Safety and operating manual
Pedestrian Lawnmowers
JCB MULCHER 48 - JCB MULCHER 48 S
JCB, SO53 3LE
www.JCBDIY.com
Customer Helpline 0845 6005526
ORIGINAL INSTRUCTIONS
JCB rsb 48_11-171503976/0:JCB rsb 48_11-171503976/0 7-12-2010 10:26 Pagina 1
JCB, SO53 3LE
www.JCBDIY.com
Customer Helpline 0845 6005526
Identification label, main components and symbols
2
7 6 59
234
8 1
Identification label
1. Conformity mark according to directive
2006/42/CE
2. Type of machine
3. Weight in kg
4. Operating engine power and speed
5. Acoustic power level according to directive
2000/14/CE
6. Serial number
7. Name and address of manufacturer
8. Article Code
9. Year of manufacture
11 12 13
16
14
1516 17
Identification of main components
11. Chassis
12. Blade
13. Engine
14. Handle
15. Drive engagement lever
16. Engine brake lever
17. Throttle control
Symbols of safety requirements
Your lawnmower should be used with due care and
attention. Symbols have therefore been placed on
various parts of the machine to remind you of the
main precautions to be taken. Their meaning is
explained below. You are also asked to carefully
read the safety regulations in the applicable chapter
of this handbook.
21. Warning: Read the instruction manual before
using the machine.
22. Beware of thrown objects. Keep other people at
a safe distance whilst working.
23. Warning: Disconnect the spark plug cap and
read the instructions before carrying out any
maintenance or repairs.
24. Danger of cutting yourself. Moving blades. Do
not put hands or feet near or under the opening
of the cutting plate.
25. Warning! Hot surfaces.
MULCHER 48 MULCHER 48 S
21 22 23 24
25
JCB rsb 48_11-171503976/0:JCB rsb 48_11-171503976/0 7-12-2010 10:26 Pagina 2
JCB, SO53 3LE
www.JCBDIY.com
Customer Helpline 0845 6005526
Safety Regulations - To be followed carefully
3
A) TRAINING
1) Read the instructions carefully. Get familiar with the controls
and proper use of the equipment. Learn how to stop the engine
quickly.
2) Only use the lawnmower for the purpose for which it was
designed, i.e. for cutting grass. Any other use can be haz-
ardous, causing damage to the machine. Examples of improper
use may include, but are not limited to:
– transport of people, children or animals on the machine;
– being transported by the machine;
– using the machine to tow or push loads;
– using the machine for leaf or debris collection;
– using the machine to trim hedges, or for cutting vegetation
other than grass;
– use of the machine by more than one person;
– using the blade on surfaces other than grass.
3) Never allow children or people unfamiliar with these instruc-
tions to use the lawnmower. Local regulations may restrict the
age of the operator.
4) Never use the lawnmower:
– When people, especially children, or pets are nearby.
– If the operator has taken medicine or substances that can
affect his ability to react and concentrate.
5) Remember that the operator or user is responsible for acci-
dents or hazards occurring to other people or their property.
B) PREPARATION
1) While mowing, always wear sturdy footwear and long
trousers. Do not operate the equipment when barefoot or wear-
ing open sandals.
2) Thoroughly inspect the area where the equipment is to be
used and remove all objects which may be thrown by the
machine or damage the cutter assembly and the engine (stones,
sticks, metal wire, bones, etc.)
3) WARNING: DANGER! Engine fuel is highly flammable:
– Store fuel in containers specifically designed for this purpose.
– Refuel using a funnel and outdoors only. Do not smoke while
refuelling or whenever handling the fuel.
– Add fuel before starting the engine. Never remove the cap of
the fuel tank or add fuel while the engine is running or when the
engine is hot.
– If fuel is spilled, do not attempt to start the engine but move
the machine away from the area of spillage and avoid creating
any source of ignition until the fuel has evaporated and the
vapour dispersed.
– Replace all fuel tanks and containers caps securely.
