Important: Please read this user manual thoroughly and
completely before operating this monitor.
Full HD LCD touchscreen monitor
USER MANUAL
PROFESSIONAL e-Screen FLEX 55”
ENGLISH
2
CONTENTS:
1 Important Safety Instructions 3
Safety Precautions 3
Installation (when installing the monitor, please follow the instructions in the manual) 3
Use 4
Cleaning 4
2 Warning For Use 5
Use 5
Exemptions 5
3 Features 5
4 Package 6
Unpacking 6
Contents of accessory bag 6
5 Installation 7
Environmental state 7
Power Input 7
Power Interface 7
Signal Source Input 7
6 Operating the Monitor 8
The side controller of the monitor 8
The Remote Control (RCU) Instructions 8
Change The RCU Battery 9
Display Mode 9
Adjusting the Volume 9
Selecting the input source 9
PIP mode 10
PIP Screen Table 10
OSD (On Screen Display) Menu Function 11
On-Screen Display (OSD) 13
Navigating through the Menu System 14
Display Settings Menu 15
Audio Settings Menu 15
Basic Settings Menu 16
Advanced Settings Menu 16
System Status Menu 17
7 Default Setting 17
8 Touch Operation 18
9 Table supported timings 19
10 Specifi cation 20
Dimensions 21
11 Troubleshooting 22
12 Compliance 22
13 Appendix 23
Moving and Carrying Notice 23
Wall Mount Safety Notes 24
3
Before using the touch monitor, please read this user manual
thoroughly to help protect against damage to your own and
other people's property and ensure your own and other people
personal safety.
Be sure to observe the following instructions.
For your safety, be sure to observe the warnings located in
this manual.
For installation or adjustment, please follow this
user manual instruction and refer all servicing to qualifi ed
service personnel.
Safety Precautions
If smoke or peculiar smell comes from the monitor, remove the
power plug from the outlet immediately.
Failure to do so may result in fi re or electrical shock.
Contact your dealer for inspection.
If the monitor has been turned on but there isn’t a picture,
remove the power plug from the outlet immediately.
Failure to do so may result in fi re or electrical shock.
Contact your dealer for inspection.
If water is spilled or objects are dropped inside the monitor,
remove the power plug from the outlet immediately.
Failure to do so may result in fi re or electrical shock.
Contact your dealer for inspection.
If the monitor is dropped or the cabinet is damaged, remove the
power plug from the outlet immediately.
Failure to do so may result in fi re or electrical shock.
Contact your dealer for inspection.
To turn off the power of the monitor, press ”” on the main
power switch at side of monitor.
The power standby/on indicator will go off and the monitor
cannot to be turned on/off by using the POWER button on the
remote control. (To turn on/off the monitor by the remote control,
press the main power switch again and light the power standby/
on indicator.)
When turning off the monitor by pressing the POWER button
on the remote control, the main power of the monitor is not
turned off completely.
To disconnect the monitor completely from power supply,
remove the power plug from the outlet.
Press “” to turn off
the monitor completely
If the power cord or plug is damaged or becomes hot, turn off the
main power switch of the monitor, make sure the power plug has
cooled down and remove the power plug from the outlet.
If the monitor is still used in this condition, it may cause a
fi re or an electrical shock.
Contact your dealer for replacement.
Installation
(when installing the monitor, please follow the instructions in the
user manual)
Don‘t install in a high-temperature environment.
If the monitor is used in high-temperature or in direct sunlight, it
may cause the case or other parts become distorted or damaged
resulting in overheating or electric shock.
Don‘t install in a high-humidity environment.
This may cause overheating or electric shock.
Don‘t install near any heat sources such as radiators, heat registers,
stoves, or other apparatus that produce heat.
This may cause a fi re or electric shock.
Don‘t overload outlets or cables beyond electrical capacity.
Don‘t use extension cords as it may cause a fi re or electric shock.
Don‘t insert the power plug into an outlet other than 100~240V AC.
This may cause a fi re or electric shock.
Don’t use a damaged power plug or worn outlet.
Don’t insert the improper power plug it may cause a fi re and
electric shock.
Don‘t place the touch monitor on an unstable shelf or surface.
The monitor may fall causing injury. Please install on a horizontal,
stable, level surface.
Don‘t place objects on the touch monitor.
If the touch monitor is covered or the vents are blocked, the
monitor could overheat and cause a fi re.
If metal or liquid gets into the monitor, it may cause a fi re
or an electrical shock.
Do not put heavy objects on the monitor as it may fall
causing injury.
Please keep a 10 cm minimum distance between the monitor
and the wall for suffi cient ventilation.
Don‘t move the touch monitor when it is connected to the power
cord and AV cables.
When moving the monitor, make sure to remove the power
plug and cables from the outlet or source.
When unpacking or carrying the monitor, at least 2 people
are needed. Make sure the monitor is carried upright.
Transport the monitor upright. Avoid placing the monitor
face up or down.
Handle the monitor gently. Do not drop.
1 Important Safety Instructions
