Strona 1/2
92798 Cape Arago Hwy, Coos Bay, OR 97420 | 541-888-3517 | Toll Free 1-800-867-6863 | www.kksound.com
T R I N I T Y S Y S T E M
Thank you for choosing the K&K Trinity Pickup/Microphone Combination System!
In this installation packet, you will find:
Trinity Microphone Installation (follows on p. 2)
Pure Pickup installation (separate manual)
Preamp installation and use (separate manual)
2
92798 Cape Arago Hwy, Coos Bay, OR 97420 | 541-888-3517 | Toll Free 1-800-867-6863 | www.kksound.com
TRINITY MICROPHONE
1. Cut a 2 1/2" piece of the supplied dual-lock and locate the base of the gooseneck (gooseneck is
thicker and stiffer than the mic cable). Loop the dual-lock piece around the base of the
gooseneck. Pinch the sticky sides together to get a tab as shown in fig. 1.
2. Cut a second piece of dual-lock approx. 1" long (see fig. 2) and stick it to a suitable spot inside
your guitar close to the edge of the sound hole (fig. 3).
3. Form the gooseneck to achieve a mic position as shown in fig. 3. This position is recommended
to avoid picking directly over the mic. The mic should aim outwards, towards the strings,
between the G and B string. The distance between strings and mic should be about 3/8 inch (ca
10 mm).
4. Press the dual- - -lock mic tab onto the second dual lock piece inside your guitar and re adjust the
mic's gooseneck.(fig. 3) The dual- - lock works like "super" velcro and can be re opened.
5. You have the option to experiment with different mic angles and positions to obtain your
personal best sound.
6. Secure all wiring inside guitar with tape.