4) Substitute faulty silencers.
5) Before use, always inspect the machine, especially the con-
dition of the blades, and check that the screws and cutting
assembly are not worn or damaged. Replace worn or damaged
blades and screws in sets to preserve balance.
C) OPERATION
1) Do not operate the engine in a confined space where dan-
gerous carbon monoxide fumes can collect.
2) Mow only in daylight or good artificial light.
3) If possible, avoid operating the equipment in wet grass.
4) Always be sure of your footing on slopes.
5) Walk, never run and do not allow yourself to be pulled along
by the lawnmower.
6) Mow across the face of slopes, never up and down.
7) Exercise extreme caution when changing direction on slopes.
8) Do not mow on slopes of more than 15°.
9) Exercise extreme caution when pulling the lawnmower
towards you.
10) Stop the blade if the lawnmower has to be tilted for trans-
portation when crossing surfaces other than grass, and when
transporting the lawnmower to and from the area to be mowed.
11) Never operate the lawnmower with defective guards.
12) Do not change the engine governor settings or overspeed
the engine.
13) On power-driven models, disengage the drive clutch before
starting the engine.
14) Start the engine carefully, following the instructions and
keeping feet well away from the blade.
15) Do not tilt the lawnmower when starting the engine. Start the
engine on a flat surface that is free of obstacles and tall grass.
16) Do not put hands or feet near or under rotating parts.
17) Never pick up or carry a lawnmower while the engine is run-
ning.
18) Stop the engine and disconnect the spark plug wire:
– Before carrying out any work underneath the cutting deck or
before unclogging the chute;
– Before checking, cleaning or working on lawnmower;
– After striking a foreign object. Inspect the lawnmower for dam-
age and make repairs before restarting and operating the lawn-
mower;
– If the lawnmower begins to abnormally vibrate (Immediate
look for the cause of the vibrations and take for necessary con-
trols at a Specialised Centre).
19) Stop the engine:
– Whenever you leave the lawnmower unattended. Remove the
key from models with electric starters.
– Before refuelling.
– Before adjusting the grass cutting height.
20) Reduce the throttle before turning off the engine and turn
the fuel off when you have finished mowing, following the
instructions in the engine handbook.
21) When mowing, always keep to a safe distance from the
rotating blade. This distance is the length of the handle.
D) MAINTENANCE AND STORAGE
1) Keep all nuts, bolts and screws tight to be sure the equipment
is in safe working condition. Regular maintenance is essential
for safety and performance.
2) Never store the equipment with fuel in the tank inside a build-
ing where vapour may reach a flame or a spark or a source of
extreme heat.
3) Allow the engine to cool before storing in an enclosed space.
4) To reduce the fire hazard, keep the engine, exhaust silencer,
battery compartment and fuel storage area free of grass, leaves,
or excessive grease. Do not leave containers with grass cuttings
in rooms.
5) If the fuel tank has to be drained, this should be done out-
doors and when the engine is cool.
6) Wear strong work gloves when removing and reassembling
the blade.
7) Keep the blade balanced during sharpening. All operations on
the blade (dismantling, sharpening, balancing, remounting
and/or replacing) require a certain familiarity and special tools.
For safety reasons, these jobs are best carried out at a special-
ized centre.
8) For safety reasons, never use the machine when it has worn
or damaged parts. Parts are to be replaced and not repaired.
Use genuine spare parts. Parts that are not of the same quality
can damage the equipment and impair your safety.
E) TRANSPORTATION AND HANDLING
1) Whenever the machine is to be handled, raised, transported
or tilted you must:
– wear strong working gloves;
– grasp the machine at the points that offer a safe grip, taking
account of the weight and its distribution.
– use an appropriate number of people for the weight of the
machine and the characteristics of the vehicle or the place
where it has to be placed or collected.
2) During transport, fasten the machine securely with ropes or
chains.
JCB rsb 48_11-171503976/0:JCB rsb 48_11-171503976/0 7-12-2010 10:26 Pagina 3
