Strona 1/2
Page 1 of 1
FEATURES
DATA LOGGER SET-UPS ORDERING INFORMATION
Stock Number
EL-USB-LITE1-off Data Logger, Battery,
Software on CD
Replacement Batteries (5 pack) BATT-3VX5
LASCAR ELECTRONICS LTD.
MODULE HOUSE
WHITEPARISH
WILTSHIRE SP5 2SJ
UK
TEL: +44 (1794) 884567
FAX: +44 (1794) 884616
E-mail: sales@lascar.co.uk
LASCAR ELECTRONICS (HK) LIMITED
FLAT C, 5/FL., LUCKY FTY. BLDG.
63-65 HUNG TO ROAD
KWUN TONG KOWLOON
HONG KONG
TEL: +852 2797 3219
FAX: +852 2343 6187
E-mail: b4lascar@samsongroup.com.hk
www.lascarelectronics.com
LASCAR ELECTRONICS INC.
3750 West 26th Street
Erie
PA 16506
USA
TEL: +1 (814) 835 0621
FAX: +1 (814) 838 8141
E-mail: us-sales@lascarelectronics.com
• -10°C to +50°C (+14 to +122°F) Measurement Range
• 30 Minute Sample Rate
• 1 Month Battery Life
• Red/Green Alarm Status Indication via Button
• USB Interface for Set-up and Data Download
2 User-programmable Alarm Thresholds•
• Dimensions : 68 x 18 x 9.4mm (2.7" x 0.7" x 0.4")
EL-USB-LITE Low Cost USB Temperature Data Logger
Specifications liable to change without prior warning EL-USB-LITE Issue 1 March/2006 M.C.
This low cost data logger measures and stores up to 4,080 temperature readings over a -10 to +50°C (+14 to +122°F)
measurement range with a fixed 30 minute sample rate and a battery life of 1 month continuous use. Press the button
and a red/green LED indicates whether a preset alarm level has been breached.
The data logger is configured and the stored data downloaded by plugging the module into a PC's USB port and running
the purpose designed control software under Windows 98, 2000 or XP. The downloaded data can be graphed, printed
and exported to other applications. The latest version of the control software may be downloaded free of charge from:
. A battery is already fitted. To start logging, pull out the tab.www.lascarelectronics.com
• Logger Name
• °C, °F
• High and Low Alarm Levels
Start Time and Start Date•
SPECIFICATIONS
Specification Min. Typ. Max. Unit
Measurement range -10 (+14) +50 (+122) °C (°F)
Internal resolution 1 (2) °C (°F)
Accuracy (overall error) 2.5 ( ) °C (°F)+
Operating temperature range -10 (+14) +50 (+122) °C (°F)
Logging rate every 30 minutes
Battery Life (CR1620 Lithium coin cell) 1 Month
+4.5
Easy to install and use, the control software runs under
Windows 98, 2000 and XP (Home and Professional
Editions)*. It allows the user to set up and download any
EL-USB-Lite. The latest version of the control software
may be downloaded from .www.lascarelectronics.com
WINDOWS CONTROL SOFTWARE
EL-USB-LITE Low Cost USB Temperature Data Logger
Page 1 of 1
www.lascarelectronics.com
EL-USB-LITE features a bi-colour LED to indicate the status of the data logger. To save power, the status indication only operates
when the push button is pressed for a short while.
LED FLASHING MODES
(Single green flash) The channel is logging, no alarm
(Single red flash) The channel is logging, low alarm
(Double red flash) The channel is logging, high alarm
The number of flashes and colours indicates :
BATTERY REPLACEMENT
We recommend that you replace the battery every 1 month, or prior to logging critical data. The EL-USB-LITE does not lose its
stored readings when the battery is discharged or when the battery is replaced; the data logging process will however be stopped
and cannot be re-started until the battery has been replaced and the logged data has been downloaded to PC.
For maximum logging life, only use Maxell or Panasonic CR1620 lithium batteries. Before replacing the battery, remove the EL-
USB-LITE from the PC.
Note:
Leaving the EL-USB-LITE plugged into the USB port for longer than necessary will cause some of the battery capacity to be lost.
WARNING: Handle lithium batteries carefully.
Dispose of in accordance with local regulations.
Red/Green LEDTemperature sensor
Specifications liable to change without prior warning EL-USB-LITE Issue 1 March/2006 M.C.
