Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla LG LV4981 (17 stron) w kategorii Magnetowid kasetowy. Ta instrukcja była pomocna dla 6 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek
Strona 1/17
Before connecting, operating or adjusting your new VCR,
please read this user guide carefully. Thank you.
user guide
Video Recorder
Model: LV4947 LV4981
English
R
GC981P1.BAUTLLS_ENG 3/9/09 2:22 PM Page 1
Contents, safety and cleaning
Please read the following information carefully.
Contents
Introducing your video recorder
and remote control 3
Connecting to a television and
satellite receiver 4
Tuning
TV stations 5
Adjusting TV stations manually 6
Operating your Video Recorder 7
Recording
Television programs 8
Timer recording 9
ShowView (LV4947 Only) 10
Advanced functions 11-14
Troubleshooting 15
Technical
Controlling your TV with the
supplied remote control and
technical specifications 16
Safety
• Position your Video Recorder so
that no bright light or sunlight falls
directly onto it.
• Care should be taken not to
expose your Video Recorder to
any unnecessary vibration,
moisture, dust or heat.
• During electrical storms it is
advisable to unplug both the aerial
cable and mains plug to prevent
accidental damage to your Video
Recorder and TV.
• Do not operate your Video
Recorder if it is damaged.
• If your Video Recorder still does
not operate properly, unplug it and
call your dealer. Your VCR should
not be repaired by anyone except
qualified service personnel.
• Never remove the top cover of
your Video Recorder as this can
expose you to very high voltage
and other hazards.
• Ensure that your Video Recorder is
placed in a position to allow a free
flow of air.
• The apparatus shall not be
exposed to dripping or splashing
and that no objects filled with liq-
uids, such as vases, shall be
placed on the apparatus.
This product is manufac-
tured to comply with EMC
Directive 2004/108/EC
Low Voltage Directive and
2006/95/EC.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere,
The Netherlands
(Tel : +31–036–547–8940)
Cleaning
1Unplug the Video Recorder from
the mains supply.
2Clean the cabinet with a soft
damp cloth, do not apply liquid
cleaners or aerosol cleaners.
Never spray cleaning liquids on or
near the Video Recorder.
Video head cleaning
Whenever a video cassette is
inserted into or ejected from your
Video the video head is automatically
cleaned. This should mean that
additional head cleaning should not
be necessary. However dirt
accumulating on the head after a
long period of time can cause the
playback picture to become blurred
or broken up. High quality video
cassette tapes will not normally
deposit dirt onto the video head, but
old or damaged tapes might.
Disposal of your old
appliance
1. When this crossed-out
wheeled bin symbol is
attached to a product it
means the product is cov-
ered by the European
Directive 2002/96/EC.
2. All electrical and electronic
products should be dis-
posed of separately from
the municipal waste
stream via designated col-
lection facilities appointed
by the government or the
local authorities.
3. The correct disposal of
your old appliance will help
prevent potential negative
consequences for the envi-
ronment and human
health.
4. For more detailed informa-
tion about disposal of your
old appliance, please con-
tact your city office, waste
disposal service or the
shop where you purchased
the product.
2
GC981P1.BAUTLLS_ENG 3/9/09 2:22 PM Page 2
Introducing your Video Recorder and Remote Control
Most of your Video Recorder’s functions are accessed using the Remote Control. A summary of the functions of the main
buttons are shown below (right), other buttons are described elsewhere in this guide.
Basic functions of your Video Recorder can also be operated using the control panel on the front of your Video Recorder.
3
Video IN and Audio IN sockets are for connecting devices such as
Video Cameras, Games Consoles and other Video Recorders. You
will need to connect to them using an Audio Visual cable.
Simulcast Recording (With SC mode by pressing AV): Hi-Fi sound
only recording using the Audio IN (L/R) sockets on the front of your
Video Recorder.
This feature enables you to simulcast sound transmitted by an audio
source and the picture transmitted by the TV station.
Don’t forget to install AAA type batteries in the Remote Control.
To turn the Video Recorder on.
After turning on, the Video Recorder can
be operated by the Remote Control
To stop or
eject the tape
Tape Compartment
To rewind a tape
To play a tape
To fast forward
a tape
Video IN
Audio IN
Select the channel
you want to watch.
Display
Panel
Remote
Control
Sensor
To record the programme you
are watching
To Pause a tape or
view it frame by frame
TV control buttons
(Controlling your TV
with the supplied
remote control
-See page 16)
To watch one TV
channel whilst
recording another.
To display the
on screen menu
To reset the tape
counter to zero
To select the
recording speed
of the tape
Use the 3 4 1 2/ / /
buttons to move
through the menus,
after accessing them
via the MENU button.
Select the channel
you want to watch
(PR+/-).
To adjust tracking
(TRK+/-).
To control vertical
tremble during pic-
ture still (TRK +/-).
Press OK to approve
a menu item or show
the clock or counter.
To select the input
source for recording
To fast forward
picture search by
30 secs.
To record
programme
being watched
To pause and view
frame by frame
See page 13
To switch the child
lock on and off
LV4947 Only : To display the
programme menu for ShowView
programming
LV498 1
GC981P1.BAUTLLS_ENG 3/9/09 2:22 PM Page 3
