Thank you for choosing the Lazer
helmet. You have made an excellent
choice that will help to reinforce your
safety while cycling: the sport for which
this helmet has been designed. Lazer
helmets conform to the strict criteria of
international standards.
Wearing a helmet may reduce the
seriousness of injuries to the head that
may occur during a sports accident. For
this reason, it is important to use this
protective gear properly.
Instructions for use and care
1) No helmet can protect the wearer
against all possible impacts.
2) The helmet is designed to be retained by
a strap under the lower jaw.
3) To be eective, a helmet must t and
be worn correctly. To check for correct
t, place helmet on head and make any
adjustments indicated. Securely fasten
retention system. Grasp the helmet and try
to rotate it to the front and rear. A correctly
tted helmet should be comfortable and
should not move forward to obscure vision
or rearward to expose the forehead.
4) No attachments should be made to the
helmet except those recommended by the
helmet manufacturer.
5) The helmet is designed to absorb shock
by partial destruction of the shell and liner.
This damage may not be visible. Therefore,
if subjected to a severe blow, the helmet
should be destroyed and replaced even if it
appears undamaged.
6) The helmet may be damaged and
rendered ineective by petroleum and
petroleum products, cleaning agents,
paints, adhesives and the like, without the
damage being visible to the user.
7) A helmet has a limited lifespan in use
and should be replaced when it shows
obvious signs of wear.
8) This helmet should not be used by
children while climbing or doing other
activities where there is a risk of hanging or
strangulation if the child gets trapped whilst
wearing the helmet.
9) This helmet is designed only for the
following activity: cycling, roller skate,
skateboard. It is not designed to be used
with mopeds or any other type of sport,
mechanical or not.
1
The Lazer Impala helmet comes with
an action camera mount, suitable for
attaching a camera or lights with a
standard GoPro mounting system.
To attach the action camera mount to
the helmet:
1) Position the mount on the center
vent hole second from the front with
the arrow on the bottom of the mount
facing forward (as shown in diagram
1A).
2) Take one Velcro strap, feed it
through the center vent hole second
from the front, then back up through
the next vent hole (as shown in
diagram 1B).
3) Then feed the strap back through
the mount, double back and fasten
Velcro pads (as shown in diagram 1C).
4) Repeat steps 1-3 for the other side.
Forward facing
For a video guide to help with the following steps please
go to the following URL and click on how to videos:
www.youtube.com/user/LazerSport
1. How to install the action camera mount
IM PA L A
2
1. How to install the action camera mount
IM PA L A
1A) 1C)
V
e
l
c
r
o
s
t
r
a
p
1B)
Lamorinièrestraat 33-37
2018 Antwerp - Belgium
www.lazersport.com
For other and more helmet
instructions, please refer to
the owner manual included
with the helmet.
3
I M PA L A I M PA L A
2. How to use the adjustable visor 2. How to use the adjustable visor
4
Impala
USER MANUAL
The adjustable visor of the Impala
can be set in 3 dierent positions
depending on your preference.
1) To adjust the visor, simply loosen
by turning the visor bolts counter
clockwise using a small coin, large
at head screwdriver or similar blunt
object.
Position the visor where you want
it, then re-tighten the bolt by turning
clockwise.
Visor boltPositions 1, 2 and 3
