* DO NOT USE ANY COPPER POT, DISH INSIDE THE CABINET!
* DO NOT LOAD ANY FOOD WITHOUT PACKAGE!
WARNING !
Fully Integrated Combi Fridge Freezer
IFF70
12
Congratulations on your choice of a New World quality Appliance which has
been designed to give you service for many years.
WARNING !
IMPORTANT !
DO NOT connect your appliance to the electricity supply until all packing and
transit protectors have been removed.
• Leave to stand for at least 4 hours before switching on to allow compressor
oil to settle if transported horizontally.
• If you are discarding an old refrigerator with a lock or latch fitted to the door,
disable the lock/latch, ensure that it is left in a safe condition to prevent the
entrapment of young children.
• This fridge/freezer must only be used for its intended purpose i.e the storing
and freezing of edible foodstuff.
• Do not dispose of the appliance on a fire. At New World, the care and
protection of our environment is an ongoing commitment. This appliance
which is among the latest range introduced is particularly environment friendly.
Your appliance contains non CFC / HFC natural substances in the cooling
system (Called R600a) and in the insulation (Called cyclopentane) which are
potentially flammable if exposed to fire. Therefore, take care not to damage,
the cooling circuit / pipes of the appliance in transportation and in use. In
case of a damage do not expose the appliance to fire, potential ignition source
and immediately ventilate the room where the appliance is situated.
• We suggest you contact your local authority for disposal information and
facilities available.
• We do not recommend use of this appliance in an unheated, cold room.
(E.g.: garage, conservatory, annex, shed, out-house etc.)
• To obtain the best possible performance and trouble free operation from your
appliance it is very important to carefully read these instructions.
• Ensure that the plug remains readily accessible. Do not use multiple adapter
bar.
• Failure to observe these instructions may invalidate your right to free service
during the guarantee period.
• Route electrical supply cord to allow easy connection and disconnection
after installation.
• We recommend a separate switch be employed to ensure easy switch on /
off.
WARNING- Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING- Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING- Do not damage the refrigerant circuit.
WARNING- Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended by
the manufacturer.
• We suggest you keep these instructions in a safeplace for easy reference.
Contents
Introduction & safety warnings...........................................................................2
Electrical requirements ......................................................................................3
Transportation instructions.................................................................................4
Installation instructions.......................................................................................4
Getting to know your combi fridge / freezer .......................................................6
Suggested arrangement of food in the fridge/freezer.........................................7
Temperature control and adjustment..................................................................8
Starting...............................................................................................................9
Storing frozen food.............................................................................................9
Freezing fresh food ..........................................................................................10
Making ice cubes .............................................................................................10
Defrosting.........................................................................................................11
Cleaning and care............................................................................................12
Replacing the interior light bulb........................................................................13
Do's and don'ts.................................................................................................14
Energy saving tips ............................................................................................15
Installation instructions .....................................................................................16
Reversing the doors.........................................................................................21
Guarantee........................................................................................................22
How to obtain service.......................................................................................23
Technical data..................................................................................................24
Wiring diagram.................................................................................................25
Customer Care..................................................................................back cover
Please keep this handbook for future reference, or for
anyone else who may use the appliance.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP
TRANSPORTATION INSTRUCTIONS
1. The appliance should be transported only in a vertical upright position. The
packing as supplied must be intact during transportation.
2. If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in the front
of the appliance. After bringing it to upright position,it must not be operated
for at least 4 hours to allow the system to settle.
3. Failure to comply with the above instructions could result in damage occuring
to the appliance. The manufacturer will not be held responsible if these
instructions are disregarded.
4. The appliance must be protected against rain, moisture and other
atmospheric influences.
5. When positioning your appliance take care not to damage your flooring,
kitchen furniture, related parts and doors, pipes, wall coverings etc. Do not
move the appliance by pulling by the door.
6. Empty any water in the drain tray before moving. See section ‘Defrosting’
and ‘Care & cleaning’ for further information.
7. Make sure that the defrost water pipe at the back of the product is fixed to
the plastic evaporating pan on the top of the compressor, to avoid defrost
water spillage on the floor.
IMPORTANT : Care must be taken while cleaning / carrying the appliance to
avoid touching the bottom of the condenser metal wires at the back of the
appliance as you might injure your fingers and hands.
Do not attempt to sit or stand on top of your appliance as it is not designed
for such use. You could injure yourself or damage the appliance.
"IMPORTANT: Make sure that mains cable is not caught under the appliance
during and after carrying / moving the appliance, to avoid the mains cable
becoming cut or damaged."
Do not allow children to play with the appliance or tamper with the controls.
New World declines to accept any liability should the instructions not be
followed.
IMPORTANT
INSTALLATION INSTRUCTIONS
1. The space in the room where the appliance is installed must not be smaller
than 10 cubic metres.
2. See for detailed Installation Instructions including reversing door opening
direction.
3. Do not put your fridge freezer in a cold room where the temperature is likely
to go below +5 degrees C (41 degrees F) during night time and/or especially
in winter.
43
ELECTRICAL REQUIREMENTS
Before you insert the plug into the wall socket make sure that the voltage and
the frequency shown in the rating plate inside the appliance corresponds to
your electricity supply.
Rating label is on the left hand side of fridge inner liner.
We recommend that this appliance is connected to the mains supply via a
suitable switched and fused socket in a readily accessible position.
Should the mains lead of the appliance become damaged or should it need
replacing at any time, it must be replaced by a special purpose made mains
lead which can only be obtained from a New World Authorised Service Agent.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted moulded plug is not suitable for your socket, then the plug should
be cut off and an appropriate plug fitted. Destroy the old plug which is cut off
as a plug with bared cord could cause a shock hazard if inserted into a socket
elsewhere in the house.
The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse
need to be replaced an ASTABEAB approved BS 1362 fuse of the same rating
must be used. Do not forget to refit the fuse cover. In the event of losing the
fuse cover the plug must not be used until a replacement fuse cover has been
fitted. Colour of the replacement fuse cover must be the same colour as that
visible on the pin face of the plug. Fuse covers can be obtained from a New
World authorised service agent.
IMPORTANT! FITTING A DIFFERENT PLUG
As the colours of the wires in the
mains lead of this appliance may
not correspond with the coloured
markings identifying the terminals
in your plug proceed as follows:
(See diagram).
1. Connect the green-yellow or
green (Earth) wire to the terminal
in the plug marked 'E' or with
the symbol or coloured
green and yellow or green.
2. Connect the blue (Neutral) wire
to the terminal in the plug
marked 'N' or coloured black.
3. Connect the brown (Live) wire to
the terminal in the plug marked 'L'
or coloured red.
With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor
or in the main fuse box. If in doubt contact a qualified electrician.
