Kramer Electronics, Ltd.

USER MANUAL



Model:

VP-100

VGA/XGA to RGBHV Converter

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

Your VP-100 VGA/XGA to RGBHV Converter 4

Connecting the VP-100 6

Technical Specifications 7

Figures

Figure 1: VP-100 VGA/XGA to RGBHV Converter 4

Figure 2: VP-100 VGA/XGA to RGBHV Converter Connections 6

Tables

Table 1: Features and Functions of the VP-100 VGA/XGA to RGBHV Converter 5

Table 2: Technical Specifications of the VP-100 VGA/XGA to RGBHV Converter 7

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer TOOLS VP-100 VGA/XGA to

RGBHV Converter. This product is ideal for the following typical

applications:

 Any professional display system requiring up to UXGA signal splitting

and conversion to BNC connectors

 Long distance graphics signal distribution

The package includes the following items:

 VP-100 VGA/XGA to RGBHV Converter

 Power adapter (12V DC Input)

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Specyfikacje produktu

Marka:	Kramer
Kategoria:	konwerter audio / video
Model:	VP-100
Kolor produktu:	Czarny
Wysokość produktu:	25 mm
Szerokość produktu:	120 mm
Głębokość produktu:	75 mm
Waga produktu:	300 g
Napięcie pracy:	12 V
Kod zharmonizowanego systemu (HS):	85176990
Maksymalna rozdzielczość filmu:	- px
Interfejs hosta:	VGA (D-Sub)
Interfejs wyjściowy:	BNC
