light source: 630 nm red LED•
Scan method: CCD linear Sensor 2500 Pixels•
Scan rate: 200 scans/sec•
Trigger mode: Manual, auto-trigger•
Reading pitch angle: -30 to 0°, 0 to +30°•
Reading skew angle: -70 to -20°, 20 to +70°•
Reading tilt angle: -25 to 0°, 0 to +25°•
Curvature: R>15 mm (EAN8), R>20 mm (EAN13) •
Min. resolution at PCS 0.9: 0.125 mm / 5 mil •
Depth of field: At PCS 0.9, Code 39 •
0 - 15 mm / 0 - 0.59 in
Supported Symbologies
Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/•
NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128
(EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,
Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5, MSI/
Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code: Chinese Post, Korean Postal Authority •
code
Durability
Temperature in operation: 0 to 50 °C / 32 to 122 °F•
Temperature in storage: -20 to 60 °C / -14 to 140 °F•
Humidity in operation: 5 - 95% (non-condensing)•
Humidity in storage: 5 - 95% (non-condensing)•
Ambient light immunity: • Fluoresecent 10,000 lx
max, Incandescent 10,000 lx max
Drop test: 1.5 m / 5 ft drop onto concrete surface•
Vibration test: 10 - 100 Hz with 2G for 1 hour•
Protection rate: IP 42•
Physical
Dimensions (w x h x d):•
75 x 150 x 53 mm / 2.95 x 5.91 x 2.09 in
Weight body: Ca. 90 g / 3.2 oz (excl. cable) •
Case: ABS, Black, White•
Regulatory & Safety
Product compliance: CE, FCC, VCCI, RoHS•
Enclosed items
Power supply 100-240V/0.5A, 50/60 Hz, 6V/2A (for •
RS232)
Models
Interface versions: RS232, Keyboard Wedge, USB•
Color versions: Black, White•
W W O NW . O P T I C . C O M
Copyright Opticon. All rights reserved. This information is subject to change without prior notice. For availability, contact your local representative.
- The Netherlands: Hoofddorp
- France: Issy Les Moulineaux
- Germany: Dietzenbach
- Italy: Castel Maggiore (BO)
- Spain: Valencia
- Sweden: Järfälla
- United Kingdom: Luton, Bedfordshire
- U.S.A.: Renton, WA
- Japan: Warabi City
- Taiwan: Taipei
- P.R.China: Shanghai
- Australia: Kariong
- Brazil: São Paulo
Opticon Sensors Europe B.V
European headquarters
Opaallaan 35
2132 XV Hoofddorp
The Netherlands
phone: +31 (0)23-5692700
fax: +31 (0)23-5638266
email: sales@opticon.com
internet: www.opticon.com
