INSTRUCTION MANUAL
HeliaLux LED / Spectrum
www.juwel-aquarium.com
1
Introduction
Thank you for choosing a JUWEL Aquarium product.
Our products represent over 50 years experience in the manufacturing of aquariums and their acessories applying most modern
production techniques bringing together the JUWEL Aquarium system, which is both easy to use and simple to maintain.
Please read this instruction manual carefully and completely to make sure you have received all components before setting up
the aquarium. Please observe the safety instructions and maintenance guidelines given in this manual.
This instruction manual has been carefully prepared to provide you with accurate and complete information. All efforts have been
made to ensure that the information given is correct. However, we cannot accept responsibility for printing or other errors.
Technical details are always approximate and are not warranted characteristics and may be subject to change without notice.
SAFETY NOTICES
The product fulfils with the regulations of the European Union (EU), and it is therefore compliant with CE standards.
www.juwel-aquarium.de/en/declaration-of-conformity/
HeliaLux LED / Spectrum
The HeliaLux LED / Spectrum is a state-of-the-art high-performance light unit for your JUWEL aquarium. The SMD-LEDs
guarantee maximum light power for optimal plant growth whilst offering up to a 50% energy saving compared to the same size T5
unit.
The HeliaLux LED / Spectrum is comprised of:
Pull the power plug for each light replacement.•
The electrical devices may only be operated in rooms.•
Pull the power plug of all devices operated in water before coming into contact with the water.•
Never repair the connection line of the light. Always replace the entire device in case of damage. •
Never open the light in case of damage or malfunction. Replace the complete light.•
Do not operate the light under water.•
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
•
Only operate with the ground fault circuit interrupter, max. 30 mA.•
The power plugs of the electrical devices must not become wet.•
Connect the power plug to the power supply at a height so that a loop is created in the connection line, on which water
could drip off.
•
For safety reasons, it is only permitted to operate the HeliaLux LED light with an original JUWEL charger.•
Only use original JUWEL spare parts for replacement.•
The charger must not be attached to or on the aquarium frame.•
HeliaLux LED / Spectrum light unit (1)•
Charger (2)•
Power cable (3) •
2
Start-up of the HeliaLux LED / Spectrum
Connect the plug (A) of the HeliaLux LED / Spectrum light unit with that of the charger (B) in accordance with the illustration and
screw the locking ring completely onto the screw connector. Also plug the power cable into the charger.
The HeliaLux LED / Spectrum can now be placed onto the top frame and can be connected to the power supply. Having done
this please fit the flaps to close the aquarium completely.
Care and maintenance
During care and maintenance activities, always disconnect the HeliaLux LED / Spectrum from the power supply. If necessary,
we recommend cleaning with a soft cloth and mild detergent.
optional
The HeliaLux SmartControl can be used to control the HeliaLux Spectrum light unit. It
is also possible to control the HeliaLux LED light unit with the optionally available
splitter. The optionally available splitter allows up to two HeliaLux lamps to be used
with one SmartControl.
The HeliaLux SmartControl has four operating modes:
Version A: HeliaLux Control + 1x HeliaLux Spectrum (4 colours)
Version B: HeliaLux SmartControl + HeliaLux Spectrum Splitter + 2x HeliaLux
Spectrum (4 colours)
Version C: HeliaLux SmartControl + HeliaLux LED Splitter + 1x HeliaLux LED (2
colours)
Version D: HeliaLux SmartControl + HeliaLux LED Splitter + 2x HeliaLux LED (2
colours
The HeliaLux SmartControl & Splitter is available as an
original JUWEL Aquarium accessory (Article Number SmartControl 48996,
HeliaLux LED Splitter 48997, HeliaLux Spectrum Splitter 48998).
Further information will be available from your retailer or on our
website "http://www.juwel-aquarium.com"
HeliaLux LED / Spectrum Universal Fit
To use the HeliaLux LED / Spectrum light unit for aquariums of other manufacturers,
the mount of the HeliaLux LED / Spectrum Universal Fit is available from specialist
retailers as an original JUWEL aquarium accessory (article number 48995). You can
find further information on our website "http://www.juwel-aquarium.com"
3
