CASE FOR 7“-DISPLAY AND RASPBERRY PI4
RB-LCD Case-7P4-
1. GENERAL INFORMATION
Dear costumer,
thank you very much for choosing our product. In the following, we will
introduce you to what to observe while starting up and using this
product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. ASSEMBLY
1. Take the front panel of the housing and insert the display into the cut out.-
2. Now connect the cables which are in the scope of delievery of the display, to the display board.
Make sure that the display cable is aligned correctly.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
3. Screw the Raspberry Pi 4 onto the spacers of the display board aer all cable are placed on the
display.
4. Connect the cables to the Raspberry Pi 4.
Ensure that the display cable is correctly aligned.
Display Pin Raspberry Pin- -
GND Pin 14 (GND)
5V Pin 2 (5V)
SDA Pin 3 (SDA)
SCL Pin 5 (SCL)
